Hitachi GR2000-B Series User manual

Hitachi Gigabit Router
GR2000-B Series
GR2K-GA-0007
Rev. 5.00
Installation Guide

Hitachi Gigabit Router GR2000-B Series Installation Guide
ii GR2K-GA-0007
Rev. 5.00
Statement on EN55022 Compliance
WARNING: This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate
measures.
Statement on Federal Communications Commission
(FCC) Compliance
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his/
her own expense. The user is cautioned that changes or modifications not expressly
approved by the manufacturer could void the user’s authority to operate the
equipment.
Class A Emission Statement (Korea)
Trademarks
Ethernet is a product name of Xerox Corp., USA.
Ethernet is a trademark of Fuji Xerox Co., Ltd.
MS-DOS® is a registered trademark of Microsoft, Corp.
UNIX is a registered trademark, in the USA and other countries, licensed by X/Open Company Limited.
NetWare is a registered trademark of Novell, Inc., USA.
IPX is a registered trademark of Novell, Inc., USA.
HP OpenView is a trademark of Hewlett-Packard Company, USA.
Windows 95 is a trademark of Microsoft, Corp., USA.
Internet Explorer is a registered trademark of Microsoft, Corp., USA.
Netscape Navigator is a registered trademark of Netscape Communications Corporation.
All other brands and product names are trademarks of their respective holders.
Copyright 2002, 2003 Hitachi, Ltd. All Rights Reserved.

GR2K-GA-0007 iii
Rev. 5.00
Release 5.00 (May 2003)
This publication contains the most current information available to date. As new and
revised sections are received, new updates will be distributed.
Notice: No part of this publication may be reproduced or transmitted in any form or
by any means, electronic or mechanical, including photocopying and recording, or
stored in a database or retrieval system for any purpose without the expressed
written permission of Hitachi, Ltd.
Hitachi, Ltd. reserves the right to make changes to this document at any time
without notice, and assumes no responsibility for its use. All the features described
in this document may not be currently available.
Change Record
Preface
This manual provides installation information for the GR2000-B series of Gigabit
routers. The manual is intended for personnel involved in the installation and
operation of this product.
This manual is one of a set of manuals describing the GR2000-B Gigabit Router. The
table below lists the entire set and provides the full name of the manual. All titles are
for version 06-05 unless otherwise noted.
The information contained in this and other manuals is subject to change without
prior notice.
Revision
No. Date Description Affected
Sections
1.00 August 2002 Initial Release —
1.01 September 2002 Minor updates and corrections All
2.00 December 2002 Update to cover GR2000-B+ features Ch. 1-5
5.00 May 2003 Update to cover GR2000-BH features
(no Rev. 3 or 4)
Ch. 1-5
GR2000 Gigabit Router Series Documentation
Title* Description/Notes Part Number
Hitachi Gigabit Router
GR2000 Series Enhanced
Version Applications Guide
In-depth information about the applications and uses for which
the router is designed to perform.
GR2K-GA-0001
Hitachi Gigabit Router
GR2000 Series Enhanced
Version Browser
Operations Guide
Operating the GR2000 Gigabit Router Series using the
browser interface. This manual is in version 06-03.
GR2K-GA-0005

Hitachi Gigabit Router GR2000-B Series Installation Guide
iv GR2K-GA-0007
Rev. 5.00
Hitachi Gigabit Router
GR2000 Series Enhanced
Version Configuration
Settings
The first of three configuration volumes. This manual shows
how to create, edit, and manipulate configurations, and
provides numerous examples of configurations and
appropriate settings.
GR2K-GA-0003
Hitachi Gigabit Router
GR2000 Series Enhanced
Version Configuration
Commands, Vol. 1
This manual provides a configuration command overview, and
a complete command reference for router management,
network interface, IP information, routing and multicast routing
protocols, and MPLS.
GR2K-GA-0013
Hitachi Gigabit Router
GR2000 Series Enhanced
Version Configuration
Commands, Vol. 2
A continuation of volume 1, volume 2 is a command reference
for filtering and QoS, IPX and bridge, SNMP, operation
management, and a list of all configuration error messages.
GR2K-GA-0014
Hitachi Gigabit Router
GR2000-B Series
Installation Guide
Provides a product overview and component details of the
GR2000-B series, and discusses various aspects of product
installation, including pre-installation planning, site
preparation, unpacking and setup, adding and removing
modules, and starting and stopping the router.
GR2K-GA-0007
Hitachi Gigabit Router
GR2000 Series Enhanced
Version Operations -
Device Management
Overview
This manual is an overview of router operation and includes
procedures for starting operation after configuration, using the
Command Line Interface (CLI), and commands for daily
management, maintenance, and troubleshooting.
GR2K-GA-0015
Hitachi Gigabit Router
GR2000 Series Enhanced
Version Operations
Commands, Vol. 1
This is volume 1 of 2 volumes of operation commands. This
manual is used for “new syntax” commands only. For the
original GR2000 UNIX-based command-line interface, see the
GR2000 Operations Guide, UNIX-Based Interface, below.
GR2K-GA-0016
Hitachi Gigabit Router
GR2000 Series Enhanced
Version Operations
Commands, Vol. 2
This is volume 2 of 2 volumes of operation commands. This
manual is used for “new syntax” commands only. For the
original GR2000 UNIX-based command-line interface, see the
GR2000 Operations Guide, UNIX-Based Interface, below.
GR2K-GA-0017
Hitachi Gigabit Router
GR2000 Series Enhanced
Version Operations Log
and MIB Reference
This operation manual presents a list of LED display and fault
codes, maintenance information, operation and log
messages, and complete MIB descriptions.
GR2K-GA-0018
Hitachi Gigabit Router
GR2000 Series Enhanced
Version Operations Guide,
UNIX-Based Interface
Operating the GR2000 Gigabit Router Series using the
original UNIX-based command-line interface. This manual is
in version 06-03.
GR2K-GA-0004
Hitachi Gigabit Router
GR2000 Series Enhanced
Version Maintenance Guide
Provides and introduction to maintenance, troubleshooting
flowcharts and checklists, and hardware information, such as
voltage checks and parts replacement procedures.
GR2K-ZG-1001
Hitachi Gigabit Router
GR2000-B Series Quick
Start Guide
The purpose of the Quick Start Guide is to provide a concise
guide to setting up the GR2000-B. It includes a guide to
unpacking and setup, basic operations, and troubleshooting.
GR2K-GA-0008
Hitachi Gigabit Router
GR2000-B Series Safety
Guide
This guide discusses general and specific safety instructions
regarding the GR2000-B. This guide is also available in
German and French.
GR2K-GA-0010 (E)
GR2K-GA-0011 (G)
GR2K-GA-0012 (F)
* When used in the documentation, the manual title is almost always shortened to, for example, GR2000
Configuration Commands, Vol. 1.
GR2000 Gigabit Router Series Documentation (continued)

GR2K-GA-0007 v
Rev. 5.00
Abbreviations
7SEG Seven-segment (alphanumeric) Light Emitting Diode display
AC Access Concentrator
ADSL Asymmetric Digital Subscriber line
AAL ATM Adaptation Layer
ABR Available Bit Rate
ACK ACKnowledge
AFI Authority and Format Indicator
AIS Alarm Indication Signal
ANSI American National Standards Institute
APS Automatic Protection Switching
ARP Address Resolution Protocol
AS Autonomous System
ATM Asynchronous Transfer Mode
BAP Bandwidth Allocation Protocol
BAS Broadband Access Server
BECN Backward Explicit Congestion Notification
BGP Border Gateway Protocol
BGP4 Border Gateway Protocol 4
BGP4+ Multi-Protocol Extensions for Border Gateway Protocol -
Version 4
bit/s bits per second, usually abbreviated bps.
BOD Bandwidth On Demand
BPDU Bridge Protocol Data Unit
BRI Basic Rate Interface
BSR Boot Strap Router
CATV Cable Television
CBR Constant Bit Rate
CIDR Classless Inter-Domain Routing
CIR Committed Information Rate
CLLM Consolidated Link Layer Management
CLNP Connectionless Network Protocol
CLP Cell Loss Priority
CoS Class of Service
CNTL CoNTrol

Hitachi Gigabit Router GR2000-B Series Installation Guide
vi GR2K-GA-0007
Rev. 5.00
COPS Common Open Policy Service
CRC Cyclic Redundancy Check
CR-LDP Constraint-Based Label Distribution Protocol
CSMA/CD Carrier Sense Multiple Access with Collision Detection
DA Destination Address
DCC Data Country Code
DCE Data Circuit terminating Equipment
DDP Datagram Delivery Protocol
DHCP Dynamic Host Configuration Protocol
Diff-serv Differentiated Services
DIMM Dual In-Line Memory Module
DLCI Data Link Connection Identifier
DLSw Data Link Switch
DNS Domain Name System
DR Designated Router
DSAP Destination Service Access Point
DSCP Differentiated Services Code Point
DSP Domain Specific Part
DSU Digital Service Unit
DTE Data Terminal Equipment
DVMRP Distance Vector Multicast Routing Protocol
EIA Electronic Industries Alliance
ELAN Emulated LAN
EoMPLS Ethernet-over-MPLS
ERP Echo Response
ERQ Echo Request
ES End System
FCS Frame Check Sequence
FDB Filtering Data Base
FDDI Fiber Distributed Data Interface
FEC Forwarding Equivalence Class
FECN Forward Explicit Congestion Notification
FERF Far End Receive Failure
FR Frame Relay
FTTH Fiber To The Home
GFR Guaranteed Frame Rate

GR2K-GA-0007 vii
Rev. 5.00
GBIC GigaBit Interface Converter
HDLC High-level Data Link Control
HNA Hitachi Network Architectural CMP Internet Control Message
Protocol
ICMP Internet Control Message Protocol
ICMPv6 Internet Control Message Protocol version 6
ID Identifier
IDI Initial Domain Identifier
IEEE Institute of Electrical and Electronics Engineers, Inc.
IETF the Internet Engineering Task Force
IGMP Internet Group Management Protocol
INS Information Network System
ILMI Interim Local Management Interface
IP Internet Protocol
IPsec Security Architecture for IP
IPv4 Internet Protocol version 4
IPv6 Internet Protocol version 6
IPV6CP IPv6 Control Protocol
IPX Internetwork Packet Exchange
ISDN Integrated Services Digital Network
ISO International Organization for Standardization
ISP Internet Service Provider
ITU-T International Telecommunication Union - Telecommunication,
Standardization Sector
JDI Japanese Domain Identifier
JIS Japanese Industrial Standards
LAN Local Area Network
LAPB Link Access Procedure Balanced Mode
LCP Link Control Protocol
LDP Label Distribution Protocol
LEC LAN Emulation Client
LED Light Emitting Diode
LES LAN Emulation Server
LIS Logical IP Subnetwork
LLB Local Loop Back
LLC Logical Link Control

Hitachi Gigabit Router GR2000-B Series Installation Guide
viii GR2K-GA-0007
Rev. 5.00
LOS Loss of Signal
LQM Link Quality Monitoring
LQR Link Quality Report
LSP Label Switched Path
LSR Label Switched Router
MAC Media Access Control
MC Memory Card
MCR Media Access Control
MD5 Message Digest 5
MIB Management Information Base
MLD Multicast Listener Discovery
MMF Multi Mode Fiber
MPLS Multi-Protocol Label Switching
MRU Maximum Receive Unit
MSS Maximum Segment Size
MTU Maximum Transfer Unit
NAT Network Address Translation
NAPT Network Address Port Translation
NAK Not AcKnowledge
NBP Name Binding Protocol
NCP Network Control Protocol
NDP Neighbor Discovery Protocol
NET Network Entity Title
NetBIOS Network Basic Input/Output System
NIF Network Interface board
NRZ Non-Return-to-Zero
NSAP Network Service Access Point
NSSA Not So Stubby Area
NTP Network Time Protocol
OAM Operation Administration and Management
OC-3c Optical Carrier level 3 concatenation
OC-12c Optical Carrier level 12 concatenation
OC-48c Optical Carrier level 48 concatenation
ONU Optical Network Unit
OSI Open Systems Interconnection
OSPF Open Shortest Path First

GR2K-GA-0007 ix
Rev. 5.00
OUI Organizationally Unique Identifier
PPS Packets Per Second, sometimes abbreviated as packets/s
PAD PADding
PADI PPPoE Active Discovery Initiation
PADO PPPoE Active Discovery Offer
PADR PPPoE Active Discovery Request
PADS PPPoE Active Discovery Session-confirmation
PAST PPPoE Active Discovery Terminate
PC Personal Computer
PCR Peak Cell Rate
PDB Permanent Data Base
PDU Protocol Data Unit
PHY PHYsical layer protocol
PID Protocol IDentifier
PIM Protocol Independent Multicast
PIM-DM Protocol Independent Multicast-Dense Mode
PIM-SM Protocol Independent Multicast-Sparse Mode
PLD Programmable Logic Design
POS PPP over SONET/SDH
PPPoE PPP over Ethernet
PPS Packet Per Second
PRI Primary Rate Interface
PVC Permanent Virtual Channel (Connection)/Permanent Virtual
Circuit
QoS Quality of Service
RA Router Advertisement
RADIUS Remote Authentication Dial In User Service
RAI Remote Alarm Indication signal
RDI Remote Defect Indication
REJ REJect
RFC Request For Comments
RIP Routing Information Protocol
RIPng Routing Information Protocol next generation
RLB Remote Loop Back
RM Routing Manager
RMON Remote Network Monitoring MIB

Hitachi Gigabit Router GR2000-B Series Installation Guide
x GR2K-GA-0007
Rev. 5.00
RP Routing Processor
RPF Reverse Path Forwarding
RQ ReQuest
RS-232C Recommended Standard 232C
RSVP Resource Reservation Protocol
SA Source Address
SAD Security Association Database
SAP Service Access Point
SD Start Delimiter
SDH Synchronous Digital Hierarchy
SDLC Service Advertising Protocol
SD-I Super Digital I interface
SDU Service Data Unit
SFD Start Frame Delimiter
SMF Single Mode Fiber
SNA Systems Networking Architecture
SNAP Sub-Network Access Protocol
SNMP Simple Network Management Protocol
SONET Synchronous Optical Network
SPF Shortest Path First
SPT Spanning Tree
SPX Sequenced Packet Exchange
SSAP Source Service Access Point
SSP Switch to Switch Protocol
SST System Simulation Test
SVC Switched Virtual Channel (Connection)
TA Terminal Adapter
TCC Transmission Control Character
TCP/IP Transmission Control Protocol/Internet Protocol
TOS Type Of Service
T/R Transmit/Receive (Transmitter/Receiver)
TTC Telecommunication Technology Committee
TTL Time To Live
UBR Unspecified Bit Rate
UDP User Datagram Protocol
UNI User Network Interface

GR2K-GA-0007 xi
Rev. 5.00
UPC Usage Parameter Control
UTP Unshielded Twisted Pair
VBR Variable Bit Rate
VC Virtual Channel/Virtual Call
VCI Virtual Channel Identifier
VLAN Virtual LAN
VoIP Voice over IP
VP Virtual Path
VPI Virtual Path Identifier
VPN Virtual Private Network
VRRP Virtual Router Redundancy Protocol
WAN Wide Area Network
WS Work Station
WWW World Wide Web
xDSL x Digital Subscriber Line

Hitachi Gigabit Router GR2000-B Series Installation Guide
xii GR2K-GA-0007
Rev. 5.00
This page left intentionally blank

GR2K-GA-0007 xiii
Rev. 5.00
Safety Guide
This document provides safety-related notices for use of the GR2000-B Gigabit
Router.
Read the following material completely and carefully before using the GR2000-B.
Keep this document at hand after you read it, so that you can always refer it
later.
For any operation involving the GR2000-B, follow the directions and procedures
given by this document.
Observe the cautions labeled on the GR2000-B or those presented by this
document. If you fail to do so, you will cause damage to yourself or the
GR2000-B.
Before Using the GR2000-B
We have standard symbols displayed on the GR2000-B and in the manuals to
guide you in using the GR2000-B correctly and safely without injuring yourself
and others, or damaging equipment assets. Below are the symbols and their
meanings.
Do not attempt to perform any operations not specifically described in the
documentation. In the event of a problem, turn off the power, unplug the power
cable, and contact a qualified service technician.
The instructions displayed on the GR2000-B or in this documentation are the
results of our thorough consideration. Still, there is the possibility of a problem
occurring unexpectedly, so be alert and use common sense.
*Note: A note is informational in nature. Unlike cautions and danger notices, notes
are not related to the physical injury or a damage to the device.
!Caution: If you ignore a caution and mistreat the GR2000-B, you could cause physical
damage to the router or surroundings, or interrupt service to your networks
users.
DANGER: If you ignore instructions preceded by a danger symbol, you could cause
personal injury or death to yourself and others.

Hitachi Gigabit Router GR2000-B Series Installation Guide
xiv GR2K-GA-0007
Rev. 5.00
Danger
Do not use the GR2000-B if there is smoke or
an unusual smell coming from it. If either
occurs, immediately turn power off and
unplug the power cable from the outlet.
Contact a qualified service technician.
If liquid is spilled on the GR2000-B, turn
power off and unplug the power cable from
the outlet. Discontinue use to avoid the risk
of fire or electric shock.
If a foreign object falls into the router when
the cover is off, turn power off and unplug the
power cable from the outlet. Do not attempt
to remove the object while the power is on.
Do not put the router on an unstable or
uneven place. Put it on a stable and flat surface to prevent it from falling and
causing damage.
When installing the GR2000-B on a desk, lay it down horizontally on it’s rubber
feet. If you stand it vertically or lean it against a wall, it could fall down and cause
damage to itself or a person.
Make sure that the router is in a stable, secure position when mounting it into a
rack. If you try to install it without anchoring it to the rack, it could fall out of the
rack.
Do not put a metal object, such as a pin
or paperclip, or a vase or flower pot on the
GR2000-B. Water or object getting into
the chassis could cause a severe electrical
shock to anyone touching the router.
Do not use a power source or voltage that
exceeds the specifications of the
GR2000-B. Observe markings on the chassis.
To prevent electric shock, use only grounded power outlets.
Do not use adapters to connect multiple power cables to the same outlet. Doing
this can cause a fire and can cause a circuit breaker to trip due to an overloaded
circuit.
Do not put a heavy object on a power cable, since it could crush it. Similarly,
don’t pull, bend or otherwise mutilate the power cable, since this could cause a
fire or electric shock.
Use the power cable packed along with a chassis. If you use a power cable other
than this, it could cause a fire or an electric shock. In addition, do not use this
power cable for devices other than the GR2000-B. If you do, it could cause a fire
or electric shock.
Do not put a power cable under the device. Doing this might cause a fire or an
electric shock.
If the power cable is ever damaged so that the wires underneath the covering are
visible or cut, stop using it and ask a maintenance staff to replace it. If you
continue to use a damaged cable, it could easily cause a fire or electric shock.
Remove the cable lock metal, and
unplug the cable.

GR2K-GA-0007 xv
Rev. 5.00
Make sure that the power plug is clean when you insert it into the device or into
the AC source. A fire or an electric shock can be caused by dust or incomplete
connection.
Do not insert any foreign objects into
the device or the ventilation slots.
Doing so may cause fire or electric
shock.
Before removing the cover from the
GR2000-B, turn off the power switch
and unplug all the cables including the
power cable. Even if the power switch
is turned off, electricity continues to be conveyed into the electric circuit through
the cables connected to the device, which can cause a fire or electric shock.
Removing the cover from the device should be done
by a trained engineer or a maintenance staff. This
label is attached to the device.
If the device is dropped and any part is broken, turn
the power switch off, unplug the power cable from
the outlet, and contact service. Continued use may
cause fire or electric shock.
Do not remodel the device. Doing this causes a fire
or an electric shock.
Turn off the power switch when installing or
replacing additional network interface boards or
memory modules.
Do not install the GR2000-B in a dusty or humid location. Doing so may cause
fire or electric shock.
Condensation may form on the surface and inside of the GR2000-B if it is moved
from a cold to a warm location. Using the device in this condition may cause fire
or electric shock. After moving the device between two locations with a large
temperature variation, let the device stand for a few hours before using.
Do not block the ventilation slots. If
you block the ventilation slots, the
inside of the router will overheat and
cause a fire. Secure at least 70 mm of
space on each side of the GR2000-B to
ensure proper air flow through the ventilation slots.
Do not put a heavy object weighing more than 5 kg on the GR2000-B. If you do, it
could damage the router, or else make it fall over and causing damage or injury.
Do not stick your fingers into the
ventilation slots, or allow your hair to
get near the ventilation slots. This
can cause electrical shock or other
physical injuries cased by working
parts.
AC100～240V
Air Entrance
Air Exit

Hitachi Gigabit Router GR2000-B Series Installation Guide
xvi GR2K-GA-0007
Rev. 5.00
Caution
Move the device carefully. Before doing so, unplug the power and other cables.
Failure to follow this warning may damage the router or cables, or could cause
fire or electric shock.
Don’t pile this equipment up on top of on another when moving it. Try to store
each device in it’s own box when transporting it to prevent it from being deformed
or damaged.
Do not put the power cable near a heating apparatus. Doing so melts the coating
of the cable and can cause a fire or electric shock.
Always hold the power plug when
inserting or removing the power cable
into or from and outlet Pulling on the
cable can causes the wires to break.
This router contains a lithium battery
for the real-time clock. Mishandling this
battery may cause heat build-up,
damage, or in an extreme case,
explosion or fire. Do not remove the
battery from the router, attempt to
disassemble it, or expose it to
temperatures of over 100°C (212°F).
Do not step on the router or place heavy
objects on it weighing more than 5 kg
on the device. Doing so can damage it.
While the access indicator (ACCESS) for
a memory card is lit, the memory card is
being accessed. DO NOT pull out a
memory card or turn off the power
switch while the memory card is being
accessed. If so, you could permanently
damage the memory card. Some
commands require a long time to finish
accessing a memory card when they are
executed. Make sure that the access to a memory card is finished before pulling it
out or turning off the power switch.
Be careful with the laser outputs on optical network
interfaces. The board with the label below shows that a laser
is used in it. As the amount of its emission is small, there is
no risk of damaging your skin. Still, never look into the
output directly. There is nothing to see inside.
Wear a wrist strap to prevent static electricity. Without a wrist strap, the device
might be damaged due to static electricity.
Do not over tighten the attachment screws when connecting a cable to the router.
Over tightening the screws could cause them to break. Use only a small,
flat-blade screwdriver to tighten the screws so as not to exert excessive torque on
the screws.
Be careful how you handle the NIFs. Since they are static sensitive, handle NIFs
only by the board edges. When you store NIFs, place them in anti-static
packaging and protect them from physical damage.
CLASS 1
LASER
PRODUCT

GR2K-GA-0007 xvii
Rev. 5.00
Make sure that you have either a NIF in, or dummy panel installed over, an
option slot. If not, air may not circulate correctly inside the router.
For the installation of a network interface board, use a screw driver when
fastening screws and make sure that the screws are fixed firmly, but do not
overtighten.
Take care so that the fan cables, etc. are not snagged or crushed inside the router
when replacing the cover.
Clean the device only with a clean, dry cloth or use a cloth that has been
dampened (not wet) with water or another pH-neutral liquid. Do not use volatile
organic solutions such as benzene or paint thinner, chemicals, chemically
treated cloths or pesticides, which may deform, discolor or damage the router.
Do not place the router in direct sunlight or
near heat sources that may cause damage.
If the router is placed together with a radio
or a TV, they might affect each other in an
unfavorable way. If you hear the burst of
noise on a TV or a radio, do the following:
Place the device as far away from a TV or a
radio as possible.
Turn the antenna of a TV or a radio to
another direction.
Do not use the same outlet as the router.
Unplug the power cable from the outlet when the router is not used for long
periods.
Dispose of exhausted devices or boards, including lithium batteries, as required
by local regulations.

Hitachi Gigabit Router GR2000-B Series Installation Guide
xviii GR2K-GA-0007
Rev. 5.00
This page left intentionally blank

GR2K-GA-0007 xix
Rev. 5.00
Table of Contents
Chapter 1 - Component Overview..........................................................1-1
1.1 Chassis Description for Models GR2000-1B, GR2000-2B, and GR2000-2B+ ............................. 1-2
1.1.1 GR2000-1B............................................................................................................................... 1-2
1.1.2 GR2000-2B............................................................................................................................... 1-5
1.1.3 GR2000-2B+............................................................................................................................. 1-8
1.1.4 Accessories for Models GR2000-1B, GR2000-2B, and GR2000-2B+ ................................... 1-11
1.2 Network Interface Boards for Models GR2000-1B, GR2000-2B, and GR2000-2B+ .................. 1-13
1.2.1 NWBMX2-4............................................................................................................................. 1-13
1.2.2 NWBT1-4................................................................................................................................ 1-15
1.2.3 NWBE1-4................................................................................................................................ 1-17
1.2.4 NWBT3-2U ............................................................................................................................. 1-19
1.2.5 NABOC3-1M........................................................................................................................... 1-21
1.2.6 NABOC3-1S ........................................................................................................................... 1-22
1.2.7 NEB100-4TB .......................................................................................................................... 1-23
1.2.8 NEB1G-1B.............................................................................................................................. 1-24
1.3 Chassis Description for Model GR2000-BH................................................................................. 1-25
1.3.1 Chassis................................................................................................................................... 1-25
1.3.2 Accessories for Model GR2000-BH........................................................................................ 1-27
1.4 Basic Control Unit for GR2000-BH ............................................................................................... 1-28
1.5 Power Supply Unit for GR2000-BH............................................................................................... 1-30
1.6 Network Interface Boards for Model GR2000-BH........................................................................ 1-31
1.6.1 NEBH1G-4C ........................................................................................................................... 1-31
1.6.2 NEBH1G-4E ........................................................................................................................... 1-33
1.7 Common Components................................................................................................................... 1-35
1.7.1 Memory Cards (MC) ............................................................................................................... 1-35
1.7.2 Main Memory (DIMM)............................................................................................................. 1-35
1.7.3 GBIC (Gigabit Interface Converter) ........................................................................................ 1-36
Chapter 2 - Preparing for Installation ....................................................2-1
2.1 Installation Preparations ................................................................................................................. 2-2
2.2 Setting Conditions for the GR2000 B ............................................................................................. 2-3
2.3 Power Supply Equipment................................................................................................................ 2-4
2.4 Electrical Noise ................................................................................................................................ 2-4
2.5 Ground Current ................................................................................................................................ 2-4

Hitachi Gigabit Router GR2000-B Series Installation Guide
xx GR2K-GA-0007
Rev. 5.00
2.6 Environmental Conditions .............................................................................................................. 2-5
2.7 Installation Space ............................................................................................................................ 2-7
2.8 Maintenance Area ............................................................................................................................ 2-8
2.9 Cooling Considerations .................................................................................................................. 2-9
2.10 Device Noise................................................................................................................................. 2-10
Chapter 3 - Preparing Interface Cables and the Terminal .................. 3-1
3.1 Connection of Cables ...................................................................................................................... 3-1
3.2 Interface Cable Specification .......................................................................................................... 3-3
3.2.1 V.24 Line Interface Cable for Modems .....................................................................................3-4
3.2.2 V.35 Line Interface Cable for Modems .....................................................................................3-5
3.2.3 X.21 Line Interface Cable for Modems .....................................................................................3-6
3.2.4 V.24 Line Interface Cable for GR2000-B.................................................................................. 3-7
3.2.5 V.35 Line Interface Cable for GR2000-B.................................................................................. 3-8
3.2.6 X.21 Line Interface Cable for GR2000-B.................................................................................. 3-9
3.2.7 Primary Group (T1/E1) Interface Cable.................................................................................. 3-10
3.2.8 Tertiary (T3) Interface Cable .................................................................................................. 3-11
3.2.9 ATM Multi-Mode Optical Fiber Cable (Core Diameter 50 mm)............................................... 3-12
3.2.10 ATM Multi-Mode Optical Fiber Cable (Core Diameter 62.5 mm).......................................... 3-13
3.2.11 ATM Single-Mode Optical Fiber Cable (Core Diameter 10 mm) .......................................... 3-14
3.2.12 1000BASE-SX/1000BASE-LX Multi-Mode Optical Fiber Cable
(Core Diameter 50 mm) ............................................................................................................. 3-15
3.2.13 1000BASE-SX/1000BASE-LX Multi-Mode Optical Fiber Cable
(Core Diameter 62.5 mm) .......................................................................................................... 3-16
3.2.14 1000BASE-LX/1000BASE-LH Multi-Mode Optical Fiber Cable
(Core Diameter 10 mm) ............................................................................................................. 3-17
3.2.15 UTP Cable (Cat-5)................................................................................................................ 3-18
3.3 The Setup Terminal and Cable Connections............................................................................... 3-19
3.3.1 Setup Terminal ....................................................................................................................... 3-19
3.3.2 Connecting Cable ................................................................................................................... 3-19
Chapter 4 - Setup.................................................................................... 4-1
4.1 Required Tools................................................................................................................................. 4-1
4.2 Dangers, Cautions, and Notes Regarding Setup .......................................................................... 4-2
4.3 Installing the GR2000-B on a Table or Desk.................................................................................. 4-3
4.3.1 Installing the GR2000-1B, GR2000-2B, and GR2000-2B+ ...................................................... 4-3
4.3.2 Installing the GR2000-BH......................................................................................................... 4-3
4.4 Mounting the GR2000-B in a Rack.................................................................................................. 4-4
4.4.1 Mounting the GR2000-1B, GR2000-2B, and GR2000-2B+...................................................... 4-4
4.4.1.1 Installing the Router in a Open Rack .............................................................................. 4-4
4.4.1.2 Installing the Router into a Cabinet (Enclosed) Rack...................................................... 4-7
