40cm Misting Fan
User Manual
Model No.: LB-FS-40
Item No.: 900285
Rev 3
Note: The specifications and/or components of this appliance are subject to change without prior notice.

Page 2 of 16
1Safety Instructions.........................................................................3
2Components ...................................................................................5
3Assembly ........................................................................................6
3.1 Base .................................................................................................................. 6
3.2 Fan Head / Controller Assembly.................................................................... 8
3.3 Fan Blade and Safety Grille............................................................................ 8
3.4 Misting Generator and Water Tank.............................................................. 10
4Filling the Water Tank..................................................................12
5Setting the Fan Head Angle.........................................................13
6Fan, Timer and Misting Generator Operation ............................13
6.1 Using the Fan and Timer Function .............................................................. 13
6.2 Using the Misting generator......................................................................... 14
6.3 Oscillating Function...................................................................................... 15
7Care and Cleaning........................................................................15
8Storage..........................................................................................15
9Warranty Against Defect .............................................................16

Page 3 of 16
1 Safety Instructions
When using electrical appliances, basic safety precautions should always be followed,
including the following:
•Carefully read this instruction manual before using appliance.
•Keep appliance out of reach of young children.
•This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance.
•Ensure children and babies do not play with plastic bags or any packaging materials.
•Do not disassemble the appliance. There are no user serviceable parts inside.
•VERY IMPORTANT:
Ensure that appliance does not get wet (water splashes etc.).
Do not use appliance with wet hands.
Do not immerse appliance in water or other liquids or use near sinks, baths or showers.
•Always operate the appliance from a power source of the same voltage, frequency and
rating as indicated on the product identification plate.
•Position the power supply lead properly so that they will not be walked on or pinched by
items placed on or against them.
•Use appliance only for its intended use. Appliance is intended for household use only
and not for commercial or industrial use.
•Do not use appliance if it has been dropped or any part of appliance (including cord or
plug) has been damaged.
•If the supply cord is damaged, it must be replaced by qualified electrical person only or the
product must be disposed.
•The use of accessories not intended for use with this appliance may cause injuries to
the user or damage to the appliance.
•Do not install the unit on other appliances, on uneven surfaces or where it could be
subject to: heat sources (e.g. radiators or stoves), direct sunlight, excessive dust or
mechanical vibrations.
•Appliance should not be used outdoors, placed near a hot gas or electrical burner or
placed in a heated oven.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus that produce heat.

Page 4 of 16
•Do not operate appliance underneath or near flammable or combustible materials (e.g.
curtains). Keep at least 300mm clearance around sides, back, front and top.
•Unplug this apparatus during lightning storms or when unused for long periods of time.
•If water is spilt on the floor, immediately wipe it up and dry the floor so as to prevent any
injury from slipping over etc.
•Be careful when using the fan with the mist function on some types of surfaces as
depending on the environmental conditions (i.e. Humid days) the mist may cause the
surface to become wet and slippery. Keep the surface dry at all times to prevent any
injury from slipping over etc.
•Do not block any ventilation openings.
•Turn off and unplug before cleaning or storing.
•Any type of servicing, apart from ordinary cleaning, must be carried out by qualified
electrical person only. There are no user serviceable parts in this appliance.
•If this appliance is used by a third party, please supply the instruction manual with it.
•Do not misuse the cord. Never carry the appliance by the cord or pull to disconnect it
from the outlet. Instead, grasp the plug and pull to disconnect.
•Do not insert or allow foreign objects to enter the grille openings as this may cause
damage to the appliance and/or injury to the user.
•No liability can be accepted for any damage caused by non-compliance with these
instructions or any other improper use or mishandling of appliance.
Additional Safety Instructions
If using an extension cord:
•The technical specifications of the extension cord must match or exceed the technical
specifications of this appliance.
•Do not allow the cord to hang over the edge of the work surface or to come into contact
with stoves or other hot surfaces.
•If the cord or plugs are worn or damaged, do not use.
•Unplug from the power socket by grasping the plug body - do not pull on the cord.
Read and Save These Instructions

Page 5 of 16
2 Components
Safety Grille
Fan Blade
3 Speed and Mist
Function Push
Button Control
Base
Water tank
Tilt Adjustable Neck
Mist Aperture
Timer
Misting
Generator
Flexible Mist Hose

Page 6 of 16
3 Assembly
Your Pedestal Fan has been boxed unassembled to minimise packaging waste.
Each part is designed to fit together and be disassembled easily for cleaning or
storage.
3.1 Base
•To Assemble the Posts to the Base, first place the Heavy Base Weight on a flat
level surface.
•Place the flat metal plate (with the two holes) in the recess as shown.
•Take the Two Posts and remove the screws from the ends.
•Place the post ends (the ends which the screws were removed from) into the holes
in the metal plate.

Page 7 of 16
•Whilst holding the posts in place, tip the Base up so that the underneath can be
accessed.
•Take the domed Washer and the Screw and fit as shown.
•Using the small spanner supplied, tighten the screw.
•Repeat on the other post.
•Stand the Base on the floor.
•Take the Plastic Base Cover and slide on over the Posts then push all the way
down.

Page 8 of 16
3.2 Fan Head / Controller Assembly
•Take the Fan Head / Controller assembly and unscrew the two thumb screws
located on the back. Do not fully unscrew otherwise the two nuts will fall off.
•Locate the two holes on the underneath of the Fan Head / Controller assembly onto
the two posts and push down until it stops.
•Tighten the two Thumb Screws until they are secure.
3.3 Fan Blade and Safety Grille
•Place the Back Grille over the threaded section on the Fan Head, ensuring the wire
handle on the back of the grille it at the top.
•Take the plastic nut and screw on to secure the grille

Page 9 of 16
•Place the Fan Blade onto the motor spindle.
Note: The groove in the rear centre of the fan blade aligns with a T-bar on the motor
spindle to ensure correct positioning.
•Fix the blade into place by gently hand tightening the spinner anticlockwise onto
the end of the motor spindle. The spinner nut is self-tightening when the motor
starts so do not force it, just nip it up.
•Fit locating tab on the front Grille over the rear grille at the top.

Page 10 of 16
•Open up all locking clips on the front safety grille by rotating outward
•Place the Front safety grille into position and secure it by closing the clips over the
outer rim. The screw and nut at the bottom of the grille must be fitted.
3.4 Misting Generator and Water Tank
•Place the Misting Generator onto the Base ensuring it is seated properly in its
recess.
•Sit the water tank on top of the Misting Generator.

Page 11 of 16
•Fit the Top Cap to the top of the Water Tank.
•Push the end of the flexible hose into the hole in the top of the cap and push in as
far as you can. (Do not kink the hose)
•Attached the other end of the hose to the Mist vent located on the front of the Fan
Grille.
•Push the end of the flexible hose into the spigot and push on as far as you can. (Do
not kink the hose).

Page 12 of 16
4 Filling the Water Tank
Warning: Unplug the appliance during filling and cleaning.
•To Fill the Water Tank, turn it upside down to access the filer cap.
•Unscrew the filler cap and lift it up to remove. Note the filler cap is tight so as to
prevent any water leaks. If need be, use a towel to grasp the cap and twist
anticlockwise to unlock.
•Fill the tank through the filler hole until the water level is within a few millimetres
from the filling hole.
•Refit the filler cap and turn clockwise to lock in place. Important: Ensure the filler
cap is fully rotated and locked in place.
DO NOT fill with any other liquid than clean fresh
cold water.
DO NOT add any additives to the water.
NOTE: There is a Valve in the filler cap which
releases the water when placed back on to the
Misting Generator. Do not tamper with this valve.
•Place the Water Tank back on top of the Misting Generator.
Note: The carry handle on the water tank goes towards the back.
Caution:
If water is spilt on the floor, immediately wipe it up and dry the floor so as to
prevent any injury from slipping over etc.

Page 13 of 16
5 Setting the Fan Head Angle
The Fan Head can be adjusted Up and Down so as to blow air at the required
height.
•To Adjust, whilst holding the Fan Grille to support it, unscrew the knob located on
the side of the fan head assembly enough to allow the Fan Head to be tilted up or
down.
•When at the desired angle, tighten the knob.
6 Fan, Timer and Misting Generator Operation
6.1 Using the Fan and Timer Function
The Fan has a three speed selection.
•Ensuring the Fan has been assembled correctly, plug into the power point and
switch on.
•If not using the Timer function, rotate the timer knob
anticlockwise to the “ON” position.
•If you prefer the fan to automatically stop after a pre-set
time (up to approximately 60 minutes) rotate the timer
knob clockwise to the desired time setting.
•For Low Fan Speed, press button “1”
•For Medium Fan Speed, press button “2”
•For High Fan Speed, press button “3”
•To Turn Off, press button “0”

Page 14 of 16
6.2 Using the Misting generator
Caution:
Be careful when using the fan with the mist function on some types of surfaces as
depending on the environmental conditions (i.e. humid days) the mist may cause
the surface to become wet and slippery. Keep the surface dry at all times to prevent
any injury from slipping over etc.
•To use the Misting Function, after setting the desired Fan speed and setting the
timer knob to either the “ON” position or by rotating to set a timer setting, press the
“MIST” button of the fan control panel.
•On the Misting Generator, switch the On / Off Switch to the On “I” Position
•At this point, mist will start to be generated.
•On the front of the Mist Generator is a variable mist control. For less mist, rotate
the knob anticlockwise. For Maximum mist, rotate fully clockwise.
•There is also an indicator light to show when the Mist Generator has run out of
water.
•During Normal use and while generating mist, the light will illuminate “Green”
•If the Mist Generator runs out of water, this light will illuminate “Red”

Page 15 of 16
Note: Should the light turn Red during use when there is water still in the water tank,
there may be an air lock preventing the water entering the mist generator. If this
should happen, lift the water tank up and down just a little to allow the valve to open
and allow the water to flow.
There could also be mist escaping from the join between the water tank and mist
generator. This is normal and will stop after a while.
6.3 Oscillating Function
The fan is fitted with an Oscillating function where when activated,
the fan head will swing from side to side.
•To activate, Press the clutch knob down.
•To stop the oscillating, pull the knob up when the fan head is
in the desired position
7 Care and Cleaning
•Ensure that the fan is switched off from the supply mains before removing the
guard (Grille).
•Unplug the appliance during filling and cleaning.
•To clean the blade and grille assembly, first remove the safety grille, unscrew the
locknut and remove the blade from the Misting Fan. Wipe them clean with a
slightly damp sponge.
•Clean the motor housing and body assembly with a clean, damp cloth and wipe
dry.
•To clean the water tank, rinse out with fresh clean cold water.
•Never spray with liquids or submerge the Misting Fan in water or any other liquid.
•Do not use flammable liquids, chemicals, abrasive creams, steel wool or scouring
pads for cleaning.
8 Storage
Switch off and unplug the fan.
Coil the cable loosely. Do not kink or pull the cable tight.
Store your fan in a cool, dry location.

Page 16 of 16
9 Warranty Against Defect
12 Month Warranty
Thank you for your purchase from Kmart.
Kmart Australia ltd warrants your new product to be free from defects in materials and
workmanship for the period stated above, from the date of purchase, provided that the
product is used in accordance with accompanying recommendations or instructions
where provided.
This warranty is in addition to your rights under the Australian Consumer Law.
Kmart will provide you with your choice of a refund, repair or exchange (where
possible) for this product if it becomes defective within the warranty period. Kmart will
bear the reasonable expense of claiming the warranty. This warranty will no longer
apply where the defect is a result of alteration, accident, misuse, abuse or neglect.
Please retain your receipt as proof of purchase and contact our Customer Service
Centre on 1800 124 125 (Australia) or 0800 945 995 (New Zealand) or alternatively,
via email at [e-mail] for any difficulties with your product.
Warranty claims and claims for expense incurred in returning this product can be
addressed to our Customer Service Centre at 690 Springvale Rd, Mulgrave Vic 3170.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
For New Zealand customers, this warranty is in addition to statutory rights observed
under New Zealand legislation.
