Holmes HOH2501 User manual

CLEANING/MAINTENANCE/
TROUBLESHOOTING WARRANTY INFORMATION
Owner’s Guide
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
SERVICE INSTRUCTIONS
1. DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit. Doing so will void the Warranty.
2. If you need to exchange the unit, please return it in its original carton, with a sales receipt, to the store where you purchased it. If you are returning the unit more than
30 days after the date of purchase, please see the enclosed Warranty.
3. If you have any questions or comments regarding this unit’s operation or believe any repair is necessary, please write to our Consumer Service Department or visit our
website at www.holmesproducts.com.
THE HOLMES GROUP, INC.
CONSUMER SERVICE DEPARTMENT
32B SPUR DRIVE
EL PASO, TX 79906
For your own records, staple or attach your sales receipt to this manual. Also, please take a moment to write the store name/location and date purchased below.
STORE NAME:
LOCATION:
DATE PURCHASED:
(STAPLE RECEIPT HERE)
FIVE (5) YEAR LIMITED WARRANTY
SAVE THIS WARRANTY INFORMATION
A. This Warranty applies only to the original purchaser of this product.
B. This Warranty applies ONLY to repair or replacement of any supplied or manufactured parts of this product that, upon inspection by The Holmes Group, Inc. authorized
personnel, is shown to have failed in normal use due to defects in material or workmanship. The Holmes Group will determine whether to repair or replace the unit.
This Warranty does not apply to installation expenses.
C. Operating this unit under conditions other than those recommended or at voltages other than the voltage indicated on the unit, or attempting to service or modify the
unit, will render this WARRANTY VOID.
D. Unless otherwise proscribed by law, The Holmes Group shall not be liable for any personal injury, property or any incidental or consequential
damage of any kind (including water damage) resulting from malfunctions, defects, misuse, improper installation or alteration of this product.
E. All parts of this product are covered under separate warranty, are guaranteed for a period of 5 years as follows:
1. Within the first 30 days from date of purchase, the store from which you purchased your product should replace this product if it is defective in material or workman ship
(provided the store has in-stock replacement.) If you intend to assert any claim in connection with the product, please follow the instructions in paragraph F.
2. Within the first Sixty days from date of purchase, The Holmes Group will repair or replace the product if it is defective in material or workmanship, subject to the
conditions in paragraph G.
F. If you have any other problem or claim in connection with this product, please write our Consumer Service Department.
G. IMPORTANT RETURN INSTRUCTIONS. Your Warranty depends on your following these instructions if you are returning the unit to The Holmes Group, Inc.:
1. Carefully pack the item in its original carton or other suitable box to avoid damage in shipping.
2. Before packing your unit for return, be sure to enclose:
a) Your name, full address with zip code and telephone number
b) A dated sales receipt or PROOF OF PURCHASE,
c) Your $10.00 check for return shipping and handling, and
d) The model number of the unit and the problem you are having. (Enclose in an envelope and tape directly to the unit before the box is sealed.)
3. The Holmes Group recommends you ship the package U.P.S. ground service for tracking purposes.
4. All shipping charges must be prepaid by you.
5. Mark the outside of your package:
HOLMES
THE HOLMES GROUP, INC.
32B SPUR DRIVE
EL PASO, TX 79906
SHIPPING AND HANDLING CHARGES: $10.00 (USD)
This Warranty gives you specific legal rights, and you may have other rights which vary from state to state. The provisions of this Warranty are in addition to, and not a
modification of, or subtraction from, the statutory warranties and other rights and remedies contained in any applicable legislation. To the extent that any provision of this
Warranty is inconsistent with any applicable law, such provision shall be deemed voided or amended, as necessary, to comply with such law.
Holmes®and the Holmes logo®are trademarks of The Holmes Group, Inc. or its subsidiaries.
Job # HOH2501.03.UM1 Printed in Turkey
HOH2501
1500 Watt
Compact
Oil Filled
Heater
CLEANING/MAINTENANCE INSTRUCTIONS:
During Season Care:
1. Always unplug the heater before cleaning.
2. Clean the unit with a soft damp cloth. Please be very cautious
near the metal fins.
3. NEVER use abrasive or flammable solvents to clean the unit.
4. After cleaning, be sure to completely dry the unit with a cloth
or towel.
After Season Care:
1. Store heater in a cool, dry location.
2. The manufacturer recommends that you store the unit
in its original carton.
TROUBLESHOOTING
If your heater fails to operate:
•UNPLUG THE UNIT.
•Make sure the electrical outlet or circuit breaker is working.
•The temperature may be set too low. Adjust the thermostat until the heater restarts.
Please DO NOT attempt to open or repair the heater.
Please see the Warranty for Service Instructions.
HOH250103EM1
HOH2501EM1_Eng.qxd 5/29/03 11:39 Page 1

PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS FEATURES - OPERATIONSFEATURES - OPERATIONS
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and
injury to persons, including the following:
1. Read all instructions before using the appliance.
2. To avoid fire or shock hazard, plug the appliance directly into
a 120V AC electrical outlet.
3. The heater is hot when in use. To avoid burns, DO NOT let bare
skin touch hot surfaces. If provided, use handles when moving
this heater. Keep combustible materials, such as furniture,
pillows, bedding, papers, clothes, and curtains at least 3 ft (0.9
m) from the front of the heater and keep them away from the
sides and rear.
4. DO NOT run cord under carpeting. DO NOT cover cord with
throw rugs, runners, or the like. Arrange cord away from
traffic area and where it will not be tripped over.
5. This heater is not intended for use in bathrooms, laundry areas
and similar indoor location. NEVER locate heater where it may
fall into a bathtub or other water container.
6. Extreme caution is necessary when any heater is used by, or
near children or invalids, and whenever the heater is left
operating and unattended.
7. Always unplug the heater when not in use.
8. When unplugging, be sure to pull by the plug and not the cord.
9. DO NOT insert or allow foreign objects to enter any ventilation
or exhaust opening as this may cause an electric shock or fire,
or damage the heater.
10. DO NOT operate heater with a damaged cord or plug, or after
the heater malfunctions, has been dropped or damaged in
any manner. Return appliance to manufacturer for
examination, electrical or mechanical adjustment, or repair.
11. A heater has hot and arcing or sparking parts inside. DO NOT
use it in areas where gasoline, paint, or flammable liquids are
used or stored.
12. Use appliance only for intended household use as described in
this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to
persons. The use of attachments not recommended or sold by
The Holmes Group may cause hazards.
13. DO NOT use outdoors.
14. To prevent a possible fire, DO NOT block air intakes or
exhaust in any manner. DO NOT use on soft surfaces, like a
bed, where openings may become blocked.
15. To disconnect heater, turn controls to OFF, then remove plug
from outlet.
16. Avoid the use of an extension cord because the extension cord
may overheat and cause a risk of fire. However, if you have
to use an extension cord, the cord shall be No. 14 AWG
minimum size and rated not less than 1875 watts.
17. DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void your
warranty. The inside of the unit contains no user serviceable
parts. All servicing should be performed by qualified
personnel only.
18. Discontinue use if plug or outlet is hot. It is recommended that
the outlet be replaced if plug or outlet is hot to touch.
PLEASE READ AND SAVE THESE
IMPORTANT INSTRUCTIONS
PRE-OPERATING INSTRUCTIONS:
1. Carefully remove your heater from the box. Please save the carton
for off-season storage.
2. Make sure the unit is in the OFF position before plugging the heater
into the outlet.
3. Place heater on firm level surface.
4. Avoid overloading your circuit by not using other high wattage
appliances in the same outlet. At 1500 Watts, this unit draws
12.5 Amps
NOTE: This unit is for FLOOR USE ONLY
THIS PRODUCT IS EQUIPPED WITH A POLARIZED AC
(Alternating Current) PLUG (a plug having one blade wider
than the other). This plug will fit into the power outlet only
one way. If the plug does not fit fully into the outlet, reverse
the plug. If it still does not fit, contact qualified personnel to
install the proper outlet.
DO NOT DEFEAT THE SAFETY PURPOSE OF THIS
POLARIZED PLUG IN ANY WAY
Figure 1
Carry Handle
Cord Wrap
Easy Roll Wheels
Carry Handle
Thermostat
OFF
I LOW (600W)
II MED (900W)
III HIGH (1500W)
Power Light
MODE Control
Figure 2
Figure 3
Figure 4
ASSEMBLY INSTRUCTIONS:
WHEEL AND FRONT FOOT ASSEMBLY
There are two wheels, one axle, one front foot, two wing nuts, and one
“U” bolt packed within the box that you will need to assemble the
heater. (See Fig. 3 & 4).
1. Insert the two wheels into the two holes in the axle. They will snap
in, and are not meant to be taken apart after being put into the
axle.
2. Turn the heater upside down. You may hear a gurgling sound
as the liquid settles. (The control panel will be closest to the floor).
3. Place the “U” bolt over the last joint of the heater with the
threaded ends pointed upward.
4. Align the holes in the axle with the “U” bolt and slide into place.
5. Secure the axle with the two provided wing nuts.
6. While the unit is still upside down, take the front foot, and snap
it into the corresponding holes in the front part of the heater.
This front foot is not meant to be removed once it is attached
to the bottom of the unit.
NOTE: This unit can not be operated without wheels and
front foot assembled.
OPERATING INSTRUCTIONS:OPERATING
1. Set the thermostat to the OFF position.
2. Plug in heater. The power light will illuminate and remain lit
when the heater is turned on.
3. For heater operation, set the Thermostat control all the way to HI.
4. Turn the Heat Setting Control to desired heat setting (LOW for
600W, MED for 900W, or HIGH for 1500W).
SETTING THE THERMOSTAT:
1. Set the Thermostat control all the way to HI. (See Fig. 2)
2. When the desired temperature/comfort level is reached, lower
the thermostat control setting until the heater stops operating.
3. The control will now automatically maintain the pre-set temperature
level by turning the heater ON and OFF.
NOTE: The Power light will remain lit during operation.
NOTE: It is normal for the heater to cycle ON and OFF as it
maintains the preset temperature. To prevent the unit from
cycling, you need to raise the thermostat setting.
ILLUSTRATIONS:
