Lyric™ W1 Wi-Fi Water Leak
and Freeze Detector
INSTALLATION INSTRUCTIONS
Before you begin
Read these instructions carefully. Failure to follow these instructions can
damage the product.
Download the Lyric app
To setup and use your new water
leak and freeze detector, search for
Honeywell Lyric in the App Store or
Google Play.
GET IT ON
Lyric

For help, go to getconnected.honeywell.com ii
Need help?
If you need help any point during the installation and setup of
the W1 Wi-Fi Water Leak and Freeze Detector, please contact
Customer Care:
Web: getconnected.honeywell.com

iii For help, go to getconnected.honeywell.com
Contents
Welcome • 1
Parts of your detector • 2
Placement • 3
Preparing for installation • 4
Download and install the app • 4
Power up the detector • 5
Pair and name your detector • 6
Connect to Wi-Fi • 7
Placement • 8
Optional cable sensor • 8
Configure the detector • 10
Select alert recipients • 11
App dashboard • 12
Temperature/Humidity trend • 12
Leak detected • 13
Using the Lyric app • 15
Rename a detector • 15
Remove a detector • 16

For help, go to getconnected.honeywell.com iv
Change alert settings • 17
Add alert recipients • 18
Remove alert recipients • 19
Reset • 20
Status LED • 20
Maintenance • 21
Frequently Asked Questions • 22
Regulations • 25
Guarantee • 25
Specifications • 26

1 For help, go to getconnected.honeywell.com
Welcome
Congratulations on your purchase of Honeywell’s Lyric™ Wi-Fi
Water Leak and Freeze Detector. This sensor keeps an eye on your
home or business, alerting you at the first sign of water leaks or
large changes in temperature or humidity, which can help stop a
leak before it becomes a flood, or alert you to conditions that can
result in frozen pipes.
What’s in the box?
You should find:
• Honeywell Lyric™ W1 Wi-Fi Water Leak and Freeze Detector
• Three AA alkaline batteries
• Optional cable sensor
• Optional mounting screw
Download the app
To setup and use your new
detector, search for Honeywell Lyric
in the App Store or Google Play.
After downloading, follow the
instructions in the app and skip the install step.
GET IT ON
Lyric

For help, go to getconnected.honeywell.com 2
Parts of your detector
LED indicator
Cable sensor
Mounting keyhole (to hang on wall)
Water sensors
Cable sensor jack
Sensor jack plug

3 For help, go to getconnected.honeywell.com
Placement
The detector and (if used) the optional cable sensor should be placed where leaks
are likely to occur. For the most part, this will be on the bottom level of your home or
business, near water sources, or anywhere you think leaks are possible.
Locations to consider:
• Floor drain
• Water heater
• Sump pump
• Washing machine
• Kitchen
• Sink
• Toilet

For help, go to getconnected.honeywell.com 4
Preparing for installation
To install this product, you will need:
• The Lyric app
• Bluetooth connectivity turned on for your Android or Apple mobile
device
• Your Wi-Fi® password
Download and install the app
1 Go to the App Store or Google Play and search
for Honeywell Lyric. Follow instructions to
download and install the free Lyric app.
2 After downloading, launch the app, register (if
necessary), go to Menu, and then go to Add New
Device.
Note: Make sure Bluetooth is enabled on your
mobile device.
Honeywell Lyric app
Download and login
to complete the setup.

5 For help, go to getconnected.honeywell.com
Power up the detector
It is important to install the app before you
install the batteries.
After the batteries are installed, the
detector will begin attempting to pair with
the app immediately.
If you are installing multiple detectors,
the easiest way to do it is to install the
batteries in one leak detector at a time.
If you have more than one leak detector
attempting to pair with the app, you will
see multiple MAC IDs listed in the app.
Remove the battery cover and the batteries
to see the detector’s MAC ID label.
The detector is powered by 3 AA batteries (included). Open the battery cover on the
detector and install the batteries.
1 Remove the battery cover from the detector.
2 Install the 3 AA alkaline batteries (included).
3 Replace the battery cover. Press firmly around the edges to ensure a snug fit.
Note: The cable sensor jack is NOT for plugging in a power adaptor. Plugging in a
power adaptor could damage the detector.

For help, go to getconnected.honeywell.com 6
Pair and name your detector
1 Under Add New Device, select Lyric
Water Leak and Freeze Detector.
Note: Make sure Bluetooth is enabled on
your mobile device.
2 Provide a location for your detector.
Press NEXT.
3 The detector will now pair with the app.
Note: If you have more than one detector,
you will need to connect each detector
individually.
4 An audible alert will sound and your
detector’s LED will turn solid blue to
indicate your detector is paired. Press
NEXT.
5 Create a custom name for the detector or
select one from the list. Press NEXT.

7 For help, go to getconnected.honeywell.com
Connect to Wi-Fi
1 Choose your network from the list. Press
NEXT.
2 Enter your Wi-Fi password, if necessary.
Press NEXT.
3 When connected to Wi-Fi, the LED will
turn solid green for 5minutes, then turn
o to preserve battery life.
Note: After you connect the detector to your
Wi-Fi network the first time, if you remove
and replace the detector’s batteries, it will
reconnect to your Wi-Fi network automatically.
Configure
Continue to follow instructions in the app to configure
your detector. Set the high and low levels for humidity and
temperature warnings, and identify the people you want notified
in case of an alarm. These settings can be updated at any time
using the app.

For help, go to getconnected.honeywell.com 8
Placement
The detector can simply be placed on a flat surface or used with the optional cable
sensor to hang from a wall or be arranged on the ground. For wall mounting, use the
included screw and hang the detector on the mounting keyhole.
If the detector is placed on the floor, be sure the
sensors have good contact with the floor. If you
expect a large flooding in the area where you
install your Lyric W1 water leak detector that
could submerge the unit, consider hanging it on
the wall (with provided screw and wall plug), and
using the included 1.2m cable sensor for water
detection. To cover an even larger area, purchase
additional cable sensors to extend your coverage.
Optional cable sensor
To install the optional cable sensor, remove the sensor jack plug and insert
the cable sensor. Insert the sensor jack plug at the end the cable sensor.
Additional cable sensors (sold separately) can be connected to extend the
cable and increase water sensing area.
The entire length of cable is an extended sensor. You can hang the detector
from the wall or place both the detector and cable sensor on the floor.
Note: The cable sensor jack is NOT for plugging in a power adaptor. Plugging
in a power adaptor could damage the detector.

9 For help, go to getconnected.honeywell.com
The detector is connected.
The detector is designed to “sleep” most of the time, only “waking up” when it senses
water or indoor temperature or humidity that could be harmful to the building.
Follow instructions in the app to configure your detector. You can set the high and
low levels for humidity and temperature warnings, and identify the people you want
notified in case of an alarm.
If you remove and replace the detector batteries, the detector will reconnect to your
Wi-Fi network automatically when you install new batteries.
In case of an alert
To preserve battery life, it can take up to 1minute for the detector to sense a leak.
You can mute the detector by pressing the Mute button in the app or removing the
batteries or cable sensor from the detector. The mute command may take up to
1minute to reach the detector.
After you’ve addressed the cause of the alert, wipe dry the detector and cable sensor
and put them back in place. Replace batteries if they were removed.

For help, go to getconnected.honeywell.com 10
Configure the detector
Selections you make here will determine how often the detector will send
temperature and humidity readings to the app. They will also determine when and
how you receive notifications for
temperature or humidity alerts.
No matter what settings you select,
you will always be notified of
temperature/humidity conditions and
water leaks if they occur.
1 Select how often you want the
detector to send updates to the
app. More communications per day
reduces battery life.
2 Select Fahrenheit or Celsius for
temperature displays.
3 Select the alert levels you want for
temperature or keep the default
settings. The detector will notify
you of temperatures below the low
temperature setting or above the
high temperature setting.
4 Select the alert levels you want
for humidity the same way you
selected them for temperature.
5 When you are done, press NEXT.

11 For help, go to getconnected.honeywell.com
Select alert recipients
Choose the people you want notified
when there is an alert condition. You
can choose e-mail, text message, or
both.
1 Press the text box to add a contact.
2 Select the contact from your
address book.
3 If you want other people to receive
alerts, press the Who else should
receive emails? text box.
4 Select the contact from your
address book.
5 Continue to add contacts until you
are done.
6 If you want to remove contacts,
press the next to their name.
7 Press Finish.

For help, go to getconnected.honeywell.com 12
App dashboard
The app dashboard displays historical information about temperature and humidity
readings taken at the detector locations. It displays an alarm screen when a leak is
detected.
Temperature/Humidity trend
Here is an example of the dashboard
showing the 30-day trend of
temperature and humidity settings.
Press Temperature or Humidity to
change from one to the other.
The remaining battery life of the
detector is displayed in the bottom-left
corner of the screen.
The next scheduled update between the
detector and the app is displayed in the
bottom-right corner of the screen. To
change the schedule see page 10.

13 For help, go to getconnected.honeywell.com
Leak detected
If a leak is detected, the detector will
sound a loud alarm.
IMPORTANT
It can take up to one minute for the
alarm to sound after water is detected.
You can silence the alarm from the app
by pressing the Mute button, then start
the alarm again by pressing Unmute.
IMPORTANT
It can take up to one minute for Mute or
Unmute commands to take eect.
After you’ve addressed the cause of the alert,
wipe dry the detector and cable sensor and
put them back in place.

For help, go to getconnected.honeywell.com 14
Other alerts
The app will alert you if temperatures drop below freezing or are otherwise above
or below your settings; if humidity is above or below your settings, or if the detector
loses internet connection.
Use the app to find out more information about these warnings.
To restore internet connection, use the app or push one end of a paperclip into the
detector’s reset hole. See “Reset” on page 20.
Humidity outside of
desired range
Low temperature
detected by device
WiFi connection
failure
Alerts and Activity
notification center

15 For help, go to getconnected.honeywell.com
Using the Lyric app
Using the Lyric app, you have
remote connection to your
detector.
To see a snapshot of alerts
and activity, press the
message icon.
Rename a detector
You might want to rename your
detector if you add other detectors
to your network or if you move an
detector to a dierent location. This is
simple to do using the app.
1 Press the side menu button.
2 Press Leak Detector.
3 Press the current detector name
you want to change, type the new
name, then press the Back arrow.

For help, go to getconnected.honeywell.com 16
Remove a detector
If you need to remove a detector from
your account, it is easy to do using
the app.
1 Press the side menu button.
2 Press Leak Detector.
3 Press DELETE DEVICE.
4 Press YES to confirm the deletion
or NO to cancel it.
