Honeywell Performance HE42XD2G User manual

Performance Series Cameras
HE42XD2G TDN 1080p IR Ball Camera
Quick Installation Guide
Document 800-23521 - Rev C - 08/2017
Thank you for purchasing a Honeywell Performance
Series HQA HE42XD2G camera. Follow the instructions
in this guide to install and log in to your camera.
Warnings and Cautions
WARNING This device is configured for 12 VDC operation. Do not connect to a higher voltage.
Use only with NRTL-approved Class 2 power supplies.
CAUTION IR emitted from this product. Do not view directly with optical instruments. Do not
stare directly into the lamp at a distance of less than 3.3 ft (1 m).
CAUTION Class 1 LED product. Invisible LED radiation (850 nm). Avoid exposure to beam.
Important Safeguards
• Read and keep these instructions.
• Confirm the installation surface can support at least three times the weight of the camera.
• Do not apply power to the camera before completing installation.
• Do not aim the camera toward a bright light source for extended periods.
• Avoid operating the unit under or close to unstable light sources (may cause flickering), or close to
fluorescent lamps or objects reflecting light.
• Do not touch the camera lens.
• Do not drop the camera or subject it to physical shock.
• Do not use a strong or abrasive detergent when cleaning the camera.
• Avoid operating or storing the unit in extremely humid, dusty, hot/cold environments, where the
operating temperature is outside the recommended range of -40°F to 140°F (-40°C to 60°C).
Before You Begin
Before you begin, check that you have received all of the parts listed below. If any parts are missing or
damaged, contact your dealer immediately.
CAUTION Installation and servicing should be performed only by qualified and experienced
technicians to conform to all local codes and to maintain your warranty.
Preparing the Mounting Surface
1. Apply the mounting template to the mounting surface.
2. Using the mounting template as a guide, drill four pilot holes in the mounting surface, then hammer
the supplied anchors into the holes.
3. Drill a cable entry hole in the mounting surface, then pull the required cables through the hole.
•Camera
• Mounting template
•Self-tappingscrews(×5)
• Plastic anchors (×5)
• Hex key (L-wrench)
•Powerpigtail
Mounting surface
Anchors
Base
Self-tapping screws
Body
Enclosure
Hex key
Locking screw

2700 Blankenbaker Pkwy, Suite 150
Louisville, KY, 40299, USA
www.honeywell.com/security
[phone]
(North America only)
Aston Fields Road, Whitehouse Industrial Estate
Runcorn, Cheshire, WA7 3DL, UK
www.honeywell.com/security/uk
[phone]
(Europe only)
35F Tower A, City Center, 100 Zunyi Road
Shanghai, 200051, China
www.asia.security.honeywell.com
[phone]
(Asia Pacific only)
Document 800-23521 – Rev C – 08/2017
© 2017 Honeywell International Inc. All rights reserved. No part of this publication may be reproduced by any means without written permission from Honeywell. The information in this publication is believed to be accurate in all respects. However, Honeywell cannotassume responsibility for any consequences
resulting from the use thereof. The information contained herein is subject to change without notice. Revisions or new editions to this publication may be issued to incorporate such changes.
Mounting the Camera
1. Loosen the locking screw on the enclosure and unscrew the camera assembly from the base.
2. Fix the base to the mounting surface using the supplied screws.
3. Connect the camera’s BNC connector to a coaxial cable.
4. The default video format is HQA/CVI. Use the DIP switch on the camera cable to change formats.
5. Connect the camera’s power connector to a 12 VDC source.
6. Reattach the camera assembly to the camera base.
7. Rotate the camera body and enclosure to achieve the
desired view.
8. Tighten the locking screw on the enclosure.
Configuring the Camera
1. Connect the camera to a Honeywell Performance Series
HQA DVR and log on as the admin user.
2. Right-click to display the shortcut menu, then click Camera
Menu. The Menu Operation window opens.
3. Click Enter to display the camera’s OSD menu.
4. To configure the camera, in the Menu Operation window,
click the up/down arrows to move through the menu list,
click the left/right arrows to change a menu setting, or click
Enter to enter a submenu (  ) or execute a command.
5. After you have finished configuring the camera, scroll down
to Exit, and then click Enter to exit the OSD menu. Right-click to close the Menu Operation window.
Recommended Recorders
Regulatory Statements
FCC Compliance
Information to the User: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.
Manufacturer’s Declaration of Conformance
Europe The manufacturer declares that the equipment supplied is compliant with the European Parliament and
Council Directive on the restriction of the use of certain hazardous substances in electrical and electronic equipment
(2011/65/EU), General Product Safety Directive (2001/95/EC), and the essential requirements of the EMC directive
(2014/30/EU), conforming to the requirements of standards EN 55032 for emissions, EN 50130-4 for immunity, and
EN 60950-1 for electrical equipment safety.
WEEE (Waste Electrical and Electronic Equipment)
Correct disposal of this product (applicable in the European Union and other European countries with
separate collection systems). This product should be disposed of, at the end of its useful life, as per applicable
local laws, regulations, and procedures.
HRHQ104* 4-channel, 1 SATA, 720p@120fps, 1080p@60fps, alarm I/O
HRHQ108* 8-channel, 2 SATA, 720p@240fps, 1080p@120fps, alarm I/O
HRHQ116* 16-channel, 2 SATA, 720p@480fps, 1080p@240fps, alarm I/O
HRHT404* 4-channel, 1 SATA, 4 MP, HQA/1080p@60fps, HQA/SD/IP@120fps
HRHT408* 8-channel, 2 SATA, 4 MP, HQA/1080p@120fps, HQA/SD/IP@120fps
HRHT416* 16-channel, 2 SATA, 4 MP, HQA/1080p@240fps, HQA/SD/IP@120fps
1 2
CVI OFF OFF
SD ON ON
AHD ON OFF
TVI OFF ON
