INSTALLATION INSTRUCTIONS
69- 1589
® U.S. Registered Trademark
Copyright © 2002 Honeywell • All Rights Reserved
UC100C Ultraviolet
Air Treatment System
Replacement Lamp
APPLICATION
The UC100C Ultraviolet Air Treatment System Replacement
Lamp is for use with the UV100C Ultraviolet Air Treatment
System.
INSTALLATION
When Installing this Product…
1. Read these instructions carefully. Failure to follow them
could damage the product or cause a hazardous condi-
tion.
2. Check the rating given in the instructions and on the
product to make sure the product is suitable for your
application.
3. Removal and replacement of the ultraviolet lamps can
easily be done by the owner following these instruc-
tions. The owner can also call an experienced service
technician.
4. After installation is complete, check out product opera-
tion as provided in these instructions.
CAUTION
Personal Injury Hazard.
Power supply can cause electrical shock.
Disconnect power supply before replacing ultraviolet
lamp(s).
Do not open lamp knob; there are no user-serviceable
components inside.
WARNING
UV Light Hazard.
Harmful to bare skin and eyes.
Can cause temporary or permanent loss of vision.
Never look at the lamps while illuminated.
Only view illumination by way of the light indicator
located on the lamp knob.
To prevent exposure to ultraviolet light, disconnect
power to the ultraviolet air treatment system before
servicing any part of the heating/air conditioning
system.
CAUTION
UV Lamp Burn Hazard.
Harmful to bare skin.
Can cause severe burns.
Disconnect power and wait 15 minutes before
removing the ultraviolet lamp(s).
CAUTION
Breakable Glass Hazard.
Can cause personal injury.
Be careful when inserting lamp(s) into lamp base.
Wear protective gloves when handling lamp(s).

69-1589 G.H.04-2 www.honeywell.com/yourhome
UC100C ULTRAVIOLET AIR TREATMENT SYSTEM REPLACEMENT LAMP
$XWRPDWLRQDQG&RQWURO6ROXWLRQV
+RQH\ZHOO+RQH\ZHOO/LPLWHG+RQH\ZHOO/LPLWpH
'RXJODV'ULYH1RUWK'\QDPLF'ULYH
*ROGHQDOOH\016FDUERURXJK2QWDULR
0=
Printed in U.S.A. on recycled
paper containing at least 10%
post-consumer paper fibers.
MERCURY NOTICE
This device contains mercury in the sealed ultraviolet
lamp(s). Do not place your used lamp(s) in the trash.
Dispose of properly.
Broken Lamp Cleanup.
Do not use a household vacuum.
Sweep debris into a plastic bag and dispose of
properly.
Contact your local waste management authority for
instructions regarding recycling and the proper
disposal of old lamp(s).
Replacing Your Lamps (Annually)
Annual replacement of your lamps is required. To replace your
lamps:
1. Obtain the correct replacement lamp for your unit. See
Table 1.
2. Disconnect the power to your HVAC system.
3. Open the enclosure door.
4. Disconnect the lamp cable from the electrical subpanel.
Allow the lamp to cool for at least 15 minutes.
5. Rotate the lamp knob until the tabs align with the slots;
then carefully remove the lamp; be careful not to strike
or hit the lamp glass on the enclosure edges.
6. Carefully insert the new lamp assembly into the
enclosure. Avoid striking the lamp glass against the hole
edges or other object to prevent damage or breakage. If
necessary, use a clean, dry cloth to help guide the lamp
assembly during installation. Do not touch the lamp
surface with your hands; use only a soft cloth.
7. Align the tabs on the lamp knob with the slots in the
lamp receptacles and turn lamp clockwise until it stops.
8. Connect the lamp assembly cord conector to the mating
receptacle located on the exterior of the electrical
sub-compartment.
9. Verify that the connector is fully inserted into the
receptacle.
WARNING
UV Light Hazard.
Harmful to bare skin and eyes.
Can cause temporary or permanent loss of vision.
Never look at the lamps while illuminated.
Only view illumination by way of the light indicator
located on the lamp knob.
10. Reconnect the power to the HVAC system.
11. Verify that your ultraviolet lamp(s) are operating only by
viewing through the lamp light indicator on the lamp
knob. Never look directly at your lamp(s) while
illuminated.
Table 1. Replacing Your Lamp(s).
Unit Description Replacement Lamps Wattage
UV100C3002 Ultraviolet Air Treatment System (Light
Commercial model)
UC100C3007 36W
