HOMEDEPOT C-31 User manual

ITEM : C
-
31
ISSUED NOV 04, 2014
Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No.
:
DELUXE X BACK CHAIR RTA
: C-31

ITEM : C
-
31
ISSUED NOV 04, 2014
Printed in Vietnam
- 2 -
BEFORE ASSEM
B
LY
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. Please take the time to read and follow the assembly instructions carefully.
Be sure to check all packing material carefully for small parts which may have come loose inside the carton
during shipment. Please separate, identify, and count all parts and metal hardware. Compare with part list to be
sure all parts are present.
If hardware is missing or you have difficulty assembling this product, please call Toll Free: 1-888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
PART
LIST
When unpacking, please carefully not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following parts:
NO
Description
Q
ty
Sketc
h
NO
Description
Q
ty
Sketch
A Chair back 1 B Seat Frame 1
C Chair Seat 1 D Front Leg
(L-R) 2
E Side
Stretcher 1
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM : C
-
31
ISSUED NOV 04, 2014
Printed in Vietnam
- 3 -
HARDWARE LIST
When unpacking, please carefully not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO Description Qty Sketch NO Description Qty Sketch
1 Short bolt
( M6 x 35mm) 2
2 Long bolt
(M6 x 60mm) 8
3 Screw
(M4 x 35mm) 6
4 Lock Washer
(6.5 x 11mm) 10
5 Flat Washer
(6.5 x 19mm) 10
6 Allen Key
(K4x80mm) 1
STEP 1
Attach seat frame (B) to the back (A) by using bolts (2), washers (4) and (5), as shown below. Tighten
with Allen key (6).
Attach Side Stretcher (E) to the back (A) by using bolts (1), washers (4) and (5), as shown below.
Tighten with Allen key (6).
Note: DO NOT tighten any of the bolts, until the chair is assembled, then put on a flat level surface to
make sure the chair is level and then tighten the bolts.

ITEM : C
-
31
ISSUED NOV 04, 2014
Printed in Vietnam
- 4 -
STEP 2
Attach Front Legs (D) to the seat frame (B) with bolts (2), and washers (4) and (5), as shown below.
Tighten with Allen Key (6).
Place side stretcher (E) between front legs, attach with screws (3) as shown below. Tighten with a
screwdriver
STEP 3
Attach the seat (C) to top of the seat frame (B) with screws (3), as shown bellow. Tighten with a
screwdriver.
