Homewell HMW-ARP2000 User manual

www.homewellproducts.com
HMW-ARP2000
Homewell 2000GHP pond pump
HMW-ARP2500
Homewell 2500GHP pond pump
HMW-ARP3000
Homewell 3000GHP pond pump
HMW-ARP3500
Homewell 3500GHP pond pump
HMW-ARP5000
Homewell 5000GHP pond pump
HMW-ARP6000
Homewell 6000GHP pond pump
HMW-ARP6500
Homewell 6500GHP pond pump
HMW-ARP7000
Homewell 7000GHP pond pump
HMW-ARP8000
Homewell 8000GHP pond pump
INSTRUCTION MANUAL
Please read all directions before using the product and retain this guide for reference.

Thanks for purchasing this HOMEWELL water pump.
This is a versatile pump ideal for fish pond, fountain and waterfall use.
It is completely submersible and designed for continuous duty operation.
SAFTY PRECAUTIONS
1. The pump is to be supplied through a residual current device (RCD) with a rated
residual operating current not exceeding 30mA. The pump should be connected
grounded properly.
2. Do not operate any appliance with a damaged cord or plug, or in abnormal state.
3. Do not immerse the plug into water or any other liquids.
4. In the following cases, please unplug the pump power plug:
①when the water pump is not in use;
②when installing or disassembling components;
③before cleaning the water pump;
④when doing any work for a waterfall or pond.
5. Maximum water temperature is 35℃ (95℉). Maximum water depth is 2 meters.
6. For safety reasons, any repair work should be done only by the manufacturer of the
products or the authorized service facility or discard it.
7. Do not lift the pump by holding the power cord to avoid the cable connection off
inside of the pump.
8. Avoid the pump dry working.
9. Do not allow children or the inexperienced to operate and play the product alone
without safety supervision.
STRUCTURE BREAKDOWN

ASSEMBLY INSTRUCTIONS
Put the rotor with impeller into the pump body, put on the sealing ring, and then
install the pump chamber. Tighten the screws, install the pre-filter, and finally install
the rear cover and suction foot.
Pump Features:
● Ideal for water gardens, koi ponds and waterfalls.
● Designed for continuous running operation.
● High quality ceramic shaft and SIC bearing for long and efficient pump life.
● No oil inside; safe for ponds with fish.
● Thermal overload protection.
● Filter particles above 6mm diameters.
● Simple maintenance with removable impeller.
●Work with Jebao electronic flow controller FC-300A, or with Smart WiFi controller MFC-
300A(Optional).
Specification Parameters:
Model
Rated voltage
Flow
(GPH)
Max. Total
Head (Ft)
Input
Current (A)
Inlet/Outlet (inch)
HMW-ARP2000
120V 60Hz
2100
15
0.95
1.5”/1.5”
HMW-ARP2500
120V 60Hz
2500
16
1.2
1.5”/1.5”
HMW-ARP3000
120V 60Hz
3000
22
1.6
1.5”/1.5”
HMW-ARP3500
120V 60Hz
3500
24
2.3
1.5”/1.5”
HMW-ARP5000
120V 60Hz
5000
21
2.45
2”/2”
HMW-ARP6000
120V 60Hz
6000
26
2.95
2”/2”
HMW-ARP6500
120V 60Hz
6600
24
3.55
2”/2”
HMW-ARP7000
120V 60Hz
7200
26
4.5
2”/2”
HMW-ARP8000
120V 60Hz
8000
28
5.2
2”/2”
Warm tips:
1. When used as a submersible pump, the pump needs to be completely immersed in
water; the diving depth needs to exceed 15 cm (6 feet) of water level to prevent
inhalation of air.
2. When used as a non-submersible pump, place the pump next to the pool below the
water surface, remove the front net, connect the water pipe, and use the height
difference between the water surface and the pump to fill the pump with water.
3. The water temperature should not exceed 35℃ (95℉) and do not let the pump

freeze in the wintertime.
4. The electrical connection should be placed in a water-proof area and should be at
least 2 meters (6 feet) away from the edge of the pond.
5. Please keep the water clean to prolong the life of the pump.
6. Keep the electrical connections dry! Ensure that the electrical cord loops below the
electrical outlet to form a “Drip Loop”. This will prevent water from running down
the cord into the electrical outlet.
7. The pump has a built-in thermal overload device which prevents the pump from
overheating. The pump must be allowed to cool down before restarting.
Maintenance
：
1. Clean the pump regularly to ensure performance.
2. When cleaning the blockage in the pump body, please disconnect the power supply
first, and then disassemble it correctly according to the steps.
3. Use soft cloth to clean the impeller and clean the pump with clear water.
4. Remove the pump inlet to access the impeller. Turn around the rotor to check if it is
broken or jammed.
5. Check the pump inlet, outlet, and connecting pipe if it is blocked.
Troubleshooting:
Problems
Reasons
Solutions
The water pump
doesn't work
1.The power is not on;
2.Rotor stuck;
3.Pump overheating.
1. Turn on electricity;
2. Clean the rotor;
3.Wait for the water pump to cool down
completely.
The flow rate is
weakened or other
abnormal
phenomena
appears
1.impeller damaged;
2.The bottom basket filter part
of the pump is out of the
water.
1.Replace the impeller with a new one;
2.Put the pump bottom basket filter
submersible under he water completely.
Water pump idles
1.The outlet pipe is too long or
blocked;
2.There is residual air in the
impeller chamber.
1.Cut the outlet pipe shorter or remove
blockage;
2. Keep the water pump in water, and
continue to turn on and off the power supply
for 2 to 3 times to remove the residual air in
the impeller chamber.

DISPOSAL:
Please don’t dispose this product as unsorted municipal waste. Collection of
such waste separately for special treatment is necessary. Not put it together
with the domestic waste which should be solved as an authorized place for recycling
of electrical and electronic appliances for collecting and recycling waste. Please
consult with your local seller, to make sure the product is disposed in an
environmental and healthy way.
WARRANTY
This item covers 1 YEAR LIMITED WARRANTY from the original date of purchase.
This warranty only applies to the original consumer purchaser and only to products
used in normal use and service.
This warranty does not apply to products that are found to have been improperly
installed ,set-up,or used in any way not in accordance with the instruction supplied
with product and failure of product’s as a result of an accidents, misuse, abuse,
negligence, alternation, or faulty installation. This warranty shall not apply to the
finish/scratching/tearing on any portion of the product, such as surface and/or
weathering,as this is considered normal wear and tear.
If you have any questions, please visit our website and contact our customer service.
www.homewellproducts.com
