HOMEY's PROFJOB L2 Guide

FLASHLIGHT 77H103-150 PROFJOB L2
MANUAL & WARRANTY
1
Congratulations with your great choice of the HOMEY’s
77H103-150 PROFJOB L2 rechargeable LED flashlight
The 10 Watt CREE® XM-L2 LED of this flashlight provides a powerful, bright light beam of ± 1100
lumen and an enormous light range of ± 350 m.
WARNING: VERY POWERFUL LIGHT BEAM, NEVER LOOK DIRECTLY INTO IT!
No more need for single batteries: the PROFJOB L2 contains a superior Li-ion rechargeable battery.
The intelligent Light Control offers the choice of the following modes: High –Middle –Low –Strobe
and SOS. The PROFJOB L2 is very efficient because of its low power consumption and the incredibly
long lifespan of the LED.
User instructions Li-ion 18650 Lithium battery
Your PROFJOB L2 flashlight has a superior and sustainable battery.
Recharging of the Li-ion battery
Before use charge the battery with the charger:
1. Press the battery against the battery spring in the charger until it snaps in place
2. Plug the cable in the connector of the 100-240V charger
3. Plug the charger in a 100-240V socket
4. The lamp on charger will now turn red, the battery is being charged
5. Turn the cap of the flashlight and slide the battery with the + sign facing forward into the
cylinder: put the cap back and tighten
ATTENTION please, to ensure long-life optimum operation:
- Never fully discharge the battery because of the risk of damage due to deep discharging
- You can easily replace the battery yourself however only use mod. 18650 3.7V / 2,000 mAh
Li-ion. Replacement is rarely needed because the battery can be recharged more than 500
times
Technical specifications
Construction/Finish Durable, anodised 6061-T6 aviation aluminum
Total length 150 mm
Weight 150 grams (189 incl. battery)
Body/bezel diameter 27 mm resp. 43 mm
Lens Tempered glass, unbreakable
LED Original CREE® XM-L2 10 Watt LED
Light output ± 1100 lumen
Light range ± 350m
Modes High –Middle –Low –Strobe - SOS
Degree of protection According to IP67, downpours resistant - and shock proof
Supplied accessories
Battery Rechargeable, mod. 18650 Li-ion Lithium
- Capacity 2,000 mAh (milli-Ampères x hour)
- Recharging With included recharger
- Max. nr. of recharges Minimum of 500
- Runtime each recharge ± 24 hours light at full intensity
- Memory Effect No capacity loss by recharging
Charger For 18650 Li-ion Lithium battery, in-/output 4.2DC
Proviso Subject to interim alteration, values are averages

FLASHLIGHT 77H103-150 PROFJOB L2
MANUAL & WARRANTY
2
Fine quality for Prolonged Use
The flashlight 77H103-150 is a fine quality flashlight for frequent, intensive use and offers a.o.:
Very powerful, original CREE® XM-L2 10 Watt LED
This flashlight contains the most modern LED-technology:
- The patented, original 10 Watt CREE® XM-L2 LED-lamp produces a very powerful and bright
light of ± 1100 Lumen
- The lamp also has an enormous light range of ± 350 m (in spotlight mode)
- It is extra efficient because with minimal energy consumption it has an extremely long lifespan
of 10 years or 100,000 hours - and even more.
This lamp is more expensive to purchase than, e.g., a Xenon-lamp, but the difference is quickly repaid
because the batteries have an increased lifetime and the LED-lamp has a much longer lifespan.
Superior Li-ion (Lithium) rechargeable battery
This battery offers important advantages with regard to other rechargeable batteries, such as:
- Long illumination time: approx. 24 hours full intensity light
- Can contain more power than other rechargeable batteries
- Very little power leakage: retains the charge for a very long time
- No reduction in capacity when charging the not yet fully discharged battery
- High capacity of 2,000 mAh (milli-Ampères x hour)
- Very strong because it can be recharged more than 500 times
- With a regulating system that a.o. helps to prevent (harmful) deep discharge
Intelligent Light Control
The 77H63-135 flashlight offers you many facilities to control the light. You can select the light mode
you want just by pressing the on/off button:
1. High: 100% light intensity
2. Middle: 50% light intensity
3. Low: 30% light intensity
4. Strobe function
5. Flashing signal/alarm light
LED Technology
- Light bulbs give light by heating a glowing element. Only a maximum of 25% of the energy is
transformed into light, the rest is dissipated as heat.
- A LED (Light Emitting Diode) is a semi-conductor made from, among other things, silicon
under electrical voltage. This stimulates an electron flow with emitted photons, which is visible
as light. Therefore, LEDs produce mainly light instead of heat.
- The advantages of LED-lighting are convincing:
LEDs have no filament which can burn out or break due to vibrations and shocks,
therefore they last for an extremely long time: approx.100.000 hours / 10 years - or
more.
They are much more efficient than standard light bulbs as a result of approx. 90% less
power consumption, so the batteries have a much longer lifespan –and that at equal
light production.

FLASHLIGHT 77H103-150 PROFJOB L2
MANUAL & WARRANTY
3
FEATURES AND USES
A flashlight is indispensable for everyone. For example, at home and at work, to have light available
always and everywhere in an emergency. But also for in your car or boat and in every outdoor kit a
flashlight is a ‘must’, sometimes even vitally important. For the police, fire service, security companies,
or during military operations, a flashlight is utterly indispensable.
MAINTENANCE AND NOTES
- Always store dry and in a dry place, also to preserve the rechargeable battery
- If the end cap is (too) difficult to screw off, you can put a drop of (sewing machine) oil on the
screw thread
- Extend the lifespan of the Li-ion battery by keeping the flashlight always at a cold, if possible
refrigerator temperature
- Never store the flashlight with an almost empty battery for longer time, this prevents possible
battery damage due to deep discharge
- For this reason, charge the battery every month partially when the flashlight temporary is not
in use, despite the slight self-discharge of the battery
- Clean the flashlight preferably with a soft, possibly slightly dampened cloth
WARRANTY
HOMEY’s gives a 5 year warranty on all materials and manufacturing defects. Defects due to
injudicious use, poor maintenance or normal wear and tear are not covered by this warranty. You can
invoke the Homeij warranty preferably via your Homeij-dealer - on production of the receipt.
One year warranty is given on the Li-ion battery.
