Hochiki VoiceNET Installation guide

TRAINING
High Rise Voice
Evacuation System
VoiceNET
firealarmresources.com

FNV Technical Training Manual
Table of Contents
Section 1
Overview of FNV Voice Evacuation System
1.1 What is Voice Evacuation ?
1.2 FNV System Data Sheet
1.3 System Capabilities
1.4 Typical Riser Diagram
1.5 Master Panel
1.5.1 MP32 Front Panel and Internal View
1.5.2 MP32/P Front Panel and Internal View
1.5.3 Master Panel Minimum and Maximum Configurations
1.6 Distributed Panel
1.6.1 DP25 Internal View
1.6.2 Four Class “B” Speaker Lines
1.6.3 Eight Class “B” Speaker Lines
1.6.4 Four Class “A” Speaker Lines
1.6.5 Four Dual Class “B” Speaker Lines
1.6.6 DP25/P Internal View
1.6.7 FPI and Phone Connection Details
1.6.8 AMI and Amplifier Connection Details
1.6.9 MBK Mounting
1.7 NetComm Loop Wiring
1.7.1 Style 4 Single Loop Network Wiring
1.7.2 Style 7 Redundant Loop Network Wiring
1.8 Single Channel and Dual Channel Systems
1.9 Specifying the FNV System
1.9.1 8-Story Building
1.9.2 32 Story Building
1.9.3 14 Story Building Retrofit
Section 2
FNV Programming Guide
Section 3
System Configuration
3.1 FNV Job Quotation Form
3.2 System Configuration Form
Section 4
FNV System Description
firealarmresources.com

4.1 Purpose and Capabilities
4.2 Master Panel
4.3 Distributed Panel
4.4 FNV Panel Components
4.4.1 DCC Data Communications Controller
4.4.2 ASC Audio System Control
4.4.3 MMC Master Microphone Controller
4.4.4 MFP Master Fire Phone
4.4.5 FPI Fire Phone Interface
4.4.6 MBR Mother Board Remote
4.4.7 MBK Mother Board Relays
4.4.8 AMI Audio Module Interface
4.4.9 II Input Interface
4.4.10 SSC Switch Scan Card and SLC Switch LED Card
4.5 A Typical FNV System
4.6 FNV System Accessories
4.6.1 FO Fiber Optic Transceiver
4.6.2 ISO Serial Port Isolator
4.6.3 LLC LED Annunciator Card
4.6.4 ZA Class A Adapter
4.6.5 ZAB Dual Class B Adapter
4.6.6 BA Backup Amplifier Switcher
4.6.7 Cab-42 Oversize Cabinet
4.6.8 PWR Power Supply
4.6.9 FJ Fire Jack
4.6.10 FH Fire Handset
4.6.11 TC Handset Cabinet
4.6.12 FS Firephone Station
4.6.13 WS Warden Station
4.6.14 AOR Area of Refuge Station
Section 5
FNV System Commissioning
Section 6
References
6.1 FNV Network Wiring Notes
6.2 RS-485 Specifications
6.3 Fiber Optic Notes
6.4 Speaker DC Supervision
6.5 Temporal Pattern Signals
6.6 Relocation Messages
6.7 Sample FNV Installations
6.8 UL Listings
firealarmresources.com

1.1 What is Voice Evacuation ?
Voice evacuation is used to make emergency voice announcements to people inside a
building. The system operates when a fire condition is detected, telling people to
evacuate the building. This is accomplished with a microphone, amplifier, and speakers,
which will sound an alarm tone, and then the building manager or fire department keys
the microphone and broadcasts instructions. “The fire alarm system has been activated.
Walk to the nearest exit and leave the building immediately.”
Voice messages are very effective in convincing people to take action in an emergency.
Many people will ignore bells or horns but will move when a human voice is telling them
what to do. This has been repeatedly proven in numerous studies by universities and
public safety agencies.
The Hochiki FNV system provides this voice evacuation function and much more.
Evacuating a high-rise building poses major challenges. Elevators are needed for fire
department use, and huge numbers of people scrambling down stairwells is slow, can
cause panic, and block firefighters from climbing up the stairs.
FNV was designed and purpose-built to address the complex problems in providing life-
safety for people in skyscrapers and other large structures.
Life-safety evac systems must be much more than speakers and amplifiers. First, they
must be supervised so that building management is immediately notified when a problem
occurs, such as a broken wire, or critical component failure. Second, they must be
Approved and Listed for use as life safety systems.
Hochiki FNV equipment is tested to tough standards such as Underwriters Laboratories
(UL), and meets strict standards and codes, such as the National Fire Protection
Association (NFPA).
firealarmresources.com

Features:
Description:
True Multiplex 6 Channel Distributed Audio
Modular System - components added as needed
Integrated 2 Channel Digital Message Repeater
Live Microphone Page to any zone
Fast RS-485 Communication Protocol
Easy Installation and Operation
Natural Sound Voice Recordings
Built in Alarm and Alert Signals
Up to 4 Minute Message Capacity
Works with 12VDC or 24VDC Fire Alarm Panel
Works with Analog/Addressable and
Microprocessor based Fire Alarm Panels.
3 Minute Message Restart on Microphone Key
Made in the USA.
Fully Supervised
The Hochiki FNV High Rise Evacuation System
operates in conjunction with the Fire Alarm Control
Panel (FACP) in a building to provide automatic
response to life safety emergencies.
The Hochiki FNV includes all necessary features
to provide an effective voice evacuation system.
The Hochiki FNV can be custom configured to
satisfy the needs of any high rise application.
Fire department authorities can easily take
command of evacuation or relocation procedures
and emergencies. Building management and fire
brigades can monitor and control emergency
response even before the professionals arrive
The FNV system includes capacity for 6 channels
of simultaneous audio. This provides for
evacuation, stay-in-place, or other public address
announcements and automatic messages.
Fire Fighter Phones or Warden Stations may be
included as required.
System Configuration:
Basic System Includes:
Master Panel (FNV-MP)
Master Mic Control
16 switch control points
Dual Channel DMR
High speed communication loop
Distributed Panel (FNV-DP)
4 Output Zones (may be configured for 8)
Dual Channel Audio Interface
Dual Channel Amplification
Optional
Integrated Fire Phone
Area-of-Rescue (Future Option)
Fan and Damper system control (Future Option)
Number of distributed panels to be
determined by building specifications
Maximum System Configuration
Up to 250 Distributed Panels (FNV-DP)
And up to 1000 monitor and control points
PAGING
CONTROL
SYSTEM
RESET
PAGE
ALL-CALL
FAULT
SILENCE
LISTED
1.2
VoiceNET
High Rise Voice
Evacuation System
7051 Village Drive, Suite 100 Buena Park, CA 90621-2268 714.522.2246 www.hochiki.com
firealarmresources.com

Hochiki FNV
True-Multiplex
System
Capabilities
NetComm Loop:
-Twisted Pair, Low Cap
-4,000 Feet between panels
(130 / 70,000pF max between panels)
-50,000 Feet Total System Loop
-Data and 6 Audio Channels Simultaneously
-High Speed RS-485 Communications
-Style “4” or Style “7” Field Selectable
W
Head End Control
FNV-MP
Master Panel
TB1
TB3
TB2 TB1
TB3
TB2
Fire Phone
#22 AWG Twisted Pair
FNV-DP
Distributed Panel
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
TB1
TB3
TB2 TB1
TB3
TB2
Fire Phone
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
TB1
TB3
TB2
TB1
TB3
TB2
TB1
TB3
TB2
TB1
TB3
TB2
Voice Evacuation
Speaker Circuits
Fire Phone
Fire Phone
FNV-DP
Distributed Panel
FNV-DP
Distributed Panel
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
TB1
TB3
TB2
TB1
TB3
TB2
TB1
TB3
TB2
TB1
TB3
TB2
Voice Evacuation
Speaker Circuits
Fire Phone
#18 AWG typ.
FF
II
RR
EE
FF
II
RR
EE
Fire
Phone
Fire
Phone
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
Fire
Phone
Fire
Phone
Fire
Phone
Fire
Phone
Fire
Phone
Fire
Phone
PAGING
CONTROL
SYSTEM
RESET
PAGE
ALL-CALL
FAULT
SILENCE
1.3
firealarmresources.com

RS 485
DATA LO OP
S
P
FNV-DP S
S
P
S
S
P
S
S
P
S
Basement
1st Floor
2nd Floor
4th Floor
5th Floor
3rd Floor
6th Floor
7th Floor
8th Floor
9th Floor
10th Floor
11th Floor
S
P
FNV-DP S
S
P
S
S
P
S
S
P
S
S
P
FNV-DP S
S
P
S
S
P
S
S
P
S
Hochiki FNV
High Rise Multiplex
11 Floor Typical Riser Diagram
FNV-MP
SP
Speaker Fire Fighter Phone Jack
1.4
firealarmresources.com

FNV-MP32 (Master Panel)
Front Panel View
PAGING
CONTROL
SYSTEM
RESET
PAGE
ALL-CALL
FAULT
SILENCE
1.5.1
firealarmresources.com

TB1TB1 TB2TB2
TB3TB3 TB4TB4 TB5TB5P1P1
P2P2
P3P3
P4P4
J1J1
11
22
33
LED3LED2LED1
TB1
P4
P3
P1
P2
P5
P5
DCC ASC
PWR-2A
31
2
21
TB2
TB3
TB1
321
FNV-MP32 (Master Panel)
Internal View
DCC ASC
SSC
firealarmresources.com

FNV-MP32/P (Master Panel)
Front Panel View
PAGING
CONTROL
SYSTEM
RESET
PAGE
ALL-CALL
FAULT
SILENCE
1.5.2
firealarmresources.com

P3
LED1
P2
MFP
P1
x
x
x
x
MFP
FNV-MP32/P
Internal View
TB1
P4
P3
P1
P2
P5
P5
ASC
PWR-2A
31
2
21
TB2
TB3
TB1
321
TB1TB1 TB2TB2
TB3TB3 TB4TB4 TB5TB5P1P1
P2P2
P3P3
P4P4
J1J1
11
22
33
LED3LED2LED1
DCC
DCC ASC
SSC
I/O
Card
IOI
TB1 TB2
firealarmresources.com

FNV-MP16 FNV-MP144
FNV-MP16/P FNV-MP112/P
PAGING
CONTROL
SYSTEM
RESET
PAGE
ALL-CALL
FAULT
SILENCE
PAGING
CONTROL
SYSTEM
RESET
PAGE
ALL-CALL
FAULT
SILENCE
PAGING
CONTROL
SYSTEM
RESET
PAGE
ALL-CALL
FAULT
SILENCE
Min / Max Panel
Configurations
PAGING
CONTROL
SYSTEM
RESET
PAGE
ALL-CALL
FAULT
SILENCE
1.5.3
firealarmresources.com

PAGING
CONTROL
SYSTEM
RESET
PAGE
ALL-CALL
FAULT
SILENCE
FNV-MP272/P
firealarmresources.com

TB1
TB3
TB2
1 2 3 45 6 7 8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10
11
MESSAGE
GAIN
MIC
GAIN
FAULT
NORMAL
ALARM
YEL
GRN
RED
J2
1 2 3
J1
P2
S1
SN1
TB1
TB3
TB2
1 2 3 45 6 7 8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10
11
MESSAGE
GAIN
MIC
GAIN
FAULT
NORMAL
ALARM
YEL
GRN
RED
J2
1 2 3
J1
P2
S1
SN1
DCC
TB1 TB2
TB3
TB4 TB5
P1
P2
P3
P4
J1
1
2
3
LED3LED2LED1
DCC
MBR
TB2 TB3 TB4
TB5
TB6
TB7
TB8
1 2 3 4
TB1
1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4
1 2 3 41 2 3 4 1 2 3 4 1 2 3 4
AMI MBK
FNV-25E FNV-25E
FNV-DP25
Internal View
8 “B”
4 “A”
1.6.1
firealarmresources.com

MBR
TB2 TB3 TB4
TB5
TB6
TB7
TB8
1 2 3 4
TB1
1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4
1 2 3 41 2 3 4 1 2 3 4 1 2 3 4
A M I M B K # 1
4
321
EOLR
EOLR
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
Standard Life Safety Speakers,
Strobes connected and powered separately
E
O
L
E
O
L
4 CLASS “B” OUTPUTS
One AMI card and one MBK card
installed on MBR.
FOUR CLASS “B” SPEAKER LINES
1
2
3
4
8 “B”
4 “A”
1.6.2
firealarmresources.com

MBR
TB2 TB3 TB4
TB5
TB6
TB7
TB8
1 2 3 4
TB1
1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4
1 2 3 41 2 3 4 1 2 3 4 1 2 3 4
A M I M B K # 1
45678
3
21 EOLR
EOLR
EOLR
Standard Life Safety Speakers,
Strobes connected and powered separately
E
O
L
E
O
L
E
O
L
M B K # 2
EIGHT CLASS “B” SPEAKER LINES
1
2
3
4
5
6
7
8
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
.
.
.
.
.
Second FNV-MBK card provides additional speaker circuits
May be configured as several options
8 “B”
4 “A”
1.6.3
firealarmresources.com

MBR
MBR
TB2
TB2
TB3
TB3
TB4
TB4
TB5
TB5
TB6
TB6
TB7
TB7
TB8
TB8
1 2 3 4
1 2 3 4
TB1
TB1
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4 1 2 3 41 2 3 4 1 2 3 41 2 3 4 1 2 3 41 2 3 4 1 2 3 4
A M IA M I M B K # 1M B K # 1 M B K # 2
M B K # 2
4
1
2
3
4
3
2
1
1
A
2
A
3
A4
A
1
B
2
B
3
B4
B
FOUR CLASS “A” SPEAKER LINES
FOUR A/B CLASS “B” SPEAKER LINES
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
EOL EOL
EOLR
EOLR
E
O
L
E
O
L
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
Standard Life Safety Speakers,
Strobes connected and powered separately
Standard Life Safety Speakers,
Strobes connected and powered separately
1A
1B
4A
4B
First Floor Speakers
Fourth Floor Speakers
One zone per floor, speakers
on alternate wire pairs.
EOLR
EOLR
E
O
L
E
O
L
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
FF
II
RR
EE
8 “B”
4 “A”
8 “B”
4 “A”
1.6.4
1.6.5
firealarmresources.com

TB1
TB3
TB2
1 2 3 45 6 7 8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10
11
MESSAGE
GAIN
MIC
GAIN
FAULT
NORMAL
ALARM
YEL
GRN
RED
J2
1 2 3
J1
P2
S1
SN1
TB1
TB3
TB2
1 2 3 45 6 7 8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10
11
MESSAGE
GAIN
MIC
GAIN
FAULT
NORMAL
ALARM
YEL
GRN
RED
J2
1 2 3
J1
P2
S1
SN1
DCC
TB1 TB2
P1
P2
P3
P4
J1
1
2
3
LED3LED2LED1
DCC
MBR
TB2 TB3 TB4
TB5
TB6
TB7
TB8
1 2 3 4
TB1
1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4
1 2 3 41 2 3 4 1 2 3 4 1 2 3 4
A M I F P I # 1 M B K #1
FNV-25E FNV-25E
FNV-DP25/P
Internal View
Addition of the FNV-FPI
card enables fire phone
communication circuits
By changing amp modules to 50W units would create a FNV-DP50/P
8 “B”
4 “A”
1.6.6
firealarmresources.com

MBR
TB2 TB3 TB4
TB5
TB6
TB7
TB8
1 2 3 4
TB1
1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4
1 2 3 41 2 3 4 1 2 3 4 1 2 3 4
4321
Supervised
Power Limited
1
2
3
4
FNV-DP25/P
Phone Connection Detail
Fire Phone
Handset
Jack
Fire Phone
Handset
Jack
Fire Phone
Handset
Jack
Fire Phone
Handset
Jack
10K 1/2W
EOLR
10K 1/2W
EOLR
Fire Phone Loop
Fire Phone Loop
* Maximum line resistance = 50 Ohms
* Maximum line resistance = 50 Ohms
A M I F P I # 1 M B K #1
8 “B”
4 “A”
1.6.7
firealarmresources.com

Fire Phone
Handset
Jack
Fire Phone
Handset
Jack
TB1
TB3
TB2
1 2 3 45 6 7 8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10
11
MESSAGE
GAIN
MIC
GAIN
FAULT
NORMAL
ALARM
YEL
GRN
RED
J2
1 2 3
J1
P2
S1
SN1
TB1
TB3
TB2
1 2 3 45 6 7 8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10
11
MESSAGE
GAIN
MIC
GAIN
FAULT
NORMAL
ALARM
YEL
GRN
RED
J2
1 2 3
J1
P2
S1
SN1
DCC
TB1 TB2
P1
P2
P3
P4
J1
1
2
3
LED1
DCC
MBR
TB2 TB3 TB4
TB5
TB6
TB7
TB8
1 2 3 4
TB1
1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4
1 2 3 41 2 3 4 1 2 3 4 1 2 3 4
A M I F P I # 1 F P I # 2 M B K #1
FNV-25E FNV-25E
FPO
Fire Phone
Handset
Jack
5
6
7
8
FNV-DP25/P
w/ FPI and FPO
Eight circuit detail
Fire Phone
Handset
Jack
10K 1/2W
EOLR
10K 1/2W
EOLR
The addition of an FPI / FPO
combination brings up an
additional 4 Fire Phone circuits
Maximum of 12 circuits in a
Distributed Panel
8 “B”
4 “A”
firealarmresources.com
