HiWeigh X1FM User manual
1
§1. Introduction
Wireless Communication Frequency
430 MHz
Wireless Communication Distance
30M/1500M (optional)
Wireless Communication Rate
9600bps
Display
X1FM: 6-digit 0.8 inches red LED
X5FM: 6-digit 0.8 inches green LED
Division
1/2/5/10/20/50/0.1/0.2/0.5/0.01/0.02/0.05/0.001/0.002/0.005
Serial Interface
RS232 interface with continuous data output
Baud rate 1200, 2400, 4800, 9600
Optional RS485 interface
Connect by RS232
Display, computer, printer, etc.
Weight Unit
kg/lb/UU (user unit should be set in factory)
Decimal System/Hexadecimal System
lb and UU can be in two systems
External AC Adapter
100-240VAC 50/60Hz
Rechargeable Internal Battery
6V/4AH
Operating Temperature
–10 °C to +40 °C
Storage Temperature
–25 °C to +55 °C
Relative Humidity
10% to 85% non-condensing
Dimensions
X1FM: 220×140×130 (mm)
X5FM: 265×162×58 (mm)
Weight
2kg
Version
VER 22.0
§2. Wireless Connection
Note: One wireless indicator only can connect with one wireless weighing transmitter, and both
wireless communication frequencies should be same. Wireless communication frequencies are set in
factory and user cannot change. Regular wireless communication frequency is 430MHz
If user wants to use two or more than two set of wireless weighing indicator and wireless weighing
transmitter, wireless communication frequencies must be different. Please let salesman know and
wireless communication frequencies will be set in factory.
1. Connect wireless weighing transmitter with load cell.
2. Switch on wireless weighing transmitter until the wireless function works.
3. Switch on wireless weighing indicator and calibrate.
4. In configuration mode, set “Con” to Con=78.
5. When indicator wireless lamp flashes, wireless weighing transmitter and wireless weighing indicator
are connecting.
6. Then, to calibrate wireless weighing indicator and configure.
7. RS-232C D-B 9: Pin 3 Output (TXD) and Pin 5 Signal Ground (GND)
8. RS232 interface is continuous data output
9. Address = 0continuous data output, form is =,X1,X2,X3,X4,X5,X6, while X1,X2,X3,X4,X5,X6 is
data,= is break. E.g.: if weigh is 123.45kg, data will be = 54.321 =54.321
Address = 99continuous data output, form is =,X6,X5,X4,X3,X2,X1, while X6,X5,X4,X3,X2,X1 is
data,= is break. E.g.: if weigh 123.45kg, data will be = 123.45= 123.45
2
§3. Keypad Function and Status Indicators
ON: Switch on OFF: Switch off
: Manual accumulation mode *: Select function and configure
→: Move flashing digit ↑: Increase flashing digit and high resolution
→0←: Zero, tare and decrease flashing digit
AC: Mains power applied : Battery capacity
AUT: Automatic accumulation mode : Weight stable
→T←: Tare mode →0←: Zero mode
lb: lb mode UU: User weighing unit mode
wireless: Wireless connected
§4. Configuration
1. Correct connect load cell – wireless weighing transmitter – wireless weighing indicator
2. Configure as follow step
3. Press *to configure and next step
Step
Operation
Displaying
Descriptions
1
Press →0←
On
000000
999999
0
In switch off states, press →0←key and ONto switch on
indicator. Segment checks, and displays [UE-22.0] to configure and
calibrate
2
Press *
Press *
CAL SP
-SEt-
Indicator in calibration mode
Indicator in configuration mode
Press →
d 1
Select division
3
Press ↑
Or →0←
d 2
0.001-0.002-0.005-10-20-50-100-200-500-0.10-0.20-0.50-1-2
-5-0.1-0.2-0.5-0.01-0.02-0.05
Factory default d = 0.01
4
Press *
Press →
Press ↑
6000
000000
001000
015000
Set full scale
Press →to move digit
Press ↑to increase digit
Press →0←to decrease digit
Factory default FS = 150.00
5
Press *
Press →
Press ↑
Or →0←
FLt 1
Filter range: 0 ~ 2 0-fastest 2-slowest
Digit flashes
Factory default Filter = 2
6
Press *
Press →
Press ↑
Or →0←
AUtP00
Ones digit means automatic switch off function:
Ones digit0,2,4 means automatic switch off function enable
Ones digit1,3,5 means automatic switch off function disable
Tens digit means range of zero track (0~9):
0:0.4d 1:0.4d 2:0.8d 3:1.2d 4:1.6d 5:2.0d
6:2.4d 7:2.8d 8:3.2d 9:3.6d
Tens digit also means range of zero:
Tens digit0 means no zero set at start operation
Tens digit≥1:
Ones digit =0 means zero when weight is 2℅F·S, and automatic
3
switch off function disable
Ones digit=1 means zero when weight is 2℅F·S, and automatic
switch off function enable
Ones digit=2 means zero when weight is 20℅F·S, and automatic
switch off function disable
Ones digit=3 means zero when weight is 20℅F·S, and automatic
switch off function enable
Ones digit=4 means zero when weight is 50℅F·S, and automatic
switch off function disable
Ones digit=5 means zero when weight is 50℅F·S, and automatic
switch off function enable
Tens digit flashes.
Factory default AUtP = 11
7
Press *
Press →
Press ↑
Or →0←
Adr 00
Select address:
Continuous data output , Adr=00 or Adr=99
Communicate is by modbus between 01-95
Factory default Address = 00
8
Press *
Press ↑
Or →0←
b 2400
b 4800
Select baud rate:
1200→2400→4800→9600
Factory default baud rate = 2400
9
Press *
0
Confirm configuration
§5. Wireless Communicate
After above configuration, set the wireless communicate
Step
Operation
Displaying
Descriptions
1
Press *
Press *
Press *
Press *
Press *
CAL SP
-SEt-
-A-d-
FACT
Con
Indicator in calibration mode
Indicator in configuration mode
Enter ADC counts display
Back to factory set
Set wireless communicate address
2
Press →
Con 78
Enter address which is same as wireless weighing transmitter
3
Press *
2300
Back to weight states
4
Press *
ConSEA
Search wireless communicate address automatically
5
Press →
Con xx
Con-78
Search wireless weighing transmitter
When indicator searched wireless weighing transmitter, it will display
the address (go to step 6 or step 7)
6
Press →
2300
Follow step 5, save the address and return to weighing mode
7
Press *
2300
Follow step 5, delete the address and return to weighing mode
§6. Calibration
After above setting, calibrate indicator directly:
Refer to the table of next page >>>
4
Step
Operation
Displaying
Descriptions
1
Press *
Press →
CAL SP
CAL 00
Indicator in calibration mode
Enter to set ZERO
2
Press *
------
3000
Set ZERO
After several seconds, indicator displays maximum weight
3
Load max weight
Press *
3000
Display weight
4
Press →
Press ↑
Or →0←
000000
002000
If the weight is not the max weight, press →and ↑or
→0←to input actually weight
e.g.: weight is 2000
5
Press *
------
2000
Calibrate
After several seconds, indicator displays weight, then finish
calibrate
§7. ADC Counts Display
Confirm load cell connect is correct to check ADC counts. After set the short pin, ADC counts should
around 100000-200000. After above setting, check ADC counts directly:
Step
Operation
Displaying
Descriptions
1
Press *
CAL SP
Indicator in calibration mode
2
Press *
-SEt-
Indicator in configuration mode
3
Press *
-A -d-
ADC counts display
4
Press →
43125
Enter to check ADC counts, and display 43125
5
Press *
0
Return to weighing mode
§8. Factory Set
Step
Operation
Displaying
Descriptions
1
Press *
CAL SP
Indicator in calibration mode
2
Press *
-SEt-
Indicator in configuration mode
3
Press *
-A -d-
Indicator in ADC counts display mode
4
Press *
FACt
Select Back to factory set
5
Press →
0
Back to factory set and return to weighing mode
Factory default: d=0.01FS=150.00FLt=2AUtP=11Adr=00b=2400
§9. Weighing Unit
Step
Operation
Displaying
Descriptions
1
Press *
On
000000
999999
0
Press *and ONto switch on indicator
If it displays [UE=21.X], user can set own unit
2
Press ↑
2.0000
Select unit
3
Press →
000000
Digit flash
4
Press ↑
→0←
01.6535
Change digit number
If user unit is Hong Kong kg, enter 1.6535
5
Press *
HE 0
Decimal/Hexadecimal(lb And UU)
0---Decimal
1---Hexadecimal
5
Hexadecimal displays automatically retain two decimal points. 2
After The Decimal Point Every 16 Binary
6
Press →
HE 0
Digit flash
7
Press ↑
→0←
HE 1
Change digit
8
Press *
d 0. 0.0
Set display form when unit is lb or UU
HE=1, d has two situations: 0. 0.0 and 0. 0
9
Press ↑
→0←
d 0. 0
Change situation
10
Press *
0
Save setting and return to weighing mode
§10. Operation
1. ON/OFF Press ONswitch on indicator; and press OFFto switch off indicator.
2. ZERO Press →0←for more than two seconds when Weight is 2F.S, weight is ZERO and
→0←will be displayed
3. TARE
a. Weight tare When →T←turns off and weight is 0 stable, press →0←to display Zero and
→T←turns on
b. Remove tare When →T←turns on, press →0←to clear tare and →T←turn off
c. Number tare Press →to set tare. Press →↑to enter tare (unit is kg), and press →0←
to save tare and →T←turns on
d. Accumulation In manual accumulation mode, weight is 20d stable, press to accumulate
weight and display accumulation times, e.g.: n 12
Note: one weighing result only can accumulate one time, next accumulation weight must after weight
20d.
4. High resolution In weighing mode, press ↑to display the weight in X10 resolution and last
decimal point turns on. Press ↑again to show regular weighing resolution.
Note: In lb and UU mode, indicator has no high resolution function.
5. Display accumulation (in weighing mode)
Step
Operation
Displaying
Descriptions
1
Press *
n 12
Display accumulation times
2
Press ↑
H 23
Display upper 4 digits of accumulated weight, e.g.: 23
3
Press ↑
L506.5
Display upper 4 digits of accumulated weight, e.g.: 506.5
So, the accumulated weight is 23506.5
Accumulated is Decimal even weight is Hexadecimal.
6. Select weighing mode (in weighing mode)
Step
Operation
Displaying
Descriptions
1
Press *
n 12
Display accumulation times
2
Press *
Aut 0
Select manual/automatically accumulation
Aut=0: regular weighing mode and manual accumulation
Aut=1: regular weighing modeautomatically accumulation after
stable, and -AUT-turns on
Aut=2: regular weighing modesave weight automatically after
stable, accumulate finial weight which is unload 20d, -AUT-
turns on
6
Aut=3: animal weighing mode, accumulate automatically finial
weight which is unload 20d, -AUT-turns on
Aut=4: peak hold mode, accumulate automatically finial weight
which is unload 20d, -AUT-turns on
Aut=5: animal weighing mode and manual accumulation
Aut=6: peak hold mode and manual accumulation
Aut=7: counting mode and manual accumulation
Aut=8: double-way weighing mode, weight pressure and pull from
positive and negative way
Aut=9: Minus weighing mode
3
Press →
Press ↑
Or →0←
Aut 0
Change mode
4
Press *
t 3
Lock time of animal function when Aut=3 or this step display on
Aut=3. Otherwise , return to weighing mode
t=0-9 second, and weighted is average during lock time.
5
Press ↑
Or →0←
t 5
Change lock time
6
Press *
0
Return to weighing mode
7. Clear accumulation Press *to display accumulation data and press →0←to clear
accumulation data.
8. Enter number Press →to move flashing digit, press ↑to increase flashing digit and press
→0←to decrease flashing digit.
9. Rechargeable internal battery Switch on indicator and display Pbt 85means battery capacity is
85%
10. Remind charge battery When battery capacity is 30%, turns on to remind user charge
battery. When battery capacity is 10%, display flashes to remind user charge battery immediately.
11. Over-discharge protection When battery capacity is 0%, indicator will switch off automatically to
protect battery.
12. Save power mode In switch off automatically mode, display -to save power after three
minutes no operation.
13. Switch off automatically In switch off automatically mode, indicator will switch off after 30 minutes
no operation.
14. Full charge battery operation Indicator can work 30 hours continually.
15. kg→lb→UU Press *more than 2 second to change weighing unit. The change order is
kg→lb→UU→kg.
16. When wireless weighing transmitter battery capacity is 10%, up digit displays b, e.g.: b 3.00
§11. Counting Mode (AUT=7)
1. Sample data Put samples on scale when net weight is zero (TARE when net weight is not zero).
Sample amount should between from 1 to 999, and more samples, weight will be more accurate.
Step
Operation
Displaying
Descriptions
1
Load samples
27
Display weighing of samples
2
press →
Cnt000
Enter sample amount
7
3
press →
press ↑
or →0←
Cnt030
Enter sample amount 30
4
press *
C 30
Save samples data and display samples amount
5
press ↑
27
Press ↑to change weighing and amount displaying
2. Operation put the weight on scale, number is weight when indicator displays 54, and number
is amount when indicator displays C 60. Press →to change weight and amount displaying. After
the sample weight is stable, press to displays accumulate weight and amount.
3. Display and clear accumulated data
Step
Operation
Displaying
Descriptions
C 47
Indicator in counting mode
1
Press *
n 8
Display number of samples
2
Press →
C 532
Display accumulation number
3
Press *
C 47
Return to counting mode
4
Press ↑
42
Change to display weighing mode
5
Press *
n 8
Display number of samples
6
Press →
H 0
Display upper 4 digits of accumulated weight
7
Press ↑
L 471
Display lower 4 digits of accumulated weight
8
Press *
42
Return to weighing mode
9
Press *
n 8
Display number of samples
10
Press →0←
C 47
Delete accumulation weightand return to counting mode
When indicator displays accumulation times, press →0←to delete accumulation weight.
§12. Double-Way Weighing Mode (AUT=8)
1. Indicator can receive positive and negative signal.
2. When the weight signal is positive, indicator displays positive weight number and it can be TARE
When the weight signal is negative, indicator displays negative weight number and it cannot be Tare
3. In double-way weighing mode, indicator hasn’t Accumulation and printer function.
§13. Minus Weighing Mode (AUT=9)
1. Indictor displays moved weight
2. Operation: put the weighing on scale and press →0←for long time to zero. If move the weigh,
indicator will display moved weigh. (the number is positive)
3. In minus weighing mode, indicator has TARE, Accumulation and printer functions.
§14. Printer format
Indicator connect printer by serial interface: Adr=01-95: press to output print signal in accumulation
mode.
Print form: O: 0002
G: 7.73kg
T: 4.82kg
N: 2.91kg
Counting mode NO: 0002
G: 7.73kg
T: 4.82kg
8
N: 2.91kg
C: 54pcs
Accumulation mode NO: 0002
S: 5.82kg
Accumulation with counting mode: NO: 0002
C: 108pcs
S: 5.82kg
§15. Safety precautions
1. Do not expose indicators to either direct sun light or any heat sources.
2. Do not use indicators in hazardous area or in dusty environments.
3. Weight cannot more than max weighing
4. Do not use strong solvents (such as: benzene, nitric acid oil) to clean the indicators.
5. Never flood the Indicator, immerse it in liquid or pour liquids on it.
6. Do not open the indicator! The warranty is void if this stipulation is ignored. The indicator may only be
opened by authorized persons.
7. Battery is recharged when AC power connects.
8. Use short pin to test indicator: if indicator doesn’t displays weight number, please switch off it, take off
load cell connector and take on short pin. Switch on indicator, after displays 0-9 self-test patterns. See
following two situations:
a. Indicator displaying one number means indicator works well.
b. Indicator displaying many mass numbers means indicator needs repair.
§16. Services
The Warranty time is in one year after sale date of non-human failure. Indicator is lifelong service.
(NOTE: Battery is not under warranty)
§17. LED Error Code
Code
Meaning
OUEr
Weight > FS + 9d
–OUEr
Weight -20d or 100%FS (in double-way weighing mode)
30% battery warning to recharge the battery
Weight number flashing
10% battery warning to recharge the battery
bxxxxx
Wireless weighing transmitter 10% battery warning to recharge the battery
This manual suits for next models
4
Table of contents
Other HiWeigh Measuring Instrument manuals
Popular Measuring Instrument manuals by other brands
SOEKS
SOEKS EcoVisor F4 user guide
Huato
Huato A200 Operation manual
SPARLING
SPARLING MainLine FM-104 Installation, operaton & maintenance manual
Schrack
Schrack MGDIZ Series Instructions for use
Rover Instruments
Rover Instruments DM14B/C DIGIMAX user guide
AMALGAMATED INSTRUMENT
AMALGAMATED INSTRUMENT RM4-FX Operation and instruction manual
