Honeywell ScanDome iii HSDC-251N/P Owner's manual

ScanDomeTMllIDomeCamera
HSDC-251N/P,HSDC-231N/P
Pleaseread this manualthoroughly beforeuseand keepit handyfor futurereference.
Rev.060210
Operation &Programming Manual

2
Warningsand Cautions
TOREDUCE THE RISK OFFIRE ORELECTRIC SHOCK, DONOTEXPOSE THISPRODUCTTO RAIN
OR MOISTURE. DONOTINSERTANYMETALLIC OBJECTS THROUGHTHE VENTILATIONGRILLSOR
OTHEROPENINGS ON THE EQUIPMENT.
EXPLANATIONOFGRAPHICALSYMBOLS
The lightning flash witharrowhead symbol,withinan equilateraltriangle,is intended to
alerttheusertothepresence ofuninsulated "dangerous voltage"withinthe product's
enclosure thatmay be of sufficient magnitude to constitute arisk of electricshock to
persons.
The exclamation pointwithinan equilateral triangleisintended to alerttheusertothe
presence of importantoperating andmaintenance(servicing) instructionin the literature
WARNING
CAUTION
accompanyingtheproduct.

3
FCCCOMPLIANCE
FCC INFORMATION: THISEQUIPMENTHASBEENTESTEDAND FOUND TO
COMPLY WITH THELIMITSFORACLASS ADIGITALDEVICE,PURSUANT TO
PART15OFTHEFCC RULES.THESELIMITSAREDESIGNEDTOPROVIDE
REASONABLEPROTECTIONAGAINSTHARMFULINTERFERENCEWHEN
THEEQUIPMENTISOPERATEDIN ACOMMERCIAL ENVIRONMENT. THIS
EQUIPMENTGENERATES,USES,AND CANRADIATERADIOFREQUENCY
ENERGYAND IF NOTINSTALLEDAND USEDIN ACCORDANCEWITHTHE
INSTRUCTIONMANUAL,MAYCAUSEHARMFULINTERFERENCETORADIO
COMMUNICATIONS.OPERATIONOFTHISEQUIPMENT IN ARESIDENTIAL
AREA ISLIKELY TOCAUSE HARMFULINTERFERENCEINWHICH CASE THE
USERWILLBE REQUIREDTOCORRECTTHEINTERFERENCEATHISOWN
EXPENSE.
CAUTION: CHANGESORMODIFICATIONSNOTEXPRESSLYAPPROVEDBY
THEPARTYRESPONSIBLEFORCOMPLIANCECOULDVOIDTHEUSER'S
AUTHORITYTOOPERATETHEEQUIPMENT.
THISCLASSADIGITALAPPARATUSCOMPLIESWITHCANADIANICES-003.
CETAPPAREILNUM RIQUEDELACLASSEAESTCONFORME ÀLANORME
NMB-003DU CANADA.
CECOMPL
IANCESTATEMENT
WARNING
THISISACLASS APRODUCT.INADOMESTICENVIRONMENTTHIS
PRODUCT MAY CAUSERADIOINTERFERENCEIN WHICHCASE THEUSER
MAY BEREQUIRED TOTAKEADEQUATEMEASURES.

4
IMPORTANTSAFEGUARDS
1.Read theseinstructions.
2.Keep theseinstructions.
3.Heed allwarnings.
4.Followallinstructions.
5.Donot usethisapparatusnearwater.
6.Cleanonlywithdrycloth.
7.Donot blockanyventilationopenings.Install inaccordancewiththe
manufacturer'sinstructions.
8.Donotinstallnearanyheatsourcessuchasradiators, heat
registers,stoves, orother apparatus(includingamplifiers) that
produceheat.
9.Donot defeatthesafetypurposeofthepolarizedorgrounding-type
plug. Apolarizedplughastwobladeswithone wider than theother.
Agroundingtypeplughastwobladesandathirdgroundingprong.
The widebladeor thethirdprongisprovided foryour safety. If the
providedplugdoesnot fitintoyouroutlet,consult anelectricianfor
replacementofthe obsoleteoutlet.
10.Protectthe powercordfrombeingwalked onor pinchedparticularly
atplugs,conveniencereceptacles,andthe pointwheretheyexitfrom
theapparatus.
11.Onlyuseattachments/accessoriesspecified bythe manufacturer.
12.Unplugthisapparatusduring lightning stormsorwhenunusedfor
long periodsoftime.
13.Refer allservicing toqualifiedservicepersonnel.Servicingis
required whentheapparatushasbeendamaged inanyway, suchas
whenthepower-supplycordor plughasbeen damaged, liquidhas
beenspilledorobjectshavefallenintotheapparatus, the apparatus
hasbeen exposedtorainor moisture, doesnotoperatenormally,or
hasbeen dropped.
14.CAUTION- THESESERVICING INSTRUCTIONSAREFORUSE
BYQUALIFIEDSERVICEPERSONNELONLY.TO REDUCE THE
RISKOFELECTRICSHOCK DO NOTPERFORM ANYSERVICING
OTHERTHANTHATCONTAINEDINTHEOPERATING
INSTRUCTIONS UNLESSYOUAREQUALIFIEDTO DOSO.
15.UseCertified/ListedClass 2power supplytransformeronly.

5
Table ofContents
Chapter1 Introduction...................................................................................................................7
1.1Features.....................................................................................................................................................7
1.2TypicalSystemConfiguration...............................................................................................................8
Chapter2 Installation andConfiguration....................................................................................9
2.1Unpackingthebox...................................................................................................................................9
2.2BasicConfigurationofScanDomeCameraSystem...........................................................................9
2.3PrincipleofTermination......................................................................................................................10
2.4DomeCameraAddress(ID)................................................................................................................11
2.5SettingProtocols....................................................................................................................................12
2.6Connections............................................................................................................................................12
2.7Mountingthe DomeCamera...............................................................................................................14
2.8Poweronand Boot-upSequence........................................................................................................14
Chapter3 ProgramandOperation..............................................................................................16
3.1FUNCTION............................................................................................................................................16
3.1.1HOMEFUNCTION (MENU =>FUNCTION=> HOMEFUNCTION).....................................................17
3.1.2PRESET( MENU => FUNCTION=>PRESETShortCut:PRST ).........................................................18
3.1.3PATTERN(MENU =>FUNCTION =>PATTERNorShortcut: PTRN).................................................19
3.1.4SCAN( MENU => FUNCTION=>SCANorShortcut: SCAN)................................................................21
3.1.5TOUR(orMENU =>FUNCTION=> TOUR, ShortCut: TOUR).............................................................22
3.2ALARM ( MENU =>ALARM)...........................................................................................................23
3.3SCREEN.................................................................................................................................................25
3.3.1LANGUAGE( MENU =>SCREEN=> LANGUAGE)................................................................................25
3.3.2PRIVACYZONE( MENU => SCREEN=> PRIVACYZONE)................................................................26
3.3.3NORTHDIRECTION( MENU => SCREEN=> NORTHDIRECTION).................................................27
3.3.4ZONETITLE( MENU =>SCREEN=>ZONETITLE).............................................................................27
3.3.5CAMERATITLE( MENU => SCREEN=> CAMERATITLE)................................................................28
3.4CAMERA( MENU =>CAMERA)....................................................................................................29

6
3.4.1FOCUSCONTROL( MENU =>CAMERA=>FOCUSCONTROL)........................................................29
3.4.2WB(white balance)( MENU => CAMERA=>WBCONTROL)..............................................................29
3.4.3AECONTROL(MENU =>CAMERA=>AECONTROL).....................................................................30
3.4.4BLC/BMBSETUP( MENU èCAMERA èBLC/BMBSETUP)..........................................................30
3.4.5SHARPNESSCONTROL( MENU =>CAMERA=>SHAPENESS)........................................................31
3.4.6DIGITALZOOM( MENU => CAMERA=>DIGITALZOOM)................................................................31
3.4.7NIGHTSHOTMENU ( MENU =>CAMERA=>NIGHTSHOT).............................................................31
3.4.8CAMERADEFAULT( MENU => CAMERA=>CAMERADEFAULT).................................................32
3.5SETUP( MENU => SETUP)...............................................................................................................32
3.5.1FLIP (MENU=>SETUP=>FLIP)..............................................................................................................32
3.5.2SPEED (MENU => SETUP=> SPEED)........................................................................................................32
3.5.3PRESETFREEZE (MENU =>SETUP=>PRESET FREEZE)....................................................................32
3.5.4PANNINGRANGE (MENU =>SETUP=>PANNINGRANGE)..............................................................33
3.5.5TILTOVERANGLE (MENU =>SETUP=> TILTOVERANGLE).........................................................33
3.5.6CALIBRATION (MENU => SETUP=>CALIBRATION)..........................................................................33
3.4.7LINELOCKCONTROL(MENU=>CAMERA=> L/LCONTROL)....................................................34
3.5.8FACTORYDEFAULT(MENU => SETUP=> FACTORYDEFAULT)...................................................34
3.5.9ERASEDATA(MENU =>SETUP=>ERASEDATA)...............................................................................34
3.5.10 SYSTEMINFORMATION(MENU =>SETUP=>ERASEDATA)........................................................35
AppendixA Specifications............................................................................................................36
AppendixB Troubleshooting.......................................................................................................39

7
Chapter1 Introduction
1.1Features
The ScanDome TMIII domecamerafeatures ahighresolution ExView HAD CCD*)option imager for
enhancedlowlight sensitivity. User friendly, on-screen pull-downmenusandshort-cuts makeit
easy tosetupand programfunctions.
System informationaidestroubleshootingby displayingthehardwareand software version of
thedomedriver, baudrate, and protocol.
•Built-in23xor 25xtimesopticalpower zoomcamera.
TrueNight Shot functionwithExViewHAD andIR cut filter removal mechanism
•248 Presets programmedwithviewdirection,zoom, BLC,BMB.
•4 Patterns recordandplay backuser preferenceof surveillancepathupto240 sec.
•16 Scans: 8speedstepsfromslowtomediumpanning withsmooth DiagonalScan.
•8 Tours: Eachtour consists upto64 Preset,Pattern, Scan andother Tours.
Tourcanbeexpanded up to500different functionsusing nested Tours.
Smooth DiagonalScan mode andprogrammableIndividual dwell timecamerafunctions.
(Speed,Dwelltime,BLC, BMB,Focus, IRISofthepreset)
•8Alarminputs with0~8priority / 2AuxiliaryoutputsprogrammableNC &NO.
•8 Privacy Zones : Videooffor up to8masked blocks and 8mask colorselectable
•64stepsof variablespeedfrom0.1°/secto90°/sec.
Maxmanual speed360°/secwith Turbo keypressed, Preset speed is380°/sec.
Minimumadjustableangleis0.0375°with SingleStep movefunction.
•Programmableuser preferencesof speed(Slow, Medium, Fast).
•Addressableupto999 camera IDs (Extendableupto3999in factorymode).
•Built-inRS-485/422receiver driver.
•On-sitesoftwareupgradeand upload/download of programmeddataintotheKBD/Dome.
•Built-inpower-linesurge protectionand lightningprotection.
•Capableoffail-safeHotSwap.
•Optional TintedBubble, Indoor &Outdoor pendanthousingwithheater &blower,Indoor Flush
Mount, Parapetmount&RoofTopmount.

8
1.2TypicalSystemConfiguration
Additional ScanDomejoystickcontrollersandavariety ofexternal switchingdevicessuchas
multiplexers(MUXes)andDigital VideoRecorders(DVRs)maybeincorporatedtoaccommodate
theneedsfromthe small tolargesurveillance/securitysystem.Figure1illustratesasmall
sampleinstallation.
Figure1 –Typical System Configuration

9
FULLDUPLEX MODE
RS-422
TXB(DOME1 -) TXA(DOME1+)
STPAWG#22
VIDEO
BNCMONITOR
AC 24V
POWER
TXB
AC-
AC+
FGND
TXA
RXB RXA
AC 24V
POWER
TXB(TX-)
RXA(RX+) RXB(RX -)
TXA(TX+)
RS-422HALF DUPLEXMODE
RS-485or
RXA RXB
TXA TXB TXB TXA
RXB RXA TXA(TX+)
TXB(TX-)
SW1
SW2
J5J7
J2 J1
AL1
GND
NO1
NC1
COM1
AL2
AL3
AL4AL8
AL7
AL6
COM2
NC2
NO2
GND
AL5
24V~ 24V~
FG
RX- RX+ TX- TX+ GND
TERMINATION ON
