Model name CPX2 series
Liquid crystal panel structure 0.63” polysilicon active-matrix TFT x 3
Number of pixels 786,432 pixels
Resolution Video 540 TV lines
RGB 1024 dots X 768 lines
Colors 16.7 million colors
Aspect ratio Native 4:3/16:9 compatible
Lens F1.8 - 1.9 manual zoom 1:1.2
Throw ratio (distance:width) 1.3 ~ 1.5 : 1
Lamp 160W UHB
Brightness 2,000
Approx. 2,000 hrs (normal); 3,000 hrs (whisper)
ANSI lumens
Expected lamp life
Contrast ratio 500 : 1
Speakers 1W x 1
Power supply AC100-120V/AC220-240V 50/60Hz
Power consumption 250W
Operating temperature 5°C ~ 35°C (41°F ~ 95°F)
Input signals RGB VGA, SVGA, XGA,SXGA,SXGA+,UXGA, MAC13”, MAC16”
Composite video NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N
Component video 480i, 576i, 480p, 720p, 1080i
Acoustic noise level 35dB (29dB in whisper mode)
H sync 15kHz ~ 106kHz
V sync 50Hz ~ 120Hz
Vertical keystone correction Digital keystone +/– 30°
Approvals UL60950 / C-UL, FCC Part15, Class B, EN60950
RGB input Analog RGB 15-pin D-sub connector x 1
RGB output RGB -----
Video input S-video Mini DIN 4-pin connector x 1
Composite video RCA jack x 1
Component video Shared with VGA 15 pin D-Sub
Audio Input Stereo mini jack x 1
Output Stereo mini jack x 1
Control terminals USB Connector (USB mouse) x 1
Wireless
Ethernet
Other
Wireless 802.11 b/g
Ethernet RJ-45 Port / 100 BASE-T
SD Card, USB 2.0 Memory Reader
Dimensions 10.8” x 2.6” x 8.1” (W x H x D)
Weight 4.1 lbs.
Supplied accessories Remote Control, Batteries (AA), RGB Cable, US Power
Cord, Multiple Language Operator / Safety Manual, Soft
Case, SD wireless card
Lamp CPX1/253LAMP (DT00781)
Remote Control HL02224
Filter MU03602
Chassis
Replace-ment
parts
Input/Output terminals
SPECIFICATIONS
• My Screen/ My Memory
• Whisper Quiet Operation
(29 dB Whisper Mode)
• Supplied Soft Case
•
Whiteboard Mode
• Blackboard Mode
• Lamp life Approx. 3,000 hrs
(Whisper Mode)
•
Kensington Security Slot
• PC-less Presentation
• Audio Input/Output
• Input Source Naming
•
Remote Control with
My Buttons
•
Networkable via RJ45
• 2,000 ANSI Lumens
• Native XGA Resolution
• 4.1 lbs
Input and Output
•
Composite /
S-Video Inputs
• 802.11 b/g Connect & Present
with 4pc's wirelessly
•
FCC Class B
•
Transition Detector
•
Auto Vertical Keystone
Correction
Screen Size 4.3 Throw distance
Diagonal* Width* Min* Max*
30 24 30 36
60 48 61 73
80 64 81 97
100 80 102 122
120 96 122 147
150 120 153 183
200 160 204 245
300 240 306 368
Throw ratio: 1.3~ 1.5:1 (distance:width)
* Measured in inches
CPX2 series
For sales information, call 1.800.225.1741.
Printed 02.07
