SecurityMan AVLCD User manual

SecurityMan®
AVLCD
Day/Night Motion/Audio sensor
2.4GHz Wireless LCD Monitoring Kit User Guide
SecurityMan
CH1 CH2
CH3
Channel
Snooze

2
Copyright Notice
This manual is furnished under license and may be used or copied only in accordance with the
terms of such license. Except as permitted by such license, no part of this publication may be
reproduced, stored in a retrieval system, or transmitted, in any form or any means, electronic,
mechanical, recording, or otherwise, including translation to another language or format, without
the prior written permission of SecurityMan.
The content of this manual is furnished for informational use only, is subject to change without
notice, and should not be construed as a commitment by SecurityMan. SecurityMan assumes no
responsibility or liability for any errors or inaccuracies that may appear in this book.
All other product names, trademarks and registered trademarks in this document are the proper-
ties of their respective holders.
FCC Information
Notes on FCC’s “Consistent Statement of Information” This product meet the requirements speci-
fied in Part 15 of FCC Regulation. Operation rests with the following two conditions:
(1) The equipment should not cause any harmful interference.
(2) The equipment must receive and process any interference, including any possible interference
caused by operation mistakes.
After testing the product, we confirm that the camera complies with the provision for class C digital
equipment in the 15th part in FCC regulations; and the receiver complies with the limitations for
class B digital equipment in Part 15 of FCC regulation. The product generates, applies and emits
radio waves. It might cause harmful interferences to wireless communication if not be installed and
used following the description of the manual.
The product may cause interference in residential area, and the customer should take remedies to
eliminate the interference on their own costs.
If the product causes any harmful interference to wireless equipment or disturbs the receiving of
TV signals (it can be identified by turning on and off the product), you can solve the trouble by fol-
lowing methods:
- Readjust the product or put it in another place.
- Extend the distance between the equipment interfered and the product.
- Refer to dealers or experienced radio electrician for help.

3
Warranty
SecurityMan warrants that this product will be free from defects in materials and workmanship for
period of time specified on the product packaging. This limited warranty shall commence from the
date of purchase. SecurityMan Products warranty is not transferable and is limited to the original
purchaser. If the product is found to be defective then, as your sole remedy and as the manufac-
turer's only obligation, SecurityMan will repair or replace the product . This warranty shall not apply
to products that have been subjected to abuse, misuse, abnormal electrical or environmental con-
ditions, normal wear and tear or any condition other than what can be considered normal use.
Limitation of Liability
The liability of SecurityMan arising from this warranty and sale shall be limited to a refund of the
purchase price. In no event shall SecurityMan be liable for costs of procurement of substitute prod-
ucts or services, or for any lost profits, or for any consequential, incidental, direct or indirect dam-
ages, however caused and on any theory of liability, arising from this warranty and sale. These
limitations shall apply not with standing any failure of essential purpose of any limited remedy.
SecurityMan
15861 Tapia Street, Irwindale, CA 91706, USA
Tel: [phone] or 626-338-2028
Fax: [phone]
Email: [email protected]
Website: http://www.securitymaninc.com
Copyright 2006 by SecurityMan v1.1
For Customer Service: 888-977-3777

4
Notice:
2.4Ghz wireless camera works at ISM band. It may cause interferences with
other wireless equipment that operates at the same band. Please turn off one
of the equipment to eliminate the interference.
Product Assurance
2.4Ghz wireless camera will emit electromagnetic wave, just like other wire-
less products. But the output power of the products is lesser than other wire-
less products such as mobile phones. The 2.4Ghz wireless camera meets
wireless frequency security standards and recommend indexes while work-
ing. These standards and indexes are certificated by academic organization
and represent the cogitative research of the scientific workers who continu-
ously explore and annotate the involved fields. So we believe that our prod-
ucts are safe for customers.
Operating Restrictions
DO NOT use this product to violate one's privacy. Monitoring one's activities
without consent is illegal and this product is not designed and manufactured
for these purposes.
DO NOT put this product near any medical equipment. Radio waves might
potentially cause breakdown of electrical medical equipment. This product
should be placed at least 1 feet away from any heart pacemaker. Radio
waves might potentially influence heart pacemaker and lead to respiratory
disturbance.
DO NOT use this product for any illegal activities. SecurityMan shall not be
responsible for any consequences of illegal conducts by users.

5
Conditions
Please read the following messages to make sure whether your working envi-
ronment is suitable.
• Ensure there is enough space around the receiver for ventilation.
• The temperature should be kept between –20˚C and 50˚C (-4F – 122˚F).
The relative humidity should remain from 20% to 80%.
• Avoid putting the product in places where occur might change rapidly in
temperature or humidity
• Keep it dry, dustless and avoid exposure in it directly in sunlight
• Keep product away from heat sources such as electric heater
• Do not use the camera near aggressive chemicals
• Do not place product near any magnetic objects
Maintenance
It might influence the normal operation of the product if used at the fringe
range of normal temperature. Please turn off the power when not in use
Do not disassemble the product.
Do not shake or stricken the product.
Do not use this camera near water- for example, near a bath tub, wash bowl,
kitchen sink or laundry tub, in a wet basement or near a swimming pool; and
the like.
Please obey the local government’s environment protection policy

6
Contents
Introduction 7
Package Contents 7
Technical Support 7
SM-850 Camera Features 8
SM-713 Receiver Features 8
Product Basics 9
Installation Diagram 10
Adapter & Battery 10
Adapter 10
Battery 11
Add-on Battery Pak (optional) 11
Installation 12
Camera Channel Setup 15
Hanging Bracket 15
Alarm Setup 16
Alarm Setting Switch 16
Alarm Indicator 16
Snooze button on Receiver 16
Mode Control Setup 17
Channel Set 18
Channel-Scan Set 18
Alarm Set 18
Night Vision 18
Troubleshooting 19

7
Introduction
Thank you for purchasing AVLCD Day/Night Motion/Audio Sensor
Wireless LCD Monitoring Kit. It consists of a vivid CMOS Color Camera
with night vision (B/W), and a handheld portable design LCD display
Monitor. The Camera converts the video and audio signals into radio sig-
nals and transmits them to the LCD display Monitor.
Note: Please read the manual entirely before using the product.
Package contents:
Wireless Color Camera (SM-850) x 1
2.4GHz Wireless LCD Monitor/Receiver (SM-713) x 1
AV Cable x 1
8V power adapter for Camera x 1
9V power adapter for LCD Monitor/Receiver x 1
Camera hanging bracket and mounting hardware
Technical Support
In U.S.A, please call 1-626-214-2770 or in other areas,
E-mail us at: [email protected]

SM-850 Camera Features:
• Vivid CMOS color camera with night vision (B/W)
• Selectable motion or audio detection triggers recorder alarm
• 3 channels available to avoid possible interference
• Special bracket for desktop and wall-mount
• Up to 300ft. video transmission
(up to 100ft for indoor and up to 300ft for clear line of sight.)
• Built-in microphone for audio detection
• No pet motion false alarm
SM-713 Receiver Features:
• Handheld portable design
• 2.5" LCD display with 480x234 resolution
• Channel-scan function support up to 3 cameras
• Frequency lock function
• Built-in speaker
• Foldable desktop stand
• Video out for recorder
8

Product Basics
ON
OFF ALARM ON
ALARM OFF
123L
VIDEO OUT
DC9V
ON/OFF BRIGHE MIN MAX
LCD
Screen
Mode
Control
LCD Monitor/Receiver
Alarm
Snooze
Button
Channel
Button
Speaker
Speaker
Barcket
Power
ON/OFF
DC
Power
Jack
Video
Output
Indicator Antenna
Volume
Control
Earphone Jack
Brightness
Control
CH1 CH2 CH3
SNOOZE CHANNEL
DC8V
ON/OFF
Desktop Base
DC Power Jack
IR light
PIR Motion
Sensor
Camera Lens
Power
Indicator
Alarm
Indicator
Camera
Antenna
Power ON/OFF
Alarm Setting Switch
PIR Motion
Sensor
Audio
Sensor
OFF
9

10
Installation Diagram
WARNING: When using power adapter, make sure the voltage indica-
tions on the adapters are compatible to the devices to avoid potential
damages for incorrect usage of power.
Adapter & Battery
Adapter
2.4GHz wireless heat detection monitor kit always conform to the
authenticated AC adapter. The adapter should be marked as follow:
CCC mark
China power
supply Authentication
GS mark
German power
supply Authentication
PES mark
Japan power
supply Authentication
CE mark
European Union power
supply Authentication
SAA mark
Australia power
supply Authentication
UL mark
American power
supply Authentication
Add-on Battery
Box (Optional)
DC Power
OR
DC Power

11
Battery
The camera and receiver could be powered by 4 AAA batteries (includ-
ed) for temporary use.
(Batteries life: SM-850 camera, approximately 1.5hr ;
SM-713 monitor/receiver, approximately 1hr)
Optional Add-on Battery Pak (optional)
The receiver can be powered by rechargeable add-on battery pak.
(optional, not included in the package)
Clip the Add-on Battery
Pak to the slot
Receiver is now
read
y
to use
ON/OFF BRIGHE MIN MAX
ON/OFF BRIGHE MIN MAX
Plug the Add-on Battery Pak jack to the DC9V
jack inside the reciver battery compartment
Add-on
Battery Pak
ON
OFF ALARM ON
ALARM OFF
123L
123
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
Camera Bottom View LCD Monitor/Receiver
Back View
ON
OFF ALARM ON
ALARM OFF
123L

Installation
1) Connect the power jack of adapter (DC 8V 300mA) or insert 4 AAA
batteries to camera. Turn on the power switch, and the red power
indicator light will on.
2) Connect the power jack of adapter (DC 9V 400mA), insert 4 AAA
batteries or attach the add-on battery pak to receiver. Turn on the
power switch, and the red power indicator light will on.
Power Outlet
AAA
AAA
AAA
AAA
LCD Monitor/Receiver
Back View
Add-on
Battery Pak
(Optional)
ON
OFF ALARM ON
ALARM OFF
123L
ON/OFF BRIGHE MIN MAX
Power Outlet
AAA
AAA
AAA
AAA
Camera Bottom View
12

3) Set the camera to desired Channel, and place the camera at
desired location.
4) Press the Channel button on the receiver until the Channel LED
indication match to the channel on the corresponding camera, and
the LED monitor will display pictures. If you cannot set the channel
by pressing the Channel button, please check the settings of mode
control. (Please refer to Mode Control Setup section for more detail)
ON
OFF ALARM ON
ALARM OFF
123L
CH1 CH2 CH3
SNOOZE CHANNEL
Channel button Control Mode
Push
Push
DC8V
ON/OFF
DC8V
ON/OFF
123
CH1: 2,414MHz
CH2: 2,432MHz
CH3: 2,468MHz
PIR Motion
Sensor
Audio
Sensor
OFF PIR Motion
Sensor
Audio
Sensor
OFF
13

14
5) Adjust the brightness and volume control to get satisfied effect.
6) Receiver can also be powered by an add-on battery pak (optional) for
portable usage. The add-on battery pak can be recharged individually
by connecting the adapter (DC 9V 1500mA) directly to the battery pak
itself, with or without removing the battery pak from receiver.
ON/OFF BRIGHE MIN MAX
Power Outlet Power Outlet
ON/OFF BRIGHE MIN MAX
Volume
Control
Brightness
Control

Camera Channel Setup
The camera has 3 selectable channel to avoid possible interference from
other nearby wireless devices.
Hanging Bracket
The camera can be mounted on the wall by using the hanging bracket in
the package. However, the hanging bracket does not include power
switch, therefore, power switch function for the camera will be disabled.
Push
Push
DC8V
ON/OFF
DC8V
ON/OFF
1234
Hanging Bracket
PIR Motion
Sensor
Audio
Sensor
OFF PIR Motion
Sensor
Audio
Sensor
OFF PIR Motion
Sensor
Audio
Sensor
OFF PIR Motion
Sensor
Audio
Sensor
OFF
Push
Push
DC8V
ON/OFF
DC8V
ON/OFF
123
CH1: 2,414MHz
CH2: 2,432MHz
CH3: 2,468MHz
PIR Motion
Sensor
Audio
Sensor
OFF PIR Motion
Sensor
Audio
Sensor
OFF
15

16
Alarm Setup
The camera provides either Heat-detection or Voice-detection alarm. You
can change alarm method via the alarm setting switch.
Alarm Setting Switch
Alarm Indicator
Snooze Button on Receiver
The receiver provides alarm beep when the camera detect motion or
noise, and alarm beep will last 9 seconds. You could press the “SNOOZE”
button on the receiver to temporarily stop the alarm from beeping for 30
seconds before it comes back on. Note: if you want to completely turn off the
alarm beep, set the alarm setting switch on the camera to” OFF”.
CH1 CH2 CH3
SNOOZE CHANNEL
SNOOZE
Alarm
Indicator
Green
The alarm indicator will light green when
you select “PIR Motion Sensor” or when
the camera detected the body motion.
Red
The alarm indicator will light red when you
select “Audio Sensor” or when the camera
detected noise.
PIR Motion Sensor
Camera will be set as Heat-detection alarm
Audio Sensor
Camera will be set as Voice-detection alarm
OFF
Camera will set as no alarm function
PIR Motion
Sensor
Audio
Sensor
OFF
Default Setting
PIR Motion
Sensor
Audio
Sensor
OFF

17
Mode Control Setup
The receiver can support up to 3 cameras working at the same time. You
can adjust the mode control to set the working status as described
below. The mode control has the highest priority.
ON
OFF ALARM ON
ALARM OFF
1
1- ON: CH1 Enable (Default)
OFF: CH1 Disable
2- ON: CH2 Enable (Default)
OFF: CH2 Disable
3- ON: CH3 Enable (Default)
OFF: CH3 Disable
23L
Channel Set
L- ON: Channel-Scan Enable
OFF: Channel-Scan Disable (Default)
Channel-Scan Set
ON
OFF ALARM ON
ALARM OFF
123L
Alarm ON: Alarm beep Enable (Default)
Alarm OFF: Alarm beep Disable
Alarm Set
ON
OFF ALARM ON
ALARM OFF
123L
ON
OFF ALARM ON
ALARM OFF
123L
Mode
Control
ON
OFF ALARM ON
ALARM OFF
123L
Default Setting

Channel Set:
You can confirm which channel is set to receive signal from correspon-
ding camera. (Note: This channel set mode is recommended for channel
setting on the receiver than channel switch.)
Channel-Scan Set:
The Channel-Scan function support multi-camera usage. When the cam-
era turn on, all available channels will display one by one looping in turn
per 5 second. So that you can watch the situation from up to 3 different
cameras via one receiver.
Alarm Set:
You can set the switch to “Alarm OFF” to disable the beeping function of
receiver when you do not need it.
Night Vision
The built-in 8 Infra-red lights in camera provide night vision for 24hrs sur-
veillance. The Infra-red lights will be automatically activated in dark night
or places without light in about 10ft range. The picture will turn to Black &
White (monochrome) in Night Vision status.
Built-in IR lights for about
10ft Night Vision Range
18

19
Troubleshooting
EU Environmental Protection
Waste electrical products should not be disposed of
with household waste. Please recycle where facili-
ties exist. Check with your Local Authority or retailer
for recycling advice.
Abnormal Phenomena Possible Reasons/Solutions
*Check the camera / receiver
connected to power supplies,
and power on.
*Check if the channel of receiver
is corresponding to camera;
*Check the distance and blocks.
*Interfered by other sources;
*Check the distance and blocks.
*Mismatching system of PAL TV
and NTSC cameras or vice versa.

www.securitymaninc.com
