• After the engine is successfully started, first pull out the jump start plug of the device and then remove the clamps from the car battery.
LCD DISPLAY EXPLANATION
1. Reverse connection
2. Shows when the jump starter is under charge. It’s moving while charging and solid lighting when charged full.
3. Car battery voltage
4. Battery percentage
5. COOLING: Jump starter is cooling (usually between each start intervals. The jump starter needs to cool for 30seconds after each start
and 10minutes after 5 continuous starts).
6. READY: Shows the jump starter is ready to start.
SOME SPECIAL NOTES
1. When using this unit to start, make sure the positive and negative connections are correct, otherwise the battery may explode.
2. The jump starter is allowed for 5 consecutive starts with 30seconds cooling time between each interval and 10minutes cooling time after
five starts.
3. Minimum start voltage of the jump starter is 2V. If your car battery is totally dead (<2V) , the jump starter will not work.
USING AS INFLATOR
USING AS INFLATOR
1
• Press and hold the power switch (6)
for 2 seconds to turn on the unit.
2
3
A. To operate inflator with pre-set function
You can press “+ ”or “- ” (4) to adjust the suitable value before inflating
automatically. Operate the device by press inflate button (1), the device will
automatically shut off once the pre-set pressure is reached.
B. To operate inflator without pre-set function
When the pre-set gauge is at “0”, it means that the compressor will work without
the pre-set function. If the pre-set is not at “0”, you can adjust the pressure gauge
to “0” by pressing Button'-' to decrease the pressure gauge. You need to press
the inflating button (1) to stop it manually when it reaches the pressure you would
like to have.
USING AS POWER BANK
1. Press and hold the power switch (6) for 3 seconds to turn on the unit.
2. Connect the USB cable to the USB output port (10) of the device.
3. The USB output will be automatically turned off after charging is completed
4. Move the USB cable from the device .
USB output: 5V /3A, 9V/2A, 12V/1.5A
• 6 •• 5 •
• To remove the air hose from your
car tire, twist the screw-on valve
connector counter clockwise.
4
LCD DISPLAY EXPLANATION
1. Pressure unit
2. Target figure
3. Real-time pressure value
1
2
3
• Connect the screw-on valve
connector to tire air valve(15).
Twisting it clockwise until it is
securely attached to the tire air
valve. Please allow the inflator to cool down for 15 minutes after each
10 minutes continuous operation.
READY
V
TARGET
PSI
COOLING
• Connect the screw-on valve connector to tire air valve(15). Twisting it clockwise until it is securely attached to the tire air valve.
USING AS INFLATOR
1
• Press and hold the power switch (6)
for 2 seconds to turn on the unit.
2
3
A. To operate inflator with pre-set function
You can press “+ ”or “- ” (4) to adjust the suitable value before inflating
automatically. Operate the device by press inflate button (1), the device will
automatically shut off once the pre-set pressure is reached.
B. To operate inflator without pre-set function
When the pre-set gauge is at “0”, it means that the compressor will work without
the pre-set function. If the pre-set is not at “0”, you can adjust the pressure gauge
to “0” by pressing Button'-' to decrease the pressure gauge. You need to press
the inflating button (1) to stop it manually when it reaches the pressure you would
like to have.
USING AS POWER BANK
1. Press and hold the power switch (6) for 3 seconds to turn on the unit.
2. Connect the USB cable to the USB output port (10) of the device.
3. The USB output will be automatically turned off after charging is completed
4. Move the USB cable from the device .
USB output: 5V /3A, 9V/2A, 12V/1.5A
• 6 •• 5 •
• To remove the air hose from your
car tire, twist the screw-on valve
connector counter clockwise.
4
LCD DISPLAY EXPLANATION
1. Pressure unit
2. Target figure
3. Real-time pressure value
1
2
3
• Connect the screw-on valve
connector to tire air valve(15).
Twisting it clockwise until it is
securely attached to the tire air
valve. Please allow the inflator to cool down for 15 minutes after each
10 minutes continuous operation.
READY
V
TARGET
PSI
COOLING
• Press and hold the power switch (6) for 2 seconds to turn on the unit.
USING AS INFLATOR
1
• Press and hold the power switch (6)
for 2 seconds to turn on the unit.
2
3
A. To operate inflator with pre-set function
You can press “+ ”or “- ” (4) to adjust the suitable value before inflating
automatically. Operate the device by press inflate button (1), the device will
automatically shut off once the pre-set pressure is reached.
B. To operate inflator without pre-set function
When the pre-set gauge is at “0”, it means that the compressor will work without
the pre-set function. If the pre-set is not at “0”, you can adjust the pressure gauge
to “0” by pressing Button'-' to decrease the pressure gauge. You need to press
the inflating button (1) to stop it manually when it reaches the pressure you would
like to have.
USING AS POWER BANK
1. Press and hold the power switch (6) for 3 seconds to turn on the unit.
2. Connect the USB cable to the USB output port (10) of the device.
3. The USB output will be automatically turned off after charging is completed
4. Move the USB cable from the device .
USB output: 5V /3A, 9V/2A, 12V/1.5A
• 6 •• 5 •
• To remove the air hose from your
car tire, twist the screw-on valve
connector counter clockwise.
4
LCD DISPLAY EXPLANATION
1. Pressure unit
2. Target figure
3. Real-time pressure value
1
2
3
• Connect the screw-on valve
connector to tire air valve(15).
Twisting it clockwise until it is
securely attached to the tire air
valve. Please allow the inflator to cool down for 15 minutes after each
10 minutes continuous operation.
READY
V
TARGET
PSI
COOLING
A. TO OPERATE INFLATOR WITH PRE-SET FUNCTION
You can press “+ ”or “- ” (4) to adjust the suitable value before inflating automatically. Operate the device by press inflate button (1), the
device will automatically shut off once the pre-set pressure is reached.
