REPAIR SHEET
TrimLite™ – UT20006
Trim ’n Edge™ – UT20026
EZ Reach™ – UT20046
25cc STRING TRIMMERS

2
HOMELITE 25cc STRING TRIMMER – MODEL NOS. UT20006, UT20026, AND UT20046
21
22
20
4
3
14
2
13
12
8
15
UT20026 ONLY
16
9
10 11
1
19
17
18
10
13
7
6
5
23
FIGURE A
Trim ’n Edge™

3
HOMELITE 25cc STRING TRIMMER – MODEL NOS. UT20006, UT20026, AND UT20046
14 308052001 GRASS DEFLECTOR ASSEMBLY
(UT20006 AND UT20026) ..................................1
308454001 GRASS SHIELD ASSEMBLY (UT20046) .........1
15 940230129 DECAL, WARNING/STARTING BOOM ...........1
16 940054123 DECAL, TRIMLITE LOGO ............................... 1
940054122 DECAL, TRIM ’N EDGE
940054121 DECAL, EASY REACH
17 940299602 DECAL, PRIMER ............................................ 1
18 940299606 DECAL, CHOKE .............................................. 1
19 940299603 DECAL, HOMELITE ........................................ 1
20 120642001 FASTENER PARTS KIT (Trim ’n Edge™ ONLY) ...1
21 518014001 EDGER BASE (Trim ’n Edge™ ONLY) ................ 1
22 518015001 EDGER GUIDE (Trim ’n Edge™ ONLY) ............... 1
23 000998230 COMPLETE STRING HEAD (.080 in.)
(INC. KEY NOS. 5, 6, AND 7) .......................... 1
1 940299605 STARTING INSTRUCTION DECAL ................. 1
2 000998229 CURVED SHAFT ASSEMBLY (INC. KEY NO. 16)
(Trimlite™ & Trim ’n Edge™ ONLY) ....................... 1
3 638001001 CLAMP (Trimlite™ & Trim ’n Edge™ ONLY) ..........1
4 660647001 * SCREW (10-32 x 3/8 in. )
(Trimlite™ & Trim ’n Edge™ ONLY) ....................... 1
5 308042002 SPOOL RETAINER (RH)
(Trimlite™ & Trim ’n Edge™ ONLY) ....................... 1
6 678022001 COMPRESSION SPRING ............................... 1
7 308044002 SPOOL W/LINE ............................................... 1
8 518327001 TRIGGER ........................................................ 1
9 660674001 * SCREW (10-14 x 7/8 in. TRUSS HD.) ............. 4
10 000998227 HANDLE GRIP ASSEMBLY ............................ 1
11 638012002 BOOM CLAMP ............................................... 1
12 518030001 FRONT HANDLE ............................................. 1
13 120650001 FASTENER PARTS KIT ................................... 1
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
** STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
REPLACEMENT PARTS
FIGURE A
KEY PART
NO. NUMBER DESCRIPTION QTY.

4
HOMELITE 25cc STRING TRIMMER – MODEL NOS. UT20006, UT20026, AND UT20046
FIGURE B
44
43
35
49
41
46 47
48 40
1
18
4
11
42
5
7
8
10
12
9
13
14
6
2
3
26
25
20
34
31
30
36
21
24
28
16
15
22
23 17
33
29
39
27 38
19
37
32
45
51
52
50
53

5
HOMELITE 25cc STRING TRIMMER – MODEL NOS. UT20006, UT20026, AND UT20046
REPLACEMENT PARTS – FIGURE B
29 300753003 STARTER HOUSING ASSEMBLY ........................... 1
30 638033001 SPRING AND CONTAINER .................................... 1
31 518098001 STARTER PULLEY .................................................. 1
32 900849002 STARTER ROPE ..................................................... 1
33 511731001 STARTER GRIP ....................................................... 1
34 638032001 BAFFLE .................................................................. 1
35 638094001 HEAT SHIELD ......................................................... 1
36 660694001 * SCREW (8-16 X 1/2 in. THREAD FORMING) ......... 3
37 660629001 * SCREW (10-14 X 3/4 in. THREAD FORMING) ....... 2
38 518106001 REAR HOUSING ..................................................... 1
39 660630002 * SCREW (10-24 X 3/4 in. TRUSS HD.) .................... 3
40 900994006 MUFFLER GASKET ................................................ 1
41 308092008 CATALYTIC MUFFLER ASSEMBLY
(INCL. KEY NO. 50 THRU 52) ................................. 1
42 900999002 GASKET ................................................................. 1
43 660638003 * SCREW (10-24 X 2-3/16 in. TORX HD. ) ................ 2
44 678138003 PISTON RING ......................................................... 1
45 308457001 PISTON ASSEMBLY
(INCLUDES KEY NO. 44) ........................................ 1
46 660870001 * SCREW (6-20 X 1/4 in. PAN HD.) ........................... 3
47 638044001 OUTLET TUBE ........................................................ 1
48 638268001 SCREEN ................................................................. 1
49 300753005 COMPLETE STARTER ASSEMBLY ........................ 1
50 660616001 * SCREW (10-24 X 7/8 in. TORX HD.) ....................... 1
51 640070002 CYLINDER .............................................................. 1
52 900953001 CYLINDER GASKET ............................................... 1
53 660342002 SCREW (M5 X 20 mm) ........................................... 3
983000857 OPERATOR'S MANUAL
983000857R REPAIR SHEET (REV:03)
05-03-06
1 308455001 SHORT BLOCK ASSEMBLY
(EXTERNAL GASKETS NOT INCLUDED) ............... 1
2 660661001 CARBURETOR BOLTS ........................................... 2
3 900994008 INTAKE GASKET .................................................... 1
4 660662001 * SCREW (10-24 X 1-1/16 in. PAN HD.) .................... 2
5 900740001 CARBURETOR GASKET ........................................ 1
6 518070001 HEAT DAM .............................................................. 1
7 678027001 * LOCK NUT (10-24) ................................................. 2
8 900952001 AIR FILTER ............................................................. 1
9 518094001 AIR FILTER BOX ..................................................... 1
10 518096001 AIR BOX COVER .................................................... 1
11 308054003 CABURETOR ASSEMBLY ...................................... 1
12 518105001 BUTTON SWITCH .................................................. 1
13 T660619001 SCREW, (6-19 X 1/2 in. T.F.) ................................... 1
14 678032002 COMPRESSION SPRING ....................................... 1
15 308055002 THROTTLE CABLE W/HANGER ............................ 1
16 570549001 BUMPER ................................................................ 1
17 308181004 FUEL TANK (INC. KEY NO. 22) .............................. 1
18 900954001 CRANK CASE COVER GASKET ............................ 1
19 660638004 * SCREW (10-24 X 3/4 in. PAN HD. TORX W/LW) ...............4
20 638092001 DRIVE CONNECTOR .............................................. 1
21 631049001 FLAT WASHER ....................................................... 1
22 300758006 FUEL CAP ASSEMBLY ........................................... 1
23 570256001 BUMPER ................................................................ 2
24 290218001 LEAD W/TERMINALS ............................................. 1
25 660660001 * SCREW (8-32 X 1 in. THREAD FORMING) ........... 2
26 308064001 IGNITION MODULE ................................................ 1
27 870170001 SPARK PLUG (CHAMPION RCJ4) ......................... 1
28 300952002 ROTOR AND PAWL ASSEMBLY ............................ 1
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
** STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY

1
43
6
7910
11
5
2
14
12
13
16
15
8
17
FIGURE C
HOMELITE 25cc STRING TRIMMER – MODEL NO. UT20046
6

1 000998228 STRAIGHT SHAFT ASSEMBLY (INC. LABEL) ..............................................1
2 308454001 GRASS SHIELD ASSEMBLY (INC. HARDWARE) .........................................1
3 660641001 * SCREW (10-24 x 5/8 in.) ...............................................................................1
4 660642001 * SCREW (1/4-20 x 1-1/4 in.) ...........................................................................1
5 308053004 GEAR HEAD ..................................................................................................1
6 678011002 WASHER .......................................................................................................1
7 678019002 SHAFT ADAPTER .........................................................................................1
8 308042003 SPOOL RETAINER (LH) ................................................................................1
9 660857001 SCREW, SQUARE HEAD ..............................................................................1
10 638020001 CUT OFF BLADE ..........................................................................................1
11 660675001 SCREW .........................................................................................................2
12 678246001 WING NUT ....................................................................................................1
13 638225001 SHIELD CLAMP ............................................................................................1
14 518328001 GRASS SHIELD ............................................................................................1
15 678022001 SPRING .........................................................................................................1
16 308044002 SPOOL & STRING (.080 in.) ..........................................................................1
17 000998230 COMPLETE STRING HEAD (.080 in.) (INC. KEY NOS. 8, 15, AND 16) ........1
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
** STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
REPLACEMENT PARTS
FIGURE C
HOMELITE 25cc STRING TRIMMER – MODEL NO. UT20046
7
