Hitachi T7K250 - Deskstar - Hard Drive User manual

Hard Disk Drive Specification
Deskstar T7K250
3.5 inch Ultra ATA/133 hard disk drive
3.5 inch Serial ATA hard disk drive
Models:
HDT722516DLAT80 HDT722516DLA380
HDT722525DLAT80 HDT722525DLA380
HDT722520DLAT80 HDT722520DLA380
Version 1.8 12 September 2006

Hard Disk Drive Specification
Deskstar T7K250
3.5 inch Ultra ATA/133 hard disk drive
3.5 inch Serial ATA hard disk drive
Models:
HDT722516DLAT80 HDT722516DLA380
HDT722525DLAT80 HDT722525DLA380
HDT722520DLAT80 HDT722520DLA380
Version 1.8 12 September 2006

1st Edition (Revision 0.1) (25 January 2005) Preliminary
2nd Edition (Revision 1.0) (27 January 2005) Revised
3rd Edition (Revision 1.1) (20 May 2005) Revised
4th Edition (Revision 1.2) (02 June 2005) Revised
5th Edition (Revision 1.3) (14 June 2005) Revised
6th Edition (Revision 1.4)(22 June 2005) Revised
7th Edition (Revision 1.5)(21 September 2005) Revised
8th Edition (Revision 1.6) (10 November 2005) Revised
9th Edition (Revision 1.7)(04 May 2006) Revised
10th Edition (Revision 1.8)( 12 September 2006) Final
The following paragraph does not apply to the United Kingdom or any country where such provisions are
inconsistent with local law: HITACHI GLOBAL STORAGE TECHNOLOGIES PROVIDES THIS PUBLI-
CATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUD-
ING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer or express or implied warranties in
certain transactions, therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the
information herein; these changes will be incorporated in new editions of the publication. Hitachi may make
improvements or changes in any products or programs described in this publication at any time.
It is possible that this publication may contain reference to, or information about, Hitachi products (machines and
programs), programming, or services that are not announced in your country. Such references or information must not
be construed to mean that Hitachi intends to announce such Hitachi products, programming, or services in your coun-
try.
Technical information about this product is available by contacting your local Hitachi Global Storage Technologies
representative or on the Internet at
http://www.hitachigst.com
Hitachi Global Storage Technologies may have patents or pending patent applications covering subject matter in this
document. The furnishing of this document does not give you any license to these patents. ©Copyright Hitachi Glo-
bal Storage Technologies
Note to U.S. Government Users - Documentation related subject to restricted rights - Use, duplication or disclosure is
subject to restrictions set forth in GSA ADP Schedule Contract with Hitachi Global Storage Technologies Inc.

Table Of Contents
1.0 General................................................................................................................1
1.1 Introduction..............................................................................................1
1.2 References................................................................................................1
1.3 Abbreviations...........................................................................................1
1.4 Caution.....................................................................................................3
2.0 General features of the drive ............................................................................5
3.0 Fixed-disk subsystem description.....................................................................9
3.1 Control electronics...................................................................................9
3.2 Head disk assembly ................................................................................9
3.3 Actuator ...................................................................................................9
4.0 Drive characteristics..........................................................................................11
4.1 Default logical drive parameters..............................................................11
4.2 Data sheet.................................................................................................11
4.3 World Wide Name Assignment...............................................................12
4.4 Drive organization ...................................................................................13
4.4.1 Drive format....................................................................................13
4.4.2 Cylinder allocation..........................................................................13
4.5 Performance characteristics.....................................................................15
4.5.1 Command overhead........................................................................15
4.5.2 Mechanical positioning...................................................................15
4.5.3 Drive ready time .............................................................................17
4.5.4 Data transfer speed..........................................................................18
4.5.5 Throughput......................................................................................19
4.5.6 Operating modes.............................................................................20
5.0 Defect flagging strategy.....................................................................................21
6.0 Electrical interface specification.......................................................................23
6.1 Connector location...................................................................................23
6.1.1 DC power connector.......................................................................24
6.1.2 AT signal connector........................................................................24
6.2 Signal definitions(PATA model).............................................................25
6.3 Signal descriptions...................................................................................26
6.4 Interface logic signal levels(PATA model) .............................................29
6.5 Signal definition (SATA model)..............................................................29
6.5.1 TX+ / TX-.......................................................................................30
6.5.2 RX+ / RX-.......................................................................................30

6.6 Out of band signaling (SATA model)......................................................30
6.7 Reset timings............................................................................................31
6.8 PIO timings..............................................................................................32
6.8.1 Write DRQ interval time.................................................................32
6.8.2 Read DRQ interval time .................................................................33
6.9 Multi word DMA timings........................................................................34
6.10 Ultra DMA timings................................................................................35
6.10.1 Initiating Read DMA ....................................................................35
6.10.2 Host Pausing Read DMA..............................................................36
6.10.3 Host Terminating Read DMA.......................................................37
6.10.4 Device Terminating Read DMA...................................................38
6.10.5 Initiating Write DMA ...................................................................39
6.10.6 Device Pausing Write DMA.........................................................40
6.10.7 Device Terminating Write DMA..................................................41
6.10.8 Host Terminating Write DMA......................................................42
6.11 Addressing of registers ..........................................................................43
6.11.1 Cabling..........................................................................................43
7.0 Specification .......................................................................................................47
7.1 Jumper settings ........................................................................................47
7.1.1 Jumper pin location.........................................................................47
7.1.2 Jumper pin identification ................................................................47
7.1.3 Jumper pin assignment....................................................................48
7.1.4 Jumper positions .............................................................................49
7.2 Environment.............................................................................................53
7.2.1 Temperature and humidity..............................................................53
7.2.2 Corrosion test..................................................................................54
7.3 DC power requirements...........................................................................54
7.3.1 Input voltage ...................................................................................54
7.3.2 Power supply current (typical)........................................................55
7.3.3 Power supply generated ripple at drive power connector...............56
7.4 Reliability.................................................................................................57
7.4.1 Data integrity ..................................................................................57
7.4.2 Cable noise interference..................................................................57
7.4.3 Start/stop cycles..............................................................................57
7.4.4 Preventive maintenance..................................................................57
7.4.5 Data reliability ................................................................................57
7.4.6 Required power-off sequence.........................................................57
7.5 Mechanical specifications........................................................................58
7.5.1 Physical dimensions and weight.....................................................58
7.5.2 Mounting hole locations .................................................................59
7.5.3 Connector locations ........................................................................60
7.5.4 Drive mounting...............................................................................60
7.5.5 Heads unload and actuator lock......................................................61
7.6 Vibration and shock.................................................................................62
7.6.1 Operating vibration.........................................................................62

7.6.2 Nonoperating vibration...................................................................62
7.6.3 Operating shock..............................................................................63
7.6.4 Nonoperating shock........................................................................63
7.6.5 Nonoperating rotational shock........................................................64
7.7 Acoustics..................................................................................................65
7.8 Identification labels..................................................................................65
7.9 Safety .......................................................................................................66
7.9.1 UL and CSA approval.....................................................................66
7.9.2 German safety mark........................................................................66
7.9.3 Flammability...................................................................................66
7.9.4 Safe handling ..................................................................................66
7.9.5 Environment....................................................................................66
7.9.6 Secondary circuit protection...........................................................66
7.10 Electromagnetic compatibility...............................................................67
7.10.1 CE mark........................................................................................67
7.10.2 C-TICK mark................................................................................67
7.10.3 BSMI mark ...................................................................................67
7.11 Packaging...............................................................................................67
8.0 General................................................................................................................69
8.1 Introduction..............................................................................................69
8.2 Terminology.............................................................................................69
8.3 Deviations from standard.........................................................................69
9.0 Registers..............................................................................................................71
9.1 Register set...............................................................................................71
9.2 Alternate Status Register .........................................................................72
9.3 Command Register ..................................................................................72
9.4 Cylinder High Register............................................................................72
9.5 Cylinder Low Register.............................................................................72
9.6 Data Register............................................................................................73
9.7 Device Control Register..........................................................................73
9.8 Drive Address Register............................................................................74
9.9 Device/Head Register ..............................................................................74
9.10 Error Register.........................................................................................75
9.11 Features Register....................................................................................75
9.12 Sector Count Register............................................................................75
9.13 Sector Number Register.........................................................................76
9.14 Status Register .......................................................................................76
10.0 General operation............................................................................................79
10.1 Reset response........................................................................................79
10.2 Register initialization.............................................................................80
10.3 Diagnostic and Reset considerations .....................................................81
10.4 Sector Addressing Mode........................................................................82

10.4.1 Logical CHS addressing mode .....................................................82
10.4.2 LBA addressing mode ..................................................................82
10.5 Overlapped and queued feature .............................................................82
10.6 Power management features..................................................................84
10.6.1 Power mode ..................................................................................84
10.6.2 Power management commands ....................................................84
10.6.3 Standby timer................................................................................84
10.6.4 Interface capability for power modes ...........................................85
10.7 S.M.A.R.T. Function .............................................................................86
10.7.1 Attributes ......................................................................................86
10.7.2 Attribute values.............................................................................86
10.7.3 Attribute thresholds.......................................................................86
10.7.4 Threshold exceeded condition ......................................................86
10.7.5 S.M.A.R.T. commands .................................................................86
10.7.6 Off-line read scanning ..................................................................86
10.7.7 Error log........................................................................................87
10.7.8 Self-test.........................................................................................87
10.8 Security Mode Feature Set.....................................................................88
10.8.1 Security mode ...............................................................................88
10.8.2 Security level ................................................................................88
10.8.3 Passwords......................................................................................89
10.8.4 Operation example........................................................................89
10.8.5 Command table.............................................................................92
10.9 Host Protected Area Feature..................................................................93
10.9.1 Example for operation (In LBA Mode)........................................93
10.9.2 Security extensions .......................................................................94
10.10 Seek overlap.........................................................................................95
10.11 Write cache function............................................................................96
10.12 Reassign function.................................................................................97
10.12.1 Auto Reassign function...............................................................97
10.13 Power-Up in Standby feature set .........................................................98
10.14 Advanced Power Management feature set (APM) ..............................99
10.15 Automatic Acoustic Management feature set (AAM).........................100
10.16 Address Offset Feature ........................................................................101
10.16.1 Enable/Disable Address Offset Mode.........................................101
10.16.2 Identify Device Data...................................................................102
10.16.3 Exceptions in Address Offset Mode..........................................102
10.17 48-bit Address Feature Set...................................................................103
10.18 Streaming Feature Set..........................................................................103
10.18.1 Streaming commands..................................................................104
11.0 Command protocol ..........................................................................................107
11.1 PIO Data In commands..........................................................................107
11.2 PIO Data Out Commands ......................................................................108
11.3 Non-data commands .............................................................................110
11.4 DMA commands....................................................................................111

11.5 DMA queued commands .......................................................................112
12.0 Command descriptions....................................................................................113
12.1 Check Power Mode (E5h/98h) ..............................................................117
12.2 Device Configuration Overlay (B1h) ....................................................118
12.2.1 DEVICE CONFIGURATION RESTORE..................................118
12.2.2 DEVICE CONFIGURATION FREEZE LOCK (subcommand C1h)118
12.2.3 DEVICE CONFIGURATION IDENTIFY (subcommand C2h).119
12.2.4 DEVICE CONFIGURATION SET (subcommand C3h).............119
12.3 Execute Device Diagnostic (90h) ..........................................................122
12.4 Flush Cache (E7h) .................................................................................123
12.5 Flush Cache Ext (EAh)..........................................................................124
12.6 Format Track (50h)................................................................................125
12.7 Format Unit (F7h)..................................................................................126
12.8 Identify Device (ECh)............................................................................127
12.9 Idle (E3h/97h).......................................................................................135
12.10 Idle Immediate (E1h/95h)....................................................................136
12.11 Initialize Device Parameters (91h) ......................................................137
12.12 NOP (00h)............................................................................................138
12.13 Read Buffer (E4h)................................................................................139
12.14 Read DMA (C8h/C9h).........................................................................140
12.15 Read DMA Ext (25h)...........................................................................142
12.16 Read DMA Queued (C7h)...................................................................144
12.17 Read DMA Queued Ext (26h) .............................................................146
12.18 Read Log Ext (2Fh) .............................................................................148
12.18.1 General Purpose Log Directory..................................................149
12.18.2 Extended Comprehensive SMART Error Log............................150
12.18.3 Extended Self-test log sector ......................................................152
12.19 Read Long (22h/23h)...........................................................................154
12.20 Read Multiple (C4h)............................................................................156
12.21 Read Multiple Ext (29h) ......................................................................158
12.22 Read Native Max ADDRESS (F8h)....................................................160
12.23 Read Native Max Address Ext (27h)...................................................161
12.24 Read Sectors (20h/21h)........................................................................162
12.25 Read Sector(s) Ext (24h)......................................................................164
12.26 Read Stream DMA Ext (2Ah) .............................................................166
12.27 Read Stream PIO (2Bh).......................................................................169
12.28 Read Verify Sectors (40h/41h) ............................................................172
12.29 Read Verify Sector(s) (42h).................................................................174
12.30 Recalibrate (1xh)..................................................................................176
12.31 Security Disable Password (F6h).........................................................177
12.32 Security Disable Password (F3h).........................................................178
12.33 Security Erase Unit (F4h) ....................................................................179
12.34 Security Freeze Lock (F5h) .................................................................181
12.35 Security Set Password (F1h)................................................................182
12.36 Security Unlock (F2h) .........................................................................184

12.37 Seek (7xh)...........................................................................................185
12.38 Service (A2h ........................................................................................)186
12.39 Set Features (EFh) ...............................................................................187
12.39.1 Set Transfer mode.......................................................................188
12.39.2 Write Cache ................................................................................188
12.39.3 Advanced Power Management...................................................188
12.39.4 Automatic Acoustic Management ..............................................189
12.40 Set Max ADDRESS (F9h)...................................................................190
12.40.1 Set Max Set Password (Feature=01h).........................................192
12.40.2 Set Max Lock (Feature=02h)......................................................193
12.40.3 Set Max Unlock (Feature = 03h) ................................................194
12.40.4 Set Max Freeze Lock (Feature = 04h) ........................................195
12.41 Set Max Address Ext (37h)..................................................................196
12.42 Sleep (E6h/99h) ...................................................................................198
12.43 S.M.A.R.T. Function Set (B0h)...........................................................199
12.43.1 S.M.A.R.T. Function Subcommands.........................................199
12.43.2 Device Attribute Data Structure .................................................203
12.43.3 Device Attribute Thresholds data structure ................................206
12.43.4 S.M.A.R.T. Log Directory..........................................................208
12.43.5 S.M.A.R.T. summary error log sector ........................................208
12.43.6 Self-test log data structure .........................................................210
12.43.7 Error reporting ............................................................................211
12.44 Standby (E2h/96h)...............................................................................212
12.45 Standby Immediate (E0h/94h).............................................................213
12.46 Write Buffer (E8h)...............................................................................214
12.47 Write DMA Queued (CAh/CBh).........................................................215
12.48 Write DMA FUA Ext (3Dh)................................................................217
12.49 Write DMA Ext (35h)..........................................................................219
12.50 Write FPDMA Queued (61h) ..............................................................221
12.51 Write Log Ext (3Fh) ............................................................................223
12.52 Write Long (32h/33h)..........................................................................224
12.53 Write Multiple (C5h) ...........................................................................226
12.54 Write Multiple Ext (39h) .....................................................................227
12.55 Write Multiple FUA Ext (CEh) ...........................................................229
12.56 Write Sectors (30h/31h).......................................................................231
12.57 Write Sector(s) (34h) ...........................................................................233
12.58 Write Stream DMA (3Ah)...................................................................235
12.59 Write Stream PIO (3Bh) ......................................................................238
13.0 Time-out values................................................................................................241

List of Tables
Table 1.Mechanical positioning performance ...........................................................11
Table 2.Cylinder allocation........................................................................................13
Table 3.Command overhead......................................................................................15
Table 4.Mechanical positioning performance ...........................................................15
Table 5.Full stroke seek time.....................................................................................16
Table 6.Head switch time ..........................................................................................16
Table 7.Single track seek time...................................................................................17
Table 8.Latency Time................................................................................................17
Table 9.Drive ready time ...........................................................................................17
Table 10.Data transfer speed .....................................................................................18
Table 11.Simple Sequential Access performance......................................................19
Table 12.Random Access Performance.....................................................................19
Table 13.Description of operating modes..................................................................20
Table 14.Mode transition time...................................................................................20
Table 15.Plist physical format ...................................................................................21
Table 16.Signal definitions........................................................................................25
Table 17.Special signal definitions for Ultra DMA...................................................26
Table 18.System reset timing chart............................................................................31
Table 19.System reset timing.....................................................................................31
Table 20.Ultra DMA cycle timing chart (Host pausing Read)..................................36
Table 21.Ultra DMA cycle timings (Host pausing Read) .........................................36
Table 22.Ultra DMA cycle timing chart (Host terminating Read)............................37
Table 23.Ultra DMA cycle timings (Host Terminating Read)..................................37
Table 24.Ultra DMA cycle timing chart (Device terminating Read) ........................38
Table 25.Ultra DMA cycle timings (Device Terminating Read) ..............................38
Table 26.Ultra DMA cycle timing chart (Initiating Write) .......................................39
Table 27.Ultra DMA cycle timings (Initiating Write)...............................................39
Table 28.Ultra DMA cycle timing chart (Device Pausing Write).............................40
Table 29.Ultra DMA cycle timing chart (Device Pausing Write).............................40
Table 30.Ultra DMA cycle timing chart (Device Terminating Write)......................41
Table 31.Ultra DMA cycle timings (Device terminating Write)...............................41
Table 32.Ultra DMA cycle timing chart (Host Terminating Write)..........................42
Table 33.Ultra DMA cycle timings (Host Terminating Write) .................................42
Table 34.I/O address map..........................................................................................43
Table 35.Temperature and humidity..........................................................................53
Table 36.Input voltage...............................................................................................54
Table 37.Power supply current of xxx-GB models ...................................................55
Table 38.Power supply generated ripple at drive power connector...........................56
Table 39.Random vibration PSD profile break points (operating)............................62
Table 40.Random Vibration PSD profile breakpoints (nonoperating)......................62
Table 41.Sinusoidal shock wave................................................................................64

Table 42.Rotational shock .......................................................................................64
Table 43.Sound power levels.....................................................................................65
Table 44.Sound power levels.....................................................................................65
Table 45.Register Set.................................................................................................71
Table 46.Alternate Status Register ............................................................................72
Table 47.Device Control Register .............................................................................73
Table 48.Drive Address Register...............................................................................74
Table 49.Device Head/Register.................................................................................74
Table 50.Error Register..............................................................................................75
Table 51.Status Register ............................................................................................76
Table 52.Reset response table....................................................................................79
Table 53.Default Register Values..............................................................................80
Table 54.Diagnostic codes.........................................................................................80
Table 55.Reset error register values ..........................................................................81
Table 56.Power conditions ........................................................................................85
Table 57.Command table for device lock operation..................................................92
Table 58.Command Set (1 of 2).................................................................................113
Table 59.Command Set (2 of 2).................................................................................114
Table 60.Command Set (subcommand).....................................................................115
Table 61.Check Power Mode command (E5h/98h)...................................................117
Table 62.Check Power Mode Command (E5h/98h)..................................................118
Table 63.Device Configuration Overlay Features register values.............................118
Table 64.Device Configuration Overlay Data structure............................................120
Table 65.DCO error information definition...............................................................121
Table 66.Execute Device Diagnostic command (90h) ..............................................122
Table 67.Flush Cache command (E7h)......................................................................123
Table 68.Flush Cache Ext Command (EAh) .............................................................124
Table 69.Format Track command (50h)....................................................................125
Table 70.Format Unit command (F7h)......................................................................126
Table 71.Identify Device command (ECh)................................................................127
Table 72.Identify device information (Part 1 of 7)....................................................128
Table 73.Identify device information (Part 2 of 7)...................................................129
Table 74.Identify device information (Part 3 of 7)....................................................130
Table 75.Identify device information (Part 4 of 7)....................................................131
Table 76.Identify device information (Part 5 of 7 .....................................................132
Table 77.Identify device information (Part 6 of 7)....................................................133
Table 78.Identify device information (Part 7 of 7)....................................................134
Table 79.Idle command (E3h/97h)............................................................................135
Table 80.Idle Immediate command (E1h/95h)..........................................................136
Table 81.Initialize Device Parameters command (91h).............................................137
Table 82.NOP Command (00h).................................................................................138
Table 83.Read Buffer (E4h).......................................................................................139
Table 84.Read DMA command (C8h/C9h)...............................................................140
Table 85.Read DMA Ext Command (25h)................................................................142
Table 86.Read DMA command (C8h/C9h)...............................................................144
Table 87.Read DMA Ext Command (25h)................................................................146

Table 88.Read Log Ext Command (2Fh)...................................................................148
Table 89.Log Address Definition ..............................................................................149
Table 90.General Purpose Log Directory..................................................................149
Table 91.Extended Comprehensive SMART Error Log ...........................................150
Table 92.Extended Error log data structure...............................................................150
Table 93.Command data structure.............................................................................151
Table 94.Error data structure .....................................................................................151
Table 95.Read Long (22h/23h)..................................................................................154
Table 96.Read Multiple (C4h)...................................................................................156
Table 97.Read DMA Ext Command (25h)................................................................158
Table 98.Read Native Max ADDRESS (F8h)...........................................................160
Table 99.Read Native Max Address Ext command (27h).........................................161
Table 100.Read Sectors Command (20h/21h)...........................................................162
Table 101.Read Sector(s) Ext command (24h).........................................................164
Table 102.Read Verify Sectors (40h/41h).................................................................172
Table 103.Read Verify Sector(s) command (42h).....................................................174
Table 104.Recalibrate (1xh) ......................................................................................176
Table 105.Security Disable Password (F6h)..............................................................177
Table 106.Password Information for Security Disable Password command.............177
Table 107.Security Disable Password (F3h)..............................................................178
Table 108.Security Erase Unit (F4h).........................................................................179
Table 109.Erase Unit information .............................................................................179
Table 110.Security Freeze Lock command (F5h) .....................................................181
Table 111.Security Set Password command (F1h)....................................................182
Table 112.Security Set Password Information ..........................................................182
Table 113.Security Unlock command (F2h)..............................................................184
Table 114.Seek command (7xh)................................................................................185
Table 115.Service command (A2h)...........................................................................186
Table 116.Set Features command (EFh)....................................................................187
Table 117.Set Max ADDRESS command (F9h).......................................................190
Table 118.Set Max Set Password command..............................................................192
Table 119.Set Max Set Password data contents ........................................................192
Table 120.Set Max Lock command...........................................................................193
Table 121.Set Max Unlock command (F9h) .............................................................194
Table 122.Set Max Freeze Lock (F9h)......................................................................195
Table 123.Set Max Address Ext command (37h)......................................................196
Table 124.Sleep command (E6h/99h) .......................................................................198
Table 125.S.M.A.R.T. Function Set command (B0h)...............................................199
Table 126.Device Attribute Data Structure ...............................................................203
Table 127.Individual Attribute Data Structure ..........................................................203
Table 128.Device Attribute Thresholds Data Structure.............................................207
Table 129.Individual Threshold Data Structure ........................................................207
Table 130.S.M.A.R.T. Log Directory........................................................................208
Table 131.S.M.A.R.T. summary error log sector ....................................................208
Table 132.Error log data structure............................................................................209
Table 133.Command data structure...........................................................................209

Table 134.Error data structure ...................................................................................209
Table 135.Self-test log data structure ........................................................................210
Table 136.S.M.A.R.T. Error Codes...........................................................................211
Table 137.Standby (E2h/96h)....................................................................................212
Table 138.Standby Immediate (E0h/94h)..................................................................213
Table 139.Write Buffer (E8h)....................................................................................214
Table 140.Write DMA Queued Command CAh/CBh) .............................................215
Table 141.Write Sectors command (30h/31h)...........................................................231
Table 142.Write Sector(s) Command (34h) .............................................................233

Deskstar T7K250 Hard Disk Drive Specification
1
1.0 General
1.1 Introduction
This document describes the specifications of the Deskstar T7K250, a 3.5-inch hard disk drive with ATA interface
and a rotational speed of 7200 RPM.
*Default setting is 1.5Gbps
These specifications are subject to change without notice.
1.2 References
• Information Technology - AT Attachment with Packet Interface-7.
• Serial ATA II: Extensions to Serial ATA 1.0
1.3 Abbreviations
Abbreviation Meaning
AAmpere
AC alternating current
AT Advanced Technology
ATA Advanced Technology Attachment
BIOS Basic Input/Output System
C Celsius
CSA Canadian Standards Association
C-UL Canadian-Underwriters Laboratory
Cyl cylinder
DC Direct Current
DFT Drive Fitness Test
DMA Direct Memory Access
ECC error correction code
EEC European Economic Community
EMC electromagnetic compatibility
ERP Error Recovery Procedure
ESD Electrostatic Discharge
HDT722516DLAT80 160.0 GB
HDT722520DLAT80 200 GB
HDT722525DLAT80 250.0 GB
HDT722516DLA380 160.0 GB (3Gbps*)
HDT722520DLA380 200 GB (3Gbps*)
HDT722525DLA380 250.0 GB (3Gbps*)

Deskstar T7K250 Hard Disk Drive Specification
2
FCC Federal Communications Commission
FRU field replacement unit
G gravity (a unit of force)
G
2
/Hz (32 ft/sec)
2
per Hertz
Gb 1,000,000,000 bits
GB 1,000,000,000 bytes
GND ground
h hexadecimal
HDD hard disk drive
Hz Hertz
I Input
ILS integrated lead suspension
I/O Input/Output
ISO International Standards Organization
KB 1,000 bytes
Kbpi 1000 bits per inch
kgf-cm kilogram (force)-centimeter
KHz kilohertz
LBA logical block addressing
Lw unit of A-weighted sound power
mmeter
max maximum
MB 1,000,000 bytes
Mbps 1,000,000 bits per second
MHz megahertz
MLC Machine Level Control
mm millimeter
ms millisecond
us, ms microsecond
OOutput
OD Open Drain Programmed Input/Output
PIO
POH power on hours
Pop population
P/N part number
p-p peak-to-peak
PSD power spectral density
RES radiated electromagnetic susceptibility
RFI radio frequency interference
RH relative humidity
RMS root mean square
RPM revolutions per minute
RST reset

Deskstar T7K250 Hard Disk Drive Specification
3
R/W read/write
sec second
SELV secondary low voltage
S.M.A.R.TSelf-Monitoring, Analysis, and Reporting Technology
TPI tracks per inch
Trk track
TTL transistor-transistor logic
UL Underwriters Laboratory
Vvolt
VDE Verband Deutscher Electrotechniker
Wwatt
3-state transistor-transistor tristate logic
1.4 Caution
• Do not apply force to the top cover.
• Do not cover the breathing hole on the top cover.
• Do not touch the interface connector pins or the surface of the printed circuit board
• This drive can be damaged by electrostatic discharge (ESD). Any damages incurred to the drive after its
removal from the shipping package and the ESD protective bag are the responsibility of the user.

Deskstar T7K250 Hard Disk Drive Specification
4

Deskstar T7K250 Hard Disk Drive specification
5
2.0 General features of the drive
• Formatted capacities of 160 GB, 200 GB, 250 GB
• Spindle speeds of 7200 RPM
• Fluid Dynamic Bearing motor
• Enhanced IDE interface
• Sector format of 512 bytes/sector
• Closed-loop actuator servo
• Load/Unload mechanism, non head disk contact start/stop
• Automatic Actuator lock
• Interleave factor 1:1
• Seek time of 8.2 ms typical without Command Overhead
• Sector Buffer size of 2048 KB and 8192 KB (Upper 260 KB is used for firmware)
• Ring buffer implementation
• Write Cache
• Queued feature support
• Advanced ECC On The Fly (EOF)
• Automatic Error Recovery procedures for read and write commands
• Self Diagnostics on Power on and resident diagnostics
• Parallel ATA PIO Register/Data Transfer Mode 4 (16.6 MB/sec)
• Parallel ATA DMA Data Transfer
• Multiword mode Mode 2 (16.6 MB/s)
• Ultra DMA Mode 6 (133 MB/s)
• Serial ATA Data Transfer 3Gbps/1.5Gbps
• CHS and LBA mode
• Power saving modes/Low RPM idle mode (APM)
• S.M.A.R.T. (Self Monitoring and Analysis Reporting Technology)
• Support security feature
• Quiet Seek mode (AAM)
• 48-bit addressing feature
• ATA-7 compliant
• UDMA 133 support
• Streaming feature set support
• World Wide Name

Deskstar T7K250 Hard Disk Drive Specification
6
