THANK YOU
We appreciate the trust and condence you have placed in Everbilt through the purchase of this closet organizer. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for
choosing Everbilt!
Item # 000-000
Model # 90248
USE AND CARE GUIDE
4 FT. - 6 FT. REGULAR DUTY CLOSET ORGANIZER KIT
Questions, problems, missing parts? Before returning to the store,
call Everbilt Customer Service
8 a.m. – 7 p.m., EST, Monday-Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-305-1726
HOMEDEPOT.COM

2
Table of Contents
Table of Contents..........................................................2
Safety Information.........................................................2
Product Specications.................................................2
Warranty.........................................................................2
Pre-installation...............................................................3
Planning Installation...............................................................3
Tools Required........................................................................3
Hardware Package Contents...................................................3
Component Package Contents................................................4
Plan Your Closet Layout................................................5
Installation ......................................................................7
Accessories (Not Included in The Kit)............................9
Care and Cleaning...........................................................9
Install Hang Track....................................................................7
Install and Secure Vertical Rails...............................................7
Install Brackets........................................................................8
Install Shelves..........................................................................8
Install Rod Support Brackets and Rods....................................8
Safety Information
DANGER: The metal may have sharp edges or corners.
The use of protective gloves is strongly recommended.
WARNING: Do not overload the shelving units. This
may cause collapse of the system and cause personal
injury or property damage.
Warranty
IMPORTANT: Please read and strictly follow the
assembly instructions for proper installation.
LOAD CAPACITY
□ Please read and strictly follow the assembly instructions for proper
installation. Failure to do so may cause objects to fall, which may
result in personal injury or property damage.
□ Make sure to distribute the weight evenly on each shelf and use the
correct hardware for system mounting.
□ Do not overloaded, which may cause collapse of the system and
cause personal injury or property damage.
□ Do not climb, stand or step on the product, which may cause
collapse of the system and cause personal injury or property
damage.
□ Be sure to wear appropriate safety equipment when using power
tools and hand tools.
□ The metal may have sharp edges or corners. The use of protective
gloves is strongly recommended.
□ Recommend to protect the work surface during assembly.
□ This product is not a toy and contains small parts which may cause
choking hazard for small children. Close supervision is necessary
near children.
This product is guaranteed to be free of defects in materials and workmanship for 2 years from the date of purchase. If this product is
defective, call 1-800-305-1726 or return the product to the store from which it was purchased for a replacement. Guarantee does not
include normal wear and tear.
Product Specications
HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
□Drywall installation requires mounting into at least 1 stud.
□Maximum spacing between two vertical rails: 24 in.
□Closet rod support bracket a maximum of 36 in. spacing.
□Installed per manufacturers requirements.
Regular Duty System – Max 45 lbs per linear foot (closet shelf+rod) / Max 20 lbs per linear foot for rod loading (when installed per
manufacturer’s instructions below):

3
Pre-installation (continued)
PLANNING INSTALLATION
TOOLS REQUIRED
HARDWARE PACKAGE CONTENTS
CHOOSE YOUR HARDWARE
NOTE: Hardware not shown to actual size.
AA
BB
CC
DD
EE
FF
Panhead Screw (#12 x 2 in.)
Anchor (1/4 in.)
Bolt (3 in.)
Toggle (3/16 in.)
Closet Rod Cap
Shelf Cap
15
15
15
15
6
30
Part QuantityDescription
1. Measure the closet width and plan the layout. See the “Plan Your Closet Layout” section for illustration examples.
2. The hang track may require cutting based on your installation needs.
3. Select the correct hardware for assembly.
4. Use stud nder to locate the studs and mark. It is recommended to mount hang tracks and vertical rails onto studs.
Screwdriver Drill Pencil Tape Measure Level Saw Stud Finder
AA BB CC DD EE FF
DRYWALL
Drill 1/2 in. holes, mount the hang
track with toggle and bolts (CC &
DD), and tighten until snug.
Secure to the wall with
panhead screws (AA) at
stud locations.
Drill 1/4 in. holes, insert wall
anchors (BB) and secure to the
wall with panhead screws (AA).
STUDS CONCRETE
HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
DD CC AA
BB AA

4
Pre-installation (continued)
COMPONENT PACKAGE CONTENTS
HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
A
B
C
D
E1
E2
F
G
H
Vertical Rail (48 in.)
Vertical Rail (30 in.)
Hang Track (30 in.)
Shelf Bracket (12 in.)
Regular Duty Shelving (48 in.)
Regular Duty Shelving (24 in.)
Closet Rod Support Bracket
Closet Rod (Dia. 3/4 in. Lgth. 48 in.)
Closet Rod (Dia. 3/4 in. Lgth. 24 in.)
3
1
2
8
2
1
8
2
1
Part QuantityDescription
A
B
D
F
G
C
E1
E2
H

HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
5
4 FT. CLOSET WIDTH 5 FT. CLOSET WIDTH
When planning your installation, measure the dimensions of your installation location. Then use one of these charts as a guide for planning the
conguration of your system.
NOTE: All vertical measurements are taken from the oor.
Plan Your Closet Layout
30 in.（76 cm）
15 in.（38 cm）
4 ft.（122 cm）
22 in.（56 cm）22 in.（56 cm）
42 in.（107 cm）
84 in.（213 cm）
70 in.（178 cm）
30 in.（76 cm）15 in. （38 cm）
4 ft.（122 cm）
22 in.（56 cm）
22 in.（56 cm）
42 in.（107 cm）
84 in.（213 cm）
42 in.（107 cm）
84 in.（213 cm）
70 in.（178 cm）
30 in.（76 cm）15 in.（38 cm）
4 ft.（122 cm）
22 in.（56 cm）22 in.（56 cm）
42 in.（107 cm）
84 in.（213 cm）
70 in.（178 cm）
30 in.（76 cm）15 in.（38 cm）
4 ft.（122 cm）
22 in.（56 cm）22 in.（56 cm）
5 ft. (152 cm)
30 in. (76 cm) 30 in. (76 cm)
18 in. (45.7 cm)
20 in. (50.8 cm)18 in. (45.7 cm)
42 in.（107 cm）
84 in.（213 cm）
5 ft. (152 cm)
30 in. (76 cm) 30 in. (76 cm)
18 in. (45.7 cm)
20 in. (50.8 cm)18 in. (45.7 cm)
42 in.（107 cm）
84 in.（213 cm）
5 ft. (152 cm)
30 in. (76 cm) 30 in. (76 cm)
18 in. (45.7 cm)
20 in. (50.8 cm)
18 in. (45.7 cm)
42 in.（107 cm）
84 in.（213 cm）

HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
6
6 FT. CLOSET WIDTH
When planning your installation, measure the dimensions of your installation location. Then use one of these charts as a guide for planning the
conguration of your system.
NOTE: All vertical measurements are taken from the oor.
Plan Your Closet Layout (continued)
42 in.（107 cm）
84 in.（213 cm）
6 ft. (183 cm)
30 in. (76 cm)30 in. (76 cm)
22 in. (56 cm)24 in. (61 cm)22 in. (56 cm)
6 ft. (183 cm)
30 in. (76 cm)30 in. (76 cm)
22 in. (56 cm)24 in. (61 cm)22 in. (56 cm)
42 in.（107 cm）
84 in.（213 cm）
70 in.（178 cm）
6 ft. (183 cm)
30 in. (76 cm)30 in. (76 cm)
22 in. (56 cm)24 in. (61 cm)22 in. (56 cm)
42 in.（107 cm）
84 in.（213 cm）
70 in.（178 cm）

7
Installation
1
Install Hang Track
□ Determine your desired hang track (C) conguration per your planned layout.
□ Measure 84 in. from the oor and level the hang track (C). Use a pencil to mark each screw hole on the wall.
□ Mount the hang track (C) with correct hardware items (AA - DD) based on drywall, wood, or concrete (see “Choose your Hardware”
in the Pre-installation section). If anchors are necessary, slide the hang track (C) to side and drill holes for wall anchors.
□ Install appropriate hardware at least every 16in apart (or closer) along hang track.
Install and Secure Vertical Rails
□Attach the vertical rails (A - B) to the hang track (C) slots as the diagram shows.
Ensure the center-to-center space is NO MORE than 24 in. apart and keep
minimum space of 2 in. at the ends of the hang track (C).
□Use a level to ensure vertical rails (A - B) are vertically straight (plumb).
Determine the correct hardware (AA - DD) to use based on drywall, wood, or
concrete (see “Choose your Hardware” in the Pre-installation section). If
anchors are necessary, slide the vertical rails (A - B) to the side and drill holes
for wall anchors.
2
HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
C
A / B
REFERENCE HANG TRACK PLACEMENT
C
TIPS: Cut hang track to 15 in. from 30 in.
15 in. (38.1 cm)
REFERENCE PLACEMENT
NOTE:
Vertical rails (A-B)
sapce marked here is center-to-center space,
which shall NO MORE than 24in. apart.
6 ft. WALL
WIDTH 2 in.
5.1 cm
2 in.
5.1 cm
22 in.
56 cm
22 in.
56 cm
24 in.
61 cm
4 ft. WALL
WIDTH 2 in.
5.1 cm
2 in.
5.1 cm
22 in.
56 cm
22 in.
56 cm
5 ft. WALL
WIDTH 2 in.
5.1 cm
2 in.
5.1 cm
18 in.
45.7 cm
18 in.
45.7 cm
20 in.
50.8 cm

8 HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
Installation (continued)
Install Brackets
Insert shelf brackets (D) to the vertical rails (A - B) at your desired positions.
3
Install Shelves
4
Install Rod Support Brackets and Rods
5
□ Make sure your shelves (E) t for your closet layout. Extra cuts may be required if shelves do not t.
□ Install shelf caps (FF) on the ends of the shelves (E).
□ Push the shelves (E) on the shelf brackets (D) towards the wall allowing the bracket tip to pass through the front lip of the shelves.
The back wire of a shelf should be placed behind the bracket hook. Then pull the shelf (E) forward until the back wire ts into the
hook.
□Put the closet rod support bracket (F) at an angle as the diagram shows and place the back part onto the horizontal rod.
□Pull down the closet rod support bracket (F) and snap onto the shelf’s front rod.
□ Place closet rod caps (EE) onto the ends of the rods (G - H) and snap the rods (G - H) into the rod support brackets (F).
1
2
D
DE
F
EE G / H
A / B
NOTE: It is advised to keep
a 1 in.-2 in. overhang (from
bracket). Max 4 in. overhang.
NOTE: Max spacing between closet
rod support brackets is 36 in. for the
regular duty system.
FF
E
12
3
+/- 32"
+/- 32"
MAX 36 in.
(91.4 cm)
3
2
1

Care and Cleaning
Accessories (Not Included in The Kit)
HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
9
□To remove dust, stains, and other deposits: Use a soft cloth (or soft brush) with a diluted solution mix of warm water and a mild
detergent (such as liquid dish-washing detergent). DO NOT use solvents.
□Make sure you thoroughly rinse the surface(s) with clean fresh water after cleaning to remove all residues.
□Thoroughly dry the surface(s) before reuse.
EverbiIt closet organizer is powder coated. Clean following these steps:
Accessories (not included) are available for further optimization of your closet.
Hanging Basket
Hang Shelf
Decorative Surface Plank
Hook Storage Rack
Shoe Shelf Kit
Large Wire Basket
NOTE: The information in this document is subject to change without notice and should not be construed as a commitment.

Retain this manual for future use.
