All specifications subject to change without notice
For sales information, please call 800.225.1741
Printed 08.10
Diagonal* Width* Min* Max*
30 24 35 42
60 48 71 85
80 64 95 114
100 80 119 143
120 96 143 171
150 120 179 215
200 160 238 286
300 240 358 430
Screen Size 4:3 Throw Distance
Throw Ratio: 1.3 - 1.8:1 (distance : width)
*Measured in inches
Model Name
Liquid Crystal Panel Structure
Number of Pixels
Resolution Video
RGB
Colors
Aspect Ratio
Lens
Throw Ratio (distance : width)
Lamp
Brightness
Color Light Output
Expected lamp Life
Contrast Ratio
Speaker Output
Power Supply
Power Consumption
Operating Temperature
Input Signals RGB
Composite Video
Component Video
Acoustic Noise Level
H-Sync
V-Sync
Vertical Keystone
Approvals
RGB Input Analog RGB
RGB Output RGB
Video Input S-Video
Composite Video
Component Video
Audio Input
Output
Dimensions (W x D x H)
Weight
Additional Features
Supplied Accessories
Lamp
Remote Control
Filter
6SHFLÀFDWLRQV
CP-RX82 Series
0.63” polysilicon active-matrix TFT x 3
786,432 pixels
540 TV lines
1024 dots X 768 lines
16.7 million colors
Native 4:3/16:9 compatible
Manual zoom (F=1.7 ~ 1.9, f=19~23mm), Manual Focus
1.5 - 1.8 : 1
200W UHP
2,200 ANSI Lumens
2,200 ANSI Lumens
Approximately 3,000 hours (normal) 4,000 hours (Eco Mode)
500 : 1
1W
AC100 - 120V / AC220 - 240V 50/60 Hz
330W
5˚C - 35˚C (41˚F - 95˚F)
VGA, SVGA, XGA, WXGA, SXGA, SXGA+, UXGA, MAC 16”
NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N, PAL60
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
35 dB (28 dB in Eco Mode)
15 Hz - 106 Hz
50 Hz - 120 Hz
+ / - 30˚
UL, C-UL, FCC, CE, RoHS
15pin Mini-Dsub x 1
15pin Mini-Dsub x 1
Mini DIN 4-pin connector x 1
RCA jack x 1
Shared with RGB
Stereo Mini x 1
Stereo Mini x 1
12.0” x 8.7” x 3.0”
5.0 lbs.
My Screen, My Memory, My Button, My Text, My Source,
Blackboard/ Whiteboard Mode, Daytime Mode, Input Source
Naming(English), Resolution Setting, Template, Closed
Caption(for NTSC only), Audio Pass Through
Remote Control, Batteries (AA), RGB cable, US Power Cord,
Multiple language operator / Safety Manual, Security Label
CPRX82LAMP (DT01151)
HL02771
MU06961
CP-RX82
s !.3) ,UMENS
s .ATIVE 8'! 2ESOLUTION
s LBS
s 0). ,OCK 3ECUTIRY
s 7HITEBOARD"LACKBOARD -ODE
s D" %CO -ODE
s &RONT !IR %XHAUST
s "LANK "UTTON ON 4OP
s %ASILY 2EPLACE ,AMP FROM 4OP
s !IR &ILTER ON 3IDE
s %ASILY !CCESSIBLE (IGH %FlCIENCY &ILTER
s )NSTANT /N/FF
s (OUR ,AMP ,IFE %CO -ODE
s 4EMPLATE &UNCTION
s 0OWER 3AVING -ODE
s !UDIO 0ASS 4HROUGH
s #LOSED #APTION
s!UTOMATIC %CO -ODE
Closed Captioning
.H\)HDWXUHV
AMX Device Discovery
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected
operating mode, user settings and usage. Hours of average lamp life specified are not guaranteed
and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
