ASSEMBLY INSTRUCTION
WF 192203 / WF192204
LOUNGER 4 SEATER SOFA SET
¯
¯
¯
¯
¯
¯
¯
¯
Notice:
1. 50% Tighten before fixing all screws, Allen wrench is
recommended instead of an electric drill.
2. Place the item on a flat ground to adjust and make sure
it remains stable.
3. Tighten up all screws with tools gradually.
4. If the screws are not aligned with holes during assembly,
please loosen all the other screws to 50% and continue
the assembly process.
5. If the item is not stable, please loosen all the screws,
adjust it on a flat ground and tighten up all screws again.
6. Note : If one or some screws are fully tightened during
assembly, chances are the others will not be aligned with
holes. In addition, all the holes are designed to be relatively
larger to provide more space for the adjustment of the screws.
B
C
E
G
F
U
A
T
D
U
T
E
I
H
J
O
L
K
Q
RQ
R
P
V
M
N
¯
¯
¯
¯
¯
¯
¯
¯
AB C
Part List & Hardware
DE F
GHI
JKL
MN O
Left Frame (1 pc ) Left Back Frame (1 pc) Left Seat Frame (1 pc)
Left Front Frame (1 pc ) Side Frame (2 pcs) Right Frame (1 pc)
Right Back Frame (1 pc) Right Seat Frame (1 pc ) Right Front Frame (1 pc )
Box Cover Frame (1 pc) Box Bottom Frame (1 pc) Box Left Frame (1 pc)
Box Right Frame (1 pc ) Box Front Frame (1 pc) Box Behind Frame (1 pc)
PQ R
Part List & Hardware
ST U
1
345
67
V2
Table Top (1 pc) Table Side Frame (2 pcs) Table Leg Frame (2 pcs)
Fabric (1 pc)
Bolt M6x40mm (16 pcs) Bolt M6x30mm (47 pcs)
Bolt M6x25mm (40 pcs) Sofa Leg (16 pcs) Sofa Leg (4 pcs)
Washer M8x5 mm (4 pcs)
Seat Cushion (4 pcs) Back Cushion (4 pcs)
Glass Table (1 pc)
8
Allen key (1 pc )
Washer M8x10 mm (1 pc)
¯
¯
1
4 pcs
1
4 pcs
STEP 1
Connect Left Back Frame (B) & Left Seat Frame (C) with Bolt (1)
B
C
1
1
1
1
STEP 2
Connect part from STEP 1 & Left Frame (A) with Bolt (1)
A
1
11
1
2
4 pcs
2
4 pcs
STEP 3
Connect part from STEP 2 & Left Front Frame (D) with Bolt (2)
D
2
2
2
2
STEP 4
Connect part from STEP 3 & Side Frame (E) with Bolt (2)
E
2
2
2
3
12 pcs
4
4 pcs
5
2 pcs
5
3
3
3
34
STEP 5
Connect part from STEP (4) & Sofa Leg (4),(5) with Bolt (3)
STEP 6
Put on Seat Cushion (T), Back Cushion (U) to complete 2 seater sofa
T
U
T
U
¯
¯
¯
¯
1
4 pcs
1
4 pcs
STEP 7
Connect Right Back Frame (G) & Right Seat Frame (H) with Bolt (1)
G
H
1
1
1
1
STEP 8
Connect part from STEP 7& Right Frame (F) with Bolt (1)
F
1
1
1
1
2
4 pcs
2
4 pcs
STEP 9
Connect part from STEP 8 & Right Front Frame (I) with Bolt (2)
I
2
2
2
2
STEP 10
Connect part from STEP 9 & Side Frame (E) with Bolt (2)
E
22
2
3
12 pcs
4
4 pcs
5
2 pcs
5
3
3
3
34
STEP 11
Connect part from STEP 10 & Sofa Leg (4), (5) with Bolt (3)
STEP 12
Put on Seat Cushion (T), Back Cushion (U) to complete 2 seater sofa
U
U
T
T
¯
¯
¯
¯
