Hitachi G900 Operating and maintenance manual

Hitachi Virtual Storage Platform G900
88-01-0x
Hardware Reference Guide
This document provides information about the system hardware components and the mechanical and
environmental specifications for the Hitachi Virtual Storage Platform G900 storage system.
MK-97HM85014-00
May 2018

© 2018 Hitachi, Ltd. All rights reserved.
No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including copying and
recording, or stored in a database or retrieval system for commercial purposes without the express written permission of Hitachi, Ltd., or
Hitachi Vantara Corporation (collectively “Hitachi”). Licensee may make copies of the Materials provided that any such copy is: (i) created as an
essential step in utilization of the Software as licensed and is used in no other manner; or (ii) used for archival purposes. Licensee may not
make any other copies of the Materials. “Materials” mean text, data, photographs, graphics, audio, video and documents.
Hitachi reserves the right to make changes to this Material at any time without notice and assumes no responsibility for its use. The Materials
contain the most current information available at the time of publication.
Some of the features described in the Materials might not be currently available. Refer to the most recent product announcement for
information about feature and product availability, or contact Hitachi Vantara Corporation at https://support.hitachivantara.com/en_us/contact-
us.html.
Notice: Hitachi products and services can be ordered only under the terms and conditions of the applicable Hitachi agreements. The use of
Hitachi products is governed by the terms of your agreements with Hitachi Vantara Corporation.
By using this software, you agree that you are responsible for:
1. Acquiring the relevant consents as may be required under local privacy laws or otherwise from authorized employees and other
individuals; and
2. Verifying that your data continues to be held, retrieved, deleted, or otherwise processed in accordance with relevant laws.
Notice on Export Controls. The technical data and technology inherent in this Document may be subject to U.S. export control laws, including
the U.S. Export Administration Act and its associated regulations, and may be subject to export or import regulations in other countries. Reader
agrees to comply strictly with all such regulations and acknowledges that Reader has the responsibility to obtain licenses to export, re-export, or
import the Document and any Compliant Products.
Hitachi is a registered trademark of Hitachi, Ltd., in the United States and other countries.
AIX, AS/400e, DB2, Domino, DS6000, DS8000, Enterprise Storage Server, eServer, FICON, FlashCopy, IBM, Lotus, MVS, OS/390, PowerPC, RS/6000,
S/390, System z9, System z10, Tivoli, z/OS, z9, z10, z13, z/VM, and z/VSE are registered trademarks or trademarks of International Business
Machines Corporation.
Active Directory, ActiveX, Bing, Excel, Hyper-V, Internet Explorer, the Internet Explorer logo, Microsoft, the Microsoft Corporate Logo, MS-DOS,
Outlook, PowerPoint, SharePoint, Silverlight, SmartScreen, SQL Server, Visual Basic, Visual C++, Visual Studio, Windows, the Windows logo,
Windows Azure, Windows PowerShell, Windows Server, the Windows start button, and Windows Vista are registered trademarks or trademarks
of Microsoft Corporation. Microsoft product screen shots are reprinted with permission from Microsoft Corporation.
iPad is a trademark of Apple Inc., registered in the U.S. and other countries.
All other trademarks, service marks, and company names in this document or website are properties of their respective owners.
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 2

Contents
Preface..................................................................................................... 7
Intended audience............................................................................................... 7
UEFI Development Kit 2010................................................................................ 7
Product version....................................................................................................8
Release notes......................................................................................................8
Document conventions........................................................................................ 8
Conventions for storage capacity values........................................................... 10
Accessing product documentation..................................................................... 11
Getting help........................................................................................................11
Comments..........................................................................................................11
Chapter 1: Overview ............................................................................ 12
Block configuration.............................................................................................12
Features.............................................................................................................12
Chapter 2: System controller ..............................................................14
CBL controller chassis....................................................................................... 14
CBL controller front panel bezel LEDs......................................................... 14
CBL controller front panel LEDs (without bezel).......................................... 16
CBL controller rear panel LEDs....................................................................18
CBL controller power supply unit LEDs and connectors.............................. 18
Host, Network, and Drive Tray Ports and LEDs.................................................19
Front end modules........................................................................................19
10-Gbps iSCSI board LEDs and connectors (optical).............................20
10-Gbps iSCSI board LEDs and connectors (copper)............................ 20
8-Gbps, 16-Gbps, or 32-Gbps Fibre Channel (4-port) board LEDs
and connectors........................................................................................22
16-Gbps Fibre Channel (2-port) board LEDs and connectors................ 24
PCIe module........................................................................................... 25
LAN blade LEDs and connectors................................................................. 27
Back-end module LEDs and connectors...................................................... 27
Chapter 3: Drive trays..........................................................................29
Small form-factor drive tray (DBS).....................................................................29
SFF with front panel bezel............................................................................29
Contents
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 3

SFF front panel without bezel.......................................................................30
SFF rear panel..............................................................................................31
AC power supply unit LEDs and connectors................................................ 32
Large form-factor drive tray (DBL)..................................................................... 33
LFF with front panel bezel............................................................................ 33
LFF front panel without bezel....................................................................... 34
LFF rear panel..............................................................................................35
AC power supply unit LEDs and connectors................................................ 36
Flash module drive tray (DBF)...........................................................................36
FMD with front panel bezel...........................................................................36
FMD front panel without bezel......................................................................37
FMD rear panel.............................................................................................39
High-density intermix drive tray (DB60)............................................................. 40
Dense intermix drive tray with front panel bezel...........................................40
Dense intermix drive tray display LEDs........................................................41
Dense intermix drive tray rear panel.............................................................42
Chapter 4: Host port expansion chassis............................................ 44
Host port expansion chassis front panel bezel LEDs........................................ 44
PCIe switchboard...............................................................................................44
Host port expansion chassis fan........................................................................45
PCIe cable connector........................................................................................ 46
Host port expansion chassis power supply........................................................47
Chapter 5: Service processor.............................................................. 49
Service Processor (Windows 10 Enterprise) hardware specifications...............49
Service processor description............................................................................50
SVP front panel............................................................................................ 51
SVP rear panel............................................................................................. 51
Chapter 6: Maintaining the storage system........................................53
Storing the storage system................................................................................ 53
Powering off the storage system........................................................................53
Battery unit.........................................................................................................54
Removing cables............................................................................................... 54
Appendix A: Storage system parts list............................................... 56
VSP G900 parts list............................................................................................56
Drive tray and drive configuration.................................................................61
Data and power cable model list........................................................................62
Appendix B: System Specifications ...................................................65
VSP G900 mechanical specifications................................................................ 65
Contents
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 4

Electrical specifications .....................................................................................71
Environmental specifications ............................................................................ 72
Shared memory................................................................................................. 81
Appendix C: Network access...............................................................84
TCP/IP port assignments...................................................................................84
Controller connections....................................................................................... 87
Physical service processor connections............................................................ 87
Appendix D: Data and power cables...................................................89
Required cables.................................................................................................89
Fibre Channel cables.........................................................................................91
iSCSI cables...................................................................................................... 94
iSCSI standards............................................................................................97
iSCSI specifications......................................................................................97
Managing cables..............................................................................................100
AC power cables..............................................................................................103
Power cable assemblies.............................................................................103
AC connections.......................................................................................... 105
Power cable usage guidelines....................................................................107
Three-phase power considerations for racks............................................. 107
Cable management.................................................................................... 107
Appendix E: Power distribution units for Hitachi Universal V2
Rack .....................................................................................................108
Americas single-phase PDU 1P30A-8C13-3C19UL.P.................................... 108
Americas single-phase PDU 1P30A-15C13-3C19UL.P.................................. 109
Americas three-phase PDU 3P30A-8C13-3C19UL.P......................................109
Americas three-phase PDU 3P30A-15C13-3C19UL.P.................................... 110
Americas three-phase PDU 3P30A-24C13-6C19UL.P.................................... 111
APAC and EMEA single-phase PDU 1P32A-9C13-3C19CE.P........................112
APAC and EMEA single-phase PDU 1P32A-18C13-3C19CE.P......................113
APAC and EMEA three-phase PDU 3P16A-9C13-3C19CE.P.........................114
APAC and EMEA three-phase PDU 3P16A-15C13-3C19CE.P.......................115
APAC and EMEA three-phase PDU 3P32A-24C13-6C19CE.P.......................116
Appendix F: Non-Hitachi racks..........................................................118
Non-Hitachi rack support .................................................................................118
Hitachi Universal V2 Rack rail kits................................................................... 118
Hitachi Universal V2 Rack accessories............................................................119
Third-party rack support for DB60 dense intermix drive trays..........................119
Contents
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 5

Appendix G: Warning labels on the storage system....................... 121
CBL controller.................................................................................................. 122
Small form factor drive tray..............................................................................123
Large form factor drive tray .............................................................................124
Flash module drive tray....................................................................................125
Dense intermix drive tray................................................................................. 126
CBL controller.................................................................................................. 127
Dense intermix drive tray power supply...........................................................127
CMA (used to secure dense intermix drive tray)..............................................128
Battery..............................................................................................................128
Host port expansion chassis............................................................................128
PCIe switch board............................................................................................129
Appendix H: Environmental notices................................................. 131
Appendix I: Regulatory compliance..................................................132
Contents
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 6

Preface
This guide describes the hardware features and specications of the Hitachi Virtual
Storage Platform G900.
Intended audience
This document is intended for system administrators, Hitachi Vantara representatives,
and authorized service providers who install, congure, and operate the VSP Gx00
models.
Readers of this document should be familiar with the following:
■Data processing and RAID storage systems and their basic functions.
■RAID storage system hardware components and operational specications
UEFI Development Kit 2010
This product includes UEFI Development Kit 2010 written by the UEFI Open Source
Community. For more information, see the UEFI Development Kit website:
http://sourceforge.net/apps/mediawiki/tianocore/index.php?title=UDK2010
© 2004, Intel Corporation.
All rights reserved.
Redistribution and use in source and binary forms, with or without modication, are
permitted provided that the following conditions are met:
Redistributions of source code must retain the above copyright notice, this list of
conditions and the following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.
Neither the name of the Intel Corporation nor the names of its contributors might be
used to endorse or promote products derived from this software without specic prior
written permission.
Preface
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 7

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS”
AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE
LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF
SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN
CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
Product version
This document revision applies to VSP G900 rmware 88-01-0x or later.
Release notes
Read the release notes before installing and using this product. They may contain
requirements or restrictions that are not fully described in this document or updates or
corrections to this document. Release notes are available on Hitachi Vantara Support
Connect: https://knowledge.hitachivantara.com/Documents.
Document conventions
This document uses the following storage system terminology conventions:
Convention Description
VSP Fx00 models Refers to all of the following models, unless otherwise noted.
■Hitachi Virtual Storage Platform F350
■Hitachi Virtual Storage Platform F370
■Hitachi Virtual Storage Platform F700
■Hitachi Virtual Storage Platform F900
VSP Gx00 models Refers to all of the following models, unless otherwise noted.
■Hitachi Virtual Storage Platform G350
■Hitachi Virtual Storage Platform G370
■Hitachi Virtual Storage Platform G700
■Hitachi Virtual Storage Platform G900
Product version
Preface
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 8

This document uses the following typographic conventions:
Convention Description
Bold ■Indicates text in a window, including window titles, menus,
menu options, buttons, elds, and labels. Example:
Click OK.
■Indicates emphasized words in list items.
Italic ■Indicates a document title or emphasized words in text.
■Indicates a variable, which is a placeholder for actual text
provided by the user or for output by the system. Example:
pairdisplay -g group
(For exceptions to this convention for variables, see the entry for
angle brackets.)
Monospace Indicates text that is displayed on screen or entered by the user.
Example: pairdisplay -g oradb
< > angle
brackets
Indicates variables in the following scenarios:
■Variables are not clearly separated from the surrounding text or
from other variables. Example:
Status-<report-name><file-version>.csv
■Variables in headings.
[ ] square
brackets
Indicates optional values. Example: [ a | b ] indicates that you can
choose a, b, or nothing.
{ } braces Indicates required or expected values. Example: { a | b } indicates
that you must choose either a or b.
| vertical bar Indicates that you have a choice between two or more options or
arguments. Examples:
[ a | b ] indicates that you can choose a, b, or nothing.
{ a | b } indicates that you must choose either a or b.
This document uses the following icons to draw attention to information:
Icon Label Description
Note Calls attention to important or additional information.
Document conventions
Preface
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 9

Icon Label Description
Tip Provides helpful information, guidelines, or suggestions for
performing tasks more eectively.
Caution Warns the user of adverse conditions and/or consequences
(for example, disruptive operations, data loss, or a system
crash).
WARNING Warns the user of a hazardous situation which, if not
avoided, could result in death or serious injury.
Conventions for storage capacity values
Physical storage capacity values (for example, disk drive capacity) are calculated based
on the following values:
Physical capacity unit Value
1 kilobyte (KB) 1,000 (103) bytes
1 megabyte (MB) 1,000 KB or 1,0002 bytes
1 gigabyte (GB) 1,000 MB or 1,0003 bytes
1 terabyte (TB) 1,000 GB or 1,0004 bytes
1 petabyte (PB) 1,000 TB or 1,0005 bytes
1 exabyte (EB) 1,000 PB or 1,0006 bytes
Logical capacity values (for example, logical device capacity, cache memory capacity) are
calculated based on the following values:
Logical capacity unit Value
1 block 512 bytes
1 cylinder Mainframe: 870 KB
Open-systems:
■OPEN-V: 960 KB
■Others: 720 KB
1 KB 1,024 (210) bytes
Conventions for storage capacity values
Preface
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 10

Logical capacity unit Value
1 MB 1,024 KB or 1,0242 bytes
1 GB 1,024 MB or 1,0243 bytes
1 TB 1,024 GB or 1,0244 bytes
1 PB 1,024 TB or 1,0245 bytes
1 EB 1,024 PB or 1,0246 bytes
Accessing product documentation
Product user documentation is available on Hitachi Vantara Support Connect: https://
knowledge.hitachivantara.com/Documents. Check this site for the most current
documentation, including important updates that may have been made after the release
of the product.
Getting help
Hitachi Vantara Support Connect is the destination for technical support of products and
solutions sold by Hitachi Vantara. To contact technical support, log on to Hitachi Vantara
Support Connect for contact information: https://support.hitachivantara.com/en_us/
contact-us.html.
Hitachi Vantara Community is a global online community for Hitachi Vantara customers,
partners, independent software vendors, employees, and prospects. It is the destination
to get answers, discover insights, and make connections. Join the conversation today!
Go to community.hitachivantara.com, register, and complete your prole.
Comments
Please send us your comments on this document to
[email protected]. Include the document title and number, including
the revision level (for example, -07), and refer to specic sections and paragraphs
whenever possible. All comments become the property of Hitachi Vantara Corporation.
Thank you!
Accessing product documentation
Preface
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 11

Chapter 1: Overview
The Hitachi Virtual Storage Platform G900 is a versatile modular, rack-mountable hybrid
array storage system equipped with drive boxes, supporting SAS drives, ash drives, and
TLC-NAND ash module drives, scaled for various storage capacity congurations.
The storage systems provide high performance operations by using dual controllers with
high-speed processors, dual in-line cache memory modules (DIMMs), cache ash
memory (CFM), battery, fans and ports to connect iSCSI and Fibre Channel I/O modules.
Each controller has an Ethernet connection for out-of-band management. If the data
path through one controller fails, all data drives remain available to hosts using a
redundant data path through the other controller.
For reliability, essential hardware components are implemented with a redundant
conguration so that the storage system can remain operational if a component fails.
Adding and replacing components, along with rmware upgrades, can be conducted
while the storage system is active and without interruption of data availability to the
hosts. A hot spare drive can be congured to replace a failed data drive automatically,
securing the fault-tolerant integrity of the logical drives. Self-contained, hardware-based
RAID logical drives provide maximum performance in compact external enclosures.
Block configuration
A storage system congured for block-level storage provides the ability to access and
provision raw storage volumes using protocols such as Fibre Channel and iSCSI.
A block conguration consists of the following:
■Two controllers
■One or more drive trays
■Optional service processor (SVP)
Features
All storage systems are highly reliable, versatile, and able to scale its performance by
adding more drive chassis and data drives. Depending on the system conguration, the
drive chassis oerings support SAS-interface disk, solid-state, and ash module drives.
Chapter 1: Overview
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 12

High performance
■Dual controller conguration distributes processing to each controller
■Equipped with high capacity cache to provide a total of 1,024 GB of high-speed
processing
■Flash drive conguration increases I/O processing speeds
■Equipped with 32/16-Gbps Fibre Channel or 10-Gbps iSCSI interface facilitates high-
speed data transfer
High reliability
■Main system components are congured with redundancy to maintain continued
service
■RAID 1, RAID 5, and RAID 6 support (RAID 6 including 14D+2P)
■Provides data security by transferring data to cache ash memory at the time of a
power outage
Scalability and versatility
■Small form-factor drive tray (DBS): Up to 24 2.5-inch HDDs or ash drives can be
installed (2U size)
■Large form-factor drive tray (DBL): Up to 12 3.5-inch HDDs can be installed (2U size)
■High-density intermix drive tray (DB60): Up to 60 3.5-inch HDDs can be installed (4U
size)
■Flash drive tray (DBF): Up to 12 ash module drives (FMD) can be installed (2U size)
■Supports system environments with mixed operating systems such as UNIX, Linux,
Windows, and VMware
Features
Chapter 1: Overview
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 13

Chapter 2: System controller
The storage systems are equipped with dual controllers for communicating with a data
host.
Each controller includes the following internal components such as a processor, dual in-
line cache memory modules (DIMMs), cache ash memory (CFM), battery, and fans. The
controller has an Ethernet connection for out-of-band management using Hitachi Device
Manager - Storage Navigator. If the data path through one controller fails, all drives
remain available to data hosts using a redundant data path through the other controller.
The controller is equipped with LED indicators for monitoring its operating conditions
and notifying possible component replacement.
CBL controller chassis
The controller chassis houses controllers, backup fan modules, and power supplies. The
chassis also includes specic functional LEDs located on the front and rear of controller
to provide its operating status.
The following table lists the controller board specications.
Component VSP G900
Chassis (4U) DW850-CBL
Controller board DW-F850-CTLH
Number of DIMM slot 8
Cache memory capacity 128 GiB to 512 GiB
Data encryption N/A
CBL controller front panel bezel LEDs
The following table describes the denitions of the CBL controller front panel bezel LEDs.
Chapter 2: System controller
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 14

Number Item Description
1 POWER LED Green: Storage system is
powered on.
Amber: Storage system is
receiving power.
2 READY LED Green: Normal operation.
3 WARNING LED O: Normal operation.
Amber: Component
requires maintenance.
Blink: Failure requires
maintenance.
Note: When System Option
Mode 1097 is set to ON,
the WARNING LED does not
blink, even if the following
failure service information
messages (SIM) are issued:
452xxx, 462xxx, 3077xx,
4100xx, and 410100.
LED might turn o during
user maintenance.
4 ALARM LED O: Normal operation.
Red: Processor failure
(system might be down).
For assistance, contact
customer support: https://
support.hitachivantara.com
/en_us/contact-us.html.
5 POWER ON/OFF (main
switch)
Powers the storage system.
CBL controller front panel bezel LEDs
Chapter 2: System controller
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 15

Number Item Description
6 Lock Locks and unlocks the front
panel bezel by using the
supplied key.
Note: Removing a controller can cause the POWER, READY, WARNING, and
ALARM LEDs on the front panel to turn o. These LEDs return to the on status
after the storage system recovers from the controller replacement.
CBL controller front panel LEDs (without bezel)
The following table describes the denitions of the CBL controller front panel LEDs.
Number Item Description
1 POWER ON/OFF (main
switch)
Powers the storage system.
2 POWER, READY, WARNING,
and ALARM LEDs
Note: When System Option
Mode 1097 is set to ON,
the WARNING LED does not
blink, even if the following
failure service information
messages (SIM) are issued:
452xxx, 462xxx, 3077xx,
4100xx, and 410100.
3 Controllers Controller 1 (bottom) and
Controller 2 (top).
4 Backup module N/A
CBL controller front panel LEDs (without bezel)
Chapter 2: System controller
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 16

Number Item Description
5 BACKUP LED Green: Power restoration in
progress following power
outage.
Fast blink green: Restoring.
Slow blink green: Restoring,
or sequential shutdown in
progress.
6 Cache ash memory N/A
7 ALM LED (for cache ash
memory)
Red: Cache ash memory
can be removed.
8 CTL ALM LED Red: Controller can be
removed.
Blink red: Failure with the
power supply unit of the
controller.
Amber: LAN reset switch
was pressed.
9 LAN-RST switch Use only when instructed
by customer support.
10 STATUS LED (for BKMF) Green: Charging of the
battery in the backup
module is complete.
Red: Backup module can
be removed.
Blink red one time: Main
battery failure.
Blink red two times:
Backup battery failure.
Blink red three times: Both
batteries failed or
preventive maintenance
replacement of batteries
can run.
CBL controller front panel LEDs (without bezel)
Chapter 2: System controller
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 17

Number Item Description
O: Battery is not
mounted, battery-
mounting failure occurred,
or rmware is being
upgraded. O is normal
status for congurations
without batteries (for
example, BKMF-10 and
BKMF-20).
CBL controller rear panel LEDs
The following table describes the denitions of the CBL controller rear panel LEDs.
Number Item
1 Power supply unit
2 Front end module
3 Back end module
4 LAN blade
CBL controller power supply unit LEDs and connectors
The following table lists the denitions of the CBL controller power supply unit LEDs and
connectors.
CBL controller rear panel LEDs
Chapter 2: System controller
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 18

Number Item Description
1 ALM / RDY LED Red: Power supply unit can
be replaced.
2 Receptacle Connects to the power
cable provided with the
storage system.
3 RDY LED Green: Normal operation.
Host, Network, and Drive Tray Ports and LEDs
The controllers are equipped with specic interfaces for connecting, powering,
conguring, and managing the storage system. The component LEDs display the
operating status of the storage system.
Front end modules
The following front end modules are available for the controllers. The LEDs display the
operating status of the module.
Host, Network, and Drive Tray Ports and LEDs
Chapter 2: System controller
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 19

10-Gbps iSCSI board LEDs and connectors (optical)
Number Item Description
1 STATUS LED Green: Front end module is
in the power-on state.
Red: Front end module can
be removed safely.
2 PORT LED Red: Small form factor
pluggable can be removed.
Blue: Normal link status.
Blink blue: Front end
module is in
communication status.
3 iSCSI connectors Connect to Ethernet cables.
10-Gbps iSCSI board LEDs and connectors (copper)
10-Gbps iSCSI board LEDs and connectors (optical)
Chapter 2: System controller
Hitachi Virtual Storage Platform G900 Hardware Reference Guide 20
