LCD PROJECTOR
PRODUCT SPECIFICATIONS
MODEL PJ-TX10 (C10H)
PJ-TX10W for Asia, Canada and USA(HAL-HED)
PJ-TX10E for Europe
PJ-TX10W(AU) for Australia
VER.1.1
Approved by
Date
August 04, 2003
Hitachi, Ltd.
Digital Media Division
Minoru Kato
Senior Engineer
History
Ver 1.1
3.4 CIE SATURATION
Blue center value y = 0.05 -> 0.04

PJ-TX10W/E/W(AU) ver 1.1
1
1.GENERAL
1.1 OPTICAL STRUCTURE 3 LCD panels, one projection lens, RGB shutter method
1.2 LCD PANEL 0.55inch, P-Si TFT panel x 3, Stripe pixel configuration
854 dots x 480 lines x 3 panels
Drive method: TFT Active Matrix, with micro lens
1.3 LENS F1.6~2.9 (f=14.2 ~ 28.4mm)
Manual Zoom x 2
Manual Focus
1.4 LAMP UHB 130W @ Normal mode
Lifetime 2000 hours This means below.
More than 50 % of lamps will operate 2000 hours.
Less than 50 % of them will stop operation before 2000 hours
including lamp burst. More than 50% performance is typical @ 2000 hours.
(Internal timer to shut projector down sets 2000 hours.
Lamp power drop around 20% down @ Whisper mode.)
1.5 FOCUS DISTANCE 0.7m ~ 7.8m (Wide), 1.5m ~ 15.7m (TELE)
1.6 DISTANCE TO SCREEN WIDTH RATIO (:1) 1.15 (WIDE), 2.35 (TELE) --- reference purpose only
1.7 DISPLAY SIZE 30 inches ~ 300 inches (60 inches (16:9) at 1.5m, wide)
1.8 LENS SHIFT Vertical 10:0 ~ 0:10, Horizontal 7:3 ~ 3:7.
1.9 COLOR 16.7 million colors
1.10 RESOLUTION
Video 480 TV lines (@ overscan mode)
RGB 848 dots x 480 lines
1.11 SIGNAL
Composite Video NTSC, NTSC4.43, PAL(-BGDHI), SECAM, PAL-M, PAL-N, PAL60
Component Video 525i(480i), 525p(480p), 625i(575i),
1125i(1080i@50/60,1035i@60, 750p(720p@60)
R,G,B IBM Compatible VGA, SVGA/XGA/SXGA/ (compressed)
MAC13",MAC16"
fv ; 56 ~ 120Hz , fH ; 31.5 ~ 91kHz (See 4.2table for compatibility)
1.12 AUDIO
Speakers 1.0 W x 1
Input RCA jack(L,R)×1(video), φ3.5 stereo mini jack x 1 (computer)
Output NONE

PJ-TX10W/E/W(AU) ver 1.1
2
1.13 ADDITIONAL FEATURES
Mirror Reverse Image
Up-side Down Image
Picture Freeze by RS-232C
Magnify 4 times by RS232C
My Memory
3D Y/C Separation for NTSC composite signal
2-3 Pull Down for NTSC
3D Noise Reducer
Digital Gamma Correction
R/G/B Color Adjustment
ASPECT selection
For Video: 4:3/16:9/Wide/MOVIE-1/MOVIE-2
For RGB: 4:3/16:9/15:9/31:15
15 Languages OSD (English, French, German, Spanish, Italian, Norwegian, Dutch, Japanese,
Portuguese, Chinese, Korean, Swedish, Russian, Finnish, Polish)
Vertical Digital Keystone Correction: ±15degrees
(Note: Input signal is WVGA @ 60Hz, Zoom position is Wide max.)
1.14PLUG & PLAY DDC1/2B(VESA) for RGB INPUT
1.15 INTERFACE CONNECTORS
(1) VIDEO INPUT
Composite Video RCA jack X 1
S-Video Mini-Din 4 pin X 1
Component Video RCA jack x 3
Audio RCA jack x 2 (Video Use)
(2) RGB Input
Analog RGB 15 pin D-Sub shrink x 1
Pin Assignments See Table below
Audio φ3.5 stereo mini jack x 1(RGB use)
(3) RGB MONITOR OUTPUT
NONE
(4) Control 9 Pin D-Sub shrink x 1
RS-232C (Serial)
NO Mouse emulation
(5) Audio output NONE

PJ-TX10W/E/W(AU) ver 1.1
3
R.G.Bin(RGB)
15 Pin D-Sub Pin assignments
NO. RGB Component Video NO. RGB Component Video
1Red Cr/Pr 9N.C. PLUG DETECT
2Green Y10 GND GND
3Blue Cb/Pb 11 N.C. ID3
4N.C. ID1 12 SDA (DDC) NC
5GND GND 13 H/Composite Sync NC
6GND(Red) GND(Cr/Pr) 14 Vsync ID2
7GND(Green) GND(Y) 15 SCL (DDC) NC
8GND(Blue) GND(Cb/Pb)
Control (RS232C)
9 Pin D-sub Pin assignments
1
2RD
3TD
4
5GND
6
7RTS
8CTS
9
1.16 POWER SUPPLY AC90 ~ 132V / AC198 ~ 264V (50/60Hz), 3 Wire Grounded
1.17 POWER CONSUMPTION 100 ~ 120V/220 ~ 240V, 50/60Hz 2.4 /1.1A typ., Max. + 10%
100V, 50/60Hz, 220W typ., Max. + 10%
1.18 DIMENSIONS 350X121X285 mm, 13.8X4.8X11.2 inch.(WXHXD)
Excluding extrusions
1.19 WEIGHT 3.6 kg, 7.9 lbs
1.20 NOISE LEVEL
Whisper mode; 26 dB average (A-weighted) at 1 m from the unit at 23 °C (Target)
Normal mode; 29 dB average (A-weighted) at 1 m from the unit at 23 °C (Target)
1.21 TEMPERATURES (at 35°C ambient)
SURFACE Metal 60 °C maximum except screws and terminals
SURFACE Plastic 65 °C maximum except around ventilation holes
EXHAUST AIR 83 °C maximum around ventilation holes
SCREWS AND TERMINALS 75 °C maximum

PJ-TX10W/E/W(AU) ver 1.1
4
1.22 CONTAMINATION
AIR Filtration at intake vent
Dust Protection to prevent visible dust collection all optical component
on or near the focal plane. (*)
*) At just focused position on image, dust is not clearly noticed and size is 16 pixels
maximum (4x4, 3x5, 2x8)
1.23 KENSINGTON SLOT
1.24 REGULATORY (AGENCY, SAFETY, EMI/RFI) APPROVALS
US/Canada UL 60950/C-UL
FCC Part15 subpart B class B
Europe CE approval
EN61000-3-2, EN61000-3-3, EN55022, EN55024
TUV EN60950, Low voltage directive
Australia AS/NZS3260
AS/NZS3548

PJ-TX10W/E/W(AU) ver 1.1
5
1.25 INCLUDED ACCESSORIES
Power Cord
For US/Canada/Asia; (US, Euro, UK) x 1
For Europe; (UK, Euro) x 1
For Australia; (Au) x 1
RCA Video/Audio Cable (3 m) x 1
Wireless Remote Control Unit
"AA" Batteries x 2
Rivet x 1
Strap x 1
Scart Adapter x 1 (Supplied by HEL and packed exclusively for Europe)
10 (*) Language Operator's Manual x 2 ( 5 languages each)
15 (**) Language Safety Instructions x 1
10 (*) Language Quick Guide x 1
(*) (English, French, Spanish, German, Italian, Norwegian, Dutch, Portuguese, Simplified Chinese, Korean)
(**) (English, French, Spanish, German, Italian, Norwegian, Dutch, Portuguese, Simplified Chinese,
Traditional Chinese, Korean, Swedish, Russian, Finnish, Polish)

PJ-TX10W/E/W(AU) ver 1.1
6
OUTWARD

PJ-TX10W/E/W(AU) ver 1.1
7
2. ENVIRONMENTAL CONDITION
2.1 AMBIENT TEMPERATURE
Operating 0 ~ 35 °C
Storage -20 ~ 60 °C
2.2 HUMIDITY
Operating 10 ~ 85% RH
Without condensation
Storage 10 ~ 85% RH
Without condensation
2.3 ALTITUDE From sea level to 6000 feet
2.4 SHOCK (HANDLING) Withstand 50 mm drop on bottom on wooden table
2.5 GAS No corrosive gas and combustible gas existed
2.6 ELECTROSTATIC DISCHARGE
Withstands 10 times 10kV electrostatic discharge from a 150 pF
capacitor through a 100 ohms resistor on any exterior surface of the unit

PJ-TX10W/E/W(AU) ver 1.1
8
3. IMAGE QUALITY
Apply following condition except where noted.
• Apply heat-running for 10 minutes or more before checking
• Ambient temperature is 23 °C
• Whisper: Normal, Gamma: Normal,
• Vertical Lens shift: 1:1, Horizontal Lens shift: 1:1
• Zoom: Wide max, Foot adjust: Retracted (Set should be even with the ground.
3.1 BRIGHTNESS
560 lumens minimum
(Note 1) ANSI 9 point Standard measurement at Screen size 40inch, Meter CL-200
Brightness = Luminance intensity averaged over 9 points x screen area
Typical 700 lumens (Target)
Brightness: Max. Contrast: Max.
3.2 BRIGHTNESS UNIFORMITY
BRIGHTNESS UNIFORMITY 60% minimum, 70% typical (Target)
(Note) ANSI Standard measurement
Brightness uniformity = Minimum of the four corner measurements/average of 9 points measurements
Zoom position: wide, Brightness/Contrast; Default setting
1/6W1/3W
1/6H
1/3H
1/20W
1
/
20H

PJ-TX10W/E/W(AU) ver 1.1
9
3.3 CONTRAST RATIO
120:1 minimum 200:1 Typical (Target)
(Note) ANSI standard measurement. Vertical Lens shift: 10:0.
(A black-and-white " chessboard " pattern consisting of 16 equal rectangles)
All white, All black 560:1 Minimum, 800:1 Typical (Target)
(Note) Vertical Lens shift: 10:0.
3.4 CIE SATURATION at Default setting
x y
White 0.30±0.04 0.35±0.04
Red 0.65±0.04 0.34±0.04
Green 0.34±0.04 0.65±0.04
Blue 0.14±0.04 0.04±0.04
3.5 COLOR UNIFORMITY (Target) at Default setting
100% white, ANSI 9 points
ExtremeCorner ∆x ±0.045, ∆y ±0.045 ∆x ±0.045, ∆y ±0.045
50% white, ANSI 9 points
ExtremeCorner ∆x ±0.045, ∆y ±0.045 ∆x ±0.045, ∆y ±0.045
(Note) ∆x, ∆y are the difference from the center point
Brightness, Contrast; Default setting
3.6 MISCONVERGENCE, FOCUS
(1) MISCONVERGENCE
1.0 pixel maximum at the center and top left, 1.2pixel others
(Note)
Misconvergence is the distance between G crosshatch lines and the other colors crosshatch lines
(2) FOCUS SHIFTS / FOCUS UNBALANCE / Flare (Screen Size 64”)
Test Condition : Image size 70 inches, Zoom : wide, Contrast and Bright at default setting
Observing distance; 1.8 m from screen (at the projector)
Test method ; Focus on the center of the image white letter E (H x W x ; 5 x 3 pixels, 1 pixel gap)
on black background.
Every letter E should be resolved in whole area of the image.

PJ-TX10W/E/W(AU) ver 1.1
10
3.7 DOT DEFECT
(1) SPECIFICATIONS
ITEM Max. NUMBER
Mode Color A-Zone B-zone Total Transmittance
Green 1 1 2 More than 10% See below *1
Sparkle Red 1 2 3
Blue * * 5
Green * * 5 Area
Black Red * * 5 More than 75 %
Blue * * 5
* ; not defined
• A sparkle mode defect and a faint sparkle mode defect
When a pixel is partially or completely transmittable during an entirely black raster.
• A black mode defect
When a pixel is partially or completely turned off during an entirely white raster.
• Transmittance
In case of a partial defect, the transmittance is average of a whole pixel transmittance.
• Line defect
There are no two or more continuous defects. (Sparkle mode)
There are no three or more continuous defects. ( Black mode)
*1 Sparkle mode
Use Dot pattern with brightness and contrast maximum.
(Make Dot pattern by 0.7Vp-p R,G, B on black (0Vp-p white) background.)
Sparkle mode is brighter than signal (0.7Vp-p white) dots with 10% ND filter.
(2) DEFINITION OF ZONE
B zone
A zone
1H
1V
V/4
V/2
H/4 H/2

PJ-TX10W/E/W(AU) ver 1.1
11
4. ELECTRICAL
4.1 VIDEO SIGNAL INPUT
(1) Composite
Amplitude 1.0 ± 0.1 Vp-p at 75 Ωterminated
Input impedance 75Ω
(2) S-VIDEO
Amplitude Y: 1.0 ± 0.1 Vp-p at 75 Ωterminated with composite sync
C: 0.3 ± 0.1 Vp-p at 75 Ωterminated
Input impedance 75Ω
(3) Component
Amplitude Y: 1.0 ± 0.1 Vp-p at 75 Ωterminated with composite sync
CB/PB,CR/PR: 0.7± 0.1 Vp-p at 75 Ωterminated
Input impedance 75 Ω
4.2 RGB SIGNAL INPUT
(1) Analog RGB
Amplitude 0.7 ± 0.1 Vp-p at 75 Ωterminated
Input impedance 75 Ω
(2) Sync. TTL level
(3) Computer compatibility
Resolution H x V Refresh Rate Horizontal Frequency Standard Type Note
640x480 59.9 Hz 31.5 kHz VESA VGA-3
640x480 66.7 Hz 35.0 kHz Mac 13"
640x480 72.8 Hz 37.9 kHz VESA
640x480 75.0 Hz 37.5 kHz VESA
640x480 85.0 Hz 43.3 kHz VESA
640x480 120.0Hz 61.8 kHz
800x600 56.3 Hz 35.2 kHz VESA
800x600 60.3 Hz 37.9 kHz VESA
800x600 72.2 Hz 48.1 kHz VESA
800x600 75.0 Hz 46.9 kHz VESA
800x600 85.1 Hz 53.7 kHz VESA
800x600 120.0 Hz 77.2kHz
832x624 74.5 Hz 49.7 kHz Mac 16"
848x480 60.0 Hz 31.1 kHz W VGA (60Hz)
1024x768 60.0 Hz 48.4 kHz VESA
1024x768 70.1 Hz 56.5 kHz VESA
1024x768 75.0 Hz 60.0 kHz VESA
1280x960 60.0 Hz 60.0 kHz VESA
1280x1024 60.0 Hz 64.0 kHz VESA
Note: SVGA/XGA /SXGA input signals shall be displayed but picture quality might be rude.

PJ-TX10W/E/W(AU) ver 1.1
12
4.3 AUDIO SIGNAL INPUT
Amplitude 200 mV rms
Input impedance 47K Ω
4.4 REMOTE CONTROL
Range with new battery
Front Front: 5.0m minimum ±30 ° (Horizontal, Vertical)

PJ-TX10W/E/W(AU) ver 1.1
13
5. PACKING
5.1 PACKAGING FORM
See Figure 5.1
Packaging materials; Plastic bag, cushion and carton box
ＷｘＨｘＤ 459x 333 x 401 mm (nominal)
Gross weight 7.6 kg
Pallet size 1223 x 1132 x 938 mm (W x H x D)
5.2 VIBRATION
There shall be no damage or change of performance out of this specification after the
following vibration test with factory fresh packing.
Vibration frequency 7 ~ 100 Hz 20 minutes per axis (10 minutes one way)
Acceleration Bottom 1.0G
Back 0.8G
Side 0.8G
Duration 2.5 hours (1.5h for Bottom, 0.5h for Back & Side)
5.3 DROP TEST
There shall be no damage or change of performance out of this specification after the
following drop test.
This test shall be done with factory fresh packing and the following sequence.
1. Surface 1 90 cm
2.Surface 2 90cm 4 6
3.Surface 4 90cm 3
4. Surface 5 90 cm
5. Surface 6 90 cm
6.Surface 3 90cm 5
7. Edge 1-2 90 cm ２
8. Edge 1-4 90 cm
9. Edge 1-5 90 cm
10. Edge 1-6 90 cm 1

PJ-TX10W/E/W(AU) ver 1.1
14
Figure 5.1
