HMS-VILGO QUIEGO FORTISSIMO 1000 User manual

User guide : Quiégo Fortissimo Version 07/2018 User guide : Quiégo Fortissimo Version 07/2018
Seat
Fixed or reclining back rest
(according to models)
High adjustable
armrests
Detachable head rest
Warning
:
-This easy chair is to be used indoors only. Do not use the chair outside, on an unsuitable or
rough ground.
-Respect the maximum user’s weight that is indicated on the label.
-Do not sit on the armrests or directly on the extended leg rest.
-Do not roll the chair with a patient sitting on it down a ramp or a slope steeper than 5°
-Use the easy chair on a flat ground
Cleaning:
-The seat can be removed to make cleaning easier. Wipe all surfaces with a non-woven fabric
and an appropriate disinfecting solution. (Anios detergent or other equivalent).
-Strictly ban the following: Pure Alcohol, Acetone, Perchloroethylene, trichloroethene ,
detergents; solvants, wax.
-Do not hose down the chair or use a high pressure water system to wash it.
Preventive maintenance:
We strongly advise to schedule a yearly check on the easy chair:
Depending on how frequently the chair is being used, please check the following points:
-General aspect and state of the metal frame and foam paddings
-Look out for any dents and alterations to the metal frame
-Check the reclining backrest (gas springs and hand lever)
-Check the leg rest (the pantograph on Q7000, the locking device on Q7500)
-Check that the castors are securely screwed in and that they roll properly (try out the 3
positions)
Descripti
on
User Guide
E
Ea as sy y C Ch ha ai ir rs s
Q
Q
U
U
I
I
E
E
G
G
O
O
F
F
O
O
R
R
T
T
I
I
S
S
S
S
I
I
M
M
O
O
Recommandations
. Quiégo
1000
Fortissimo
: Chair with fixed backrest
400kg
. Quiégo 1500 Fortissimo: Chair with reclining backrest 400kg
. Quiégo 2000 Fortissimo : Chair with fixed backrest , adjustable feet (5 positions) 330kg
. Quiégo 2500 Fortissimo: Chair with reclining backrest, adjustable feet (5 positions) 330kg
High density foam
40 kg/m3
M1 non-fire cover

Displacement
castors
QUIEGO 1000 Fortissimo

User guide : Quiégo Fortissimo Version 07/2018 User guide : Quiégo Fortissimo Version 07/2018
Head rest:
Slide in the head rest in the two open
tubes on top of the backrest.
Assembling the backrest
:
Slide in the backrest in the two chassis
tubes. Secure the backrest with the 2
screws BHC 6x30 and lock nuts M6
using the keys provided (4mm Allen key
and D10 flat key)
Adjusting the armrests up and down:
Pull up the small hand lever to adjust the height of the
armrest
Adjusting the backrest
:
1 – to recline the backrest, pull up the lever while you
push your back into the backrest, till you reach the
position you wish. Let go of the lever to lock the backrest
into that position.
2 – To bring the backrest back up, pull up the lever but
don’t push your back into the backrest.
IMPORTANT: please check that the armrest is securely locked into one of
the 3 positions
Use of the easy
chair
Assembling the chair
Clic
IMPORTANT: Please check that the locking pin sticks out, that the feet are all
properly locked in.
Adjusting the chair height
(on QUIEGO
2000 – 2500):
The height of the easychair can be adjusted
with the locking pins (5 positions) on each of
the 4 feet.
