Hochiki America FN-300ULX User manual

Rev. 101112
FN-300ULX
Power Supply/Charger
Installation Guide
Altronix Corp.
140 58th St. Brooklyn, NY

Overview:
The FN-300ULX is a power supply that converts a 115VAC / 60Hz input to a 12VDC or 24VDC regulating output
(see specifications below).
Specifications:
- 2 -
Agency Listings:
• ULFile#S4707:
UL Listed for Access Control
 SystemUnits(UL294),ULListedStandardforPower
 SuppliesforUsewithBurglar-AlarmSystems(UL603),
 ULListedHospitalSignalingandNurseCallEquipment
 (UL1069),ULListedStandardforSafetyforFire
 ProtectiveSignalingSystems(UL1481).
• MEA-NYCDepartmentofBuildingsApproved.
• CSFM-CaliforniaStateFireMarshalApproved.
Input:
• Input115VAC,60Hz,3amp.
• ACinputandDCoutputLEDindicators.
Output:
• Class2Ratedpower-limitedoutput.
• 12VDCor24VDCselectableoutput.
• 2.5amptotalsupplycurrentat12VDCor24VDC.
• Filteredandelectronicallyregulatedoutputs.
• Shortcircuitandthermaloverloadprotection.
Battery Backup:
• Built-inchargerforsealedleadacidorgeltypebatteries.
• Automaticswitchovertostand-bybatterywhen
AC fails.
• Maximumchargecurrent0.7amp.
• Zerovoltagedropwhenswitchedovertobatterybackup.
Supervision:
• ACfailsupervision(form“C”contacts).
• Lowbatterysupervision(form“C”contacts).
• Batterypresencesupervision(form“C”contacts).
Additional Features:
•Powersupply,enclosure,camlockandbatteryleads.
Enclosures:
FN-300ULX-R(Red)
FN-300ULX-C(CharcoalGrey)
Enclosure Dimensions (H x W x D):
13.5”x13”x3.25”(342.9mmx330.2mmx82.55mm)
Power Supply Voltage Output Selections:
Output Switch Position
12VDC SW1-CLOSED(Fig. 1, on right)
24VDC SW1-OPEN(Fig. 1, on right)
Stand-by Specifications:
Output 4 hr. of Stand-by &
5 Minutes of Alarm
24 hr. of Stand-by &
5 Minutes of Alarm
60 hr. of Stand-by &
5 Minutes of Alarm
12VDC/40AHBattery Stand-by=2.5amp
Alarm=2.5amp
Stand-by=1.0amp
Alarm=2.5amp
Stand-by=300mA
Alarm=2.5amp
24VDC/12AHBattery -------- Stand-by=200mA
Alarm=2.5amp --------
24VDC/40AHBattery Stand-by=2.5amp
Alarm=2.5amp
Stand-by=1.0amp
Alarm=2.5amp
Stand-by=300mA
Alarm=2.5amp
Installation Instructions:
Theunitshouldbeinstalledinaccordancewitharticle760ofTheNationalElectricalCodeaswellasNFPA72andall
applicableLocalCodes.
1. Mountunitinthedesiredlocation. Markandpredrillholesinthewalltolineupwiththetoptwokeyholesinthe
 enclosure.Installtwoupperfastenersandscrewsinthewallwiththescrewheadsprotruding.Placetheenclosure’s
 upperkeyholesoverthetwoupperscrews;levelandsecure.Markthepositionofthelowertwoholes.Removethe 
 enclosure.Drillthelowerholesandinstalltwofasteners.Placetheenclosure’supperkeyholesoverthe two upper
 screws.Installthetwolowerscrewsandmakesuretotightenallscrews(Enclosure Dimensions, pg. 4).
2. SettheFN-300ULXtothedesiredDCoutputvoltagebysettingSW1(Fig. 1, pg. 2, Fig. 2c, pg. 3) to the appropriate
 position(refer to Power Supply Voltage Output Selections chart).
3. ConnectACpower(115VAC60Hz)toterminalsmarked[L,G,N](Fig. 2, pg. 3).Use14AWGorlargerforall
 powerconnections(Battery,DCoutput,ACinput).Use22AWGto18AWGforpower-limitedcircuits
 (ACFail/LowBatteryreporting).
Keep power-limited wiring separate from non power-limited wiring (115VAC / 60Hz Input, Battery Wires).
Minimum 0.25” spacing must be provided.
CAUTION: Do not touch exposed metal parts. Shut branch circuit power before installing or servicing equipment.
There are no user serviceable parts inside. Refer installation and servicing to qualified service personnel.
4. Connectdevicestobepoweredtoterminalsmarked[+DC–](Fig. 2, pg. 3).
Altronix Corp.
14058th St. Brooklyn, NY
OPEN SWITCH
CLOSED SWITCH
Switch Detail
+DC ---
NC C NO NC C NO
+ BAT ---
AC DC Bat
Risk of Fire,
Replace Fuses
As Marked
Opened - 24V
Closed - 12V
AC FailBat Fail
J1
SW1
5A 250V
15A 250V
AC Delay
15
L G N
Fig. 1

- 3 -
5. Measureoutputvoltagebeforeconnectingdevices.Thishelpsavoidpotentialdamage.
6. ForAccessControlapplications,batteriesareoptional.Whenbatteriesarenotused,alossofACwillresultinthe
 lossofoutputvoltage.Whentheuseofstand-bybatteriesisdesired,theymustbeleadacidorgeltype.
 Connectbatterytoterminalsmarked[+BAT–](Fig. 2, pg. 3).Usetwo(2)12VDCbatteriesconnectedinseriesfor
 24VDCoperation(batteryleadsincluded).
7. ConnectappropriatesignalingnotificationdevicestoACFAIL&BATFAIL(Fig. 2a, pg. 3) supervisory relay outputs.
Note:Whenusedinfirealarm,burglaralarmoraccesscontrolapplications,“ACFail”relayshouldbe
 utilizedtovisuallyindicatethatACpowerison.Todelayreport6hourscut“ACDelay”jumper(Fig. 2b, pg. 3).
8. Pleaseensurethatthedoorissecuredwiththeprovidedcamlock.
Wiring:
Use14AWGorlargerforallpowerconnections.
Note:Takecaretokeeppower-limitedcircuitsseparatefromnonpower-limitedwiring(115VAC,Battery).
Maintenance:
Unitshouldbetestedatleastonceayearfortheproperoperationasfollows:
Output Voltage Test:Undernormalloadconditions,theDCoutputvoltageshouldbecheckedforpropervoltagelevel
(refer to Power Supply Voltage Output Specifications chart).
Battery Test:Undernormalloadconditionscheckthatthebatteryisfullycharged,checkspecifiedvoltagebothat
batteryterminalandattheboardterminalsmarked[+BAT–]toensurethatthereisnobreakinthebattery
connection wires.
Note:Maximumchargingcurrentunderdischargeis0.7amp.
Note:Expectedbatterylifeis5years,howeveritisrecommendedchangingbatteriesin4yearsorlessifneeded.
+DC ---
NC C NO NC C NO
+ BAT ---
AC DC Bat
Risk of Fire, Replace Fuses As Marked
Opened - 24V Closed - 12V
AC FailBat Fail
J1
SW1
5A 250V
15A 250V
AC Delay
15
L G N
Door
CAUTION: De-energize unit prior to servicing. For continued protection against risk of electric shock and
fire hazard replace fuse with the same type and rating. Do not expose to rain or moisture.
Battery 1 Battery 2
Green
Lead
Battery connection
(nonpower-limited)
Wire
Strap
(from
Enclosure
toDoor)
115VAC
powermains
non power-
limited
Class 1
Do Not Touch
Exposed Metal Parts
DCOutputtodevices
(power-limited)
Opened - 24V
Closed - 12V SW1
Battery&ACSupervision
Circuit
(power-limited)
NC C NO NC C NO AC FailBat Fail
J1
AC Delay
CAUTION: Optional rechargeable stand-by batteries must match
the power supply output voltage setting.
Keep power-limited wiring separate from non power-limited.
Use minimum 0.25" spacing.
Fig. 2
Fig. 2a
Fig. 2b
Fig. 2c

- 4 -
LED Diagnostics:
Red (DC) Green (AC) Red (BAT) Status
ON ON ON Normaloperatingcondition.
ON OFF ON LossofAC.Stand-bybatterysupplyingpower.
OFF ON OFF NoDCoutput.BatteryTrouble
OFF OFF OFF LossofAC.Dischargedornostand-bybattery.NoDCoutput.
ON ON OFF Batterymissing/Lowbattery.
Terminal Identification:
Terminal Legend Function/Description
L,G,N Connect115VAC60Hz.totheseterminals:Ltohot,NtoNeutral.Donotusethe[G]terminal..
+DC--- 12VDCor24VDC@2.5ampcontinuouspower-limitedoutput.
AC Fail
NC,C,NO
IndicateslossofACpower,e.g.connecttoaudibledeviceoralarmpanel.Relaynormally
energizedwhenACpowerispresent.Contactrating1amp@28VDC.ACorbrownoutfailis
reportedwithin1minuteofevent.Todelayreportingofupto6hrs.,cut“ACdelay”jumperand
reset power to unit.
BatFail
NC,C,NO
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized when DC
powerispresent.Contactrating1amp@28VDC.
+BAT--- Stand-bybatteryconnections.Maximumchargecurrent0.7amp.
Enclosure Dimensions (H x W x D):
13.5”x13”x3.25”(342.9mmx330.2mmx82.55mm)
HochikiAmericaCorp.
7051VillageDrive,Suite100,BuenaPark,CA90621-2268,714-522-2246,Fax:714-690-7890,www.hochiki.com
IIFN-300ULX G02N
1.40”
(36mm)
1.40”
(36mm)
4.85”
(123mm)
4.85”
(123mm)
1.40”
(36mm)
1.40”
(36mm)
5.10”
(130mm)
5.10”
(130mm)
13.0”
(330mm)
5.10”
(130mm)
6.5625”
(167mm)
1.20”
(31mm)
1.20”
(31mm) 1.20”
(31mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
1.0”
(25mm)
1.0”
(
25mm
)
10.5”
(
267mm
)
1.0”
(
25mm
)
1.0”
(25mm)
0.75”
(19mm)
0.75”
(19mm)
0.9375”
(24mm)
0.9375”
(24mm)
11.0”
(279mm)
12.5”
(318mm)
