Honeywell 8620 User manual

8620 Ring Scanner
For Dolphin 70e/75e Wearable Solution
Quick Start Guide
8620-ENUS-QS Rev B
2/16
Aller à www.honeywellaidc.com pour le français.
Vai a www.honeywellaidc.com per l'italiano.
Gehe zu www.honeywellaidc.com für Deutsch.
Ir a www.honeywellaidc.com para español.
Para Português, acesse www.honeywellaidc.com.
Перейти на русскоязычный сайт www.honeywellaidc.com.
Pro češtinu jdi na www.honeywellaidc.com.
Pre slovenčinu choďna www.honeywellaidc.com.
Türkçe için lütfen www.honeywellaidc.com sayfasını ziyaret ediniz.
Idźna stronę: www.honeywellaidc.com po quick start w języku polskim.
查看中文简体版请登陆 www.honeywellaidc.com
查看繁体版请登陆 www.honeywellaidc.com
.ﺔﻴﺑﺮﻌﻟﺍ ﺔﻐﻠﻟwww.honeywellaidc.com ﻰﻟﺇ ﻞﻘﺘﻧﺍ

Wearable Ring Scanner
Scan Window
Ring Strap
Trigger
Connector
(connect to sled)
Optional C-Ring to replace
Ring Strap. Available in two
sizes: Small and large.

Trigger Rotation
Connect Scanner to Arm Mount Sled
Slide the ring scanner cable connector into the bottom of the sled
until the connector ring clicks shut.
Left Hand Right Hand
Scanner head can
be rotated 180°

Attach Ring to Finger
1. Remove shipping film off the scanner window.
2. Slide finger into loosened ring strap.
3. Pull ring strap to secure ring to finger.
Note: If using the C-ring simply slide on to finger.
The ring cable should not cross under the hand.
Shipping
film

How to Scan a Bar Code
Note: For WEH6.5 and WE8H, you must have a scanning
application open on your terminal for the ring scanner to be
able to scan. See the Wearable Solution User’s Guide for your
terminal on our website at www.honeywellaidc.com for more
information.
Linear bar codes:
2-D bar codes:
WARNING: Do not stare directly in to the laser beam.
!

Wrist Position When Scanning
Incorrect Incorrect
Correct

Remove Ring Strap/C-Ring
1. Turn the scanner 90°.
2. Press latch down.
3. Remove the ring strap or c-ring.

Replace Ring Strap/C-Ring
1. Connect ring latch with trigger catch.
2. Press together until a click occurs.
3. Turn 90°.
4. Ready to scan.

Remove Trigger
1. Remove ring strap or c-ring.
2. Unscrew the 4 screws.
3. Remove trigger.

Replace Trigger
1. Place trigger on the scanner.
2. Screw in the 4 screws to secure the trigger.
3. Snap on ring strap or c-ring.

Technical Assistance
Contact information for technical support, product service, and repair can be
found at www.honeywellaidc.com.
User Documentation
For localized versions of this document, and to download the User’s Guide,
go to www.honeywellaidc.com.
Limited Warranty
Refer to www.honeywellaidc.com/warranty_information for your product’s
warranty information.
Patents
For patent information, please refer to www.hsmpats.com.
