HoldPeak MinIR 950A User manual

About this IR Camera User Guide
Symbols Used
This mark denotes issues that may affect the IR camera’s operation.
This mark denotes additional topics that complement the basic
operation procedures.
What do the icons listed in the Camera User Guide mean?
Information displayed on the LCD Monitor (p.17)
Trademark Acknowledgments
· HOLDPEAK is trademarks of ZHUHAI JIDA HUAPU INSTRUMENT CO., LTD..
·Microsoft, Windows and Windows logo is either registered trademarks or
trademarks of Microsoft Corporation in the United States and / or other
countries.
·Other names and products not mentioned above may be registered
trademarks or trademarks of their respective companies.
Copyright © 2012 HUAPU LTD. All rights reserved.
1

Thumb Index
Introduction of camera components and battery
loading.
Describes basic functions, learning how to turn
on/off the IR camera and work with the control panel
and LCD monitor.
Describes some of the advanced features,
such as use the camera’s various analysis tools and
turning on/off laser pointer etc
Preparing the
IR Camera
Basic function
Shooting
Explains
how to save images and review
recorded images.
Explains how to transfer images to a computer.
Explains how to use the monitor for shooting and
playback images.
2
Playback
Download
Connection

Table of Contents
Read This First………………………………………………
Component Guide……………………………….………….
Front View ……………………………………………….………..
Bottom/ Dock (optional)………………………………………….
5
10
10
11
Preparing the IR Camera….…………………….…………. 13
Charging the Battery Pack………………………………….…...
Installing the Battery Pack / SD Card………………….….
Turning the Power On/ Off……………………………………….
Checking the Information………………………………………..
Enter NULL mode………………………………………………..
Setting the Date/ Time…………………………………………...
Mode Settings…….……………..………………………………..
13
14
16
17
18
19
20
Basic Functions….……………………………….………… 21
Using the LCD Monitor………………..…………………………
Selecting Menus and Settings……………………………..……
Resetting the Setting to Default………..……………………….
21
22
24
Shooting………………………………………………........ 25
IR Camera Adjustment………..…………………………………
Focus. ………………………………..…………………………
Manual Focus…………….…………………………………
Image Adjustment………………………………………….…..
Auto Adjust……..……………………………………………
Manual Adjustment…………………………………………
Palette settings……………………………………………...
Freezing/ Activating an Image…………………………………
Object/Ambient parameter and Alert …………………………
Setting Analysis Tools…………………………………….……
Spot Analysis…………………………………………………
Saving/Playback Images……………...…………………..……..
Saving Images……………………………………………….
Playback images….………………………………………….
25
25
25
26
26
26
26
27
28
30
30
32
32
32
Download the Images…………………………………...…. 35
Download via SD Card………………………...……………….… 35
Connecting and Download……..………….…………...…. 36
Connecting to the dock……. …………………………….…..
Charging via the dock …………………………………........
36
37
3

Connecting to a Monitor……………….…………………..………
Accessory……………………………………………………
38
39
Troubles Shooting……………………….…………………. 40
Appendix………………………………………………….….
Use the optional lens……………………………………………...
Camera Care and Maintenance………………….……………..
Emissivity table……………………………………………………
41
41
42
43
Specifications…………………………….…….…………… 48
4

Read This First
Please Read
Test Shots
Before you try to shoot important subjects, we highly recommend
that you shoot several trial images to confirm that the IR camera is
operating and being operated correctly.
Please note that HOLDPEAK, its subsidiaries and affiliates, and its
distributors are not liable for any consequential damages arising
from any malfunction of an IR camera or accessory that results in
the failure of an image to be recorded or to be recorded in a format
that is machine readable.
Warranty and technical support
Warranty and other after-sales service, please see the warranty
card attached.
Safety Precautions
Before using the camera, please ensure that you read and
understand the safety precautions described below. Always ensure
that the IR camera is operated correctly.
The safety precautions noted on the following pages are intended to
instruct you in the safe and correct operation of the IR camera and
its accessories to prevent injuries or damage to yourself, other
persons and equipment.
5

Warnings
Read on to learn about using IR camera properly.
Avoid damaging eyesight
Warning: Do not trigger the laser pointer in human or animal eyes.
Exposure to the laser produced by the laser pointer may damage
eyesight.
Do not disassemble
Do not attempt to disassemble or alter any part of the equipment that is
not expressly described this guide
Stop operating immediately if it emits smoke or noxious fumes
Failure to do so may result in fire or electrical shock. Immediately turn
the IR camera’s power off, remove the IR camera battery or unplug the
power cord from the power outlet. Confirm that smoke and fume
emissions have ceased.
Stop operating immediately if it is dropped or the casing is
damaged
Failure to do so may result in fire or electrical shock. Immediately turn
the IR camera’s power off, remove the IR camera battery or unplug the
power cord from the power outlet.
Do not use substances containing alcohol, benzene, thinners
or other flammable substances to clean or maintain the IR
camera
The use of these substances may lead to fire.
Remove the power cord on a regular periodic basis and wipe
away the dust and dirt that collects on the plug, the exterior of
the power outlet and the surrounding area
In dust, humid or greasy environments, the dust that collects around
the plug over long periods of time may become HOLDPEAKurated with humidity
and short-circuit, leading to fire.
6

Do not handle the power cord if your hands are wet
Handling it with wet hands may lead to electrical shock. When
unplugging the cord, ensure that you hold the solid portion of the plug.
Pulling on the flexible portion of the cord may damage or expose the
wire and insulation, creating the potential for fires and electrical shocks.
Do not cut, alter or place heavy items on the power adapter
cord
Any of these actions may cause an electrical short circuit, which may
lead to fire or electrical shock.
Use only the recommended power accessories
Use of power sources not expressly recommended for this IR camera
may lead to overheating, distortion of the IR camera, fire, electrical
shock or other hazards.
Do not place the batteries near a heat source or expose them
to directly to flame or heat
Neither should you immerse them in water. Such exposure may
damage the batteries and lead to the leakage of corrosive liquids, fire,
electrical shock, explosion or serious injury.
Do not attempt to disassemble, alter or apply heat to the
batteries
This is serious risk of injury due to an explosion. Immediately flush with
water any area of the body, including the eyes and mouth, or clothing,
that comes into contact with the inner contents of a battery. If the eyes
or mouth contact these substances, immediately flush with water and
seek medical assistance.
Avoid dropping or subjecting the batteries to severe impacts
that could damage the casings
It could lead to leakage and injury.
Do not short-circuit the battery terminals with metallic objects,
such as key holders
It could lead to overheating, burns and other injuries.
7

Before you discard a battery, cover the terminal with tape or
other insulators to prevent direct contact with other objects
Contact with the metallic components of other materials in waste
containers may lead to fire or explosions. Discard the batteries in
specialized waste facilities if available in your area.
Use only recommended batteries and accessories
Using of batteries not expressly recommended for this equipment may
cause explosions or leaks, resulting in fire, injury and damage to the
surroundings.
Disconnect the compact power adapter from both the IR
camera and power outlet after recharging and when the IR
camera is not in use to avoid fires and other hazards
Continuous use over a long period of time may cause the unit to
overheat and distort, resulting in fire.
Do not use the battery charger or compact power adapter if the
cable or plug is damaged, or if the plug is not fully inserted
into the power outlet
The battery charger varies according to region.
Exercise due caution when screwing on the separately sold
tele-lens, close-up lens
If the lens is loosened and fallen off, the glass shards may cause an
injury.
If your camera is used for prolong periods, the IR camera body
may become warm
Please take care when operating the IR camera for an extended period
as your hands may experience a burning senHOLDPEAKion.
8

Prevent Malfunction
Read on to learn about preventing malfunction of IR camera
Avoid damaging the detector of the IR camera
Warning: Do not aim the IR camera directly into the sun or at other
intense heat source which could damage the detector of the IR
camera.
Avoid CondenHOLDPEAKion Related Problems
Moving the IR camera rapidly between hot and cold temperatures may
cause condenHOLDPEAKion (water droplets) on its external and internal
surfaces.
You can avoid this by placing the IR camera in the plastic case (bundle)
and letting it adjust to temperature changes slowly before removing it
from the case.
If CondenHOLDPEAKion Forms Inside the IR Camera
Stop using the camera immediately if you detect condenHOLDPEAKion.
Continue to use may damage the IR camera. Remove the PC card, and
battery or a household power source, from the IR camera and wait until
moisture evaporates completely before resuming use.
Extended Storage
When not using the IR camera for extended periods of time, remove the
battery from the IR camera or battery charger and store the IR camera in
a safe place. Storing the IR camera for extended periods with battery
installed will run down the battery.
Different Models
Some advanced functions are included only in E8-TN and E8-GN, E8-N
only has the fundamental function
Right Reserved
HOLDPEAK reserve the right to change the functions and configurations of our
products without prior notice.
9

Component Guide
Front View
*Illuminator
Focus Ring
Thermal
Lens
Lens Locking
Ring
*Laser Pointer
10

Component Guide
Controls / Multi-function Dock Auto Adjust Key
Power Switch
Power Indicator
Freeze / Activate
Cancel Key
Menu / Enter Key
Cursor Key
USB
Terminal
Video Output Power Terminal
Terminal
11

Component Guide
Bottom / Connectors
Multi connector
SD Card Slot
Battery Lock
Battery
insertion slot
Lock
Multi connector
12

Preparing the IR Camera
Charging the Battery Pack
Follow the steps below to charge the battery pack for the first time and
subsequently when the low battery icon appears on the Display Panel.
1
2
Align the edge of the battery
pack with the line on the
battery, then insert the battery
in the direction of the arrow.
Attach the power cord to the battery charger and plug the other
end into a power outlet.
·The charge indicator light is red while the battery pack is charging
and it turns green when charging is complete.
·After charging, unplug the battery charger and remove the battery
pack.
·
·
This is a lithium ion battery pack so there is no need to discharge it
completely before recharging. It can be recharged at any time. However,
since the maximum number of charge cycle is approximately 300
(battery life), you are recommended to only charge the battery pack after
having discharge it completely to prolong battery life.
Charging times will vary according to the surrounding humidity and
battery pack charge state.
13

Preparing the IR Camera
Installing the Battery Pack / SD Card
Install Battery Pack into the camera as following,
Charge the battery pack before using it for the first time.
1
Check if the power is off and
slide the battery cover in the
direction of the arrow.
2
Insert the battery pack.
Insert the battery in
direction of the arrow.
the
3
4
14
Insert SD card.
Insert the SD card in the
direction of the arrow.
Close the battery / SD card cover.

·Remove the battery pack when the camera is not in use.
·The SD Card must be formatted in FAT32. Otherwise, the IR camera
may not recognize the SD card.
Battery Status Symbols
The following icons indicate the battery status on the LCD display.
Sufficient battery charge
Low battery
Replace or recharge the battery
15

Preparing the IR Camera
Turning the Power On and Hold the Camera Correctly
The power indicator is lit while the power of the camera is on.
1
Holding the camera correctly
with your right hand, put your
thumb above the key pad and
put your forefinger in front of
the definable trigger.
2
Power Switch
Press and hold the power
switch for 3 seconds. the
power indicator will light
green.
3
4
After a while, a startup image
will appear on the screen.
Turn off the camera.
Hold the power switch for 3 seconds,The power indicator goes
off.
16

Preparing the IR Camera
Checking the Information on the LCD Monitor
The LCD monitor has a field of vision of 100% of the actual shooting
image.
The following displays in information view.
Reading
Upper limit
of
color scale
Color
scale
Lower limit of
color scale
Time
SD Card Battery Charge
Activate
/ Freeze
Current
Emissivity
Operation
indicator
17

About the operation indicator
The operation indicator shows the current operation status
of the camera.
Status of the camera
Menu
Null
Represents the menu mode.
Represents the non-menu mode and no
analysis tools is selected.
Status of
the
camera
SP1
CAP.
E
Represents the current analysis tool is
spot 1
Reprents the current analysis tool is
auto-tracking spot.
Current Emissivity value
SD card has been inserted.
How to enter [Null] mode：
Press the C key repeatedly until see the message of null in the operation
Indicator
If you select menu, except submenu of [Analysis], you can press
MENU/ENTER key to close the menu window.
18

Preparing the IR Camera
Setting the date and time
You need to set the Data / Time when the IR camera is turned on for the
first time.
1
2
3
4
Make sure that the IR camera is in null mode.(p.18)
Press the MENU/ENTER key then
press the UP or DOWN arrow on
the omni selector to select the
[System Setup] menu.
Press the UP or DOWN arrow on the
omni selector to select [Date & Time]
then press the MENU/ENTER key.
Setting Date and Time
·Press the UP or DOWN arrow on
the omni selector to select an item
to change.
·
Press the LEFT or RIGHT arrow on
the omni selector to set the values.
5
After adjusting the settings, press the MENU/ ENTER key to
save changes, or press the C key to go back to upper menu
without saving.
19

Preparing the IR Camera
Mode Settings
In this menu item, you can display style of the built-in menu system.
1
2
3
Make sure that the IR camera is in null mode.(p.18)
Press the MENU/ENTER key then
press the UP or DOWN arrow on
the omni selector to select the
[System Setup] menu.
Press the LEFT or RIGHT arrow
on the omni selector to select
[Standard Mode] or [Low Power]
The default is the Low Power mode. Low Power mode:
continuous operation does not turn off automatically 30 seconds
LCD display, for 5 minutes without operating automatic
shutdown.
20
