Hitachi Virtual Storage Platform E Series User manual

Hitachi Virtual Storage Platform E Series
Hitachi Virtual Storage Platform G130,
G/F350, G/F370, G/F700, G/F900
SVOS RF 9.5.1
SIM Reference Guide
This document describes the service information messages (SIMs) issued by Hitachi Virtual Storage
Platform E series and Hitachi Virtual Storage Platform G130, G/F350, G/F370, G/F700, G/F900, provides
instructions for handling SIMs, and provides lists of the SIM codes for troubleshooting by users and
service personnel.
MK-97HM85023-09
December 2020

© 2018, 2020 Hitachi, Ltd. All rights reserved.
No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including copying and
recording, or stored in a database or retrieval system for commercial purposes without the express written permission of Hitachi, Ltd., or
Hitachi Vantara LLC (collectively “Hitachi”). Licensee may make copies of the Materials provided that any such copy is: (i) created as an essential
step in utilization of the Software as licensed and is used in no other manner; or (ii) used for archival purposes. Licensee may not make any
other copies of the Materials. “Materials” mean text, data, photographs, graphics, audio, video and documents.
Hitachi reserves the right to make changes to this Material at any time without notice and assumes no responsibility for its use. The Materials
contain the most current information available at the time of publication.
Some of the features described in the Materials might not be currently available. Refer to the most recent product announcement for
information about feature and product availability, or contact Hitachi Vantara LLC at https://support.hitachivantara.com/en_us/contact-us.html.
Notice: Hitachi products and services can be ordered only under the terms and conditions of the applicable Hitachi agreements. The use of
Hitachi products is governed by the terms of your agreements with Hitachi Vantara LLC.
By using this software, you agree that you are responsible for:
1. Acquiring the relevant consents as may be required under local privacy laws or otherwise from authorized employees and other
individuals; and
2. Verifying that your data continues to be held, retrieved, deleted, or otherwise processed in accordance with relevant laws.
Notice on Export Controls. The technical data and technology inherent in this Document may be subject to U.S. export control laws, including
the U.S. Export Administration Act and its associated regulations, and may be subject to export or import regulations in other countries. Reader
agrees to comply strictly with all such regulations and acknowledges that Reader has the responsibility to obtain licenses to export, re-export, or
import the Document and any Compliant Products.
Hitachi and Lumada are trademarks or registered trademarks of Hitachi, Ltd., in the United States and other countries.
AIX, AS/400e, DB2, Domino, DS6000, DS8000, Enterprise Storage Server, eServer, FICON, FlashCopy, GDPS, HyperSwap, IBM, Lotus, MVS, OS/390,
PowerHA, PowerPC, RS/6000, S/390, System z9, System z10, Tivoli, z/OS, z9, z10, z13, z14, z/VM, and z/VSE are registered trademarks or
trademarks of International Business Machines Corporation.
Active Directory, ActiveX, Bing, Excel, Hyper-V, Internet Explorer, the Internet Explorer logo, Microsoft, the Microsoft Corporate Logo, MS-DOS,
Outlook, PowerPoint, SharePoint, Silverlight, SmartScreen, SQL Server, Visual Basic, Visual C++, Visual Studio, Windows, the Windows logo,
Windows Azure, Windows PowerShell, Windows Server, the Windows start button, and Windows Vista are registered trademarks or trademarks
of Microsoft Corporation. Microsoft product screen shots are reprinted with permission from Microsoft Corporation.
All other trademarks, service marks, and company names in this document or website are properties of their respective owners.
Copyright and license information for third-party and open source software used in Hitachi Vantara products can be found at https://
www.hitachivantara.com/en-us/company/legal.html.
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 2

Contents
Preface..................................................................................................... 4
Intended audience............................................................................................... 4
Product version....................................................................................................4
Release notes......................................................................................................4
Changes in this revision.......................................................................................5
Document conventions........................................................................................ 5
Accessing product documentation.......................................................................6
Getting help..........................................................................................................6
Comments............................................................................................................6
Chapter 1: Service Information Message (SIM) overview................... 7
Message types.....................................................................................................7
Actions to take when a SIM is output...................................................................7
Checking SIM reference codes............................................................................8
Searching for SIM reference codes..................................................................... 8
Handling failures.................................................................................................. 8
Setting failure notification methods......................................................................9
Chapter 2: SIM code lists..................................................................... 10
Columns in the SIM code lists............................................................................10
SIM code list for troubleshooting by users......................................................... 11
SIM code list for troubleshooting by service personnel..................................... 13
Obtaining drive box and drive numbers............................................................. 29
Contents
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 3

Preface
This document describes the service information messages (SIMs) issued by Hitachi
Virtual Storage Platform E series and Hitachi Virtual Storage Platform G130, G/F350, G/
F370, G/F700, G/F900, provides instructions for handling SIMs, and provides lists of the
SIM codes for troubleshooting by users and service personnel.
Please read this document carefully to understand how to use this product, and maintain
a copy for reference purposes.
Intended audience
This document is intended for system administrators, Hitachi Vantara representatives,
and authorized service providers who install, congure, and operate .
Readers of this document should be familiar with the following:
■Data processing and RAID storage systems and their basic functions.
Product version
This document revision applies the following product versions:
■VSP E series: 93-03-2x or later
■VSP G130, G/F350, G/F370, G/F700, G/F900: 88-07-0x or later
■SVOS RF 9.5.1 or later
Release notes
Read the release notes before installing and using this product. They may contain
requirements or restrictions that are not fully described in this document or updates or
corrections to this document. Release notes are available on Hitachi Vantara Support
Connect: https://knowledge.hitachivantara.com/Documents.
Preface
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 4

Changes in this revision
■Added SIM codes.
Document conventions
This document uses the following typographic conventions:
Convention Description
Bold ■Indicates text in a window, including window titles, menus,
menu options, buttons, elds, and labels. Example:
Click OK.
■Indicates emphasized words in list items.
Italic ■Indicates a document title or emphasized words in text.
■Indicates a variable, which is a placeholder for actual text
provided by the user or for output by the system. Example:
pairdisplay -g group
(For exceptions to this convention for variables, see the entry for
angle brackets.)
Monospace Indicates text that is displayed on screen or entered by the user.
Example: pairdisplay -g oradb
< > angle
brackets
Indicates variables in the following scenarios:
■Variables are not clearly separated from the surrounding text or
from other variables. Example:
Status-<report-name><file-version>.csv
■Variables in headings.
[ ] square
brackets
Indicates optional values. Example: [ a | b ] indicates that you can
choose a, b, or nothing.
{ } braces Indicates required or expected values. Example: { a | b } indicates
that you must choose either a or b.
| vertical bar Indicates that you have a choice between two or more options or
arguments. Examples:
[ a | b ] indicates that you can choose a, b, or nothing.
{ a | b } indicates that you must choose either a or b.
Changes in this revision
Preface
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 5

This document uses the following icons to draw attention to information:
Icon Label Description
Note Calls attention to important or additional information.
Tip Provides helpful information, guidelines, or suggestions for
performing tasks more eectively.
Caution Warns the user of adverse conditions and/or consequences
(for example, disruptive operations, data loss, or a system
crash).
WARNING Warns the user of a hazardous situation which, if not
avoided, could result in death or serious injury.
Accessing product documentation
Product user documentation is available on Hitachi Vantara Support Connect: https://
knowledge.hitachivantara.com/Documents. Check this site for the most current
documentation, including important updates that may have been made after the release
of the product.
Getting help
Hitachi Vantara Support Connect is the destination for technical support of products and
solutions sold by Hitachi Vantara. To contact technical support, log on to Hitachi Vantara
Support Connect for contact information: https://support.hitachivantara.com/en_us/
contact-us.html.
Hitachi Vantara Community is a global online community for Hitachi Vantara customers,
partners, independent software vendors, employees, and prospects. It is the destination
to get answers, discover insights, and make connections. Join the conversation today!
Go to community.hitachivantara.com, register, and complete your prole.
Comments
Please send us your comments on this document to
[email protected]. Include the document title and number, including
the revision level (for example, -07), and refer to specic sections and paragraphs
whenever possible. All comments become the property of Hitachi Vantara LLC.
Thank you!
Accessing product documentation
Preface
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 6

Chapter 1: Service Information Message (SIM)
overview
SIMs are a type of messages issued from storage systems. You can congure when and
how the SIMs (Service Information Message) are generated, and the notication
methods.
Message types
The following table lists the types of messages output from storage systems.
Message types Description
Device Manager - Storage
Navigator message
Output when Device Manager - Storage Navigator and
maintenance utility are being used. For details, see the
Hitachi Device Manager - Storage Navigator Messages.
SIM Output from channels, paths, microprocessors of storage
systems. For details, see SIM code lists (on page 10) .
Other messages Output when Storage Device List is being used or when a
batch command is being executed on the SVP. See the
following HTML le in the SVP:
■<SVP installation directory>\wk\supervisor
\sdlist\help\sdl_message_ja.html
■The default <SVP installation directory> is "C:\Mapp".
Actions to take when a SIM is output
When a storage system requires maintenance, a message is output. This is called a
failure of a storage system (SIM: Service Information Message). SIMs are output from
channels, paths, microprocessors, and so on, of the storage system. The following gure
illustrates actions to take after a failure occurs.
Chapter 1: Service Information Message (SIM) overview
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 7

Checking SIM reference codes
All SIMs are recorded in the storage system. When a SIM is output, Warning or Failed is
displayed at the upper left of the Maintenance Utility window to notify users.
You can check SIMs on the Alert tab in the Maintenance Utility window. For details, see
the System Administrator Guide.
Searching for SIM reference codes
In the SIM code lists, SIM codes that begin with the same digits are listed as a single
code. For example, 602001 is shown as 602xxx (xxx indicates a pool number) in the SIM
code list. Therefore, when searching for a SIM code, use the rst few digits, 602 in this
case, as a key word.
Handling failures
There are two types of SIMs. One can be handled by users, and the other must be
handled by service personnel. For SIMs that can be handled by users, see the recovery
procedures of the SIMs described in the applicable user guide to solve the problem. For
the SIMs that must be handled by service personnel, contact the customer support. See
SIM code list for troubleshooting by users (on page 11) or SIM code list for
troubleshooting by service personnel (on page 13) for the SIM code lists.
Checking SIM reference codes
Chapter 1: Service Information Message (SIM) overview
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 8

Setting failure notification methods
SIMs can be checked on the Alert tab. In addition, they can be notied by email
messages, Syslog, SNMP, or Windows Event Log. For the procedures for setting email,
Syslog, and Windows Event Log notications, see the System Administrator Guide. For the
procedure for conguring the SNMP notication, see the Hitachi Alert Notication Guide.
Setting failure notication methods
Chapter 1: Service Information Message (SIM) overview
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 9

Chapter 2: SIM code lists
This chapter describes the lists of the SIM reference codes that are reported when
failures occur in storage systems, and a matrix of drive box numbers, CDEV numbers,
and RDEV numbers.
Columns in the SIM code lists
The SIM code list tables have columns shown below.
The description of each column is as follows:
1: SIM code number. x is a variable value.
2: Brief description of the failure
3: Failed location in the storage system
4: Severity of the failure
Item Description
SERVICE Mild failure
MODERATE Partial failure
SERIOUS The failure part stops operation.
ACUTE The entire storage system stops operation.
5: With or without host report
6: Document to be referenced for troubleshooting by users. For the document title, see
the legends for the table in SIM code list for troubleshooting by users (on page 11) .
Only that table has this column.
Chapter 2: SIM code lists
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 10

SIM code list for troubleshooting by users
The following table lists and describes SIM codes that require action or restoration by
users. xxx in the following table indicates the port number.
If you select Host Report for Notication Alert in the Set Up Alert Notications
window, alert notication for SIMs that are reported to the host is sent. If you select All,
alert notication for all SIMs is sent.
Reference
code Failure
Alert level
(Severity)
Host
report
Reference
document
602xxx Pool blocking DKC
environment
MODERATE Yes Thin Image
602e Pools blocking by SM
volatile
DKC
environment
MODERATE Yes Thin Image
603000 SM Space Warning DKC
environment
MODERATE Yes Thin Image
604xxx Exceeded Threshold of
actual pool use rate
DKC
environment
MODERATE Yes Thin Image
605xxx Actual pool use rate
reaches upper limit
DKC
environment
MODERATE Yes Thin Image
606xxx Exceeded Fixed outage
Threshold of pool use
rate
DKC
environment
MODERATE Yes Thin Image
624000 SM Full DKC
environment
MODERATE Yes Provisioning
627xxx The DP POOL LDEV
blockade
DKC
environment
SERIOUS Yes Provisioning
628000 DP Protect attribute
setting of DRU
DKC
environment
SERIOUS Yes Provisioning
629xxx Exceeded Warning
Threshold of DP pool use
rate
DKC
environment
MODERATE Yes Provisioning
62axxx Actual DP pool use rate
reaches upper limit
DKC
environment
MODERATE Yes Provisioning
62b000 Threshold of DP pool use
rate remains exceeded
DKC
environment
MODERATE Yes Provisioning
SIM code list for troubleshooting by users
Chapter 2: SIM code lists
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 11

Reference
code Failure
Alert level
(Severity)
Host
report
Reference
document
62cxxx Exceeded Depletion
Threshold of DP pool use
rate
DKC
environment
MODERATE Yes Provisioning
62dxxx Exceeded Fixed outage
Threshold of DP pool use
rate
DKC
environment
MODERATE Yes Provisioning
62exxx Exceeded DP pool
depletion threshold for
TI pairs
DKC
environment
MODERATE Yes Provisioning
631xxx Auto pool expansion
failed due to system
error
DKC
environment
MODERATE Yes Provisioning
634xxx Auto pool expansion
failed due to no more
LDEV IDs
DKC
environment
MODERATE Yes Provisioning
641xxx Tier relocation is not
completed
DKC
environment
SERVICE Yes Provisioning
660100 No free encryption key DKC
environment
MODERATE Yes Encryption
License Key
660200 Remaining free
encryption key warning
DKC
environment
SERVICE Yes Encryption
License Key
670000 Warning for depletion of
cache management
devices
Cache MODERATE Yes Thin Image
681xxx Operation error of
deduplication system
data volume automatic
deletion was detected.
DKC
environment
MODERATE Yes Provisioning
682000 Deduplication system
data volume automatic
deletion was suspended.
DKC
environment
MODERATE Yes Provisioning
7c1xxx1Error in server registered
by using HSAE
DKC
environment
MODERATE Yes CCI
7d030x2GUM AuditLog lost DKC
environment
MODERATE Yes Audit Log
7d040x2GUM AuditLog Warning
Threshold was exceeded
DKC
environment
MODERATE Yes Audit Log
SIM code list for troubleshooting by users
Chapter 2: SIM code lists
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 12

Reference
code Failure
Alert level
(Severity)
Host
report
Reference
document
ee0000 Volume I/O upper limit
reached
QoS alert SERVICE Yes Performance
Manager
ee1000 Volume I/O lower limit
not reached
QoS alert SERVICE Yes Performance
Manager
ee2000 Volume I/O response
delay
QoS alert SERVICE Yes Performance
Manager
Legend:
■Yes: This SIM performs the host report.
■No: This SIM does not perform the host report.
■x: A hexadecimal number from 0 to f.
■Audit Log: SIM Codes in the Hitachi Audit Log User Guide
■Encryption License Key: Troubleshooting in the Encryption License Key User Guide
■Provisioning: Troubleshooting for provisioning in the Provisioning Guide.
■Thin Image: Troubleshooting Thin Image in the Hitachi Thin Image User Guide.
■CCI: Troubleshooting in the Command Control Interface User and Reference Guide.
Notes:
1. xxx indicates the server ID of Storage Advisor Embedded.
2. x = 1: An error occurred in CTL1.
x = 2: An error occurred in CTL2.
SIM code list for troubleshooting by service personnel
The following table lists and describes the SIM codes that require action or restoration by
service personnel. If a SIM in the table is output, contact customer support.
If you select Host Report for Notication Alert in the Set Up Alert Notications
window, alert notication for SIMs that are reported to the host is sent. If you select All,
alert notication for all SIMs is sent.
Reference
code Description Section
Alert level
(Severity) Host report
1420xx Transmitted data abnormality
between MP and GUM
Processor MODERATE Yes
180000 Audit Log lost DKC environment MODERATE Yes
SIM code list for troubleshooting by service personnel
Chapter 2: SIM code lists
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 13

Reference
code Description Section
Alert level
(Severity) Host report
1C0000 Detected a specic error code
SSB
DKC environment SERVICE Yes
2120xx Channel port blocking DKC environment MODERATE Yes
2130xx CHB blocking DKC environment MODERATE Yes
2140xx DKB blocking DKC environment MODERATE Yes
2153xx PECB blocking DKC environment MODERATE Yes
2154xx SWPK blocking DKC environment MODERATE Yes
2157xx PECB warning DKC environment MODERATE Yes
2180xx RIO path closed DKC environment MODERATE Yes
2190xx AL_PA value conict DKC environment SERVICE Yes
2193xx Link failure1 DKC environment SERIOUS Yes
2194xx Link failure2 DKC environment SERIOUS Yes
21a8xx SFP wrong type DKC environment MODERATE Yes
21aaxx SFP TxFault DKC environment MODERATE Yes
21d0xx External storage system
connection path blocking
DKC environment MODERATE Yes
21d1xx External storage system
connection path restore
DKC environment SERVICE Yes
21d2xx External subsystem path
response timeout
DKC environment SERVICE Yes
3070xx CHK1A threshold over Processor SERVICE Yes
3071xx CHK1B threshold over Processor SERVICE Yes
3072xx CHK3 threshold over Processor SERVICE Yes
3073xx Processor blocking Processor MODERATE Yes
3075xx CFM Failure Cache MODERATE Yes
3076xx Incorrect SUM value of FM Processor SERVICE Yes
3077xx Processor memory temporary
error
Processor SERVICE Yes
3078xx BFM error Processor SERIOUS Yes
SIM code list for troubleshooting by service personnel
Chapter 2: SIM code lists
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 14

Reference
code Description Section
Alert level
(Severity) Host report
3080xx WCHK1 dump Processor MODERATE Yes
388f00 PS OFF impossible PS(DKC) MODERATE Yes
389f00 PS OFF impossible (Device
reserved)
PS(DKC) MODERATE Yes
3990xx Undened Package is mounted Processor MODERATE Yes
3991xx V-R or serial number is
inconsistent
Processor MODERATE Yes
3993xx Replace failed Processor MODERATE Yes
399dxx Injustice dc voltage control DKC environment MODERATE Yes
399exx Injustice CEMODE DKC environment MODERATE Yes
399fxx Injustice CEDT DKC environment MODERATE Yes
39a000 The upper temperature limit was
exceeded
DKC environment SERVICE Yes
39b0xx MP patrol check error DKC environment SERVICE Yes
3a0xxx LDEV Blockade (Eect of
microcode error)
Drive MODERATE Yes
3c9500 CHB/DKB Type disagreement DKC environment MODERATE Yes
3c9600 No CHB mounted Processor MODERATE Yes
3c97xx iSCSI rmware update warning DKC environment MODERATE Yes
410000 Format complete (Normal end) Drive SERVICE Yes
410001 Format complete (Abnormal
end)
Drive SERVICE Yes
410002 Format complete (Partial
abnormal end)
Drive SERVICE Yes
410100 Quick Format nish Drive SERVICE Yes
410200 Parity consistency check
completed
Environment SERVICE No
410201 Parity consistency check
suspended
Environment SERVICE No
410300 Parity consistency check
abnormality detection
Environment MODERATE No
SIM code list for troubleshooting by service personnel
Chapter 2: SIM code lists
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 15

Reference
code Description Section
Alert level
(Severity) Host report
434xxx1Drive media error Drive SERVICE Yes
43bxxx1Drive blockade (media)(with
redundancy)
Drive SERIOUS Yes
43cxxx1Drive blockade (media)(without
redundancy)
Drive SERIOUS Yes
451xxx1Correction copy start Drive SERVICE Yes
452xxx1Correction copy normal end Drive SERVICE Yes
453xxx1Correction copy abnormal end Drive SERIOUS Yes
454xxx1Correction copy discontinued Drive SERVICE Yes
455xxx1Correction copy warning end Drive SERVICE Yes
461xxx1Dynamic sparing start(Drive
copy)
Drive SERVICE Yes
462xxx1Dynamic sparing normal
end(Drive copy)
Drive SERVICE Yes
463xxx1Dynamic sparing abnormal end
(Drive copy)
Drive MODERATE Yes
464xxx1Dynamic sparing discontinued
(Drive copy)
Drive SERVICE Yes
465xxx1Dynamic Sparing(Drive Copy)
warning end
Drive SERVICE Yes
468xxx Collection Copy/Copyback
disabled(drive replace)
Drive MODERATE Yes
46axxx1Drive Copy/Correction Copy
delay
Drive MODERATE Yes
47dxxx Shadow Image Copy abnormal
end
DKC environment MODERATE Yes
47e700 Forcible suspend by SM volatile DKC environment MODERATE Yes
47ec00 Forcible suspend by SM volatile DKC environment MODERATE Yes
47fxxx4Volume Migration abnormal end DKC environment MODERATE Yes
491000 Cache overload condition Cache SERVICE Yes
4a80xx Expander Micro Exchange failed DKC environment MODERATE Yes
SIM code list for troubleshooting by service personnel
Chapter 2: SIM code lists
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 16

Reference
code Description Section
Alert level
(Severity) Host report
4b3xxx Thin Image Option abnormal
end
DKC environment MODERATE Yes
4c1xxx PDEV Erase Start Drive SERVICE Yes
4c2xxx PDEV Erase Normal End Drive SERVICE Yes
4c3xxx PDEV Erase Abnormal End Drive SERVICE Yes
4c4xxx Flash module drive initialization
failed
Drive MODERATE Yes
4d1xxx Dierential area blocking Drive SERIOUS Yes
4e0xxx Drive blockade due to Media
Sanitization start
Drive SERVICE Yes
4e2xxx Media Sanitization start Drive SERVICE Yes
4e4xxx Media Sanitization normal end Drive SERVICE Yes
4e6xxx Media Sanitization abnormal end Drive MODERATE Yes
4e8xxx Media Sanitization warning end Drive MODERATE Yes
501xxx Drive temporary error Drive SERVICE Yes
502xxx Drive media error Drive SERVICE Yes
505xxx1Flash module drive internal
battery error (ORM)
Drive SERVICE Yes
508xxx1Flash module drive internal
battery error
Drive MODERATE Yes
50bxxx1Flash drive End of life Drive SERVICE Yes
50cxxx1Flash module drive End of life Drive SERVICE Yes
50dxxx1Flash module drive battery
warning
Drive SERVICE Yes
50exxx1Flash module drive battery
capacity shortage
Drive MODERATE Yes
50f000 Flash module drive micro-
program version warning
Drive MODERATE Yes
610001 Backup/restore SM Information
failed (Backup)
SM MODERATE Yes
SIM code list for troubleshooting by service personnel
Chapter 2: SIM code lists
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 17

Reference
code Description Section
Alert level
(Severity) Host report
610002 Backup/restore SM Information
failed (Restore)
SM MODERATE Yes
623xxx The DP POOL error is detected DKC environment MODERATE Yes
623e DP Pools blocking by Shared
Memory volatile
DKC environment MODERATE Yes
632xxx Auto pool expansion failed due
to pool error
DKC environment MODERATE Yes
633xxx Failed to create, expand, or
delete pools
DKC environment MODERATE Yes
660100 No free encryption key DKC environment MODERATE Yes
660200 Remaining free encryption key
warning
DKC environment SERVICE Yes
6610xx Acquisition of encryption key
from KMS failed
DKC environment MODERATE Yes
6620xx Encryption key setting
abnormality
DKC environment SERIOUS Yes
6800xx2Dedupe and compression
abnormality detect
DKC environment MODERATE Yes
760000 CUDG detected error DKC environment MODERATE Yes
7900xx BOOT detected error DKC environment MODERATE Yes
7d000xGUM error DKC environment MODERATE Yes
7d010xLAN error (Internal Network) DKC environment MODERATE Yes
7d020xLAN error (CTL1-CTL2) DKC environment MODERATE Yes
7d050xNotication of Alert failed DKC environment MODERATE Yes
7d06xx MP error Processor MODERATE Yes
7d07xx GUM security error detected DKC environment MODERATE Yes
7d08xx Failed to recover GUM
conguration information
DKC environment MODERATE Yes
7d0900 DKC warning Processor SERIOUS Yes
7d0axx GUM version warning DKC environment MODERATE Yes
7d0bxx Conguration backup failed DKC environment MODERATE Yes
SIM code list for troubleshooting by service personnel
Chapter 2: SIM code lists
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 18

Reference
code Description Section
Alert level
(Severity) Host report
7102 SI DKC environment SERVICE No
7104 TI DKC environment SERVICE No
71064Volume Migration Pair DKC environment SERVICE No
77xx The term of validity is over DKC environment MODERATE Yes
78xx The capacity of validity is over DKC environment MODERATE Yes
79xx The PP is invalid by assumption
PP invalidity
DKC environment MODERATE Yes
7a00 Synchronization time failure DKC environment SERVICE Yes
ac50xx DB power o PS(DKU) MODERATE Yes
ac51xx DB power recovered PS(DKU) SERVICE Yes
ac6000 DKC was set to power error
mode
PS(DKC) MODERATE Yes
ac6100 DKC was released from power
error mode
PS(DKC) SERVICE Yes
ac6200 Destaging startup normal PS(DKC) SERVICE Yes
ac6300 Destaging startup failed PS(DKC) MODERATE Yes
ac800xServer failure DKC environment SERIOUS Yes
af00xx Injustice JP Warning DKC environment MODERATE Yes
af10xx MP Temperature abnormality
warning
DKC environment MODERATE Yes
af11xx External temperature warning DKC environment MODERATE Yes
af12xx External temperature alarm DKC environment MODERATE Yes
af13xx Thermal monitor warning DKC environment MODERATE Yes
af20xx DKCPS warning PS(DKC) MODERATE Yes
af21xx DKCPS input voltage abnormality PS(DKC) MODERATE Yes
af30xx Environmental microcomputer
warning
DKC environment MODERATE Yes
af31xx Device movement mode warning DKC environment MODERATE Yes
af32xx Environmental Firmware Update
warning
DKC environment MODERATE Yes
SIM code list for troubleshooting by service personnel
Chapter 2: SIM code lists
SIM Reference Guide for VSP E Series, and VSP G130, G/F350, G/F370, G/F700, G/F900 19

Reference
code Description Section
Alert level
(Severity) Host report
af33xx Voltage change setting warning PS(DKC) MODERATE Yes
af40xx BKM/BKMF warning DKC environment MODERATE Yes
af41xx Battery replacement should be
scheduled
Battery MODERATE Yes
af42xx CHBB environmental
microcontroller warning
DKC environment MODERATE Yes
af43xx SCM environmental
microcontroller warning
DKC environment MODERATE Yes
af44xx CHBB environmental rmware
update warning
DKC environment MODERATE Yes
af45xx SCM environmental rmware
update warning
DKC environment MODERATE Yes
af46xx SWPK temperature warning DKC environment MODERATE Yes
af48xx CHBB voltage change failure
warning
DKC environment MODERATE Yes
af49xx SCM voltage change failure
warning
DKC environment MODERATE Yes
af4axx CHBBPS warning DKC environment MODERATE Yes
af4bxx CHBBPS abnormal input voltage DKC environment MODERATE Yes
af4cxx CHBBFAN warning DKC environment MODERATE Yes
af4dxx Panel switch warning DKC environment MODERATE Yes
af4exx Invalid PS ON warning DKC environment MODERATE Yes
af50xx DBPS warning PS(DKU) MODERATE Yes
af51xx DBPS-1 warning PS(DKU) MODERATE Yes
af52xx DBPS-2 warning PS(DKU) MODERATE Yes
af60xx DBPS input voltage abnormality PS(DKU) MODERATE Yes
af61xx DBPS-1 input voltage
abnormality
PS(DKU) MODERATE Yes
af62xx DBPS-2 input voltage
abnormality
PS(DKU) MODERATE Yes
SIM code list for troubleshooting by service personnel
Chapter 2: SIM code lists
