Hitachi CP-A200 User manual

Ultra-Short Throw LCD Projector
CP-A200
397mm (15.63")
356mm (14.02")
379mm (14.92")
391mm (15.39")
225mm (8.86")
131mm
(5.16")
113mm (4.45") 139mm (5.47")
DIMENSIONS
TERMINALS
Computer In 1Computer In 2Monitor Out
Control (RS-232C)
Component Video
S-Video
Composite Video
Audio In 2
Audio In 1
Audio Out
Security Bar
Kensington Lock
Audio In 3 (L/R)
3,000 Lumens
-
Bright and Clear!
77 type
interactive whiteboard
(77 inches/196cm screen)
projected at 60.3cm
(24 inches)
Model name
Liquid crystal panel
Number of pixels
Resolution
Digital zoom
Focus
Lamp
Light output (brightness)
Contrast ratio
Audio
Keystone correction
Power supply
Operating temperature
Input
signals
Input/output
terminals
Agency certifications
Dimensions (WxHxD)
Weight
Standard accessories
Optional accessories
Computer input
Video input
Video input
Audio input
Computer input
Audio output
Monitor output
Control
SPECIFICATIONS
CP-A200
0.63 type (inch), 1.6cm polysilicon active-matrix TFT x 3
786,432 pixels (H1,024 x V768)
1,024 x 768 color pixels (XGA)
x1.2
Power focus
230W UHB
3,000 Lumens
500:1
7W
Manual Vertical/Horizontal Keystone
AC100-120V/AC220-240V
5-35°C (41-95°F)
VGA, SVGA, XGA, SXGA, UXGA, MAC16"
NTSC, NTSC4.43, PAL, SECAM, M-PAL, N-PAL
HDTV: 720p@50/60, 1080i@50/60, 1080p@50/60
SDTV: 480i, 480p, 576i, 576p
S-Video: Mini Din 4-pin x 1, Composite video: RCA jack x 1
Component video: RCA jack x 3
Stereo Mini jack x 2, RCA jack x 2 (L/R)
Analog RGB: 15-pin Mini-Dsub x 2
Stereo Mini jack x 1
Analog RGB: 15-pin Mini-Dsub x 1
9-pin Dsub x 1 for RS232C
UL/cUL, FCC Part15 class B, AS/NZS CISPR22 class B,
CE, GOST-R
397 x 131 x 356mm (15.63" x 5.16" x 14.02")
[excluding protruding part, when mirror is closed.]
5.8kg (12.8 lbs.)
Computer cable, Remote Control, Batteries, Cable cover,
Power cord, User's manual, Security label
Lamp: DT00893,
Filter unit: UX35381,
Soft case: CA100
• The projected images and comparison photos in this catalog are simulations.
• LCD panels, polarizers and other optical components and cooling fans may need replacement after prolonged usage. For more details, please consult a Hitachi sales representative.
• Do not use in places where there is a lot of water, dampness, steam, dust, soot or tobacco smoke. This may result in fire or malfunction.
• Optical components (lamp, LCD panel, polarizing plate, PBS [polarizer beam splitter]) have limited service lives. They must be repaired or replaced if they are used for a long period of time.
• These projectors use a mercury lamp with high internal pressure. Because of its properties, this lamp may burst with a loud noise or burn out if struck or after it has been used for a period of time. The time until it bursts or
burns out varies greatly according to differences between lamps and usage conditions. Turning the lamp’s power on and off frequently shortens its service life.
• Optical components other than the lamp: If the projector is used for six hours or more per day, they may need to be replaced in less than a year.
• LCD panel: If the projector is used continuously for six hours or more, its replacement cycle may be shortened.
• Do not turn projector on again for ten minutes after shutdown. Neglect can shorten the lifetime of the lamp. During use and immediately after use, do not touch anywhere near the lamp and the vents as these parts are extremely hot.
• Design and specifications are subject to change without notice.
Printed in Japan (H)NM-E347 0310
Compliance with EU Directive RoHS*1Power saving mode engaged during
standby
Whisper mode
Whisper mode provides power saving.
Reduction of resin usage in production
Use of hot runners in molds for making upper housing in order to reduce mill ends.
Consideration for the Environment
*1 RoHS is the acronym of "DIRECTIVE 2002/95/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of
27 January 2003 on the restriction of the use of certain hazardous substances in electrical and electronic equipment".
Hitachi America, Ltd., Digital Media Division, Business Solutions Group 900 Hitachi Way, Chula Vista, CA 91914-3556, U.S.A. and Canada
Tel: +1-800-HITACHI Fax: [phone] www.hitachi-america.us/digitalmedia
Hitachi Home Electronics Asia (S) Pte. Ltd. 438A Alexandra Road #01-01/02/03, Alexandra Technopark, Singapore 119967
Tel: [phone] Fax: [phone] www.hitachiconsumer.com.sg
Hitachi Sales (Malaysia) Sdn. Berhad (11543-V) Lot 12, Jalan Kemajuan, Bangi Industrial Estate, 43650 Bandar Baru Bangi, Selangor Darul Ehsan, Malaysia.
Tel: [phone] Fax: [phone] www.hitachiconsumer.com.my
Hitachi Sales (Thailand), Ltd. 994 Soi Thonglor, Sukhumvit 55 Road, Klongtonnua, Vadhana Bangkok 10110, Thailand
Tel: [phone] Fax: [phone]-0021 www.hitachi-th.com
Hitachi (Hong Kong), Ltd. 18th Floor, Ever Gain Centre, 28 On Muk Street, Shatin, N.T., Hong Kong Tel: [phone] Fax: [phone] www.hitachi-hk.com.hk
Hitachi Sales Corp. of Taiwan 2nd Floor, No.65, Nanking East Road, Section 3, Taipei 104, Taiwan Tel: [phone] Fax: [phone] www.hsct.com.tw
Hitachi Australia Pty Ltd. Level 3, 82 Waterloo Road, North Ryde, NSW 2113, Australia Tel: [phone] Fax: [phone] www.hitachi.com.au
Hitachi Europe Ltd. Whitebrook Park, Lower Cookham Road, Maidenhead, Berkshire, SL6 8YA, UK Tel: [phone] Fax: [phone] www.hitachidigitalmedia.com
PROJECTION DISTANCE
Screen Size (4:3 Screen)
60 type (inch), 1.5m
70 type (inch), 1.8m
80 type (inch), 2.0m
90 type (inch), 2.3m
100 type (inch), 2.5m
a1
9.6cm (4")
17.2cm (7")
24.8cm (10")
32.4cm (13")
39.9cm (16")
a2
47.4cm (19")
55.0cm (22")
62.6cm (25")
70.2cm (28")
77.7cm (31")
b1
28.9cm (11")
32.6cm (13")
36.2cm (14")
39.9cm (16")
43.6cm (17")
b2
120.4cm (47")
139.3cm (55")
158.2cm (62")
177.1cm (70")
196.0cm (77")
• Final specifications may vary slightly.
• Manufacturer’s recommended size is
60 type (inch), 1.5m – 100 type (inch), 2.5m.
• Tolerance 8% (for projection distance a2)
+
-
b2
b2
b1
b1
a2
a1
a2
a1
Soft Case
(CA100)
Cable cover

Conducting lessons is easier and more effective with high brightness,
ultra-short throw and a wide variety of functions.
Ultra-Short Throw LCD Projector
CP-A200
The Power Saving mode at standby setting
reduces standby power consumption to
less than 5W. The following features are
disabled: RS-232C control except
power-on command, and audio capability
including audio pass through.
Power Saving Mode
Security bar
The CP-A200 is equipped with a security
bar that allows the attachment of a security
chain. The PIN Lock function limits
the number of users.
The MyScreen
function can be
used for owner
identification, and
is also protected
by a PIN Lock.
Versatile Security
Functions
Easy Maintenance
The Hybrid Filter requires less frequent
maintenance and cleaning, making longer
operation possible.
Filter maintenance
frequency has been
improved* from
every 400 hours to
every 2,000 hours.
Hybrid Filter
* In comparison to CP-A100.
• Actual filter maintenance necessity varies according
to environment.
Daytime Mode
• Low Noise of 28dB* (Whisper Mode) • Blackboard
or Whiteboard Modes at Picture Setting
• Input Source Naming • 4-Second Quick
Start • Direct Power On/Off • Resolution
Preset and Custom Modes • My Button
• My Text • Horizontal Keystone Correction
• Versatile, Easy Connectivity • Serial No.
Label on Side • Security Label Included
• My Source/Document Camera Button on
Remote Controller • IR Remote Frequency
Change • Closed Caption
Other Features
Projected images may sometimes be difficult
to see under bright lighting. The Daytime
Mode uses image quality correction
technology to counter the effects of light,
ensuring clear, vivid images.
Normal mode Daytime mode
Using it together with an interactive
whiteboard enables presentations
and lessons to be more easily
understood.
Interactive
whiteboard use
It can be used in narrow spaces
such as show windows in stores
or booths at exhibitions.
Store window use
It can be used to give effective
presentations in complex spaces
such as amusement facilities.
Amusement
space use
Various situations
where it can be used
When projecting onto a whiteboard,
blackboard, etc., this function projects
lines, making writing on the board easier.
You can choose four types of lines:
black lines on a white background,
black lines on a white grid, white lines
on a black background or white lines on
a black grid. * Patent pending
Audio can be output via external speakers
in standby condition. This saves lamp life
when only sound is required.
Audio Pass Through*
Black lines on a white grid Black lines
on a white background
* When in Normal mode at standby setting. It does not
function in Saving mode.
The lamp door is on the top and the filter
cover on the back, so maintenance and
replacement of these parts can be
done easily.
Template Function*
The CP-A200 provides high brightness of 3,000 lumens, allowing the projection of easily
visible images, even in bright rooms. It can be used without darkening the room, so pupils
can take notes, permitting more efficient lessons.
3,000 Lumens Light Output (Brightness)
Perfect Fit
Adjust each of
the four corners.
Adjust for barrel or pincushion distortion
that occurs on rounded surfaces.
Curved whiteboard
0
200mm
(8")
400mm
(16")
600mm
(24")
800mm
(31")
1000mm
(39")
1200mm
(47")
1400mm
(55")
1600mm
(63")
1800mm
(71")
2000mm
(79")
2200mm
(87")
2400mm
(94")
CP-X2010
CP-A200
Short installation
distance
0200mm
(8")
400mm
(16") 600mm
(24")
800mm
(31") 1000mm
(39")
1200mm
(47") 1400mm
(55")
1600mm
(63") 1800mm
(71")
2000mm
(79") 2200mm
(87")
2400mm
(94") 2600mm
(102")
2800mm
(110") 3000mm
(118")
60.3cm 2.3m
• Ratios of dimensions
in photo are not actual.
(90")
(24")
2600mm
(102")
77 type
interactive
whiteboard
(77 inches/
196cm screen)
Ultra-Short Throw Length
High
installation
position
* Typical. Tested in 23°C environmental conditions.
large images onto a 77 type (inch), 196cm interactive whiteboard
from a distance of only 60.3cm (24 inches). Ultra-short throw
and the projector’s high installation position reduce shadows
from the teacher’s hands and body on the interactive
whiteboard. Annoying glare from the projector’s light source
and hot exhaust air are also reduced, allowing lessons to be
conduced with greater ease. In addition, the short distance
from the screen makes installation easier and permits the use
of a short connection cable.
The CP-A200 features two of
Hitachi’s latest technologies:
a free-shaped plastic lens and
a mirror projection system.
Even in a classroom with
limited space, it can project
Lamp Door
on the top
Filter Cover
on the back
In addition, barrel or pincushion distortion, which occur on
blackboards or whiteboards with rounded surfaces, can easily
be corrected. Making adjustments is easy with the remote
control and the on-screen operating menu.
Perfect Fit enables quick
adjustment of the projected
image by moving its four
corners one at a time.
