Hoffmann MS35-SF-TP Operating instructions






















Hoffmann Machine Company, Inc.
1386 Drexel Road Valdese, NC 28690 –USA
Ph: (828) 430 - 4510
www.Hoffmann-USA.com
Effective: 06-2017
Operating and Maintenance Manual
MS35-SF-TP Double Miter Saw with
Dovetail Routing Stations
HOFFMANN
Machine
Company, Inc.

Operating and Maintenance Manual
2 HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017
1 Table of contents
2WARNING AND SAFETY SYMBOLS USED IN THIS MANUAL ...........................................................4
2.1 WARNING AND SAFETY LABELS ATTACHED TO MACHINE...........................................................5
3INTENDED USE AND OPERATION .......................................................................................................7
4MACHINE DESCRIPTION.......................................................................................................................9
4.1 Terminology used in this manual ...................................................................................................9
5TECHNICAL DATA AND SPECIFICATIONS........................................................................................10
6OPERATOR ENVIRONMENT................................................................................................................11
7POTENTIALLY DANGEROUS AREAS ................................................................................................12
8POTENTIAL SOURCES OF DANGER..................................................................................................13
8.1 Unapproved Use ..........................................................................................................................13
8.2 Mechanical Dangers.....................................................................................................................13
8.3 Defective equipment.....................................................................................................................14
8.4 Electrical Dangers ........................................................................................................................14
8.5 Cleaning agents and chemicals ...................................................................................................14
9NOISE EMISSIONS ...............................................................................................................................16
10 GENERAL SAFETY RULES IN ACCORDANCE WITH DIN 1870-9....................................................17
11 SAFETY DEVICES.................................................................................................................................20
11.1 Safety Devices .............................................................................................................................21
11.2 What to do in an Emergency?......................................................................................................22
11.3 Safety device check list................................................................................................................23
12 WARRANTY AND LIABILITY................................................................................................................24
13 TRANSPORTATION AND INSTALLATION..........................................................................................25
13.1 Transportation ..............................................................................................................................25
13.2 Installation and Set-Up.................................................................................................................27
13.3 Machine installation diagram........................................................................................................28
13.4 Electrical and compressed air connections..................................................................................29
13.4.1 Connecting electrical enclosure to power supply .........................................................30
13.4.2 Compressed air connections ........................................................................................31
13.4.3 Check Connections.......................................................................................................32
13.4.4 Installation of infeed and outfeed tables and fence rails...............................................33
13.4.5 Dust collection connections ..........................................................................................34
14 OPERATION –WARNINGS AND SAFETY RULES.............................................................................35
14.1 Initial start-up................................................................................................................................36
14.2 Tooling change.............................................................................................................................37
14.2.1 Opening machine front cover........................................................................................37
14.2.2 Saw blade change ........................................................................................................38
14.2.3 Chip breaker (table insert) change ...............................................................................39
14.2.4 Router bit installation and adjustments (with set-up jig)...............................................40
14.3 Router bit adjustments .................................................................................................................41
14.3.1 Router bit adjustments (with caliper) ............................................................................42
14.2 Adjustment of keyway positions..................................................................................43

Operating and Maintenance Manual
HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017 3
14.3.2 Adjustment of router feed rate......................................................................................44
14.4 Adjustment of sawing stations .....................................................................................................45
14.4.1 Adjustment of saw feed rate.........................................................................................45
14.5 Adjustment of table movement.....................................................................................................46
14.6 Material clamping cylinders..........................................................................................................46
15 OPERATION..........................................................................................................................................47
15.1 Controls........................................................................................................................................47
15.1.1 Front console details ....................................................................................................47
15.1.2 Touch-Panel Functions.................................................................................................48
16 OPERATION..........................................................................................................................................56
16.6 Operation .....................................................................................................................................56
16.6.1 Machining Sequence....................................................................................................56
16.7 Machine Operation.......................................................................................................................57
16.8 Machine shut down......................................................................................................................57
16.9 „SET-UP“ mode and function of “CONFIRM” button ...................................................................58
16.9.1 CONFIRM Button function during normal operation:....................................................58
16.9.2 Set-Up mode.................................................................................................................59
16.9.3 Indicator Light...............................................................................................................59
16.10 Faults –Errors - Emergencies.....................................................................................................60
16.10.1 Emergency Stop reset..................................................................................................60
17 CALIBRATION OF DIGITAL LENGTH STOP DISPLAY MODEL Z-16...............................................61
17.6.1 Trouble Shooting Chart ................................................................................................65
18 MAINTENANCE.....................................................................................................................................66
18.6 Maintenance Schedule ................................................................................................................67
18.7 Manual lowering of saw carriage .................................................................................................68
18.8 Drive Belt adjustments.................................................................................................................69
18.9 Lubrication Schedule ...................................................................................................................70
18.9.1 Location of lubrication points........................................................................................70
18.10 Pneumatic circuit and air regulator-filter-lubricator assembly......................................................71
19 EG-CONFORMITY CERTIFICATION....................................................................................................72
20 PARTS LIST AND DIAGRAM ...............................................................................................................73
20.6 Router Motor UWC-24-R .............................................................................................................73
20.7 Parts List –Router Motor UWC-24-R ..........................................................................................74
21 TERMS AND CONDITIONS OF SALE AND WARRANTY.......................................................................75
22 TECHNICAL SUPPORT DOCUMENTATION - ADDENDUM....................................................................78
22.1 Addendum Overview......................................................................................................................78
20.2 Cutting Capacity Diagram MS 35SF-TP......................................................................................78
23 SPARE PARTS LIST MS 35SF-TP.......................................................................................................79
23.6.1 Saw Units......................................................................................................................79
23.6.2 Parts List for router unit................................................................................................80
23.6.3 Parts .............................................................................................................................81
23.6.4 Machine diagram and Parts List...................................................................................82

Operating and Maintenance Manual
4 HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017
2 Warning and Safety Symbols used in this manual
Operator must read, understand and follow all safety rules,
symbols and operating instructions at all times.
The following symbols are used in this operating manual:
Danger Symbol
This symbol warns of a serious danger.
Ignoring the safety instructions will lead to serious bodily harm
and/or death!
Warning Symbol
This symbol warns of a possible danger.
Ignoring the safety instructions can lead to serious bodily harm
and/or death!
Safety Warning Symbol
This symbol warns of a possible danger.
Ignoring the safety instructions can lead to serious bodily harm
and/or damage to the equipment and/or material being processed.
This symbol does not include a warning.
It is used to denote helpful hints and tips to improve the operation
and performance of the equipment.
Important Instructions
Instructions listed with this symbol must be strictly adhered to.

Operating and Maintenance Manual
HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017 5
2.1 Warning and Safety Labels attached to machine
A number of important warning labels have been attached to this MS35SF-TP Double Miter Saw for your
information and protection.
For your own safety, please take a moment to locate and read all warning labels before operating this
machine.
If a label has been removed, defaced or is illegible, please contact Hoffmann Machine Company, Inc. to
request a free replacement.
NEVER REMOVE ANY SAFETY OR WARNING LABEL!

Operating and Maintenance Manual
6 HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017

Operating and Maintenance Manual
HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017 7
3 Intended Use and Operation
The HOFFMANN MS35SF-TP Double Miter Saw is designed solely for length cutting and dovetail keyway
routing of solid wood and wood-related materials.
The machine may not be used for any other processes or materials.
All work pieces must fall within the following dimensional parameters:
Dimension
MIN (mm)
MAX (mm)
Width
10
92
Thickness
10
100
Length
100
unlimited
Using the HOFFMANN MS35SF-TP Double
Miter Saw for any other operation or material
can result in unforeseen dangers and is
hereby forbidden!
The manufacturer is not liable for any damages resulting from
unapproved use or operation of the equipment.
The operator is solely responsible for any such risks and
dangers.
The equipment may not be copied or dismantled for the purpose
of duplication of all or part of the design or operation.
Technical changes to this equipment require the prior written
consent of the manufacturer.
Any changes, additions, removal of components, etc. not
expressly permitted in writing by the manufacturer will
immediately void the warranty. Any risks, dangers or damages
resulting from unauthorized modifications are solely the
responsibility of the user/operator.
Adjustments on moveable components of the HOFFMANN
MS35SF-TP Double Miter Saw during the operating process are
only permitted if such adjustments are required for the proper
operation of the equipment and if such adjustment procedures
are outlined in this manual. All pertinent safety rules and
regulations are to be strictly adhered to.
3.1 Transportation and Installation
Only trained and qualified personnel may transport, set-up and
install this equipment and any auxiliary components.
You are required to assure a safe, clean and suitable
environment for this equipment and its operation.

Operating and Maintenance Manual
8 HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017
3.2 Technical Changes and Maintenance
Technical changes or alterations of any kind are only permitted if the prior written
authorization from Hoffmann Machine Company, Inc. has been secured.
Never remove safety guards and shields, remove or by-pass safety devices, switches,
sensors, use or install tooling other than originally supplied.
The manufacturer is not liable for any injuries or damages caused by unauthorized changes,
removal or add-ons to this equipment.
Only trained, qualified personnel may perform installation, set-up and maintenance
procedures as well as replacement of parts or components of any kind.
3.3 Operator and Maintenance Personnel
Machine operator and maintenance personnel may only perform activities described in this
manual.
Persons working on or with this machine must be at least 18 years old, they must be
thoroughly familiar with this operating manual and they must adhere to all local safety rules
and regulations. All OSHA specified rules must be followed if applicable.
Persons working on or with this machine must wear suitable clothing designed to avoid
entrapment in rotating machine components.
No loose fitting clothes e.g. ties or shawls, or bracelets, wristwatches, necklaces, etc. may
be worn when operating this machine.
Persons with long hair must tie their hair securely and wear an appropriate hair covering to
avoid entanglement.
3.4 Equipment Owner’s Responsibilities
The owner of the equipment must make this operator manual available to all machine
operators and maintenance personnel.
The equipment owner must assure that all operators and maintenance personnel are
qualified to work on this equipment and that they have read and fully understand this
operator manual, especially all sections pertaining to possible dangers and safety rules.
The owner must assure that all areas of responsibility, including set-up, operation,
maintenance, etc. –are clearly defined and explained.
All responsibilities must be assigned to and understood by all involved persons to avoid the
risk of injury and /or damage to material.
The owner is responsible for the adherence to all applicable safety rules and regulations.
The owner is responsible for the proper and safe condition of the machine; he is further
responsible for the proper installation and set-up and he must provide a safe and secure
work environment.
The owner must be familiar with and is responsible for the adherence to any and all local
and national safety rules and regulations pertaining to this equipment.
The manufacturer is not liable for any injuries or damages as a result of non-compliance
with, or adherence to, applicable safety rules and regulations.
If the operator and/or maintenance personnel do not understand English, the owner must
provide a properly translated operator manual to assure the safety of all personnel.
3.5 Change of Ownership
In case of sale of this equipment all components, tools, manuals, safety instructions,
accessories as well as any electronic or software updates you have originally received with
the machine must be included.
This includes any and all operator manuals, maintenance instructions, equipment or
components replacement parts, etc.

Operating and Maintenance Manual
HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017 9
4 Machine Description
4.1 Terminology used in this manual
MS35SF-TP or MS35SF = HOFFMANN Double Miter Saw model MS35SF-TP
Bit = Hoffmann dovetail router bits in sizes W-1 / W-2 / W3
Workpiece = User supplied moulding profiles made of wood or wood related materials
Dovetail Key = HOFFMANN Dovetail Keys
4.2 Machine Description
HOFFMANN Double Miter Saw MS35SF-TP consists of:
HOFFMANN Double Miter Saw model MS35SF-TP
Adjustable table supports (2)
Infeed and outfeed table extensions
Adjustment gauge for router bits
Length stop 45° with locking lever
Length stop system DMS 10
Toolkit
Operating manual
The HOFFMANN MS35SF-TP Double Miter Saw is designed to miter-cut to length moulding profiles made of
wood or wood related materials and to rout dovetail keyways into the mitered ends.
Adjustments for material length and length and position of routing strokes allow the operator to process
different moulding styles.
Machine performance:
Up to 100 cycle per hour (depending on operator performance,
material condition, work flow, etc.)
Work stations
2x saw motor, 3 phase @ 1,8 kW
2x router motor, single phase @ 500W
Accessories and Options:
Flip Stops
Horizontal workpiece clamps, pneumatic
Fence extensions (for tall material)

Operating and Maintenance Manual
10 HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017
5 Technical Data and Specifications
Electrical Power Supply
Supply voltage
Frequency
Input Amperage
Total power requirement
Safety Code
Supply line breaker
Saw motors
Router motors
Saw blades
Router bits
230 V / 3 phase / ground supply wires: 3x 4mm²
60 Hz
14 A
6 kVA
IP 54
16 A slow acting
2x three-phase motor (1,8 kW) 2800 rpm
with electronic brake BR VB230-25L
2x router motor Type UWC-24-R (500 Watt)
24000 rpm
Saw blades, diameter 350mm x 3,4 / arbor size 30mm
84 teeth, carbide tipped, HOFFMANN brand
2x Hoffmann Dovetail Router Bits, size W1 / W2 / W3
Pneumatics
Compressed air supply
Volume requirement
Air
Filter mesh size
6 bar –90 psi (max. 8 bar)
Up to 1.5 cubic feet per cycle
lubricated
5µ
Other Specifications
Work piece material
Machine performance
Weight
Dim. Length x depth x height
Noise emissions:
Sound Pressure Level (SPL):
Sound Pressure Level at the Source:
Wood and wood related materials
Up to 100 cycles/hour (depending on operator, material flow,
material quality, etc.)
approx. 1430 lbs.
approx. 57” x 67” x 38”
84,1 dB
102,1 dB
Machine Environment
Temperature range for operation
Temperature for storage / transport
Temperature change during operation
Temperature change during storage / transport
Relative humidity according to DIN 40040
Air pressure during operation
Air pressure during storage / transport
59.... + 104 F
32.... + 140 F
max. 20 F
max. 40 F
15... 80 % without condensation at 95 F
860-1060 hPA (bar)
860-1060 hPA (bar)

Operating and Maintenance Manual
HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017 11
6 Operator Environment
The work areas for the operator have been designed with
ergonomic principles in mind.
The machine owner is responsible for ease of access,
adequate lighting, fresh air supply, etc.
Specific work areas for this machine are:
In front of the machine to load and unload work
pieces and to adjust settings.
In front of the operator panel to start the
machine and to initiate the machining cycle.
At the back of the machine for maintenance
procedures only.
Rules for safe work areas:
The work area must be free from clutter and must be
kept neat and unobstructed. Local and national
safety rules, including but not limited to all
applicable OSHA Rules must be adhered to.
Access space of no less than 24” shall be available
on all sides of the machine for set-up and
maintenance procedures.
All electrical and compressed air supply lines must
be securely fastened in accordance with all local
and national safety codes. Secure all wires, hoses
and lines and do not allow lines to lie on the floor as
they may present a trip hazard to the operator.
Supply lines, wires and hoses must be inspected
periodically and replaced if any damage is
observed.
The environmental conditions must meet the guide
lines given under section 5 “Technical Date and
Specifications”.

Operating and Maintenance Manual
12 HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017
7 Potentially Dangerous Areas
Especially dangerous areas of the machine are:
Areas around the miter cutting operations
Areas around the dovetail routing operations
During set-up and maintenance procedures, the
following dangers exist in the above areas:
Danger of entanglement and pinching!
During set-up and maintenance work,
especially when access doors must be
opened, additional dangers of
entanglement or pinching on belts,
sprockets, saw station, router station,
drilling station, etc. are present. Do not
wear loose fitting clothing. Long hair must
be covered with a hair net.
Danger of cutting of hands and fingers!
All sawing, routing and drilling areas
present dangers of cutting of hands and
fingers.
Danger of amputation!
All sawing areas present the danger of
severe cutting or amputation of fingers.

Operating and Maintenance Manual
HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017 13
8 Potential Sources of Danger
8.1 Unapproved Use
Unapproved procedures are:
Processing work pieces made of material other
than solid wood or wood related material such as
MDF, particle board, plywood, etc.
Operating of the machine by more than one
operator at the same time.
Unapproved use and/or misuse of the machine can result in the
following:
Minor to severe injuries to the machine operator
and/or bystanders.
Damage to the machine and/or work pieces.
8.2 Mechanical Dangers
During operation of this machine, saw blades, router
bits and drive belts rotate and sections or
components of the machine are being moved and
adjusted pneumatically, mechanically and/or
electronically.
These components can cause severe injury or death
if hair, clothing or extremities become entangled.
Never reach into the machine during operation!!
Only make adjustments during operation if these
adjustments are absolutely necessary and if the
procedure is fully outlined and approved in this
operator manual.

Operating and Maintenance Manual
14 HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017
8.3 Defective equipment
If the machine does not function properly and if the fault cannot be
rectified immediately, the equipment must be shut down by the person
responsible for the operation.
Signs of defective are:
The machine shows signs of mechanical damage.
Electrical wires or cables are damaged.
Pneumatic air lines are damaged.
The machine was stored or has not been in use for an
extended period of time in an unsuitable environment,
for example in high relative humidity or too high or too
low temperature.
8.4 Electrical Dangers
Dangerous electrical current is present in many different
locations inside of the machine when the main power is
switched on. Do not remove any covers or components
unless the written guidelines instruct you to do so and you
can do so without the use of a key or a tool. Warning
symbols show areas and terminals where electrical
currents may be present.
Be aware that if an uninterruptable power supply (UPS) is
installed, some areas inside the machine may have
electrical current present even if the main power is
switched off.
Never use damaged or worn cables, wires, supply lines or
electrical components or parts on this machine.
Only trained and authorized Service Technicians shall be
allowed to replace parts on this machine.
Switch off and lock the main power supply before starting
any maintenance procedures. Always follow proper Lock-
Out / Tag-Out Protocol and all applicable OSHA Rules and
Regulations.
8.5 Cleaning agents and chemicals
Review and observe all safety rules provided by the
chemicals manufacturer while working with cleaning agents
and other chemicals. Read and understand the Material
Safety Data Sheets (MSDS) provided by the manufacturer
and follow all safety precautions described therein.
Always wear proper protective gear, including safety
glasses and gloves, when using cleaning agents,
degreaser, etc.
Do not eat, drink or smoke when using chemicals.
Dispose of used cleaning agents and other chemicals in
accordance with all State and local laws.

Operating and Maintenance Manual
HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017 15
8.6 Remaining Risks
If the operator does not pay attention, it is possible to
squeeze ones’ fingers when loading and pre-clamping a
work piece. The maximum air pressure is limited to 2 bar
and the maximum clamping force is limited to 60N.

Operating and Maintenance Manual
16 HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017
9 Noise Emissions
The machine generates a work place Sound
Pressure Level (SPL) of 84.1 dB(A) when
processing a work piece.
The Sound Pressure Level at the Source (Lw)
is 102.1 dB(A) when processing a work piece.
Local conditions could increase the SPL,
which could cause hearing damage or loss.
The machine owner must provide suitable
protective gear to protect employees from
hearing damage, as required by local and
state laws and OSHA regulations.
Measurement margin of error = 4dB
Noise emission was measured according to
EN3746
Notes:
All listed values are measured noise emission
levels –they are not necessarily safe working
environment levels.
Local conditions, the proximity of walls and
ceilings, the type of wall, ceiling and floor material
as well other equipment in close proximity could
affect the total noise emissions at the work place.
The SPL values are provided as information only
and it is recommended that the machine owner
measure the actual local noise levels after
installation.
Machine is owner is responsible for providing
suitable protective gear depending on total noise
emissions and local and state laws and
regulations.
All OSHA regulations pertaining to noise
protection are to be adhered to.

Operating and Maintenance Manual
HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017 17
10 General Safety Rules in accordance with DIN 1870-9
DANGER: The following safety rules must
be followed at all times!
Read and understand this operator manual thoroughly and store it
in a safe place for future reference.
Heed all safety warnings and all applicable rules and regulations,
including but not limited to all applicable OSHA rules, when
operating or performing maintenance or set-up procedures on this
equipment.
1. HOFFMANN Service Technicians will instruct machine operators in the
proper use of this equipment upon installation and set-up.
2. The HOFFMANN MS35SF-TP double miter saw may only be operated
by trained personnel who have read and understood the operator
manual. The manual shall be kept in a safe location, easily accessible
for future reference.
3. Only trained and authorized persons may be allowed to operate the
HOFFMANN MS35SF-TP double miter saw. Untrained or
unauthorized persons are to be kept away from the machine area. The
operator(s) must disconnect the electrical and pneumatic power
supplies when the machine is not under their control.
4. All applicable Safety Rules, including all applicable OSHA rules, are to
be adhered to.
5. Only trained and qualified persons may perform work on the electrical
components of the machine.
6. Before connecting the HOFFMANN MS35SF-TP double miter saw to
the electrical power supply, all electrical specifications must be
confirmed with the machine’s data sheet.
7. Never disable, remove or bypass any safety features, guards or
devices!
8. HOFFMANN MS35SF-TP double miter saw may only be energized if
no danger for persons or materials is present.
9. All safety features, guards and safety devices must be checked for
proper function at least every three months (always follow
recommended maintenance schedule).
10. Upon discovery of any damage to any part or component of
HOFFMANN MS35SF-TP double miter saw, the machine must be
shut off and locked to prevent further operation until all damager and/or
faults are repaired.
11. The operator must inform his or her supervisor immediately upon notice
of any damage or fault on the machine.

Operating and Maintenance Manual
18 HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017
12. If the HOFFMANN MS35SF-TP double miter saw has been moved,
or has been out of service for an extended period of time, all safety
features, guards and safety devices must be checked and repaired or
replaced if necessary before the machine is put back into operation.
13. Operator must always wear tight fitting clothes without loose straps,
ties, etc. to avoid the danger of entanglement. Long hair must be tied
together and covered with a hair net.
14. Always wear eye and ear protection when operating this equipment!
Do not wear gloves when operating this equipment –danger of
entanglement!
15. Ensure adequate light conditions on and around the machine, with an
ambient temperature of around 70 degrees Fahrenheit.
16. Keep the floor around the machine free from debris, saw dust or wood
chips, etc. Larger cut-offs and waste material may not be left in the
machine and must be removed manually in compliance with all
applicable safety rules!
17. Tooling Change:
Danger –cutting tools can injure and cut! Safety gloves are
recommended when handling saw blades and router bits.
Saw blades shall be compliant with prEN 847-1:2011.
Do not change motor speeds or tooling speeds on saw, router or drill
heads.
All tooling (saw blades, router bits) is to be inspected daily for
sharpness and breakage –dull and/or defective tooling is to be
replaced before operating the machine.
18. Do not expose this machine to moisture or water and do not expose
this machine to flammable liquids or gases.
19. Route and place all electrical and pneumatic supply lines to avoid the
possibility of creating a trip hazard. All supply lines shall be
adequately protected from accidental mechanical damage.
20. Disconnect the machine from all electrical and pneumatic power
sources when performing any maintenance, repair or set-up
procedures. Follow all applicable OSHA Lock-Out –Tag-Out
Procedures.

Operating and Maintenance Manual
HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017 19
Guidelines for safe work practices in accordance with DIN1870-9:2000 sub-section B:
It is important for all machine operators to be:
a) Adequately trained in all set-up and operational procedures of the machine
b) Informed about factors which influence the noise emission of equipment,
e.g.
i) Saw blades
ii) Optimum saw blade speed (rpm)
iii)Maintenance of saw blades and machine
c) Informed about factors which could contribute to a dust explosion, e.g.
i) Type of material being processed
ii) Importance of the individual dust collection ports
iii)Proper adjustment of dust collection guide panels
IV) Activation of the central dust collection system before starting the
machine
d) Informed about the condition of the environment around the machine, e.g.
i) Floor shall be level, clean and free from debris, cut-off and other trash.
ii) There shall be adequate common as well as task lighting in place.
iii)The raw material and the finished material shall be placed close to the
machine in a position to allow for proper work flow.
The operator shall always wear suitable personal protective gear, e.g.
oHearing protection
oBreathing protection to avid breathing of wood dust
oGloves should be worn whenever tooling is handled or changed.
oSaw blades should be transported in a saw blade carrier.
iv) The machine should be switched-off when not in use.
v) Any faults, error messages or damage to the machine must be
reported to a supervisor immediately.
vi) The operator shall be trained in the proper procedures to remove
cut-off, waste, dust and debris from the machine to reduce the risk
of fire.
vii) The operator shall follow all rules and guidelines in regards to
tooling maintenance, sharpening and installation.
viii) The operator shall not exceed the maximum speed engraved on
the saw blades.
ix) The operator shall only use correctly sized and properly sharpened
saw blades.
x) The operator shall assure that all saw spindle discs and nuts are of
adequate size and condition.
xi) The operator shall not remove cut-offs or debris while the machine
is in operation.
xii) The operator shall assure that all safety features, guards
and safety devices are checked and repaired or replaced if
necessary before the machine is put into operation.

Operating and Maintenance Manual
20 HOFFMANN MS35SF-TP Double Miter Saw • Version 7.148.66 • 06-2017
11 Safety Devices
A number of safety devices have been designed and installed
on the HOFFMANN MS35SF-TP double miter saw to provide
the best possible protection for the operator.
Warning: Strictly follow all safety rules!
1. The machine features safety shields, doors and guards
which must be in place and locked when operating the
equipment.
2. Danger of personal injury and/or death exists if the safety
shields, doors and guards are not place during operation.
3. Safety devices shall not be removed, damaged or by-
passed.
4. Any unauthorized modifications, including but limited to
by-passing of safety switches or sensor, immediately void
the warranty on the equipment.
5. All safety features, guards and safety devices must be
checked every time for proper operation before the
machine is started and operated.
6. If any damage or malfunction on any safety feature, guard
and safety device is found, it must be repaired or replaced
before the HOFFMANN MS35SF-TP double miter saw is
put into operation
