Honeywell Thor VM3 User manual

Thor™ VM3
Vehicle-Mount Computer
Quick Start Guide
Aller à www.honeywellaidc.com pour le français.
Vai a www.honeywellaidc.com per l'italiano.
Gehe zu www.honeywellaidc.com für Deutsch.
Ir a www.honeywellaidc.com para español.
Para Português, acesse www.honeywellaidc.com.
Перейти на русскоязычный сайт www.honeywellaidc.com.
Pro češtinu jdi na www.honeywellaidc.com.
Pre slovenčinu choďna www.honeywellaidc.com.
Türkçe için lütfen www.honeywellaidc.com sayfasını ziyaret ediniz.
Idźna stronę: www.honeywellaidc.com po quick start w języku polskim.
如要到中国 www.honeywellaidc.com（简体）。
www.honeywellaidc.com
VM3-QS Rev B
6/15

Components - Front
P8
P1 P14 P7
P13
P6
P12
P5
P11
P4
P10
P3
P9
P2
System
LEDs
Power
Button
Connection
LEDs

Components - Rear
See the Thor VM3 User’s Guide for dock fuse replacement in-
structions.
Fuse Power
Switch
Power
Cable
Connector
I/O Connectors:
CANbus/Audio
COM2
COM1
USB1
USB2
Dock
Release
Ethernet USB Host
!

Mount to Vehicle
The Thor VM3 should be secured to an area in the vehicle where it:
• Does not obstruct the driver's vision or safe vehicle operation.
• Will be protected from rain or inclement weather.
• Will be protected from extremely high concentrations of dust or
wind-blown debris.
• Can be easily accessed by a user seated in the driver's seat while
the vehicle is not in operation.
To mount the Thor VM3 using a RAM mount system:
1. Attach RAM base to vehicle (RAM ball, RAM Clamp, RAM Plate,
etc.).
2. Attach RAM ball and optional keyboard bracket to the Smart
Dock.
3. Attach Thor VM3 assembly to RAM base using RAM arm and
tighten knob on RAM arm.
4. If using keyboard bracket, attack keyboard to mounting plate.
5. Attach keyboard assembly to Thor VM3 assembly using RAM
arm and tighten knob on RAM arm.
Note: An external keyboard is required for initial setup.
For more details and other mounting options, refer to the Thor VM3
User’s Guide available at www.honeywellaidc.com.

Connect Accessories
Connect serial accessories, such as a bar code scanner, to the
COM1 or COM2 port on the Smart Dock.
Connect the optional VMT keyboard to the USB1 port on the Smart
Dock.
Connect other USB accessories to the optional VM3052CABLE
adapter cable which attaches to the USB2 port.
Connect Power
The Thor VM3 can be connected to vehicle power as follows:
• Direct power connection (12-48VDC vehicles). See Connecting
the Power Cable, below.
• Replace a previously installed VX6/VX7 or Thor VX8/VX9 with an
adapter cable. See the Thor VM3 User’s Guide, available at
www.honeywellaidc.com.
• High voltage forklifts (over 60V). Refer to the Thor VM3 User’s
Guide available at www.honeywellaidc.com.

Connecting the Power Cable
The following power option is for 12-48VDC vehicles (10-60VDC
direct connection).
• Route the power cable away from the outside of the forklift.
• Choose a mounting location so that the power cable does not
extend outside the vehicle and that provides sufficient clearance
so that the power cable (especially the dock connector end) is not
pressed against part of the vehicle.
• Regularly inspect power cable for damage, especially in low
temperature environments.
CAUTION - For installation by trained service personnel only.
Fuse Requirements
WARNING - For proper and safe installation, the input power
cable must be connected to a fused circuit on the vehicle. If
the supply connection is made directly to the battery, the fuse
should be installed in the positive lead within 5 inches of the
battery’s positive (+) terminal. Use VM3055FUSE (or equiva-
lent) to install the fuse as shown below:
• F o r 12VDC input, use the 10A fuse from the kit or a slow
blow fuse that has a DC voltage rating greater than 12VDC.
• F o r 24VDC input, use the 6A fuse from the kit or a slow
blow fuse that has a DC voltage rating greater than 24VDC.
• F o r 36VDC input, use the 4A fuse from the kit or a slow
blow fuse that has a DC voltage rating greater than 36VDC.
• F o r 48VDC input, use the 3A fuse from the kit or a slow
blow fuse that has a DC voltage rating greater than 48VDC.
Note: For North America, a UL Listed fuse is to be used
!
!

Power Cable Routing
Power Cable Information
Twist the red and red/white wires together and twist the black
and black/white wires together before connecting to vehicle
power.

Connect the green wire to vehicle ground:
Power Cable Installation
1. The Thor VM3 must not be mounted in the Smart Dock.
The power switch on the dock must be turned Off. The
power cable must be UNPLUGGED from the dock.
2. Install the VM3 fuse kit (or equivalent slow blow fuse) within
5” (12.7 cm) of the vehicle battery (if using unswitched
power). Refer to the installation instructions included with
the fuse kit or Fuse Requirements earlier in this document.
3. The cable is rated for a maximum temperature of 221°F
(105°C). The cable should be protected from surfaces that
For battery powered vehicles:
The green wire must be connected to the vehicle chassis
ground.
For internal combustion engine powered vehicles:
The green wire is connected to the vehicle chassis
ground, which can also be battery negative.
Wire Color Connection
Red DC + (10-60 VDC)
Red/White DC + (10-60 VDC)
Black DC -
Black/White DC -
Green Ground
Blue Ignition Input (optional)
Refer to the Thor VM3 User’s Guide, avail-
able at www.honeywellaidc.com, for further
information about ignition control.
!

exceed this temperature, from physical damage from
moving parts, and from chemicals or oil that cause the
insulation to deteriorate.
4. Avoid sharp bends. The power cable is less flexible in low
temperature environments.
5. Route the cable the shortest way possible removing any
leftover cable, making sure the cable does not interfere with
safe operation and maintenance of the vehicle.
6. Secure the cable to the vehicle structure at approximately
one foot intervals, taking care not to over tighten, pinch
conductors, or penetrate the insulation.
7. Use proper electrical and mechanical fastening means for
terminating the cable. Properly sized “crimp” type electrical
terminals are an accepted method of termination. Select
electrical connectors sized for use with 20AWG (0.81mm2)
conductors.
8. Connect the watertight connector end of the power cable to
the Smart Dock power connector by aligning the connector
pins to the power connector; push down on the watertight
connector and twist it to fasten securely.
9. Secure the power cable to the dock using strain relief cable
clamps, and place the Thor VM3 in the dock.
10. If using the Screen Blanking feature, install the screen
blanking box or switch. (Refer to the installation
instructions that came with the Screen Blanking box, or to
the Thor VM3 User’s Guide, available at
www.honeywellaidc.com for further information.)
11. Move the power switch on the back of the dock to the on
position.
12. Press the power button on the front of the Thor VM3.

Setting up the Thor VM3 Software
Note: Have the following information available before setting up
your Thor VM3:
•Network ID (SSID) of the Access Point
•Wireless network authentication credentials
1. Connect the Thor VM3 to an external power source.
2. Press the Power button.
3. Attach a USB keyboard during the setup process.
4. Accept the EULA.
5. Calibrate the touch screen (resistive touch screen only, not
applicable to PCAP touch screen).
6. Set the date and time.
7. Edit the radio parameters.
8. Edit Enterprise Control Panel settings (i.e.: Bluetooth Scanning,
Enterprise Settings, etc.).
9. Edit the RFTerm or Enterprise TE Terminal Emulation
parameters (optional).
10. Perform a reboot.
Bluetooth
Refer to the Thor VM3 User’s Guide, available at
www.honeywellaidc.com, for information when using the Thor VM3
with Bluetooth.

Wireless Network Configuration
To configure the WLAN connection use the Honeywell Wireless
Configuration Utility (WCU).
1. Tap Admin Login.
2. Enter the password. The default password is Honeywell.
3. Tap New to create a new profile.
4. Select Create an auto profile.
5. Enter a profile name and the SSID of the network.
6. Tap Next.
7. Tap Change connection settings.
8. Complete the Security tab by selecting security and encryption
types.
9. Additional entries may be required based on security and
encryption chosen.
10. Tap OK when completed.
11. Tap Connect to... to connect to the network.
For more details see the Thor VM3 User’s Guide available at
www.honeywellaidc.com.

Connecting to Terminal Emulation
The Thor VM3 supports terminal emulators such as RFTerm® and
Enterprise TE.
Before you make a host connection, you will, at a minimum, need to
know:
•the alias name or IP address (Host Address) and
•the port number (Telnet Port) of the host system to properly set
up your host session.
1. Make sure the mobile client network settings are properly con-
figured. If you are connecting via WLAN (802.11x), make sure
your Thor VM3 is connected to the network.
2. Launch the terminal emulation program.
For more details refer to the RFTerm User’s Guide or the Enterprise
TE User Guide, available at www.honeywellaidc.com.
Rebooting the Thor VM3
To reboot the Thor VM3 with Windows Embedded Compact 7:
1. Select Start > Settings > Control Panel > Registry.
2. Tap the Restart button.
To reboot the Thor VM3 with all other Windows operating systems:
1. Select Start > Shutdown > Restart to reboot.
When the Thor VM3 is booting, there may be small delays while the
wireless client connects, applications launch, remote management
completes and Bluetooth devices connect.
