CP-S210 series
Model name CP-S210 series
Liquid crystal panel structure 0.55” polysilicon active-matrix TFT x 3
Number of pixels 480, 000 pixels (H800 x V600)
Resolution Video 540 TV lines
RGB 800 dots x 600 lines
Colors 16.7 million colors
Aspect ratio Native 4:3/16:9 compatible
Lens Manual zoom 1:1.2 (F1.6 - 1.8)
Throw ratio (distance:width) 1.47 ~ 1.79 : 1
Lamp 130W UHB
Brightness 1,200 ANSI lumens (approx. 960 in whisper mode)
Expected lamp life Approx. 2,000 hours
Contrast ratio 300 : 1
Speakers 1W x 1
Power supply AC90-132V/AC220-240V 50/60Hz
Power consumption 220W
Operating temperature 0 ~ 35°C (32° ~ 95°F)
Input signals RGB VGA, SVGA, XGA/SXGA/UXGA (COMPRESSED), MAC13”,
MAC16”
Composite video NTSC, NTSC4.43, PAL, PAL-M, PAL-N, SECAM, PAL60, S-video
Component video 480i, 625i, 480p, 1,080i, 720p
Acoustic noise level 32dB (27dB in whisper mode)
H sync 15kHz ~ 91kHz
V sync 50Hz ~ 120Hz
Vertical keystone correction Digital keystone +/- 15°
Horizontal keystone correction –
Approvals UL, C-UL, FCC Class B, CE, TUV
RGB input RGB D-sub 15-pin connector x 1
Audio Stereo mini jack x 1
Video input S-video Mini DIN 4-pin input connector x 1
Composite video RCA jack x 1
Component video RCA jack x 3
Audio RCA jack x 2 (L/R)
Control terminals D-sub 9-pin connector x 1
Compatible controls RS-232C (Serial)
Dimensions 13.1” x 9.8” x 3.6” (W x H x D)
Weight 6.5 lbs.
Supplied accessories Remote control, batteries (AA), power cord, RGB cable,
multiple language operator/safety manual, soft case
Lamp CPS210LAMP (Part #DT00581)
Remote control Part #HL01894
Mouse kit Part #RMU101 Optional
SPECIFICATIONS
• Vertical keystone correction
• Video noise reduction
• 16:9 mode
• Digital zoom & freeze
function
• Supplied soft case
• Whisper mode 27dB
•Progressive Scan
Technology
Input/Output terminals
Chassis
Replacement parts
• 1,200 ANSI lumens
• Native SVGA resolution
• 6.5 lbs.
• RGB/component/
composite/S-video inputs
• HDTV theater ready
• Short throw lens
•My Memory
• Manual zoom & manual focus
• Color temperature and gamma correction
• Reverse image function for ceiling mount
• Kensington security slot

CP-S210 series Dimensions
87.5mm (3-7/16")
332mm (13-1/16")
254mm
(10")
92mm (3-5/8")
14mm (9/16")
57mm
(2-1/4")
3mm (1/8")
(incl.protruding part)
CP-S210 series
For sales information, call 1.800.225.1741.
Printed 04/04
Specifications are subject to change without notification.
www.hitachi.us/digitalmedia
Screen Size 4.3 Throw distance
Diagonal* Width* Min* Max*
40 32 47 56
60 48 71 85
80 64 95 114
100 80 119 143
120 96 143 171
150 120 179 215
200 160 240 287
Throw ratio: 1.47 ~ 1.79:1 (distance:width)
*: Measured in inches
