Honeywell Ex-Or MSB1001DT Installation and operation manual

Installation and Commissioning
Instructions
IP65 BattenFit Sensor with Regulating Photocell
MSB1001DT for use with DSI ballasts
MSB1001DALIT for use with DALI ballasts
Note: QuickSet Pro or HP18* required for commissioning
* Please note that the HP18 offers different/limited programming options

Only suitably qualified personnel should install this equipment.
- 2 -
IP65 BattenFit Sensor with Regulating Photocell: MSB1001DT - for use with DSI ballasts
MSB1001DALIT - for use with DALI ballasts
This passive infrared presence detector is designed to be fitted to a batten-style luminaire.
Installation
1. Remove the M20 knockout from the end cap of the luminaire.
2. Pass the sensor wires through from the outside and insert the threaded end of the sensor into the hole.
3. A polarising plate can be made in order to prevent rotation of the sensor - an example design is given on
page 3 (Fig. 5).
4. If a polarising plate is to be used, pass the wires through the slot and position the polarising plate against
the inside face of the end cap. Ensure that the tab is positioned correctly i.e. at the ceiling side, away from
the lamp.
5. Fit and tighten the locknut.
6. Connect the wires in accordance with the wiring instructions.
SENSOR
OPTIONAL POLARISING PLATE
IP65 LIGHT FITTING
LOCKNUT
ENSURE THAT THE TWO O-RINGS
ARE FITTED AS SHOWN
Fig. 1
Fig. 2
Fig. 1a
If there is insufficient space for the locknut,
the adaptor shown below (Fig. 3) can be used.
Fig. 3
20mm Female Adaptor
MK part number EFA/2
Angled Washer Kit (supplied)
If the light fitting has an angled (drafted) end
face then use the kit provided as shown
(Fig. 4).
IP65 SENSOR 20mm O-RING LUMINAIRE WITH ANGLED END FACE
ANGLED SPACER ANGLED WASHER
Fig. 4

Polarising Plate (not supplied)
The purpose of the polarising plate is to ensure that the sensor does
not rotate from the correct position, i.e. pointing vertically
downwards, during transport or installation.
The two overall dimensions marked ‘SEE TEXT’ need to be made
such that when the plate is positioned against the inner face of the
luminaire end cap, it cannot rotate.
The 3.5mm ‘tab’ should be located closest to the ceiling (away from
the lamp). The 6.0mm slot is optional and is to allow the wires to
pass through for ease of assembly.
Material can be plastic sheet, minimum thicknesss 1.0mm,
recommended thickness 1.5-2.0mm, or mild/stainless steel sheet,
minimum thickness 0.6mm, recommended thickness 1.0-1.6mm.
SEE TEXT
SEE TEXT
7.3
6.0
20
3.5
Fig.5
Electrical Connections
SUPPLY
L N E
Always check product label before connecting.
Fig.6
- 3 -
Blue
Brown
White
White
BALLAST BALLAST BALLAST BALLAST
Note: White/White
Dimming Signal
Pair is Polarity Free.
Do not connect the
Dimming Signal Pair
of one detector to that
of another detector.
L N E L N E L N E L N ED D D D D D D D
Fig.7 See ‘Technical Data’ on back page for
maximum number of ballasts

Detection Profile
Plan View
o
Detection pattern is a 360 cone shape.
Diameter is 2.25 x the mounting height.
The squares show the arrangement
of the detection pattern.
Fig. 8
Direction of most
commonly used
entry into detection
zone, i.e. start of
corridor or doorway
Fig. 9
5m
5m
2.5m
o
97
2.5m
DETECTION ZONE
- 4 -
5.6m
BATTEN LUMINAIRE
If the distance between the
bottom of the sensor and the
bottom of the end cap exceeds
59mm (in the case of square
covers) or 82mm (for rounded
covers), there may be a blind
spot in the detection zone.
Fig. 10 DETECTION ZONE

- 5 -
Fig. 11
Setting the Regulating Photocell
This product is intended for use with high frequency regulating ballasts with digital control inputs. An infrared
programming tool QuickSet Pro or HP18 is required for programming the regulating light level set point.
The setting is preserved in the event of a power failure and can be re-programmed any number of times.
Using the QuickSet Pro: Enter the Utilities menu then choose ‘LightSpot/MLS/LCM’ and select ‘Set Light Level’.
Use the ‘up’ and ‘down’ buttons to manually adjust the light output from the luminaire(s) and when at the required
level press and hold ‘OK’ to store.
On the HP18 Programmer, use the ‘+’ and ‘-’ buttons to manually adjust the light output from the luminaire(s) and when at
the required level press ‘ü’ to store. The luminaire(s) will blink to acknowledge a successful store operation.
Sensor Positioning Notes
The majority of light seen by the photocell must be from the batten under its control - not that contributed by
another device (see Fig. 11 ).

- 6 -
Walk Testing
In order to verify the installation, there is an inbuilt facility (Walk Test Mode) to temporarily reduce the time
delay to 10 seconds. A QuickSet Pro or HP18 Programmer is required to access this facility.
Using the HP18:
Press the ‘TEST’ button to enable walk test mode.
Move around the area that is being controlled, stopping for 10 seconds to allow the lights to switch off, before
moving and triggering the lights back on.
Re-programme the desired Off Delay once testing is complete.
Using the QuickSet Pro:
Go to the Utilities menu, choose ‘LightSpot/MLS/LCM’, then ‘User Test’, then place the cursor over ‘Walk Test,
point the programmer at the detector and press OK.
Move around the area that is being controlled, stopping for 10 seconds to allow the lights to switch off, before
moving and triggering the lights back on.
After 5 minutes, the time-out will be restored to what it was before walk test was enabled.
Notes on Walk Testing:
l During walk test, after the lights have turned off, wait 5 seconds before moving again because the sensitivity
is deliberately reduced for a few seconds following switch off.
l Sensitivity is greater when approaching the circular footprint at a tangent rather than heading towards the
centre (see Fig. 8).
l Most luminaires take approximately 1 second to strike after presence has been detected.
l The detection pattern is cone-shaped which means that when standing at the very edge of the detection
footprint only a person’s feet will be visible (see Fig. 9).
Commissioning
The factory default settings will be appropriate for most applications. However, the installer does have the facility
to re-programme a wide range of parameters and to set the regulating light level using the infrared programming
tools. Please note that the full range of parameters is accessible via the QuickSet Pro; the HP18 offers
different/limited programming options.
Please read carefully the operating instructions that accompany the programmer prior to performing a
programming operation.
The following table shows the pre-set factory settings and a brief explanation of each parameter. These
parameters may be re-programmed any number of times and all settings will be retained in the event of a power
loss.
LED Operation
There is a blue LED on the detector which will flash when power is first applied or during a download from
the QuickSet Pro. If the LED is required to flash whenever movement is detected, please contact Technical
Support.

- 7 -
Important Additional Notes
1. A means for disconnection must be incorporated in the fixed wiring in accordance with the current wiring regulations.
2. The dimming control output should be connected only to the control input of the ballasts - never to other detectors.
3. This equipment should be used to control only those ballasts powered from the same phase as the detector
4. Although nominally 12V, the dimming output is not SELV and therefore should be treated with the same respect as mains
with regard to wiring practice. The 0V line of the dimming output is almost at Neutral potential.
5. DSI/DALI wiring to be on mains-rated safety wire.
6. Due to the fact that the photocell is on the ceiling looking down, it is not possible for measurements made with a lux meter on
the working plane to remain constant when daylight illuminates the ceiling and the working plane to a differing extent.
Therefore, products of this type should be regarded as capable of maintaining an APPROXIMATE light level only.
7. This equipment switches lights no more frequently than would a responsible human occupant. However, manufacturers of
some particular lighting types (e.g. ‘2D’ luminaires) may specify a maximum number of switching cycles in order to achieve a
predicted lamp life. Please check with the manufacturer of the luminaires to ensure that they are compatible with automatic
controls in this respect.
8. In order to achieve satisfactory light-level regulating operation, a detector must observe a substantially greater proportion of
artificial light from the luminaire(s) under its control than from neighbouring luminaires not under its control.
Parameter Options Pre-Set Notes
Power Up On / Off On Sets the luminaire state at power up irrespective of occupancy.
Useful in reducing start-up load following power cut. Power-
up off - responds to occupancy after 30 seconds.
Response Auto / Semi-auto Auto If set to auto, the presence detector switches the luminaire on
and off automatically. If set to semi-auto, the lum inaire will not
turn on automatically when a person enters the area. It can be
turned on using the hand-held controller or by toggling the
power switch. When the area is vacated, the light will turn off
automatically.
Off Delay 1 min-96 hrs (QuickSet Pro)
5, 10 or 20 mins (HP18)
20 mins The time for which the lum inaire will stay on following the last
detected movement. Also 10-second setting for walk-testing.
Start Lamps Max / Min Max Sets the level at which the lamps strike when turning on.
Entry Scene* 1-6 Scene 1 Sets which scene is recalled when unoccupied area is
entered.
Bright Out Yes / No No If set to yes, movement fails to refres h the off delay if ambient
light level exceeds 125% of set level and the luminaire will
switch off when the off delay has elapsed. NB: Dim ming must
be set to 100%.
Dimm ing* Reg 50%-Reg100% 100% Can be set to operate between 50% and 100% ballast output
from max down to a bottom-end limit when working on
photocell control.
Lamp Max* 10%-100% 100% Can be set to limit the absolute maxim um output of the ballast
in all operating modes.
Fade to Off Yes / No No When no presence is detected, and after the off delay period,
the lamps can fade out ins tead of switching off (approx 80
seconds to fade from 100% to 0%).
When Vacant Off / Min / Reg <25% / Scene 6 (latter via
QuickSet Pro only)
Off Options for a vacant area after it has timed out. Luminaires
can turn off, remain at m inimum output, or regulate with a 25%
output limit, until the next period of occupancy. If programmed
to remain at minimum, to regulate below 25% (or go to scene
6 - available via QuickSet Pro only), there is an option to switch
off after 3 times the Off Delay (XTN).
Upper/Lower
Threshold
0-254 254 Point at which photocell switches lights on/off.
100 Hour Burn-In Burn-in 100 hrs / Cancel / Resume 0 hr See Application Note: AN4028
Additional feature accessible under Utilities on QuickSet Pro:
* These parameters are programmable using the QuickSet Pro only

At the end of their useful life
the packaging and product
should be disposed of via a
suitable recycling centre.
Do not dispose of with normal
household waste.
Do not burn.
Dimensions
Fig. 12
135580
40
Fig. 13
15
M20 x 1.5
14
29
Fig.12
All dimensions in mm
W5017H
Technical Data
MAXIMUM RECOMMENDED MOUNTING HEIGHT: 5 metres
OPERATING VOLTAGE: 230V~ 50Hz (UK & Europe)
POWER CONSUMPTION: <0.5W
CAPACITY: MSB1001DT - 4 x DSI ballasts
MSB1001DALIT - 4 x DALI ballasts
WEIGHT: 120g
COLOUR: White (RAL9010)
MATERIAL: Flame retardant PC
IP RATING: 65
