Hoggan Scientific microFET3 User manual

microFET3 User Guide

Congratulations on becoming the proud owner of the new microFET3 with wireless technology, Hoggan Scientific LLC
highly renowned dual function handheld digital muscle tester and inclinometer. The new microFET3 wireless allows
muscle and inclinometry testing to be done FREE of cords in conjunction with microFET clinical patient software. This
provides freedom and ease of use while performing tests.
Hoggan has been creating innovative solutions for accurate, objective measurement since 1984, with the introduction
of the original FET muscle tester. Over the past 20 + years, our product line has expanded to include inclinometers, grip
and pinch gauges, and innovative ergonomic measurement instruments.
During that time, Hoggan's products have developed a reputation for innovation, excellent quality, ease of use, and long
lasting accuracy and reliability. Our highly satisfied customers include hospitals, universities, clinics and research
institutions worldwide. The microFET products are used by organizations as diverse as NASA, the Shands Institute, the
US Olympics and professional sports teams.
At Hoggan, we are constantly improving our products to better meet your needs. Besides the addition of the new
wireless technology incorporated into the microFET line of products, we've added some important new features to the
microFET3. You can now measure forces up to 150 lbs and select the unit of measure to read out in lbs, Newtons, or
KGF.
We understand the value of customer feedback. Our customers provide us with many of our best product
improvement ideas, as well as interesting new measurement applications. As you have comments and suggestions,
we'd love to hear from you. Please e-mail us at [e-mail].
In the meantime, we hope you enjoy using your microFET3 with new wireless technology immediately, and for
many years to come. For more information on all of our innovative medical, ergonomic and fitness products, please
visit us at www.hogganhealth.net.
Copyright © 2011 Hoggan Scientific LLC
Page 1

Table of Contents
Page
MicroFET3 Wireless Overview 3
What is Included 4
Specifications 4
Care and Cleaning 5
Calibration 5
Transporting microFET3 5
Operating Features 5
On/Off Switch 5
Sleep Mode 5
Reset Button 5
LCD Windows 6
Threshold Button –Muscle Testing 7
Inclinometer Button and Cycle Switch 8
Force Measurement 9
Wireless Radio Frequency –RF Power 9-10
Bluetooth / FET Stick 11
Battery Check 11
Battery Saver/Sleep Mode 12
MicroFET3 Muscle Testing 12-13
MicroFET3 Inclinometry Testing 13-14
Validity Requirements/Repeat Trial Consistency 14-15
Recording and Retrieving Test Data 15-17
Low Batteries 18
Changing Batteries 18
Warranty Information 18-19
Customer Service/Repairs 19
Ordering Replacement Parts 19
Page 2

microFET3 Wireless Overview
microFET3 is an accurate, portable Combination Force Evaluation and Range of Motion testing system. It is a
battery operated, hand held device weighing less than one pound and fits comfortably in the palm of your hand.
microFET3 provides you with objective, quantifiable data from the time-tested art of “hands-on” manual
muscle and range of motion testing. microFET3 aids in the differential diagnosis, prognosis, and treatment
protocols for the neuromuscular and musculoskeletal disorders.
Recessed into the main outer shell is a polycarbonate overlay with clear lenses for the LCD displays (Liquid
Crystal Display), and 3 membrane switches. A red switch is located to one side of the unit in proximity to
where the thumb or the index finger is positioned during use.
As information from the gauges is processed, it is displayed in two LCD windows. During manual muscle
testing, the Peak Force LCD shows the force being applied against the transducer pad during the test, and it
displays the highest force reached when the test is concluded. The Duration/Secs LCD shows the duration of
the test from the time testing threshold was crossed until the test is concluded.
For inclinometer use the unit is placed on the starting point and an angle is set. The patient moves through the
range of motion and the second angle is set. Then by clicking the cycle switch one more time the difference
between both angles will appear in the left hand LCD window.
The newly updated microFET3 Wireless with radio frequency technology provides convenience for both you
and your patients. The wireless microFET3, when used with HOGGAN microFET clinical software, alleviates
the inconvenience of being wired to the computer and provides easier interaction with patients. A wireless
instrument allows greater freedom in the exam room or testing area, and eliminates dictating the location of the
computer and length of instrument cable so you can move freely during testing.
The microFET3 can also be used as a standalone gauge for capturing individual force measurements for any
muscle test and inclinometry test.
Page 3

What Is Included:
microFET3
Curved transducer pad (Slip-In Dent Ball Retainer Shaft)
Flat transducer pad (Slip-In Dent Ball Retainer Shaft)
Digit transducer pad (Slip-In Dent Ball Retainer Shaft)
Muscle Testing Positions chart
Inclinometer Testing Position chart
Upper body test record tablet
Lower body test record tablet
(4) Inclinometer testing tablets
Product Warranty card
Calibration Certificate
Carrying Case
Optional - Bluetooth / FET stick (Included with software when software ordered)
Specifications:
WEIGHT: 1 lb.
POWER SOURCE: 3.7 V (LI-ION Rechargeable Battery)
CONTROLS: Reset, Muscle Testing Threshold and Inclinometer Testing
OPERATING TEMPERATURE: (52°- 92° F) (11°- 33° C)
HUMIDITY: 60- 80% non-condensing
MUSCLE TESTER RANGE:
Low Threshold- .8 lbs. to 150 lbs. in .1 lb. increments
(3.6N- 667N Newton Increments)
High Threshold- 3 lb. to 150 lbs. in .1 lb. increments
(13.3N-667N Newton increments)
LOAD CELL CAPACITY- 150 lbs.
INCLINOMETER RESOLUTION- 0.1 degree increments from 0 degrees to 360 degrees.
ACCURACY: Within 1%
DATA STORAGE: 30 muscle tests, 21 range of motion angles
Page 4

Care and Cleaning
Your microFET3 is built to provide long lasting, reliable service. As with any precision instrument, it
should be used with care. It should not be dropped, banged against hard surfaces, or used as a scale.
The microFET3's exterior surface can be cleaned with damp soft cloth. Small amount of household spray
cleaner can be used. Any cleaner residue should be removed with soft cloth dampened with clean water. We
recommend that you periodically inspect your unit for wear, and proper functioning.
Calibration
The microFET3 comes with a calibration certificate, ensuring that the unit was properly calibrated at the
time of shipment. To ensure continued accuracy and reliability your microFET3 unit should be
recalibrated annually, by a properly authorized service technician.
microFET3 Transporting/Storage
Hoggan Scientific strongly recommends that you store and transport the microFET3 in the hard sided
protective carrying case provided.
Operating Features
IMAGE A
Power On
Pressing the RESET button activates the microFET3 unit. The unit will power-up in the testing mode that
was last used. Refer to Image A above.
Power Off
The unit will turn itself off automatically after 3 minutes of inactivity. This helps to maximize battery life.
Reset Button
Besides powering on the unit, the RESET button can be used to clear the displays and re-initialize the unit.
This may be necessary occasionally. Refer to Image A above for location of RESET Button.
It is not necessary to press reset after each test. The microFET3 automatically begins recording new data
when the force threshold is crossed.
Page 5

LCD Windows
Muscle Testing
Peak Force
During muscle testing the Peak Force LCD (right LCD Window) numerically shows the actual force being
applied to the transducer pad. At test completion, the maximum force value (peak force) is displayed. Refer to
Image D below.
Duration/Sec.
The Duration/Sec. LCD window (left LCD Window) shows the elapsed time (in tenths of second) from the
time the force threshold was crossed until pressure was released. Monitoring test duration is an important
element in maintaining consistency between tests. Also displayed in the Duration/Sec. window is the threshold
setting (Low or High). Refer to Image B below.
IMAGE B
LCD Windows
Inclinometer Testing
When the unit is in inclinometer mode for inclinometer testing, numerical readings or data are displayed in both
LCD windows during the sequencing of inclinometry testing. Refer to Image C below.
IMAGE C
Page 6

Muscle Testing/Threshold Button
Pressing the MT/ THRESH button will cause the unit to enter “Muscle Testing” mode. Each successive press
of the MT/ THRESH button will alternate the high/low threshold feature
High: display “H” in the time display and fractional units in the “force” display
Low: display “L” in the “time” display and fractional units in the “force” display.
High is the most commonly used threshold setting. In the high setting, three pounds of force must be exerted
before the microFET3 will begin recording test results. High threshold displays in 0.10 lb. increments during
testing. See Image D below to see Threshold setting set to L –Low.
Image D
Threshold
Threshold refers to the amount of force required before the microFET3 begins recording test data. The
threshold level can be set to either High or Low setting, and is displayed in the duration/force window.
High Threshold
The High Threshold is most commonly used. In the High setting, three pounds of force must be exerted
before the microFET3 will begin recording test data. The High threshold allows for easier placement of the unit,
and reduces false starts. High threshold displays force in 0.1 lb increments (.44N) during testing. The unit
begins recording test data at 3.0 lbs force (12.1N), and records data in 0.1 lb increments up to 150 lbs (.44N
increments to 1320N). Pressing Reset does not change the threshold setting
Low Threshold
The Low threshold setting is designed for more sensitive, lower force readings such as when testing finger
and hand muscle weakness. Greater care must be used when positioning the unit while in the Low setting, as the
threshold of 0.8 lbs (3.6 N) is easily crossed. The unit begins recording test data at 0.8 lbs (3.6N) and records
data in 0.1 lb increments up to 150 lbs (0.8 increments to 1320N) Pressing Reset does not change the threshold
setting.
Page 7

Inclinometer Button
Pressing the INCL button will put the unit in “inclinometer” mode. Refer to Image C below showing unit in
inclinometer mode.
Image C
Using a “two button” approach the right display shows the “live” readings until the Inclinometer cycle switch,
which is a red button located on the side of the microFET3, is pressed. After the inclinometer cycle switch is
pressed the first reading is moved to the left display, and the right display contains the “live” reading. See
Image D below for location of the red inclinometer cycle switch.
Image D
Pressing the inclinometer cycle switch again “freezes” the data in the right display. Then, press the INCL
button. This will subtract the number in the left display from the number in the right display. The final
inclinometer reading result or angle is displayed in the left display.
To begin the cycle of a new inclinometer test, press the INCL button again. The unit will zero out both displays
to begin the cycle again.
Page 8

Force Measurement Settings
To select unit of measure to display force in Pounds, Newtons, or KGF follow these steps:
1. Press and hold the MT/threshold button for five seconds. The display will show units of measure options.
“L” = Lbs., “g” = KGF, “n” = Newtons.
2. Press the MT/THRES button to toggle through options. Refer to Image F below where “L” (Lbs.) is selected
IMAGE F
3. Press the Reset button to return to test mode.
Wireless Mode - Power On/Off
To turn on RF or wireless mode for microFET3 for use with software follow these steps:
1. Hold the MT/THRES button down for 5 seconds for the force measurement setting mode.
2. Continue to hold the MT/THRES button down for another 5 seconds to turn on the wireless power.
3. The Peak Force display will show RF (wireless) (left LCD window), and the Duration/Secs (right LCD
window) display will show On or Off.
4. Press the MT/THRES to toggle the RF (wireless) power on or off. Toggle On for RF wireless mode to use
unit with software. Refer to Image G below.
IMAGE G
Page 9

5. Press the Reset button to return to test mode.
6. When wireless mode or RF is turned on, an indicator dot will be displayed in the left LCD display at the
bottom on the left side of the display. See Image H below.
IMAGE H
Page 10

Bluetooth / FET Stick
Included with your microFET3 is a Bluetooth / FET Stick. Refer to Image J below. The FET stick is used in
conjunction with software with microFET3. The FET stick is included with software CD disk ordered for the
microFET3. Instructions for using the FET stick are included with your software purchase.
Image J
Battery Check
The LI-ION battery used for microFET3 will provide 100 hours of operating use in standalone mode, and 9
hours of operating use in wireless mode. Depending on your usage pattern, the life of the battery may vary. To
help you identify when the battery will need rechargeable, microFET3 is equipped with "power check" feature
to allow you to see remaining battery power.
To conduct power check, follow these three steps:
1. While holding the side red button, press and release the reset button once.
2. “P” for Power will display in the Duration/Secs LCD window, and the level of battery power will display in
the Peak Force LCD window. See Image K below.
IMAGE K
3. The unit will return to test mode after five seconds.
Page 11

Battery Saver/Sleep Mode
The microFET3’s self activating 'sleep' mode is designed to extend battery life. The microFET3 goes to
sleep when the unit has not received any input for three minutes. The unit can be 'awakened' from sleep
mode by pressing the Reset button.
NOTE: When using microFET3 RF with FET Stick and software: if the microFET3 has not received any input
for 3 minute or crossed the threshold setting, “sleep” mode will activate and signal transmission will stop.
Simply press the reset button and the signal will start transmitting again.
Testing with MICROFET 3
Manual Muscle Testing
Muscle testing was designed to identify and objectively document muscle weakness, or impairment, rather
than muscle strength. The major advantages of muscle testing using handheld dynamometers compared to the
traditional method are the objectivity of the measurements and the consistency of results as measured by both
single testers over multiple tests, and across multiple testers.
During manual muscle testing the clinician normally assigns value to the test result (without the
microFET3), such as 15, or good fair poor, depending on how much force the clinician estimated that the
patient exerted. Problems arise however, in attempting to assign consistent scores based on feel, especially
when the patient is retested at later date.
The microFET3 was developed to eliminate the subjective nature of testing by giving clear, accurate,
objective, quantified force measurements. The microFET3 increases testing reliability and accuracy. As a
result, the microFET3 makes manual muscle a testing more reliable diagnostic practice.
The microFET3 is designed to be used with either the "make" or the "break" form of manual muscle testing.
"Make" testing is performed by the clinician positioning the patient to isolate and contract the muscle, and by
carefully placing the device in the proper position and angle to conduct the test. With the "Make" test, the
clinician gets into "power position" a stable position that will provide the clinician the maximum ability to resist
the force applied by the patient. The clinician instructs the patient to apply force against the device, while the
clinician resists. The object of the test is for the patient to exert or "make" the maximum force he is capable of,
using only the muscle being tested. "Make" tests typically run for seconds (slow count of 4). Many people find
it helpful to start the test by announcing "go" and end the test by stating "relax".
"Break" testing is also performed by carefully positioning the patient and the device. The clinician stabilizes
the patient in the isolated position, with one hand, while placing the microFET3 unit in position to exert force
against the limb associated with the muscle. The test begins with the clinician gradually applying force and the
patient trying to resist. The object of the test is for the clinician to overcome, or "break" the patient's resistance.
Page 12

Multiple published studies have proven manual muscle testing to provide consistent, reliable results, both
across multiple tests by single tester, and across multiple testers. The keys to achieving valid results are proper
patient and device positioning, and consistency of the testing methodology used.
Several noted clinicians and researchers have attempted to document muscle testing norms for specific patient
populations. For example, see: Bohannon, Richard W: Reference Values for Extremity Muscle Strength
Obtained by Hand Held Dynamometry from Adults aged 20 to 79 Years. Arch Phys Med Rehabil, Vol.
78, January 1997). The general conclusion from these studies is that norms for healthy adult populations can
be determined, within broad ranges, with gender, age, and weight being the strongest predictors of muscle
strength. It is important to note, however, that norms are provided with fairly wide standard deviations. Only
individuals whose muscle strength falls more than two standard deviations below the norm can conclusively be
considered 'impaired'.
However, these conclusions cannot be extended beyond the youngest or oldest ranges of the adult populations
tested. For example, research conducted on grade school children determined that developmental differences
between individual children were much bigger factor in determining muscle strength than were age or size.
The most relevant norm for Muscle Testing measures is the patient himself; through his/her identification of
change from what has been his personal norm, left/right comparisons, and progress tracking over time.
For best results, when using the microFET3, be sure to install the proper attachment for the area of the body
being tested: flat round pad for flat, larger surfaces, curved pad for rounded surfaces, and digit pad for fingers
and toes. Check to ensure that the unit is properly positioned for maximum surface area contact and direct force
application.
The microFET3 is ambidextrous. It can be held in either the left or right hand, or you may switch hands
from test to test, depending on stabilization requirements.
For information on positions and manual muscle testing for main muscle groups, refer to the Manual
Muscle Testing Positions Wall Chart included with your microFET3. For additional clarification or how to
test for additional muscle test positions, refer to manuals such as Daniels and Worthingham.
Inclinometer Testing
An Inclinometer is a device that measures a static angle in relationship to the horizontal or vertical, or in
relationship to a determined zero starting point. The MIRCOFET3 Inclinometer is a gauge that uses a sensor to
accurately measure to within 1 degrees. When the inclinometer is moved, the sensor will settle to a stable
position in 0.1 seconds which means you can click the button to mark the angle as soon as the patient stops
moving. This feature makes the measurement process more comfortable for the patient because they do not
have to remain in an uncomfortable posture for any significant amount of time. Single inclinometers provide a
simple and accurate method of measuring range of motion. One hand holds the inclinometer and the other hand
is free to either stabilize or assist the patient through the range of motion.
Page 13

To ensure you eliminate any unwanted movement, mark your testing positions w/tape or a marker. To test the
first position, place the unit on the starting position and set your angle, click (photo 1). Then move the unit to
the second position, click (photo 2). Click the side button a third time to get the (PSP) Patient Starting Position
value. Write that number on the appropriate recording tablet. One more click will start the process over. While
leaving the unit in the second position, click (photo 4). Click the side button a third time to get the (PFP)
Patient Finishing Position value. Now subtract the PSP from the PFP and now you have the true ROM.
Photo 1 Photo 2 Photo 3 Photo 4
Stabilization of Inclinometer
Proper gauge placement and stabilization is critical for accurate measurements. One location that is extremely
difficult to locate, especially on obese patients, is the sacral landmark. With a thick adipose layer one may not
be able to feel a bony location and the gauge may “rock” on the adipose layer. When this occurs, the pelvis
must be stabilized with the free hand over the anterior pelvis for counter pressure while the gauge is pressed
firmly into the soft tissue over the sacrum with an attempt to hold the gauge flat as possible against the sacrum.
It is important to assure that the inclinometer remains flat against the patient’s body part at all times. If one foot
of the inclinometer is not in good contact with the bony landmark, the angle marked will be erroneous and all
subsequent calculations will be inaccurate.
Validity Requirements –Inclinometry Testing
Repeat trial consistency is the main validity criteria for spinal inclinometery. Consistency is based on the
cervical, thoracic or lumbar range of motion numbers only. Three consecutive measurements should fall within
5 degrees or 10% (whichever is greater) of the mean (average) of the three measurements in order to meet
validity. If the mean is below 50 degrees, then each measurement must fall within 5 degrees of the mean and if
the mean is over 50 degrees, then all three measurements must fall within 10% of the mean.
TRIAL 1 2 3
Example:
Total ROM at T12………………………………… 110 110 110
Total Hip ROM…………………………………… 50 55 60
Total Lumbar ROM………………………………. 60 55 50
Mean Lumbar……………………………………... 55 degree
10%.......................................................................... 5.5 degree or 6 degrees
Valid……………………………………………… Yes, 50 & 60 are both within 6 degrees of 55.
Page 14

If the patient does not meet validity, then instruct the patient that they are failing the validity criteria, which is
invalidating the measurements and tell them that they must move further in order to achieve valid results. You
may record up to 6 repeat trials and if validity is not met, then invalidate that portion of the evaluation. The test
may be performed at a later date.
Normative Date- the AMA Guidelines
Norms for spinal inclinometry were developed and published in the American Medical Associations Guides
to Evaluation of Permanent Impairment. These norms are very aggressive, i.e., based on a young population
and they are not age or sex adjusted. A copy of the AMA Guides can be purchased from the AMA office.
American Medical Association
515 North State Street
Chicago, IL 60610
1-800-621-8335
Repeat Trial Consistency –Muscle Testing
The values used for repeat trial consistency, which have been determined from six years testing, is a calculation
of the percentage between peak forces of two consecutive exertions. For example:
Consistency
Trial One: 40.0 lbs. 2.5% - Valid
Trial Two: 39.0
The criteria used for interpretation of validity is as follows:
Intrinsic Hand Muscles
VALID 0-15.0 %
EQUIVOCAL 15.1-20.0 %
INVALID >20.0 %
The criteria used for all other muscles is:
VALID 0-10.0 %
EQUIVOCAL 10.1-15.0 %
INVALID > 15.0 %
Page 15

Recording and Retrieving Test Data
The microFET3 is designed to store and retrieve results for the 30 most recent tests for muscle testing, and 30
most recent test angles for inclinometer testing.
In test mode, results are displayed for the most recent test only. Results for each new test, peak force,
and duration, will be displayed as soon as the test is completed, replacing results from the previous test.
The same applies for inclinometer tests.
Six test record tablets are included with your MICROFET3. Sheets in the tablets provide space for writing the
peak force and the test duration and range of motion data. Additional tablets can be ordered through Hoggan
Scientific LLC.
To retrieve and display saved muscle tests, follow these steps:
1. To put the unit in muscle test data retrieval mode hold down the MT/Threshold button and press and
release the Reset button once.
The unit will display the test number and durations in seconds in the Durations/Sec LCD display (left display)
and peak force in the peak force LCD display (right display) for the first test or test 1. Refer to Image L
below.
IMAGE L
In muscle test data retrieval mode, test duration displays: in tenths of seconds for tests of .1 to 9.9 seconds a
decimal point appears. In the display in whole seconds for tests of 10 seconds to 99 seconds no decimal point
will appear.
2. To scroll through test results, press the MT/Threshold button. The unit will display a new test number
representing 2nd most recent test, new peak force, and test duration for the 2nd test displayed.
Each time you press the MT/Threshold button, the unit will move backward to the previous test, up to
total of 30 tests.
30 tests will be stored as long as the unit has battery power. Turning off the unit, or allowing the unit to go to
sleep mode will not affect the stored results. However, the 31st test will bump the oldest test. At that point,
the oldest test(s) will no longer be retrievable.
Page 16

3. To return to test mode, press the reset button the unit will display peak force of 0.0, L or H, indicating low
or high threshold, and duration/secs of 0.0. You can enter data retrieval mode at any time, by holding down the
MT/Threshold button, and then pressing the Reset button. The unit will display the most recent test results.
To retrieve and display saved inclinometer tests, follow these steps:
1. To put the unit in inclinometer test data retrieval mode hold down the INCL button and press and
release the Reset button once.
The unit will display the angle in the Durations/Sec LCD Window and test number in the peak force LCD
display for the first test or test 1. Refer to Image M below.
IMAGE M
In inclinometer test data retrieval mode, the angle is displayed in whole angles.
2. To scroll through test results, press the INCL button. The unit will display a new test number representing
2nd most recent test, and new angle for the 2nd test displayed.
Each time you press the INCL button, the unit will move backward to the previous test, up to total
of 30 angle tests saved.
30 tests will be stored as long as the unit has battery power. Turning off the unit, or allowing the unit to go to
sleep mode will not affect the stored results. However, the 31st test will bump the oldest test. At that point,
the oldest test(s) will no longer be retrievable.
3. To return to test mode, press the reset button the unit will return to the inclinometer test mode. You can
enter data retrieval mode at any time, by holding down the INCL button, and then pressing the Reset button.
The unit will display the most recent test results.
Included with your microFET3 are (6) test record tablets. Sheets in the tablets provide space for writing the
peak force and the test duration and range of motion data. Additional tablets can be ordered through Hoggan
Scientific LLC customer service at 800-678-7888.
The microFET3 was designed as standalone gauge for simple measurements. However, with newly
incorporated wireless technology, the unit allows you the option to use microFET3, cord free, with Hoggan
Scientific clinical testing software to increase your evaluation, documentation and research capability.
Page 17

Low Batteries
When battery power is getting low, the LCD displays will blink indicating low battery power. Blinking
LCD displays indicate that the microFET3's battery power may be low. If LCD displays keeps blinking after
pressing Reset, the battery should be recharged.
To avoid testing interruptions due to low battery power, we recommend that you check remaining batter
power regularly, and recharge battery when it reach approximately 15% power level. To check battery power,
follow the battery check instructions on page 9.
Changing Batteries
MICROFET3 uses (1) 3.7V LI-ION high quality battery. To change the battery, turn the unit over and remove
the attachment. Unscrew the 4 Phillips head screws, remove bottom of the unit, replace the battery and re-
tighten the screws. If the segment does not light up after installing a new battery, contact Hoggan Customer
Service Department at 800-678-7888.
Warranty
Product Warranty Information
The microFET3 is warranted for a period of one year from the time of purchase. If the microFET3 fails to
operate because of defect in materials or workmanship at any time within one year of the purchase date, it will
be repaired or replaced free of charge by Hoggan Scientific LLC. Extended warranties (additional year or
years) are available at an additional nominal fee.
If you wish to purchase and extended warranty after the purchase of your microFET3, there is a 30 grace period
to purchase an extended warranty package. Contact Hoggan Scientific for more information.
Warranty Registration
To ensure that your warranty is in force, please complete and mail, or fax your warranty card to Hoggan
Scientific LLC at 800-915-3439. Or visit www.hogganhealth.net to register your warranty information online.
Please save proof of your original purchase date, such as your sales slip, invoice, credit card voucher, or
cancelled check to establish the warranty period.
Warranty Repairs
Before deciding that your microFET3 is inoperable or defective, please review and follow the information in
the instruction booklet.
In the unlikely event that your microFET3 becomes inoperable, please contact Hoggan Scientific to arrange to
have the equipment repaired or replaced. Hoggan reserves the right to repair or replace the unit with new or
refurbished parts or equipment.
Hoggan Scientifics’ Customer Service Department can be contacted at 800-678-7888, or by email at
[email protected].
When Hoggan Scientific Customer Service Representative authorizes return of the product, you will be
given Return Merchandise Authorization (RMA) number. Please include the RMA number with your unit.
Warranty Exclusions and Limitations
The microFET3 warranty does not cover damage by negligence, misuse, or accident. Damage or unit
failure caused by modifications or repair other than by Hoggan Scientific or its authorized repair agent, or
damage to equipment resulting from improper installation or operation is not covered. Any warning or
instructional labels or decals must remain on the unit for the warranty to be valid.
Page 18

This warranty applies to the original purchaser. Some states do not allow the exclusion or limitation of
incidental or consequential damages, in which case the exclusions and limitations may not apply. This warranty
gives specific legal rights, and may also have other rights, which vary from state to state. To determine the legal
rights in your state, consult your local or state consumer affairs office or State Attorney General.
Customer Service Repairs
Customer satisfaction is important to Hoggan Scientific. We are happy to assist with questions, problems or
service issues on any Hoggan products you may own. Our business has grown on the basis of excellent product
quality and customer satisfaction. Our fulltime customer service representatives are available from 8:30 am to
4:00 pm MST at 800-678-7888 to meet your needs. You can also contact Hoggan Scientific online regarding
your customer service issue or calibration by e-mailing us at [email protected].
Any repairs to the microFET2 unit should be completed by qualified service technician.
Ordering Replacement Parts
Hoggan Scientific Products are manufactured to exacting specifications. When replacing worn or damaged
parts, use only original ‘Hoggan’manufactured parts. The use of substitute or unauthorized parts will void your
warranty and may increase the possibility of injury to the user, or cause additional damage to the unit.
When ordering Replacement Parts, please take the unit out of service, and complete the following:
1. Identify the brand, model, and serial number, and note the unit’s function.
2. Identify and document the problem and the worn or missing parts.
3. Contact Hoggan Scientific LLC. Replacement parts (attachments) will be shipped directly from
Hoggan.
All repair services will be performed at Hoggan Scientific LLC Manufacturing plant.
*Except for replacing battery, do not attempt to repair the unit on your own. This will void all warranties.
Page 19
