MetroSelect®
Single-Line Scanner
Configuration Guide

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in
specifications and other information contained in this document without prior
notice, and the reader should in all cases consult HII to determine whether any
such changes have been made. The information in this publication does not
represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained
herein: nor for incidental or consequential damages resulting from the
furnishing, performance, or use of this manual.
This document contains propriety information that is protected by copyright.
All rights reserved. No part of this document may be photocopied, reproduced,
or translated into another language without the prior written consent of HII.
© 2000 – 2011 Honeywell International Inc. All rights reserved.
Web Address: www.honeywellaidc.com
Trademarks
Omniplanar, MetroSet2, Metrologic, MetroSelect, RangeGate, CodeGate,
CodeSelect, Voyager, VoyagerCG, VoyagerBT and Focus are trademarks or
registered trademarks of Metrologic Instruments, Inc. or Honeywell
International Inc.
Microsoft and Windows are trademarks or registered trademarks of Microsoft
Corporation.
IBM is a trademark of International Business Machines Corporation.
The Bluetooth word mark is owned by the Bluetooth SIG, Inc. and any use of
such marks by Honeywell International Inc. is under license.
Other product names mentioned in this manual may be trademarks or
registered trademarks of their respective companies and are the property of
their respective owners.

iii
Table of Contents
Introduction
Bar Code Configuration Methods.............................................................. 1–1
Single-Code Method.............................................................................. 1–1
Multi-Code Method ................................................................................ 1–1
Need to Start Over?.................................................................................. 1–2
Code Types and Decode Rules
UPC/EAN.................................................................................................. 2–1
Code 128.................................................................................................. 2–2
Code 39.................................................................................................... 2–2
2 of 5 Codes ............................................................................................. 2–4
Codabar.................................................................................................... 2–6
Code 93.................................................................................................... 2–6
Code 11.................................................................................................... 2–6
Telepen..................................................................................................... 2–7
Plessey Codes.......................................................................................... 2–7
Additional Decode Features...................................................................... 2–8
Configurable Code Lengths...................................................................... 2–9
Supplements ....................................................................................3–1
GS1 Databar .....................................................................................4–1
GS1 Databar Limited ................................................................................ 4–2
GS1 Databar Expanded............................................................................ 4–2
ISBT Code 128 Implementation
Configuration Mode .................................................................................. 5–1
Concatenation Configuration Mode .......................................................... 5–2
Pre-Defined Concatenation Configuration Mode ...................................... 5–2
User-Defined Concatenation Configuration Mode .................................... 5–3
Communications..............................................................................6–1

iv
Scanner Operation
Configuration Mode Options......................................................................7–1
Scan Buffers..............................................................................................7–1
Redundant Scans......................................................................................7–2
Miscellaneous Decode Features...............................................................7–2
Same Symbol Timeouts ............................................................................7–3
LED Options..............................................................................................7–3
Beeper Options .........................................................................................7–4
Data Transmission Delays.........................................................................7–6
Communication Timeout Options..............................................................7–7
Host Scanner Commands .........................................................................7–8
Test Modes..............................................................................................7–10
Prefixes/Suffixes
User Configurable Prefixes, All Data.........................................................8–1
User Configurable ID Characters, Code Specific ......................................8–2
Standard Prefix Characters.......................................................................8–4
Standard Suffix Characters .......................................................................8–6
Longitudinal Redundancy Check...............................................................8–7
Block Check Character..............................................................................8–7
Character Replacements...........................................................................8–8
User Configurable Suffixes, All Data.........................................................8–9
Special Formats ......................................................................................8–10
Code Formatting
UPC/EAN Formatting ................................................................................9–1
Codabar Formatting ..................................................................................9–3
Code 39 Formatting...................................................................................9–4
Code 11 Formatting...................................................................................9–4
Telepen .....................................................................................................9–4
Plessey......................................................................................................9–5
2 of 5 Code Formatting..............................................................................9–5

v
RS232
Parity Features ....................................................................................... 10–1
Baud Rate............................................................................................... 10–1
Data/Stop Bits......................................................................................... 10–2
Hardware Handshaking .......................................................................... 10–2
Software Handshaking............................................................................ 10–4
Miscellaneous......................................................................................... 10–5
Keyboard
Enable Keyboard Emulation ................................................................... 11–1
Country/Scan Code Table Selects.......................................................... 11–1
Keyboard/System Type........................................................................... 11–2
’Dumb’ Terminal Selections.................................................................... 11–3
Special Keyboard Features..................................................................... 11–4
InterScan Code Delays........................................................................... 11–6
Control Sets............................................................................................ 11–7
OCIA................................................................................................12–1
Light Pen Parameters....................................................................13–1
Set Narrow Element Width...................................................................... 13–2
RS485 Configuration
IBM Port.................................................................................................. 14–1
IBM Reserve Codes................................................................................ 14–1
USB..................................................................................................15–1
Code Bytes Usage
Code Bytes 0-9....................................................................................... 16–1
Reserved Codes..................................................................................... 16–2
Code Type Table.................................................................................... 16–2
ASCII Reference Table........................................................................... 16–3
Extended Key Code Reference Table..................................................... 16–7

vi
MS9520 Voyager®and MS9540 VoyagerCG®Series
Activation Range.....................................................................................17–1
Stand Scan Modes..................................................................................17–1
CodeGate® Status..................................................................................17–1
Laser/Scan Modes ..................................................................................17–2
Same Symbol Time Outs.........................................................................17–3
MS9520/9540-00 Laser Emulation Mode................................................17–4
MS9524 and MS9544 VoyagerPDF®Series
PDF CodeGate Status.............................................................................18–1
MicroPDF and Composite Code Handling...............................................18–1
MS9535 VoyagerBT .......................................................................19–1
MS9535-5M VoyagerBT..................................................................20–1
Inventory Quantity Bar Codes.................................................................20–3
IS4125 and IS4225 Scan Engines .................................................21–1
IS4823 and IS4825 Scan Engines .................................................22–1
Operating Modes.....................................................................................22–1
Miscellaneous Features
Custom Defaults......................................................................................23–1
Serial Program Mode ..............................................................................23–2
Customer Support..........................................................................24–1
Technical Assistance...............................................................................24–1
Product Service and Repair.....................................................................24–2

1–1
Introduction
Your new scanner has been factory configured with a set of default
parameters. Since many host systems have unique formats and protocol
requirements, Honeywell provides a wide range of configurable features
that may be selected using this bar code based configuration tool. Once the
configuration is completed, the scanner stores the settings in nonvolatile
memory (NOVRAM). NOVRAM saves the settings when the power is off.
Note: Bar code descriptions marked with an asterisk ( * ) define a feature that
is a factory default. Bar codes marked with a tilde ( ~ ) require the
Multi-Code configuration method.
Bar Code Configuration Methods
The MetroSelect class of scanners can be bar code configured in two ways:
the Single-Code Method and the Multi-Code Method.
Note: To properly configure an MS9540 scanner, all configuration
codes must be scanned using the CodeGate®option.
Single-Code Method
Most features can be enabled or disabled using the Single-Code Method.
1. Power-up the scanner.
2. Scan the bar code for the desired feature.
3. The scanner will emit a multi-toned beep to indicate the configuration
has been saved to NOVRAM.
Multi-Code Method
All features can be enabled or disabled using the Multi-Code Method.
A feature marked with a tilde ( ~ ) requires the Multi-Code Method.
1. Power-up the scanner.
2. Scan the enter/exit configuration mode bar code (3 beeps).
3. Scan the bar code for the desired feature (1 beep). Multiple features
can be enabled/disabled before scanning the enter/exit configuration
mode bar code.
4. Scan the enter/exit configuration mode bar code (3 beeps) and save
the new configuration. To abort a configuration change, power off the
scanner before scanning the enter/exit code.
Enter/Exit Configuration Mode
³ 9 9 9 9 9 9
1

1–2
Need To Start Over?
Scan the Recall Defaultsbar code to erase all previous settings and return
the scanner to its factory default communication protocol. Keyboard Wedge
interface scanners will load keyboard wedge defaults. All other scanners load
RS232 defaults.
Note: Honeywell manufactures several products for OEM applications.
These OEM products are configured with custom OEM defaults, which
may use a different set of defaults than the standard set of factory
defaults. See page 23–1 for additional information on custom defaults
and how they affect factory defaults.
Recall Defaults
³ 9 9 9 9 9 8

2–1
Code Types and Decode Rules
Bar code descriptions marked with an asterisk ( * ) define a feature that is a
factory default. Bar codes marked with a tilde ( ~ ) require the Multi-Code
configuration method.
UPC/EAN
³ 1 0 0 1 1 6
* Enable UPC/EAN
³ 1 0 0 1 0 6
Disable UPC/EAN
³ 1 0 0 2 1 6
* Enable UPC-A
³ 1 0 0 2 0 6
Disable UPC-A
³ 1 0 0 2 1 0
* Enable UPC-E
³ 1 0 0 2 0 0
Disable UPC-E
³ 1 0 0 2 1 1
* Enable EAN-13
³ 1 0 0 2 0 1
Disable EAN-13
³ 1 0 0 2 1 4
* Enable EAN-8
³ 1 0 0 2 0 4
Disable EAN-8
2
