Hober HSPL750L User manual

User Manual -Solar Pumping Inverter
1
SOLAR PUMPING INVERTER
USER MANUAL
VERSION - 2015
VERSION
V4.0
DATE
APRIL / 5 / 2015
PRODUCER
LEO
To ensure of your health, equipment and property, please read this chapter carefully before use the solar
pumping inverter and act in compliance with the instructions.
1．SAFETY DEFINITION:

User Manual -Solar Pumping Inverter
2
Danger: It will cause serious injuries and even death while operating against the rules
Storage Condition:
NOTE
Temperature
Humidity
Temperature -40 ℃to +65 ℃.
5% to 90%, no condensation
Storage in dry, dust-free Do not store in the environment containing corrosive gas, liquid
Installation:
Danger
FORBID to connect the switcher between the Ac output of inverter with the pump
Wire is connected by professional person only.
Each wire connect to the device must be wrapped with electrical tape for safety
Prohibiting the installation location: direct sunlight, thick dust, corrosive gas or oil mist, flammable
gas, liquid.
Attention
To ensure good convection cooling effect, the device must be installed Vertically
The height of the device installation should be over 1.1m or more, and please establish the risk identified
beside the device.
The ambient temperature -20 ℃-+60 ℃,If Over 45 ℃,Please make sure well ventilated and the backside
of inverter should be covered to make sure the air of fan is output from TOP of inverter.
Relative humidity 15%-+95%RH
The device ONLY can be used to control the three-phase AC asynchronous Pump and Resistor Heater.
Attention
If the output flow is small, please exchange the two line of U.V.W
The equipment of the environmental temperature will directly influence the durability and reliability, make
sure the environment to meet the above requirements for prolong the service life of the machine
Maintance:
Danger
Under any circumstances, without professional guidance, do not disassemble the machine or touch the
internal parts
Forbid to maintain the equipment when device is Power-on

User Manual -Solar Pumping Inverter
3
2. NAMING RULE
Solar Pumping Inverter:
HSPL 2200 H/L A/B X
X: Build In the Booster Circuit.
A/B：Output Frequency A：50Hz B：60H
H/L：AC Output Voltage, H：380V L ：220V
2200: Support Rated Power of Pump 2200W,
HSPL：Company product code, HOBER and Solar Pumping Inverter
Solar /AC/Diesel Switcher
HSAS 2200 H/L A/B
A/B：AC Input Frequency A：50Hz B：60H
H/L：AC Input Voltage, H：380V L ：220V
2200: Power 2200W
HSAS：Company product code, HOBER and Solar/AC Switcher
Solar Pumping System Construction:
PARAMETERS
Optional
Optional
Optional
Optional

User Manual -Solar Pumping Inverter
4
Table 1
NOTE : Solar Panel’s Power configured to 1.2 ~ 2 times of pump’s power , according to the pump’s efficiency and
sunshine of solar pumping system installed location.
WIRING.

User Manual -Solar Pumping Inverter
5
Table-2
3. INSTRUCTIONS.
3.1 Socket

User Manual -Solar Pumping Inverter
6
1：LED /LCD Display
2：System status display：Include Power, running, stop, well, tank, fault
3：Keyboard
4：Ac output: four lines (3phase and ground line)
5：Dc input: Negative and Positive
6：Fan: According to the temperature, wind cooling
7：Well sensor
8：Tank sensor
9：RS485 / GPRS Communication
10：Stop /Boot control and output flow size control
3.2 DC Input
a. Please refer to the Table-1 and check the input voltage whether within the standard or not... Then input voltage
can be measured by multi-meter. For example:220V AC output ,so the DC input voltage range is: 250V~450V
b. To PV Panel to Input of pumping inverter can connect the switcher if needs.
c. Please make sure the input negative and positive line wiring correcting
3.3 AC Output
FORBID to connect the switcher between the Ac output and pump
1
3
1
2
4
6
7
8
10
9
5

User Manual -Solar Pumping Inverter
7
Red Color
Yellow Color
Blue Color
Yellow_Green
U
V
W
Ground
NOTE: if the output flow of pump is too small, please try to exchange two wire of 3phase .
3.4 WELL and TANK SENSOR
Picture – 3
Length wire of well and tank is 0.5M, each sensor have three wire, include High level of water detect, middle level of
water detect, low level of water detect. For example of Well Connecting Method（Tank connect wire is the same）：
1) The longest length of reserved wire is for well low level of water detect
2) The middle length of reserved wire is for well middle level of water detect
3) The shortest length of reserved wire is for well high level of water detect
Remarks: The connection is not on basis of line color difference, according to the length of reserved line
Middle Level Water Detect
High Level Water Detect
Low Level Water Detect
Water
3phase wire
+1Ground wire of
pump
H1
Tank/Well
Sensor
Pipe
High Level
detect

User Manual -Solar Pumping Inverter
8
Example:
Total Height(H) of Well is 100meters, water deep (H1+H2+H3) is 90 meters
H3: from bottom of well to the water input of pump is 10meters
H2: 40meters
H1: 40meters.
Well/Tank wiring method
Picture – 4
3.5 LCD Type
LCD Screen operation Diagram:
Working Time
Start – Stop (H:M)
Time: 0 :0 – 23:59
Tank Sensor Set
Enable
Disable
StateNow: Enable
Well Sensor Set
Enable
Disable
StateNow: Enable
Enter Into
Setting Menu
0 0 0 0
Verify the PW
HOBER TECH
HSPL22KH
Run
13:26 02/11/15
Inverter State
No Warning!
No Error!
Temp: 35. 0(Degree))
Water State
Tank Empty
Well Full
Solar Low
Power to Stop
MinFreq: 10 Hz 5 M
Stop Time: 20 M
Solar Power
Voltage: 540 (V)
Current: 2 (A)
Power: 1.08 (KW)
System Setting
1. Working Time
2. Solar Power
3. Dry-Run Detect
4. Tank Sensor
5. Well Sensor
6. Output Freq
7. Output Voltage
8. Gprs Password
9. Time Calibrate
10. System PW Set
11. Factory Reset
Dry-Run Setting
Enable/Disable
Parm Setting
Ref LE Curt: 10A
Dry-Run Protect
Enable
Disable
StateNow: Disable
AC Output 3Phase
Freq: 50 (Hz)
Current: 2 (A)
Dry-Run Protect
By Soft @ 45Hz
LE Current: 10 (A)
Stop Time: 30 (M)

User Manual -Solar Pumping Inverter
9
Main Menu
“UP”,”Down” Key for Change Menu
“Enter” Key for enter Setting Menu
Line 1: Company Name
Line2: Model
Line3: Show System is Running or Stop
Line 4: System Time
NOTE: system time is important , as the working time of inverter is related
with this. Please correct with local time.
Input State
Show the Input Voltage, Current ,Power of Solar Panel
Output State
Show the Output frequency, Current of AC to the pump
AC Output Max
50
Frequency(Hz)
Error History
Error: 32
11:43 02/09/15
More Clear All
Machine-ID
4015
MFD: 17/15
Gprs Control PW
8618688958696
0 0 0 0
Verify PW First
Error History
Error:32
11:43 02/09/15
More Clear All
Error History
Error: 32
11:43 02/09/15
More Clear All
Time Calibrate
(H:M M/D/Y)
20 : 25 2 / 11 / 15
Error History
Clear All Data?
ESC / Enter
More Clear All
System PW
0 0 0 0
Verify PW First
Factory Reset
Enter
Back
ESC Key to Back
HOBER TECH
HSPL22KH
Run
13:26 02/11/15
Solar Power
Voltage: 540 (V)
Current: 2 (A)
Power: 1.08 (KW)
AC Output 3Phase
Freq: 50 (Hz)
Current: 2 (A)

User Manual -Solar Pumping Inverter
10
Inverter State
Show the Warring, Error and Temperature of Solar Pumping inverter
Tank /Well’s water status Display
Show the water of Tank and Well status.
If the water of tank is full or water of well is empty , will automatic stop
running and show the status
Error History
For inquiry the Error flag history
Press the “Enter” key to enter this menu, then “UP”/”Down ”to select the
command for inquiry more record or clear the history.
Note: if current cursor is on More, press “Enter” key to confirm view more
records, then “UP”/”Down” key to change the records number.
Machine ID
The Unique Serial id of inverter
MFD: manufacture Date
Verify the Password to Enter the Setting Menu
Original is: 0000
System Setting
“UP”/”Down” to change Menu Item
Working Time
For Inverter working time set. If the system time within this setting then
work, or else standby.
Low Power of Solar Panel to Protect the Pump
Solar Panel output power is low and no water output in the
morning/dusk ,also in cloudy days
Inverter State
No Warning!
No Error!
Temp: 35. 0(Degree))
Water State
Tank Empty
Well Full
Error History
Error: 32
11:43 02/09/15
More Clear All
Machine-ID
4015
MFD: 17/15
Enter Into
Setting Menu
0 0 0 0
Verify the PW
System Setting
1. Working Time
2. Solar Power
3. Dry-Run Detect
4. Tank Sensor
5. Well Sensor
6. Output Freq
7. Output Voltage
8. Gprs Password
9. Time Calibrate
10. System PW Set
11. Factory Reset
Working Time
Start – Stop (H:M)
Time: 0 :0 – 23:59
Solar Low
Power to Stop
MinFreq: 10 Hz 5 M
Stop Time: 20 M

User Manual -Solar Pumping Inverter
11
Dry-Run Detect
Dry-Run of pump(Water level of well), detect by software. when inverter run
to 45Hz or higher, it detect the current of pump, Automatic Stop run once
less than the set parameters of Current, after stop time finished ,restart
again.
NOTE:
If the well sensor input and Enable Well sensor detect the water level ,this
function is disable
Ref LE Curt: Current value is 2/3 times of rated current of pump. The inverter
will give the reference value once the pump running to 40Hz or more with
water
Tank /Well Sensor Set
To Enable/Disable the sensor working.
AC Max Output Frequency
Set the Max output Frequency, Range from 50 to 60Hz
NOTE: Please confirm it with your pump’s parameter, if the pump is 50Hz,
but the setting is Max 60Hz, then pump will be damaged!
Max Output Voltage of AC
Set the Max output Voltage. Invalid for inverter that 220V output.
NOTE: Please confirm your pump’s parameter, if the pump is 380V, but the
setting is Max 440V, then pump will be broken!
GPRS Control Password
The Password is used for Command Verification that send by GPRS
System Time
System Time Calibrate
System Password
The password is for enter the setting menu
Dry-Run Setting
Enable/Disable
Parm Setting
Ref LE Curt: 10A
Dry-Run Protect
Enable
Disable
StateNow: Disable
Dry-Run Protect
By Soft @ 45Hz
LE Current: 10 (A)
Stop Time: 30 (M)
Tank Sensor Set
Enable
Disable
StateNow: Enable
Well Sensor Set
Enable
Disable
StateNow: Enable
AC Output Max
50
Frequency(Hz)
AC Output
Max Voltage
Max 380V
State Now: 380V
Gprs Control PW
8618688958696
0 0 0 0
Verify PW First
Time Calibrate
(H:M M/D/Y)
20 : 25 2 / 11 / 15
System PW
0 0 0 0
Verify PW First

User Manual -Solar Pumping Inverter
12
Factory Reset
For Reset all of setting to default value.
3.6 POWER ON/OFF AND FLOW CONTROL
Startup:
Clockwise
Output Freq: Min to Max
Shut Down：
Anticlockwise
Output Freq: Max to Min
3.7 GPRS Control(Optional, need the use it together with GPRS module of Hober)
Remote Control the Inverter By SMS.
SMS Sample:
1
The SIM Car Number/ 2G
Factory Reset
Enter
Back
ESC Key to Back
1
2
3
4
5

User Manual -Solar Pumping Inverter
13
2
SMS to Control the Inverter On(Start
output)
3
Feed back by Inverter
4
Set the Inverter’s Min Freq, Running Time
and restart time.
5
Update the Password for SMS control
6
SMS to Control the Inverter Off(Stop
output)
Attention
The password in the SMS command is the one that your set
The character “,”and “.”is necessary.
4. Error Flag Display
NOTE :
a. express the status is true, for example : Error Flag is 8 indicate system inverter is
over temperature.

User Manual -Solar Pumping Inverter
14
5. CASE
3Phase 380V 2HP AC pump solar pumping system:
PV Connection:
Total 6pcs
use 2pcs in series to a group
Three Group in Parallel
Total Voc is 92V, Vmp 78V. Total Watt is 1860W
NOTE: As the low power of pump efficiency is low , will ask more power for input, please use 4Groups.
6. PACKAGING
Inverter: 1pcs
DC Input Connector: 2-12pcs according to the Table-2
Tank Sensor: 1pcs
Well Sensor: 1pcs
AC Output Connector: 1pcs
User Manual: 1pcs

User Manual -Solar Pumping Inverter
15
7. QUALITY WARRANTY
In order to protect your interests, to solve your any menace from the "rear" except! The company provides 2
YEAR of warranty of quality service for you.
Please provide machine failure photos or video and the ID of machine, then send to our technical department to
analysis, we will reply within 24 hours.
The following situation does not belong to the quality warranty: the user to alter the serial number and machine;
quality warranty label tag; use environment does not meet the conditions of using. Product be repaired or
disassembled without our authorization.
The following situation not free fee, the specific charging standard according the device (material cost extra):
both in or out of the warranty period: irresistible natural forces such as earthquake, fire damage caused by
improper use; fault; machine water damage.
ID
