ASSEMBLY GUIDE
Congratulations, you are now the owner of a brand new home & office chair!
To best enjoy the comfort of the chair, you have to put it together first! This assembly guide
will take you through the assembly process. To make sure the assembly goes well,
please follow the instructions, and especially the important safety information.
It is possible to assemble the chair on your own, but it is recommended to have a
second person to make it easier and safer.
Please check if there are any missing parts from the package before starting. If
there is any issue, please don't hesitate to drop us an email and we'll help you out
ASAP. If you run into any difficulty when assembling the chair, remember to check
out the assembly video to see if you've missed anything. If you're unable to resolve
the problem, just send us an email and our support team will assist you.
WARNING
To ensure proper assembly, please follow all steps and use all parts. Failure to
follow this warning can result in serious injury to yourself or others.

3
[email protected]
[phone] | [phone]
Package List
Without further ado, we kindly suggest you to list all parts needed
for the chair first.
Backrest
Mechanism Base Base Leg
Caster Foot RingGas Lift
Bolts
(A)*1 (B)*1 (C)*1(L)*1(R)
(D)*1 (E)*1 (F)*5
(G)*5 (H)*1 (I)*1
(J)*4
Seat Cushion Armrests
Bolts
(L)*6
(M)*5
Bolts
Bolts
(K)*4
(N)*1
Wrench
M6X20mm
M6X18mm
M6X20mm M6X35mm

4
[email protected]
[phone] | [phone]
Assembly Instruction
Step 1:
Take Cover (b) away from the
Base (E). Turn the Base (6)
upside down. Use Wrench (N)
to connect Base (a) and Base
Leg (F)*5 with Bolts (M)*5
and finally put Cover (b)
back on the Base (a).
Both hands are forced at the
same time to press the Casters
(H) into the holes at the end
of each Base Leg.
Step 2:
Insert the Gas Lift (E) into
the center hole of the Base.
Step 3:
(M)
(F)
a
b
(E)
a
b
1
(H)
(I)
(E)
2
3
(H)

5
[email protected]
[phone] | [phone]
FRONT
(L)×6
(B)
(C)
Turn Seat Cushion (B) upside down.
Using Wrench (N), attach Armrests (C)
to the Seat Cushion (B) with
Bolts (L)*6. Do not tighten the
Bolts (L) completely.
Step 4:
Note 1: Make sure the "Front" on the Armrests (C) and the "Front" on
the Seat Cushion (B) in the same direction.
Note 2: 2.Armrests (C) are labeled with "L" (left) or "R" (right) to show which
side they should be placed on.
FRONT
(J)×4
(D)
Using Wrench (N), attach
Mechanism (D) to the bottom
of the Seat Cushion (B)
with Bolts (J)*4.
Step 5:
FRONT
50%
50%
4
5

6
[email protected]
[phone] | [phone]
Insert Gas Lift (H) into the center hole
of the Mechanism (D) and press
down until fully engaged.
Step 6:
Using Wrench (N), attach
Backrest (A) to the Armrest
(C)*1(R) to fix one Bolt (J)
into position B1. Do not
tighten the Bolts (K)
completely.
Step 7:
6
(A)
50%
A
B
B1
B2
(k)
7

7
[email protected]
[phone] | [phone]
Step 8:
Using Wrench (N), attach
Backrest (A) to the Armrest
(C)*1(L) to fix one Bolt (J) into
position B1. Do not tighten the
Bolts (K) completely.
Using Wrench (N), screw (K)*2
into the left and right position
B2. Tighten all bolts completely.
Step 9:
Make sure all bolts and screws are fully tightened before using chair.
Lubricate all moving parts and tighten all bolts/screws every 6 month
or whenever needed.
CAUTION:
50%
A
B
B1
B2
(A)
(J)
B1
B2
B1
B2
(J)
(J)
100%
100%
8
9

[email protected]
[phone] | [phone]
Instructions For Use
1. Seat Height: Paddle-shaped lever on the right side
2. Padded Flip-up Arms
To lower:
While seated, lift lever up.
To raise:
While taking your weight off chair,
lift lever up.
* At the proper height, your feet should rest flat on the floor.
The padded feature allows you to rest
comfortably.
The armrests of the office chair have
a flip up design, you could customize
them according to your needs.
8

Safety And Maintenance
Safety Information
9
Do not stand on the chair, Do Not use the chair as a stepladder.
Use this product for seating one person at a time.
Do not use the chair unless all bolts and screws are firmly secured.
Avoid contact with sharp objects to prevent puncturing the fabric.
Every 6 months, check all bolts and screws to ensure they are tight.
To clean, spot clean only using a damp towel and mild cleaner, first
test on a small, unseen area of fabric.
Chair weight limit not to exceed 250 lbs.
Sit in the center of the
chair, with your back to
the backrest
Do not push the chair
around when a person
is sitting in it
Do not push down on
the backrest when a
person is reclined
Do not place all your
weight on only the
backrest
Do not sit at the front
edge of the chair Do not stand on the chair Do not use the chair with more than one
person
