Home Decorators Collection BRADSTONE JS-3421-A User manual

USE AND CARE GUIDE
Item # 1005564190
Model # JS-3421-B
Item # 1005564189
Model # JS-3421-A
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
HOMEDEPOT.COM/HOMEDECORATORS
1-800-986-3460
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this Bradstone
4 Door Storage Console. We strive to continually create quality products designed to enhance your home. Visit us online to see
our full line of products available for your home improvement needs. Thank you for choosing Home Decorators Collection!
BRADSTONE 4 DOOR STORAGE CONSOLE

Table of Contents
HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
2

HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
3
Pre-assembly
PLANNING ASSEMBLY
Keep children and pets away from build area. Make sure your area is large enough to unpack, sort and assemble the unit.
TOOLS REQUIRED
Small head
Phillips
screwdriver
(Not Included)
Large head
Phillips
screwdriver
(Not Included)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
AA
BB
CC
DD
EE
FF
GG
Cam lock
Cam lock bolt
Hexagon socket bolt
Flat gasket
Spring washer
Layer shelf support
Cross round head bolt
HH
II
JJ
KK
Handle
Magnetic clamp
Flat head screw (Ø6x12mm)
Round head screw 25+2
4
4
14+2
8
4
14+2
8
8
8
24+2
Part Description Quantity Part Description Quantity
L shaped bracket
Anti-tipping hardware package 1
4
AA BB CC DD EE FF GG
HH II JJ KK
(1)X4 (2)X2 (3)X2 (4)X2 (5)X2 NN
LL
LL
NN
OO
Socket head screw wrench
2
MM
MM
1
OO
Thread hole cover
PP
PP Flat head screw(Ø6x16mm) 8

Pre-assembly (continued)
PACKAGE CONTENTS
4HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
A
B
C
D
E
F
F
H
I
J
K
J
G
K
A
B
C
D
E
F
G
Top panel
Left side panel
Right side panel
Bottom Board
Middle side panel
Shelf
Middle leg
H
I
J
Front dam board
Back panel
Left door panel 2
1
11
2
1
1
1
1
1
Part Description Quantity Part Description Quantity
2
Right door panel
K

5HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
NOTE: UPON OPENING THOROUGHLY CLEAN ALL WOODS SURFACES TO REMOVE DUST AND DIRT THAT MAY
HAVE SETTLED ONTO FINISH DURING SHIPMENT. IN ORDER TO PREVENT DAMAGE DURING ASSEMBLY,
PLEASE ASSEMBLE THIS ITEM WITH AT LEAST TWO PEOPLE.
HOW TO USE THE CAM TOOL
NOTE: THE ARROWS ON THE HIDDEN CAM-LOCKS SHOULD POINT TO THE CAM-BOLTS.
SHOULDER
NOTE:TURN THE CAM-BOLT SCREWS UNTIL THEY
ARE TIGHT,THE SHOULDER SHOULD BE AGAINST
THE SURFACE OF THE PART.
Notification
ARROW
ARROW
BB
AA

6 HOMEDEPOT.COM/HOMEDECORATORS
Assembly
1
Please contact 1-800-986-3460 for further assistance.
Small head Large head
(AA)x2 (BB)x2
Connect Panels (E & D)and middle leg(G)
a) Insert cam lock bolt (BB) to Bottom board(D) C) Fix cam lock(AA) on middle side panel(E)
d) Assemble middle leg (G)
Cam lock Cam lock bolt
BB D
D
E
AA
G
D
E
b) Align and join cam lock bolt(BB) on middle side panel(E),
please kindly be attention the direction of middle side
panel(E).

7 HOMEDEPOT.COM/HOMEDECORATORS
Assembly
2
Please contact 1-800-986-3460 for further assistance.
(AA)x6 (BB)x6 Small head Large head
(CC) x 8 (DD) x 8 (OOx 1)
(EE) x 8
(LL) x4
B
CBB
H
CC
EE
DD
LL
B
C
BB
CC
EE
DD
H
OO OO
AA
Assemble side panel (B/C)
a) Insert cam lock bolt (BB) to side panels(B/C) c) Align front dam board (H) to the bottom board(D) and
connect with side board (B/C)
b) Semi-fixed hexagon socket bolt(CC), spring washer(EE), flat
gasket(DD), L shaped bracket(LL) to the front dam board (H)
d) Join cam lock to side pannels(B/C), and tighten
hexagon socket bolt(CC)
Cam lock Cam lock
bolt
L shaped
bracket
Hexagon
socket bolt Flat gasket Spring
washer
Socket head
screw wrench

8 HOMEDEPOT.COM/HOMEDECORATORS
Assembly
3
Please contact 1-800-986-3460 for further assistance.
Small head Large head
A
II
PP
A
D
B
C
E
front
back
BB
AA
II
Assemble Top panel (A)
a) Join cam lock bolt (BB) to magnetic
clam(II) on top panel(A) C) Tighten cam lock(AA)on side panels(B/C) and
middle side panels(E)
b) Align and join side panels(B/C)& middle side
panel(E)with top panel(A)
(AA)x6 (BB)x6
Cam lock Cam lock bolt
(II)x4 (PP)x8
Magnetic clamp Flat head screw

9HOMEDEPOT.COM/HOMEDECORATORS
Assembly
4
Please contact 1-800-986-3460 for further assistance.
Small head
(KK)x25 (MM)x 2
I
KK
IMM
Assemble back panel
a) Open back panel(I) and adjust it as arrows. Put thread hole cover(MM)
to the thread hole, and fix it with round head screw(KK)
Round head screw Thread hole cover

(FF)x8
10 HOMEDEPOT.COM/HOMEDECORATORS
Assembly
5
Please contact 1-800-986-3460 for further assistance.
(HH)x4 (JJ)x24 Small head
(GG)x4
J
JJ
F
F
FF
D
HH
GG
FF
K
J
K
a) Fix hinge on side panels(B/C)and middle side board(E)
with flat head screw(JJ). Then join hanle(HH)with cross
round head screw(GG)on each door
b)Join layer shelf support(FF) on inner of side panels(B/ C)
and middle side panel(E),and put shelf (F) as folowing graphic.
Assemble door panels(J/K)
and shelf (F)
Layer shelf
support
Cross round
head bolt Handle Flat head
screw

IF THE GROUND IS NOT EVEN THE SIDEBOARD WILL BE UNSTABLE OR THE
DOORS UNSYMMETRICAL,YOU CAN ADJUST THE FOOT LEVELER UNDER THE
LEG.TURN LEFT TO TIGHTEN,TURN RIGHT TO LOOSEN.
ADJUST MAGNETIC CLAMP
(1)X4
11 HOMEDEPOT.COM/HOMEDECORATORS
Assembly
6
Please contact 1-800-986-3460 for further assistance.
NN
(2)X2 (3)X2 (4)X2 (5)X2
Rectangle
metal plate
0.63 in.Round
head screw
Plastic anchor Plastic band 1.97 in.Round
head screw
Small head
(2)
(1)
(5)
(1)
(3)
Wall
Floor Wall
Wall
Floor
Adjust door panels(J/K) and
assemble anti-tipping hardware
package(NN)
a) Adjust door panels
b) Join retangle metal plate(1)with round head screw(2) on
back of panel;Join retangle metal plate(1）and plastic
anchor(3)with round head screw(5)on the wall; then tighten
with plastic band(4)

HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
12
PROBLEMS SOLUTIONS
Not all of the product's
legs touch the floor
Make sure adjustable center feet levelers a re adjusted properly. T he levelers are pre -
assem bled on the bottom of the legs
T he product is KD construction. Y ou may nee d to loosen the bolts and pla ce the product on
a flat surfa ce. E nsure that the legs all touch the flat surface and then re-tighten the bolts.
Loosen all the bolts and apply som e weight to the product to get all the feet to touch the
floor. T hen re-tighten the bolts in that position.
Panel cannot be
assem bled Make sure panel is on right direction.
Door cannot be closed or
without magnetic function Adjust the magnetic clamp, make sure it is assembled on appropriate position.
Door is not flat Adjust the hinge, make sure it is assem bled on appropriate position.
