HoMedics BPW-060-CA User manual

Automatic Wrist
Blood Pressure Monitor
BPW-060-CA
Guide français
en page 36

1
TABLE OF CONTENTS
INTRODUCTORY INFORMATION:
Important Product Notices and
Safety Instructions ...............................3
About Blood Pressure..........................6
What is Blood Pressure?
Why Measure Your Blood Pressure?
Blood Pressure Standard.....................7
How This Blood Pressure
Monitor Works ......................................8
USAGE INFORMATION:
Name/Function of Each Part ..............10
Display Explanations..........................11
Installing Batteries .............................13
Date & Time Set Procedure................15
Applying the Cuff................................15
Correct Measurement Posture ..........17
Measurement Procedure....................18
Risk Category Indicator .....................22
Recalling Values from Memory..........23
Clearing Values from Memory...........25

2
Important Notes Regarding Your
Blood Pressure Measurement...........26
Care, Maintenance & Cleaning ..........28
Potential for Electromagnetic
Interference.........................................31
Troubleshooting..................................32
Specifications .....................................33
5 Year Limited Warranty.....................34

3
IMPORTANT PRODUCT NOTICES AND
SAFETY INSTRUCTIONS
When using your blood pressure monitor,
basic precautions should always be
followed. Please read and follow all
instructions and warnings before using this
product. Save these instructions for future
reference.
• Pleasenotethatthisisahomehealthcare
product only and it is not intended to
serve as a substitute for the advice of a
physician or medical professional.
• Donotusethisdevicefordiagnosis
or treatment of any health problem or
disease. Measurement results are for
reference only. Consult a healthcare
professional for interpretation of
pressure measurements. Contact your
physician if you have or suspect any
medical problem. Do not change your
medications without the advice of your
physician or healthcare professional.
• Thisproductisnotsuitableforpeople
with arrhythmias. This device may have

4
difficulty determining the proper blood
pressure for individuals with diabetes,
poor circulation of blood, kidney
problems or for users who have suffered
from a stroke.
• Consultyourphysicianbefore
measuring blood pressure at the wrist if
you have any of the following conditions:
Severe hypertension, irregular heartbeat,
severe diabetes, severe arteriosclerosis,
severe kidney disease or vascular
disease that may compromise
circulation.
• Thepulsedisplayisnotsuitable
for checking the frequency of heart
pacemakers.
• Electromagneticinterference:Thedevice
contains sensitive electronic components.
Avoid strong electrical or electromagnetic
fields in the direct vicinity of the device
(e.g. mobile telephones, microwave
ovens). These may lead to temporary
impairment of measurement accuracy.
• Usebloodpressuremonitoronlyforits
intended use.

5
• Donotwrapthecuffaroundbodyparts
other than your wrist.
• Thisunitisintendedforusein
measuring the blood pressure and pulse
rate of adults. Do not use this device
on infants or those who cannot express
their own consent. This unit should not
be operated by children.
• Useonly1.5VAAAalkalinebatteriesfor
power supply.
Blood pressure measurements determined
with this device are equivalent to those
obtained by a trained observer using
the cuff/stethoscope auscultatory
method, within the limits prescribed
by the American National Standard,
Manual, electronic, or automated
sphygmomanometers.

6
ABOUT BLOOD PRESSURE
What is Blood Pressure?
Blood pressure is the pressure exerted on
the artery walls while blood flows through
the arteries. The pressure measured when
the heart contracts and sends blood out
of the heart is systolic (highest) blood
pressure. The pressure measured when
the heart dilates with blood flowing back
into the heart is called diastolic (lowest)
blood pressure.
Why Measure Your Blood Pressure?
Among today’s various health problems,
those associated with high blood pressure
are very common. High blood pressure
dangerously correlates with cardiovascular
diseases. Therefore, blood pressure
monitoring is important for identifying those at
risk.

7
BLOOD PRESSURE STANDARD
The U.S. Department of Health and
Human Services and the National
Institutes of Health have developed a
blood pressure standard that identifies
areas of low- and high-risk blood pressure.
This standard, however, is a general
guideline as blood pressure varies among
different people, age groups, etc.
Categories for Blood Pressure Levels in Adults
Systolic (mmHg) Diastolic (mmHg)
Stage 2 Hypertension >160 >100
Stage 1 Hypertension 140~159 90~99
Prehypertension 120~139 80~89
Normal <120 <80
_ _
Foradults18andolderwhoarenotonmedicineforhighblood
pressure, are not having a short-term serious illness, and do not have
other conditions, such as diabetes and kidney disease.
To determine category of risk when systolic and diastolic readings fall
into two areas, use the higher of the two numbers for classification.
There is an exception to the above definition of high blood pressure for
people with diabetes and chronic kidney disease. A blood pressure of
130/80mmHgorhigherisconsideredhighbloodpressureforthose
individuals.

8
This monitor comes equipped with a Risk
Category Indicator to visually indicate the
assumed risk level of each reading based
upon these standards. See page 22 for more
information on this feature.
It is important that you consult with your physician
regularly. Your physician will tell you your normal
blood pressure range as well as the point at
which you will be considered at risk. For reliable
monitoring and reference of blood pressure,
keeping long-term records is recommended.
HOW THIS BLOOD PRESSURE
MONITOR WORKS
This monitor uses Smart Measure™ technology
to detect your blood pressure. With one touch
of a button, the cuff will automatically inflate to
block the blood flow through your artery. Next,
the deflation process starts. Smart Measure™
technology enables the monitor to automatically
inflate and deflate to the appropriate level for
each individual. Please note that any muscle
movement during inflation or deflation will cause
measurement error. When measurement is
complete, the monitor will display your systolic
pressure, diastolic pressure, and pulse readings.

9
Based upon your measurement results, the
monitor’s Risk Category Indicator will alert you
if your reading falls into the pre-hypertension,
stage1hypertension,orstage2hypertension
categories. See page 22 for more information on
the Risk Category Indicator.

10
NAME/FUNCTION OF EACH PART
Battery
Cover
Memory Recall
Button START/STOP Button
Wrist Cuff
Accessories for unit:
2“AAA”size,1.5Valkaline
batteries included in the
carrying case with the unit.
LCD Display
Date/Time/User
Set Buttons

11
DISPLAY EXPLANATIONS
Systolic
Pressure
Diastolic
Pressure
Date/Time Indicator
Pulse Rate

12
Measurement Error: Measure again. Wrap
the cuff correctly and keep wrist steady
during measurement.
Air Circuit Abnormality: Measure again.
Pressure Exceeding 300 mmHg: Switch the unit
off to clear, then measure again.
Error Determining Measurement Data: Measure
again.
If and any of the following letters and numbers
appear in the area that systolic pressure should be
displayed, an error has occurred with your reading.
See Troubleshooting section of this manual for more
information.
Systolic
Pressure
User 1: Appears when the monitor is operated
byUser1.
User 2: Appears when the monitor is
operated by User 2.
Weak Battery Symbol: Appears when batteries
should be replaced.
Pulse Symbol: Shows the pulse rate per minute.
Memory Average: Displays average of last
3 readings.
Risk Category Indicator: Compares readings
against blood pressure guidelines. See page 22
for more information.
Display Symbols:
/
START
STOP
M
(No Symbol)

13
INSTALLING BATTERIES
1.Thebatterycover
is located along the
bottom side of the
monitor. Remove battery
cover by pressing down
and pulling away from
the monitor.
2. Install batteries
according to the polarity
indications inside the
compartment (as shown
in figure 2).
Battery Type:
2 Alkaline LR03
(AAA) size
3. Place in the other
battery, according to the
polarity indications inside
the compartment (as
shown in figure 3).
4. Replace the cover by
inserting it back into
place.
1.
2.
3.

14
Replace the batteries if:
1.Theweakbattery
symbol appears in the
display.
2. Nothing appears in the
display when the power
is switched on.
As the supplied batteries
are for test only, they may
be discharged earlier than
batteries you buy in stores.
4.
Replacethebatteriesinpairs.Useonly1.5V
AAA alkaline batteries. Remove batteries
when unit is not in use for extended periods
of time. Date and time will need to be reset if
batteries are removed or replaced.
Note: Batteries are hazardous waste.
Do not dispose of them together
with the household garbage.

15
DATE & TIME SET PROCEDURE
1.Toadjustthedate/time,presstheSet button
located on the side of the monitor. The display
will show a blinking number showing the month.
2. Change the month by pressing the button.
Each press will increase the number by one in
cycling manner. Press the Set button again
to confirm the entry, and the screen will show
a blinking number representing the day of the
month.
3. Change the date and time as described in Step
2 above, using the button to change the
numbers and the Set button to confirm the
entries.
APPLYING THE CUFF
1.Removeallwatches,wristjewelry,etc.prior
to attaching the wrist monitor. Clothing
sleeves should be rolled up and the cuff
should be wrapped around bare skin for
correct measurements.
Press the button
blinking month
increasing month
confirm the entry
repeat process to set date and time

16
2. Apply cuff to left wrist with
palm facing up as shown
in Fig. A.
3. Make sure the edge of the
cuffisabout1/4”~1/2”
(1cm)fromthepalmas
shown in Fig. B.
4. In order to insure accurate
measurements, fasten
the hook and loop strap
securely around your
wrist so there is no extra
space between the cuff
and the wrist as shown
in Fig. C. If the cuff is not
wrapped tight enough, the
measurement values will
not be accurate.
5.Ifyourphysicianhas
diagnosed you with poor
circulation in your left arm,
place the cuff around your
right wrist as shown in
Fig. D.
Fig. A
Fig. B
Fig. D
Fig. C

17
CORRECT
MEASUREMENT
POSTURE
1.Placeyourelbowonatable
so that the cuff is at the same
level as your heart as shown
in Fig. A.
Note: Your heart is located
slightly below your
armpit.
Relax your entire body,
especially between your elbow
and fingers.
2. If the cuff is not at the same
level as your heart or if
you cannot keep your arm
completely still throughout
the reading, use a softobject
such as a folded towel to
support your arm as shown
in Fig. B.
3. Turn your palm upwards.
4. Sit upright in a chair, and
take5-6deepbreaths.
Avoid leaning back while the
measurement is being taken
as shown in Fig. C.
Fig. A
Fig. B
Fig. C
(X)

18
MEASUREMENT PROCEDURE
Important Notes:
•Positionthemonitoratthesamelevelasyour
heart during measurement to ensure accurate
readings.
•Bloodpressurechangeswitheveryheartbeat
and is in constant fluctuation throughout the
day.
•Bloodpressuremeasurementcanbe
affected by the position of the user, his
or her physiologic condition and other
factors.Forgreatestaccuracy,wait1hour
after exercising, bathing, eating, drinking
beverages with alcohol or caffeine, or
smoking to measure blood pressure.
•Beforemeasurement,itissuggestedthatyou
sitquietlyfor15minutesasmeasurements
taken during a relaxed state will have greater
accuracy. You should not be physically tired
or exhausted while taking a measurement.
•Duringthemeasurement,donottalkor
move your arm or hand muscles.
•Seepage26foradditionalnotesregarding
your blood pressure measurement.
If you are using this blood pressure monitor for the first
time, please remove the protective film from the screen.

19
1.PressthebuttontochooseUser1or
User 2.
After the user number is selected, press
the START/STOP button to confirm the
chosen user.
2. With the cuff wrapped around your
wrist, press the START/STOP button.
Do not inflate the cuff unless it is
wrapped around your wrist. All digits
will light up, checking the display
functions. The checking procedure will
be completed after about 3 seconds.
Original Document Name: BH-LD-01-V4
Original Document Name: BH-LD-01-V4
/
START
STOP
M
OR
