HOFEINZ VS1101 User manual

1011SV:ledoM
Instruction Manual

- 1 -
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that product heat.
9. AC adapter is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the AC
adapter should be disconnected from the mains socket outlet completely.
10. Only use attachments/accessories specified by the manufacturer.
11. Use only with a cart, stand, tripod, bracket, or table recommended by
the manufacturer, or sold with the product. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
12. Unplug this apparatus during lightning storms or when unused for a
long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
14. This appliance shall not be exposed to dripping or splashing water and that no object filled
with liquids such as vases shall be placed on the apparatus.
15. Do not overload wall outlet. Use only power source as indicated.
16. Use replacement part as specified by the manufacturer.
17. Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks.
18. Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your home,

- 2 -
consult your product dealer or local power company.
19. Object and Liquid Entry - Never push objects of any kind into this product through openings
as they may touch dangerous voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.
20. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
•If liquid has been spilled, or objects have fallen into the product,
•If the product has been exposed to rain or water,
•If the product does not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive work
by a qualified technician to restore the product to its normal operation.
•If the product has been dropped or damaged in any way, and
•When the product exhibits a distinct change in performance - this indicates a need for
service.
21. Excessive sound pressure from earphones and headphone can cause hearing loss
22. Minimum distances of 10 cm aroundthe apparatus for sufficient ventilation.
23. The ventilation should not be impeded by covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
24. No naked flame sources, such as lighted candles, should be placed on the apparatus.
25. The use of apparatus in moderate climates.
26. The Rating Plates are located at the bottom enclosure of the turntable and rear enclosure
of the speaker units.
SAVE THESE INSTRUCTIONS
COMPLIANCE WITH FCC REGULATIONS
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1)
This device may not cause harmful interference, and
(2)
This device must accept any interference received, including interference that may
cause undesired
operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful
interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the
interference by one or more of the following measures:
�
Reorient or relocate the receiving antenna.
�
Increase the separation between the equipment and receiver.
�
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
�
Consult the dealer or an experienced radio/TV technician for help.
WARNING
Changes or modifications not expressly approved by the party responsible for compliance
could void the
user‟s authority to operate the equipment.

- 3 -
PROTECT YOUR FURNITURE!!
The Turntable and Speakers of this system are equipped with non-skid rubber ‘feet’ to prevent the
product from moving when you operate the controls. These ‘feet’ are made from non-migrating rubber
material specially formulated to avoid leaving any marks or stains on your furniture. However certain
types of oil based furniture polishes, wood preservatives, or cleaning sprays may cause the rubber
‘feet’ to soften, and leave marks or a rubber residue on the furniture. To prevent any damage to your
furniture we strongly recommend that you purchase small self-adhesive felt pads, available at
hardware stores and home improvement centers everywhere, and apply these pads to the bottom of
the rubber ‘feet’ before you place the product on fine wooden furniture.
CONTENTS OF YOUR PRODUCT
Turntable unit x 1 set
Detachable Dust Cover x 1 pc
45 RPM Adapter x 1 pc
Line Out Cable (with RCA plugs) x 1 set
AC Adapter for Turntable (DC9V 1.5A ) x 1 pc
User Manual x 1 set
LOCATION OF CONTROLS
TURNTABLE UNIT (TOP VIEW)
1)45rpm Aaptor
2)Turntable Platter
3)Control Panel
4)Transit Screw
5)Cue Lever
6)Speed Selector
7)Tonearm Holder
8)Headshell
9)Volume Control

Location of Controls
4
9)POWER button
10)USB-MP3 button
PHONO-REC button
DN/FR button
PLAY/PAUSE button
14) UP/FF button
15)BT button
16)PHONO/AUX button
17)BT Indicator
18)PHONO/AUX Indicator
19)USB Socket
20)USB Indicator
21)ON Indicator
Control Panel
Back Panel
1)3.5mm Aux in Socket
2)3.5mm RCA Lineout Socket(R)
3)3.5mm RCA Lineout Socket(L)
4) DC Power Socket
81 71
1912 02
10
915
16
11 12 13 14

- 5 -
IMPORTANT NOTES
DO NOT INSTALL the unit in locations described below:
POWER SOURCE
This Unit is designed to only operate on AC adapters (included) that run on normal 120V~ 60Hz
household power. Do not attempt to operate the unit using any other power source. You could cause
damage to the unit and void your warranty.
GETTING STARTED
SETTING UP THE PHONO TURNTABLE
1.
Install the DETACHABLE DUST COVER by aligning the hinges to the dedicated sockets on the
Turntable unit and snap in fully.
2.
Remove the cable tie securing the TONEARM.
3.
Remove the original protective plastic cover from the STYLUS and keep it for replacement after
playing records or before changing the CARTRIDGE in future.
CABLE CONNECTION
1.
Plug the smaller AC Adapter (DC9V 1.5A) into the DC Jack of the Turntable unit.
SCREW
TURNTABLE UNIT OPERATION
1. Press the POWER BUTTON once to switch ON the Turntable unit.
2. Press the PHONO/AUX to select PHONO function.
Corresponding indicator will light.
PLAYING VINYL RECORDS
1. Set the POWER on and press ‘PHONO/AUX’, the PHONO/AUX indicator will light.
2. Remove the original plastic stylus protector from the STYLUS and release the Locking Clip of the
TONEARM HOLDER to free the TONEARM.
3. Set the SPEED SELECTOR to 33 or 45 rpm according to the record requirement.
4. Place the included 45 RPM ADAPTER over the CENTER SPINDLE when playing 45
records.
5. Raise the TONEARM using the CUE LEVER and move the TONEARM to the beginning of the
record or to the beginning of a particular track. Use the CUE LEVER to lower the TONEARM
STYLUS onto the record to start playing.
6. Adjust the audio output level using the VOLUME CONTROL to obtain a comfortable listening level.
7. The turntable will automatically stop and the TONEARM HOLDER when
the record has finished playing.
8. To stop the record before it ends, lift the TONEARM using the CUE LEVER and return it carefully
to the home position and use the CUE LEVER to lower the TONEARM onto the TONEARM
HOLDER.
9. the original protective plastic onto the STYLUS when not in use.
10. Auto STOP ON/OFF button: when the button is pressed, the turntable is in auto stop mode. The record
the last track of the
will stop automatically when the tone arm reaches the end. When the button is released, the turntable
in manual mode and it will not stop at the end.

- 6 -
Important Notes:
�Do not turn the PLATTER manually or in a counterclockwise direction to avoid damage.
�Moving or jarring the Turntable without securing the Locking Clip of the TONEARM HOLDER
could result in damage to the TONEARM.
ENCODING RECORD TRACKS INTO MP3 FILES
You can convert your favorite vinyl record sound tracks into MP3 files which are saved on a USB Flash
Drive via the USB PORT located on the front panel.
1. Press the “PHONO/AUX" button and the PHONO INDICATOR will light steadily.
2. Set up the vinyl record track that you want to record using the CUE LEVER to position it at the
starting point and suspend playing.
3. Press the “PHONO REC” button.
4. Start playing the selected song you want to record by lowering the CUE LEVER.
5. When the end of the current song is reached, press the PHONO/REC button to stop encoding.
6. To encode more sound tracks, please repeat steps #2 thru #5 above, otherwise all songs on
the vinyl record will be encoded into one single MP3 file.
Note:
The flash drive (not included) must be formatted in FAT32 file system and the maximum supported
capacity is 64GB. High speed flash drives are recommended for smooth encoding.
PLAYING SONGS ON A USB FLASH DRIVE
1. Insert your USB Flash Drive with MP3 songs into the USB PORT located on the front panel.
2. Press USB-MP3 button to start to play the USB. The USB INDICATOR will light.
3. Press PLAY/PAUSE BUTTON to control play/pause.
4. Press SKIP FORWARD BUTTON to skip to next song and SKIP BACKWARD BUTTON
to skip to previous song.
PLAYING SONGS FROM A BLUETOOTH DEVICE
PAIRING A SMARTPHONE OR BLUETOOTH ENABLED DEVICE
1. Press the BT buttonand the BT indicator will light steadily.
2. To establish a new link, turn on the Bluetooth function of your Bluetooth enabled device and
enable the search or scan feature to find ‘BT Turntable’ in the list of discoverable Bluetooth devices.
3. Select the “BT Turntable” from your active device list .neercsstinosraeppatinehw
4. After successfully pairing and connecting your device with ‘BT Turntable” you can now play music
from your Bluetooth enabled device wirelessly to the “VS1101”.
5. Rotate the VOLUME CONTROL on the Active Speaker to increase the listening volume gradually
until a comfortable listening level is reached.
6. Press PLAY/PAUSE BUTTON to control play/pause.
7. Press SKIP FORWARD BUTTON to skip to next song and SKIP BACKWARD BUTTON
to skip to previous song.
TECHNICAL SUPPORT
Technical support:
Please visit www.hofeinz.com then go to Support to find trouble shooting guides and product manual.
Email us:
Please visit www.hofeinz.com then go to Contact Us to email our technical support team. We
will provide unlimited professional support service. All emails will be replied in 24 hrs.
