Holz-Blech ELISABETH 28 User manual

× 60
× 15
× 12
× 510
× 35
× 30
4×405×70
4×506×1401,4×40
M8×60
Ø 3 mm
Ø 4 mm
Ø 5 mm
Ø 8 mm
1/20
ELISABETH 28
PREPARE THE GROUND, UNWRAP THE PACKAGE,
LAY OUT THE COMPONENTS, FIND THE TOOLS.

2/20
ELISABETH 28
MAKE SURE THAT THE FOUNDATION
IS INSTALLED ON A LEVEL SURFACE.
CHECKING ALL DIRECTIONS,
INCLUDING CORNER TO CORNER. 3%
LAY OUT THE FOUNDATION BEAMS
AND SQUARE IT BY MEASURING
FROM CORNER TO CORNER.
IFB
AC
DB
AB=CD
0°

× 5× 12
5×70
6×140
Ø 4 mm
Ø 5 mm
3/20
ELISABETH 28
LAY OUT THE BOTTOM LOGS,
ATTACH TO THE FOUNDATION.
THE WALL LOGS WILL HANG OVER
THE FOUNDATION BEAMS BY
APPROXIMATELY 5MM. THIS OVERHANG
IS DESIGNED AS A RAIN DRIP. 5%
2 BL-1
6×140
1 BL- 1
1 BL-1
A LG-1
B LG-1
5×70
5mm

× 4
5×70Ø 4 mm
× 5
6×140Ø 5 mm
4/20
ELISABETH 28
7%
ATTACH THE FIRST ROW OF
WALL LOGS INTO THE BOTTOM
LOGS WITH SCREWS.
2 LG-6
1 LG-5
1 LG-5
6×140
5×70

5/20
ELISABETH 28
12%
AFTER PLACING 3-4 ROWS OF WALL LOGS, TAP EACH
WALL LOG IN PLACE USING A HAMMER AND THE
HITBLOCK PROVIDED, TO TIGHTEN THE LOGS.
HITBLOCK

6/20
ELISABETH 28
13%
SLIDE THE DOOR IN,
ATTACH THE HANDLE.
BDD5R
3 LOGS IN PLACE

7/20
ELISABETH 28
26%
DON`T FORGET TO
TIGHTEN THE LOGS AFTER
EVERY 3-4 ROWS.
1 LG-2
1 LG-5
1 LG-1

8/20
ELISABETH 28
SLIDE THE WINDOW IN,
ATTACH THE HANDLE.
28%
BW1L
BW1R

× 4
6×140Ø 5 mm
9/20
ELISABETH 28
42%
INSTALL THE GABLES WITH LONG SCREWS
TO THE WALL LOGS ON THE FRONT AND
REAR WALLS.
15 LOGS IN PLACE
GABLE
A TL-1 B TL-1
B LG-2
A LG-2

× 10
6×140Ø 5 mm
10/20
ELISABETH 28
43%
INSTALL THE ROOF PURLINS AND
ATTACH THEM WITH SCREWS.
RFR
RFB

× 272
4×50
11/20
ELISABETH 28
PLACE THE FIRST ROOFBOARD FLUSH WITH THE
END OF THE PURLINS AND ATTACH
WITH 6 SCREWS, 3 INTO EACH NEXT,
SAW THE LAST BOARD TO MAKE IT FIT.
46%
RB

× 32
4×40
12/20
ELISABETH 28
79%
FOR THE FASCIA TRIMS INSERT
SCREWS AFTER EVERY 0,5 METERS.
RR1
RR2

× 40
4×40Ø 3 mm
13/20
ELISABETH 28
83%
EAVES EDGES GO ON TOP
OF THE ROOFING*.
*(NOT INCLUDED) RF
EE

×4
4×40Ø 3 mm
14/20
ELISABETH 28
84%
ATTACH ROMBS WITH SCREWS.
ROMB

× 216
4×50
15/20
ELISABETH 28
89%
12 SCREWS INTO THE FIRST FLOORBOARD,
6 INTO EACH NEXT, SAW THE
LAST BOARD TO MAKE IT FIT.
FB

× 30
1,4×40
16/20
ELISABETH 28
96%
SAW THE BASEBOARDS
AND ATTACH WITH NAILS
AT EVERY 0,5 METERS
BB

× 12
M8×60
Ø 8 mm
17/20
ELISABETH 28
97%
DRILL THROUGH THE WALL, HOLE MUST
BE AT THE BOTTOM OF THE OVAL,
ATTACH WITH BOLT.
4CM
20CM
WINDBOARD

90º
90º
18/20
ELISABETH 28
98%
IF DOOR IS TILTED,
PUSH THE DOOR FRAME SO
THAT ALL CORNERS ARE 90º.

19/20
ELISABETH 28
99%
IF DOORS ARE IN DIFFERENT HEIGHTS
OR THERE IS A GAP BETWEEN THEM,
ADJUST 3 SCREWS ON DOOR HINGES.

20/20
ELISABETH 28
WHEN THE HOUSE IS ASSEMBLED, YOU SHOULD
COVER THE TIMBER WITH WOOD PROTECTIVE SEAL,
PAINT OR STAIN AS SOON AS POSSIBLE TO AVOID
DETERIORATION TO THE WOOD.
100%
