Hitachi CP-RS56 series User manual

CP-RX60
Model Number CP-RS56
Liquid crystal panel structure 0.55” polysilicon active-matrix TFT x 3 with micro lens
Resolution Video 540 TV Lines
RGB 800 Dots x 600 Lines
Colors 16.7 million colors
Aspect ratio Native 4:3; or 16:9 Compatible
Lens F1.6-1.9, Manual Zoom x 1.2, manual focus
Throw ratio (distance:width) 1.6-1.9:1
Lamp 165W UHB
Brightness 1,600 ANSI Lumens
Contrast Ratio 500:1
Expected lamp life Approx. 2,000 hours (Approx. 3,000 hours in Whisper Mode)
Speakers 1Wx 1
Power supply AC100-120V/AC220-240V, 50/60 Hz, Auto Switching
Power consumption 240W
Approvals UL60950/C-UL, FCC Class B, CE, EN60950
Operating temperature 0 ~ 35°C (32° ~ 95°F)
Inputs RGB VGA, SVGA, XGA, SXGA, UXGA
MAC 16”, 480i, 576i, 480p, 720p, 1080i
Composite Video NTSC, NTSC4.43, PAL (-BGDH), SECAM, PAL-M, PAL-N
Plug & Play DDC1/2B
Acoustic noise level 38dB (33dB in Whisper Mode)
Vertical keystone correction Digital Keystone +/- 15°
Data input RGB 15-pin D-sub connector x 2
Data output 15 pin D-sub connector x1
Video input S-video Mini DIN 4-pin input connector x 1
Composite video RCA jack x 1
Audio input Stereo mini jack x1
Audio output Stereo mini jack x1
Control terminals 9-pin D-sub connector x 1
RS-232C (Serial)
Dimensions 11.22” x 2.87” x 7.94” (W x H x D)
Weight 5.1 lbs.
Supplied accessories Remote control, batteries (AA), power cord, RGB cable,
Filter Cover for Ceiling Mount Use, Safey Instruction
Guide, User Manual (CD)
Lamp CPRS55LAMP
Remote control HL02212
Filter NJ20922
SPECIFICATIONS
•Gamma Correction
• Freeze Function
•Magnify (4x)
• 33dB (Whisper Mode)
• Native SVGA Resolution
• 2-3 Pull Down
• Throw Ratio 1.6-1.9:1
• Optical Zoom &
Digital Zoom x 1.2
Chassis
Replacement
parts
• 1,600 ANSI Lumens
• 5.1 lbs.
• Vertical Keystone Correction
• RGB / Component / Composite /
S-video Inputs
• RGB Input/Output x2/x1
• Contrast Ratio 500:1
•Auto Configuration (H-Size,
Position)
•Approx. 3
,000 Hour Lamp Life
Whisper Mode
•Reverse Image Function for
Ceiling Mount
CP-RS56 series
Input/Output terminals

www.hitachi.us/digitalmedia
Screen Size 4:3 Throw distance
Diagonal* Width* Min* Max*
40 32 32 63
60 48 79 95
80 64 105 127
100 80 132 158
120 96 158 190
150 120 198 238
200 160 264 318
Throw ratio: 1.6-1.9:1 (distance:width)
* Measured in inches
(*) Excluding Lens and Leg
11-1/4 ”
2-7/8 ”
7-15/16 ” (*)
(*)
(*)
CP-RS56 Dimensions
CP-RS56 series
For sales information, call 1.800.225.1741
Printed 03.06
Specifications are subject to change without notification.
