Hochiki CHQ-WS2 User manual

2-3-0-626/ISS6/MAY11
HOCHIKI WALL SOUNDER & WALL SOUNDER BEACON
INSTALLATION INSTRUCTIONS
Products Covered: CHQ-WS2 / CHQ-WS2(WHT) Wall Sounders, CHQ-WSB / CHQ-WSB(WHT) Wall Sounder
Beacons, YBO-R/3(RED / YBO-R/3(WHT) Standard Bases, YBO-R/SCI(RED) / YBO-R/SCI(WHT-SNDR)
Isolator Bases.
Introduction
The CHQ-WS2 is a loop-powered addressable wall sounder. The CHQ-WSB is a loop-powered addressable wall
sounder beacon. Both units are compatible with the standard red mounting base (YBO-R/3(RED)) and the red
isolator base (YBO-R/SCI(RED)); the units have connections for both these types of base. Do not attempt to use
any other base type with these units. Both sounders and bases are also available in WHITE (see above).
Both the CHQ-WS2 and CHQ-WSB are Ingress Protection rated to IP21 for internal use, but can be made
weatherproof when used in conjunction with the WS2-WPK Weather Proofing Kit, in which case they are Ingress
Protection rated to IP65*1but only when used in accordance with the WS2-WPK instructions (2-3-0-627).
Address Setting (with Hand Held Programmer)
The units will need to be manually addressed between 1 and 127. The sounder address can be set using the Hand
Held programmer (TCH-B100) as the units both include the appropriate terminals to fit directly onto the
Programmer. See the TCH-B100 instructions for further details of address setting. The address must be set
before installation.
Tones and Volumes
Table 1 below shows the full range of sound outputs available from the CHQ-WS2 and CHQ-WSB together with
the amount of current drawn when operated. The units are also capable of utilising a number of different EN54-3
Approved tones; these are listed in Table 2, page 3. The tone of the sounder and the volume level is selected
and controlled by the control panel, therefore check with the control panel manufacturer for options and
default values available. The sounder and beacon elements of the CHQ-WSB can be controlled
independently, check with the control panel manufacturer for compatibility.
Table 1 CHQ-WS2 / CHQ-WSB
(sounder activated)
CHQ-WSB
(sounder & beacon activated)
Nominal Sound Output dB(A)*2 ‡ Current Drawn mA
90 2.0 7.0
95 3.0 8.0
98 4.5 8.5
100 6.5 11.5
102 8.0 13.0
*2Refer to Application Notes AP084 and AP117 (available from our website) for complete EN54-3 A-weighted sound levels.
‡ @ 1m distance.
Precautions
Ensure that the unit is installed in accordance with Local Standards or Regulations.
Only use the specified Hochiki mounting bases (or WS2-WPK Weather Proofing Kit) with this wall
sounder/wall sounder beacon.
Only install in suitable environments, the following in particular should be avoided: -
Excessive ambient temperature.
Where excessive condensation or moisture is present (unless WS2-WPK is utilised).
Hazardous areas.
A high voltage tester must not be used with these units or either of the specified bases.
Ensure that the unit is securely fixed to the mounting base (and WS2-WPK if utilised).
For proper wiring supervision ensure that the cables are wired as shown in Fig 4.
Locking Mechanism
The units can be locked onto the relevant mounting base by removing a plastic lug on the underside of the
sounder, refer to Fig. 1.
*1This product has only been approved to IP33 by LPCB

2-3-0-626/ISS6/MAY11
The unit can then only be removed from the base by using a special
removal tool, TSE-SRT, which is available from Hochiki Europe
(UK) Ltd.
Installation
Both the CHQ-WS2 wall sounder and the CHQ-WSB Wall Sounder
Beacon are designed to be mounted directly onto the Red Standard
Mounting Base (YBO-R/3(RED)) or the Red Short-Circuit Isolator
Mounting Base (YBO-R/SCI(RED)) in the same method as a Sensor
(see Fig. 2). The terminals on the mounting base hold the units in
place.
Remove tab carefully using a pair of pliers.
Fig. 1
Fix the mounting base to the required surface using appropriate
fixings. For correct wiring of the each base type, refer to Fig. 4.
When installing either of these units in exterior locations use the
WS2-WPK Weather Proofing Kit. The kit consists of a
weatherproof back box and two gaskets, which must be used in
conjunction with either mounting base to maintain the IP rating
(see Fig. 3). For further information, refer to the WS2-WPK
Weather Proofing Kit instructions (2-3-0-627).
Wiring
Please refer to Fig. 4 for wiring the Red Standard Mounting Base
(YBO-R/3(RED)) and the Red Short-Circuit Isolator Mounting Base
(YBO-R/SCI(RED)):
Fig. 2
Fig. 3
Key: A: Loop (+) B: Loop (-) C: Cable Screen
Fig. 4
0832-CPD-0455
0832-CPD-1247
09
EN54-3 Alarm Devices –
Sounder
CHQ-WS2
CHQ-WSB
Protocol specified in TI/006
CHQ-WS2 / CHQ-WSB
CHQ-WS2 / CHQ-WSB

2-3-0-626/ISS6/MAY11
CHQ-WS2 Operating Voltage 17 ~ 41 Vd.c.
Table 2
Tone
Number
Tone
Description
Graphic
Representation
Tone
Number
Tone
Description
Graphic
Representation
0 Sounder Off 19 800 Hz : 250 ms
970 Hz : 250 ms
1 925 Hz : 250 ms
628 Hz : 250 ms
20 2850 Hz Continuous
2 925 Hz Continuous
21 2400 Hz : 250 ms
2850 Hz : 250 ms
3 628 Hz Continuous
22 800 Hz : 500 ms
970 Hz : 500 ms
4 (French) 554 Hz : 100 ms
440 Hz : 400 ms
23 2850 Hz : 500 ms
Off : 500 ms
5 (Swedish) 660 Hz : 150 ms
Off : 150 ms
24 925 Hz : 250 ms
Off : 1000 ms
6 925 Hz : 150 ms
Off : 600 ms
25 970 Hz Continuous
7 670 Hz : 250 ms
845 Hz : 370 ms
26 660 Hz : 1800 ms
Off: 1800 ms
8 Whoop 500 Hz - 1200 Hz 3000 ms
Off : 500 ms
27 660 Hz : 6500 ms
Off : 13000 ms
9 1200 Hz : 500 ms
500 Hz : 500 ms
28 660 Hz Continuous
10 970 Hz : 500 ms
Off : 500 ms
29 554 Hz : 500 ms
440 Hz : 500 ms
11 Sweep 800 Hz - 970 Hz
over 140 ms (7 Hz)
30 660 Hz : 500 ms
Off : 500 ms
12 Sweep 800 Hz - 970 Hz
over 1000 ms (1 Hz)
31 2850 Hz : 150 ms
Off : 100 ms
13 Sweep 800 Hz - 970 Hz
over 20 ms (50 Hz)
32 Sweep 2400 Hz – 2850 Hz
over 20 ms (50 Hz)
14 Sweep 2400 Hz – 2850 Hz
over 140 ms (7 Hz)
33 Sweep 800 Hz – 970 Hz
over 500 ms (2 Hz)
15 Sweep 2400 Hz – 2850 Hz
over 1000 ms (1 Hz)
34 988 Hz : 250 ms
645 Hz : 250 ms
16 Sweep 300 Hz – 1200 Hz
over 1000 ms (1 Hz)
35 510 Hz : 250 ms
610 Hz : 250 ms
17 ISO8201 : 970 Hz : 500 ms
36 Sweep 800 Hz – 970 Hz
over 110 ms (9 Hz)
18 ISO8201 : 2850 Hz : 500 ms
37 Sweep 800 Hz – 970 Hz
over 330 ms (3 Hz)

2-3-0-626/ISS6/MAY11
Tone
Number
Tone
Description
Graphic
Representation
Tone
Number
Tone
Description
Graphic
Representation
38 845 Hz Continuous
46 440 Hz : 600 ms
Off : 600 ms
39 970 Hz : 1000 ms
Off : 1000 ms
47 Whoop 500 Hz – 1200 Hz : 3750 ms
Off : 250 ms
40 800 Hz : 150 ms
970 Hz : 150 ms
48 ISO8201 925 Hz, 628 Hz : 250 ms
Off 500 ms
41 Sweep 2400 Hz – 2850 Hz
over 110 ms (9 Hz)
49 ISO8201 : Sweep 300 Hz – 1200 Hz : 500 ms
Off : 500 ms
42 Sweep 2400 Hz – 2850 Hz
over 330 ms (3 Hz)
50 ISO8201 : Sweep 1200 Hz – 300 Hz : 500 ms
Off : 500 ms
43 2850 Hz : 1000 ms
Off : 1000 ms
51 Whoop
500-1200 3.5s/0.5s
44 2400 Hz : 150 ms
2850 Hz : 150 ms
45 (German) Whoop 1200 Hz – 500 Hz : 1000ms
Off : 10 ms
CHQ-WSB Volume Compatibility
Hochiki Europe (UK) Ltd
Grosvenor Road, Gillingham Business Park,
Gillingham, Kent, ME8 0SA, England
Telephone: [phone]
Facsimile: [phone]
Email: [e-mail]
Web: www.hochikieurope.com
Hochiki Europe (UK) Ltd. reserves the right to alter the
specification of its products from time to time without
notice. Although every effort has been made to ensure the
accuracy of the information contained within this document
it is not warranted or represented by Hochiki Europe (UK)
Ltd. to be a complete and up-to-date description. Please
check our web site for the latest version of this document.
YBO-BSB
Setting Corresponding CHQ-WSB Level
Sound Level
dB(A) Current mA Sound Level
dB(A) Current mA*
Off Quiescent
→Off Quiescent
50 0.8
→90 2.0
55 0.8
→90 2.0
60 0.8
→90 2.0
70 0.8
→90 2.0
78 1.5
→90 2.0
80 2.0
→90 2.0
85 3.0
→95 3.0
88 4.5
→98 4.5
90 6.5
→100 6.5
93 8.0
→102 8.0
94 10
→102 8.0
95 11
→102 8.0
If a control panel has not
implemented the CHQ-WSB then
it will be recognised as a YBO-
BSB. The table below shows the
volume level set as a YBO-BSB
and the corresponding level that
is set on the CHQ-WSB by any
panel configuration software that
recognises the CHQ-WSB as a
YBO-BSB.
For example, if 55dB(A) is
selected on the panel for a YBO-
BSB, the actual volume of the
CHQ-WSB will set to 90dB(A).
* Note that this is sounder current only. If
the Beacon is operating please add 5mA to
this value.
These differences in current should be
taken into consideration when calculating
total loop loading.
98 16
→102 8.0
