4800p
The 4800p is a compact solution that delivers high performance
barcode scanning, plus the added versatility of digital image capture.
The 4800p’s unique form factor makes it ideal for installation where
space is limited and continuous scan mode enables a user to easily
scan items by simply placing them in front of the scanner -- no need
to press a trigger.
Powered by Adaptus®Imaging Technology 5.0, the 4800p
delivers high-performance omni-directional reading of all barcode
symbologies - including linear, stacked and 2D barcodes - with
a single technology solution. Regardless of the barcodes in your
application today, Adaptus Imaging gives you the flexibility to adapt
as your business requirements change without the need to reinvest
in new hardware.
Adaptus Imaging also enables the 4800p to take digital pictures
– allowing the user to electronically capture, store, and retrieve
information, including signatures, pharmacy prescriptions, and forms
of personal identification - streamlining and simplifying the storage
and management of information by going from paper to digital.
The 4800p’s platform stand features an integrated tray that’s
optimized for capturing digital images of small documents such as
drivers’ licenses, ID cards or insurance cards. Angle and distance
from the document are all pre-configured, making it fast and easy
for users to capture and store high quality images of hard copy
documents.
Used without the stand, the 4800p can serve as a triggerless
handheld scanner, a fixed position scanning solution or an integrated
component of a broader system such as a kiosk.
High Performance and Versatile Data Collection:
Adaptus Imaging 5.0 provides aggressive omni-directional
reading of all linear, composite, and 2D bar codes, plus
digital image capture – enabling you to collect and manage
more data with a single device.
Compact, User-Friendly Design: Small footprint makes
installation easy, even in locations where space is limited
without sacrificing ease-of-use or functionality.
Robust Image Processing Software: Advanced on-
board software enabling you to crop, rotate, enhance, and
compress digital images, ensuring their usability.
•
•
•
Multi-Functional Stand: Positions the 4800p for easy
presentation scanning and provides an integrated tray for
imaging small documents.
Built to Last: Solid-state technology ensures reliability.
Common Cabling: Uses same cable solutions as our other
linear and 2D imagers – simplifying ordering and spares
pool management.
•
•
•
2D Image Pod
Features

Copyright ©2008 Honeywell International Inc.
Automation and Control Solutions
Honeywell
Imaging and Mobility
700 Visions Drive
PO Box 208
Skaneateles Falls, NY 13153-0208
www.honeywell.com/aidc
4800p Specifications
4800P-DS Rev B 3/08
Performance
Illumination LEDs: 626nm +30nm
Aiming (Green LED Aimer): 526nm +30nm
Image: VGA, 752x480. BMP, TIFF, or JPEG output.
Working Range:
SF 7.5 mil Code 39
(.019cm)
13 mil UPC
(.033cm)
6.6 mil PDF417
(.017cm)
10 mil PDF417
(.025cm)
8.3 mil QR Code
(.021cm)
Near 2.5 in. (6.4cm) 2.0 in. (5.1cm) 2.8 in. (7.1cm) 2.2 in. (5.6cm) 3.3 in. (8.4cm)
Far 6.4 in. (16.3cm) 8.8 in. (22.4cm) 5.9 in. (15.0cm) 7.5 in. (19.1cm) 5.4 in. (13.7cm)
Skew Angle: +40o
Pitch Angle: +40o
Motion Tolerance: 4 in. (10 cm) per second
Mechanical/Electrical
Pod Stand
Length: 3.35 in. (8.5 cm) 3.43 in. (8.7cm)
Height: 1.38 in. (3.5 cm) 6.99 in. (17.8cm)
Width: 2.33 in. (5.9 cm) 3.92 in. (10.0cm)
Weight: 3.0 oz. (85.0 g) 8.0 oz. (227.0 g)
Housing: UL94-HB UL94-HB
Power Requirements: 4.5 - 5.5VDC
Current Draw (Typical) Input
5 V
Scanning
350mA
Idle
75mA
Trigger: Presentation trigger only (no mechanical trigger)
Good Read LED: No
Beeper: Ye s
Power Supply
Noise Rejection: Maximum 100mV peak to peak, 10 to 100 kHz
Environmental
Operating Temperature: -22oF to +104oF (-30oC to +40oC) - Based on no more than 20 scans/minute
Storage Temperature: -40oF to 158oF (-40oC to +70oC)
Humidity: 0 to 95%, non-condensing
Mechanical Shock: Operational after 50 drops from 6 ft. (1.8 m) to concrete
Ambient Light: 50 to 100,000 lux (full sunlight)
ESD Protection: Functional after 100 15kV discharges
Vibration: Withstands 5G peak from 22 to 300 Hz
Agency: USA: FCC Class B, UL
Canada: IC Class B, cUL
Europe: GS mark, CE mark, 60825-1 Class 1 LED, 60950-1
MTBF: per MIL-HDBK-217F Ground Benign exceeds 70,000 hours
Symbologies
2 Dimensional: PDF417, MicroPDF417, MaxiCode, Data Matrix, QR Code, Aztec, Aztec Mesas, Code 49, and EAN•UCC Composite
Linear: Codabar, Code 39, Interleaved 2 of 5, Code 93, Code 128, UPC, EAN, RSS, Codablock F, and BC412*
*available to licensed users
Postal (SR/SF Only): Postnet, Planet Code, British Post, Canadian Post, Japanese Post, KIX (Netherlands) Post
OCR Fonts (SR/SF Only): OCR-A, OCR-B
Interfaces: USB Serial Com Port Emulation, USB Keyboard, USB Retail (IBM SurePOS), USB HID
Warranty: 5 years
