Hoffer SP3380 Manual

Communicator Controls
Removing the BELT CLIP:
1. Pull the BELT CLIP LATCH away from the unit.
2. While pulling the BELT CLIP LATCH, push up on the BELT CLIP to
remove it from the unit.See Figure 1.
Installing the Belt Clip:
1. Slide the BELT CLIP into the BELT CLIP SLOT.See Figure 2.
2. A "click" indicates the BELT CLIP is locked into position.
Battery Installation: 1. Releasethe BATTERY COMPARTMENT
COVER LATCH located on the rear
side of the unit (see Figure 3) and
remove the BATTERY COMPARTMENT
COVER from the BATTERY
COMPARTMENT (See Figure 4).
2. Install 4x1.5V AAA alkaline batteries
or Ni-MH rechargeable batteries (not
included) as shown.
3. Reinstallthe BATTERY COMPARTMENT
COVER and lock the BATTERY
COMPARTMENT COVER LATCH into
position.
The COMMUNICATOR has a built in POWER SAVER feature for
maximum battery life. But when the COMMUNICATOR is not being
used, conserve battery power by pressing the button to OFF.
Remove the batteries if the unit will not be used for a long period
of time.
LCD Screen:
Operation
Figure 1. Figure 2.
Figure 3. Figure 4.
SCAN  Displayed during CHANNEL SCAN mode.
Press and hold the ENTER button
until the BUTTON LOCK symbol is displayed.
BUSY Displayed when receiving a signal.
Channel Number changes from 1 to 8
as selected by user.
Displays current BATTERY LEVEL.
Displays current VOLUME LEVEL.
DW Displayed during DUAL WATCH mode.
VOX Displayed during VOX mode is on.
Carefully remove your communicator from its Packing. If there is any
visible damage, do not attempt to operate this communicator. Return
it to the place of purchase
Getting Started
COMMUNICATOR MODEL SP3380
OWNER'S MANUAL AND
OPERATING INSTRUCTIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
M
C
BUSY
SCAN
VOX
DW
Turning the Unit ON:
Press and hold the button. The unit will "beep" with dual tone and
the LCD SCREEN will briefly display a SELF-TEST Screen.
Turning the Unit OFF:
Press and hold the button. The unit will "beep" with a signal tone
and the LCD Screen will turn blank.
Adjusting SpeakerVolume:
1. Press the Up button to increase the SpeakerVolume.
2. Press the Down button to decrease the SpeakerVolume.
3. The Speaker Volume level is indicated by the number of bars displayed
in the lower right corner of the LCD Screen.
NOTE: Volume Up and Down buttons are disabled during BUTTON
LOCK mode
Receiving a Signal:
The unit is continuously in the RECEIVE mode when the unit is ON and
not Transmitting.When you receive a signal on the current channel,the RX
icon (BUSY) is displayed.(See "LCD SCREEN" for details).
Transmitting a Signal:
1. Check the channel activity by pressing and holding the MONITOR M
button.You'll hear static if the channel is unoccupied. Don't TRANSMIT
if someone is talking on the channel.Press and hold the PTT button to
TRANSMIT.The TX LED Indicator will light up in red.Hold the unit in a
vertical position with the MICROPHONE 2 to 3 inches from the mouth.
2. While holding the PTT button,speak into the unit using a normal tone
of voice.
3. Release the PTT button when you have finished transmitting.
NOTE: In order for other people to receive your transmission, they must
also be on the same channel you are currently using.Refer to the
"Changing Channels" section for more information.
Changing Channels:
The COMMUNICATOR has 8 available channels.To change channels:
1. Press the MENU button until the current channel number flashes
on the LCD Screen.
2. While the channel number is flashing:
Press the Up button to move to a higher channel.
Press the Down button to move to a lower channel.
The channel changes from 1 to 8,or from 8 to 1.
3. Press the ENTER button to confirm the selected channel and
return to the NORMAL mode.
4. Channel change operations are disabled during BUTTON LOCK
mode.
NOTE: Refer to the "Channel Table" section of this Owner's Manual
for detailed frequency listings.
Monitor:
You can use the MONITOR feature to check for weak signals in the
current channel.
1. Press the MONITOR Mbutton once to activate this function.
2. Rx BUSY icon will display on the LCD Screen while this function is
activated.
3. Press again the MONITOR Mbutton to deactivate the function.
ENTER / Back-light / Button Lock:
1. Press and immediately release the ENTER button to light up
the LCD Screen. The BACKLIGHT will automatically shut off after 4
seconds if no other buttons have been pressed.
2. Press and hold the ENTER button until the BUTTON LOCK icon
is displayed on the LCD Screen.
NOTE: Volume and Channel Change Operations are disabled during
BUTTON LOCK mode.Press and hold the ENTER button
again to deactivate BUTTON LOCK mode.
RX Icon
1. Antenna
2. LCD Screen: Displays current channel selection and other radio
status symbols.
3. Up button (VOLUME/CHANNEL): Press to adjust volume level and
change channels.
4. Down button (VOLUME/CHANNEL): Press to adjust volume level
and change channels.
5. Call Cbutton: Press to transmit CALL TONES.
6. Enter button: Used to turn LCD Screen LAMP ON/OFF Buttons
are locked when pressed and held.
7. Speaker
8. Battery Compartment (LOCATED ON THE REAR): Houses 4 x "AAA"
alkaline or Ni-MH rechargeable batteries (not included).
9. Battery Compartment Cover Latch (LOCATED ON THE REAR):
Secures Battery Compartment cover.
10. Mic: Microphone.
11. Monitor Mbutton: Press to tune in and hold onto weak signals.
12. Menu button: Allows you to change channels.
13. PUSH TO TALK PTT button: Press to transmit.
14. Power On/Off button: Press and hold the button to turn your unit
ON/OFF.
15. TX (Transmission) LED indicator: Illuminates red when transmitting.16.
Sp. /Mic. / Battery Charge Jack
17. Belt Clip (LOCATED ON THE REAR)
Channel Number Battery Indicator
Volume Level
Channel
Scan
Selection
Button Lock
Dual Watch
BUSY
SCAN
VOX
DW
VOX icon

Troubleshooting
Specifications
Battery Level Indicator:
1. The BATTERY LEVEL is indicated by the number of squares present
inside the BATTERY icon on the LCD Screen.
2. When the BATTERY LEVEL is low,the BATTERY icon will flash to indicate
that the batteries need to be replaced.
3.  Do not charge this unit using an AC/DC adapter with regular "AAA"
alkaline batteries installed. Only use optional AC/DC adapter with
"AAA" Ni-MH rechargeable batteries (not included).
Battery Charge Indication
During BATTERY CHARGE mode, the BATTERY indicator will keep
flashing.
NOTE: Please ensure that the unit is turned off during BATTERY CHARGE
mode.
To Charge The COMMUNICATOR
In the event you wish to use the unit with rechargeable batteries (not
Included) you will be required to use an AC/DC adaptor - Input 230
VAC 50 Hz - Output 6 VDC 100MA (not included).
= Insert 4 "AAA" NI-MH rechargeable batteries (not included)
= Turn the unit OFF
= Plug the adaptor into the wall and insert the round end into the
CHARGE JACK marked CHG on the top of the COMMUNICATOR.
= Unplug the adaptor.Turn the unit ON.The BATTERY LEVEL INDICATOR
on the LCD Screen will display the new BATTERY LEVEL.
NOTE: It takes approximately 6 hours to fully charge the batteries if
they are at their lowest level or takes around 14 hours to fully
charge the new batteries.
Dual Watch:
You can use Dual Watch to monitor 2 channels.
To enter Dual Watch mode:
1. Press MENU button 3 times.
2. Press Up and Down buttons to select desired channel.
3. Once Dual Watch is on,automatically scan the channel that between 2
between 2 prefixed channel and the carrier stop on either activated
channel to receive.Dual Watch restarts when the carrier disppears.
4. Press MONITOR Mbutton to monitor weak signal.
5. Press ENTER ,PTT or CALL Cbutton to end the Dual Watch
mode.
Internal VOX Control Function
On VOX mode, automatically transmitting and receiving signals without
pressing any button.
To turn on the VOX function:
1.Press MENU button 4 times to enter the VOX mode;
2.While the VOX icon is flashing;
3.Press Up button to select higher VOX sensitivity;
4.Press Down buttons to select lower VOX sensitivity;
5.Press MENU button twice to confirm the selected mode.
NOTE: 1.The VOX sensitivity is indicated by the number of bars displayed
in the lower right corner of the LCD Screen.
2. You can press the ENTER button twice rapidly to stop
transmitting for 4 seconds and adjust the VOX sensitivity to
lower level if the surroundings is too noisy which cause
transmitting continuously.
To turn off theVOX function:
1.While the VOX icon is flashing,press Down buttons until the number
of bars disappears.
2.Press the MENU button twice to confirm the VOX off mode.
To activate theVOX sensitivity:
1. While the VOX mode is on, plug the connector of the headset (not
included) into SP./MIC jacks of the communicator and then speak
through the microphone of the headset to activate the transmitting
mode.
2.Transmitting mode will turn on automatically and on standby mode.
3.The TX LED indicator illuminates red when transmitting.
NOTE: The VOX sensitivity is automatically activated once plug the
connector of the Headset (not included) into SP./MIC jacks of
the communicator. You don't have to push the PTT button of
the communicator while transmitting.
Second Counter Function:
Use for counter second meter from 00 to 99 seconds.
To enter Second Counter mode:
Press MENU button 5 times to enter Second Counter mode.
While the Second Counter Meter is flashing:
1.Press Up button to run Second Counter continuously;
2.Press Down button to pause the Second Counter.
3.Press MENU button to confirm the second counter and return to the
original default channel automatically;
4.If an active signal is detected while in Second Counter mode,the unit will
return to RECEIVE mode automatically;
To reset the Second Counter meter:
Once enter the Second Counter mode and while it is flashing,press ENTER
button to reset the Second Counter to 00 status and press MENU
button to confirm.
NOTE: The maximum transmission range will vary depending on terrain
and environment.
1
2
3
4
5
6
7
8
446.00625
446.01875
446.03125
446.04375
446.05625
446.06875
446.08125
446.09375
CHANNEL TABLE
CHANNEL NUMBER FREQUENCY (MHz)
Channels Available 8 Channels
Output Power (TX) 0.5W (FCC Maximum)
Battery Life 30 Hours (typical)
Range About 3 Miles
Channel Scan:
CHANNEL SCAN performs searches for active signals in an endless
loop from 1 to 8.
1. Press MENU button twice and Up , Down buttons to activate
CHANNEL SCAN.The channel number on the LCD Screen changes
rapidly until an active signal is detected.
During CHANNEL SCAN mode.
Press ENTER button or PTT button to confirm the selected
channel.
Press the CALL Cbutton to change to CALL function and to send
a CALL TONE on that active channel.
Press the MENU button 4 times to deactivate CHANNEL SCAN
mode.
2. When an active signal (one of 8 channels) is detected.CHANNEL SCAN
pauses,keeping the active signal broadcasted.
3. Press the PTT button to communicate through the active signal channel
and CHANNEL SCAN is deactivated.
4. When an active signal (one of 8 channels) is detected, but another
channel is desired, press the Up or Down button to bypass the
current channel and continue to search for another active channel.
Sending Call Tones
You can use CALL TONES to alert the other when you are attempting to
contact them.You can also use CALL TONES to signal the beginning or
the end of a transmission.
1. Press the CALL Cbutton,the red TX LED indicator will light up and the
CALL TONE continues for 3 seconds.
2. Release the CALL Cbutton,your CALL TONES will transmit to nearby
receivers set to the same channel.
SYMPTOM
No power.
Reception is
weak.
Cannot change
channels.
Range is limited.
Sound distortion
problems.
SOLUTION
=Check batteries. Ensure that the batteries are installed
properly.
=The batteries may be weak.
= Replace old batteries with four (4) new "AAA" alkaline
batteries or Ni-MH rechargeable batteries.
=Press the Up button to increase VOLUME.
=The receiving signal may be weak and/or out of range.
=If this happens,press the MONITOR Mbutton.
=To change channels, press the MENU button until the
channel number flashes on the LCD Screen.
= Press the Up or Down buttons to change channels.
= Batteries may be weak.
=BATTERIES may be weak.
=Replace with new batteries if the BATTERY LEVEL indicator
is low.
=The maximum range will vary depending on terrain and
environment.
=Open fields provide the maximum range,while steel/concrete
structures, heavy foliage and use in buildings and in vehicles
may limit the range significantly.
=Wearing the radio close to the body, such as in a pocket or
on a belt,will decrease range; change the location of the radio.
=If you are transmitting,speak in a normal tone of voice,2 to 3
inches away from the MICROPHONE.
=If you are receiving,lower the volume to a comfortable level.
=Radios too close.Radios must be at least 5 feet apart; increase
your distance.
=Radios too far apart. Obstacles interfere with transmission.
Talk range is up to 2 miles in clear unobstructed conditions.
