Hochiki CHQ-BS Installation manual
CHQ-BS -Programming Lead Instructions
General Description
The enclosed lead must be used for addressing
CHQ-BS if they are selected as Wall Sounders.
Operation-Address Setting
To program a CHQ-BS connect the black croc
clips to the left hand terminal on the TCH-B100
address programmer and to the C terminal of the
Base Sounder and the red croc clips to the right
hand terminal of the TCH-B100 address
programmer and to the L terminal on the Base
Sounder. The address can now be programmed in
the same way as an ASX range sensor. Please
note that when programming CHQ-BS the
maximum address permissible is 254. CHQ-
BS/Control Panel instructions should be
checked for address range.
Caution
qOnly to be used with Hochiki Loop devices.
qDo not short croc clips together.
qRemove from programmer when not in use.
qDisconnect Sounders from the loop before
programming.
DSO174/ISS1/FEB 1998
Black Clips
Red Clips
2-3-0-325
Hochiki Europe (UK) Limited, Grosvenor Road,
Gillingham Business Park, Gillingham, Kent, ME8 0SA.
Telephone: 01634-260133 Facsimilie: 01634-260132
E-mail : [email protected]
CHQ-BS PROGRAMMING LEAD -PL1
U.K Manufactured Product
