Honeywell Aube Technologies TH113-A User manual

400-230-000-C 5/12/05 1/2
1. Introduction
This master and slave unit system is specially
designed for large floor heating applications
exceeding 15 A.
The master thermostat controls a single or
multiple floor heating zones driven by slave units.
The master thermostat can control up to 10 slave
units.
Each slave unit drives its own zone and is
equipped with a GFCI test button and warning
light as well as an On/Standby switch to facilitate
maintenance on specific zones of the floor
installation.
2. Operation
Master Thermostat
The master unit controls the temperature and
sends a signal to slave units when heating is
required. The floor sensor is connected to the
master unit. The master unit is powered by the
slave units.
Slave Unit
The slave unit receives the signal sent by the
master unit and activates its load.
NOTE: There must be a minimum of one slave
unit ON to power the master unit.
3. Installation
Turn off power to the heating system at the
main power panel to avoid electrical shock.
Installation should be carried out by an
electrician.
3.1 Wiring Guidelines
• The wire distance between the master thermo-
stat and slave unit should not exceed 500 ft.
(150 m).
• The floor sensor cable should not exceed
200 ft. (60 m).
• A 3-wire 20 AWG cable is recommended.
3.2 Slave Units - Installation and Wiring
The slave units can operate on different voltages (e.g. 5 units @ 120 V and 5 @ 240 V).
•Required parts: CT230-120GA, -120GB, -240GA or -240GB
•Installation: On an electrical box
•Location: Installation near the master
thermostat is not required (i.e. can be
installed in a utility room).
•Wiring: The power bases are joined
through a daisy chain connection.
nConnect the 120 V or 240 V power
base wires to the power (line) and to
the load (floor) using solderless con-
nectors for copper wires, and secure
the base to the electrical box.
oAffix the wiring sticker (in the CT230
box) to the base.
pConnect the slave power bases
together as per FIGURE 1.
qOnce installation and wiring is com-
plete, mount the CT230 interface:
a) Align the bracket tabs of the
CT230 with the holes located on
top of the power base.
b) Secure the CT230 interface using the screw (captive).
rSwitch all slave power bases to STANDBY by sliding the protective door upwards
and positioning the switch to STANDBY.
Install and connect the master unit (see 3.3).
MASTER THERMOSTATS
TH113-A/F/AF (12VDC)
TH114-A/F/AF (12VDC)
TH115-A/F/AF (12VDC)
TH116-A/F/AF (12VDC)
FIGURE 1
Connections
Installation Instructions
SLAVE UNITS
CT230-120GA
CT230-120GB
CT230-240GA
CT230-240GB

400-230-000-C 5/12/05 2/2
3.3 Master Thermostat - Installation and Wiring
WARNING: Make sure all slave units are in STANDBY mode.
•Required parts: TH113-A/F/AF (12VDC),
TH114-A/F/AF (12VDC),
TH115-A/F/AF (12VDC) or
TH116-A/F/AF (12VDC)
•Location: anywhere easily accessible to users.
Temperature control: AF (ambient with floor limit) / A (ambient)
• Install the master thermostat in the controlled area.
• Choose a location about 5 ft. above the floor in an area where the tempera-
ture is stable.
• Avoid locations where there are air drafts (top of staircase, air outlet), dead air
spots (behind a door), direct sunlight or concealed chimneys or stove pipes.
Temperature control: F (floor)
• Can be installed anywhere.
sWire the 12 VDC base to the nearest slave unit.
The floor sensor must be installed in an area where average temperature can be
read. The cable must follow the wall down to the floor and must not cross any
heater wires or be directly on or adjacent to a heating wire.
For maximum performance, the sensor probe should be centered between the
wires in the mat (max. 80°C).
tPush the excess wire into the wall, secure the base using the provided screws
and wall anchors, and install the TH11x thermostat onto the base.
uOnce the thermostat is installed, return power to heating system and switch all
slave units and the master thermostat to ON.
3.4 Slave Units - GFCI Test
We recommend you test the GFCI immediately after installing the thermostat, and
once a month thereafter to ensure it is operating properly.
If the test warning light comes ON during normal operation, cut power to heating
system from the main power panel and verify the installation.
nSlide the protective door upwards and make sure the switch is ON.
oPress TEST.
• The test is successful if the TEST warning light is ON and power is cut off.
• If the test fails (first installation test):
a. Verify installation
b. Check the load wires
c. Once you've identified the problem, run the GFCI test again
• If the test fails (monthly maintenance):
a. Cut power to heating system from the main power panel and call customer
service
pWhen the test is successful, reset the slave unit by switching from ON to
STANDBY then back to ON.
qRepeat steps 1 to 3 for all slave units.
Technical Specifications
Temperature:
- Operation: 32°F to 122°F (0°C to 50°C)
- Storage: -4°F to 122°F (-20°C to 50°C)
TH113/TH114/TH115/TH116 (A/F/AF-12VDC)
NOTE: Refer to the TH11x user guide for techni-
cal specifications.
CT230-120GA/120GB/240GA/240GB
Service
If you have any questions concerning the
installation of the master thermostat or slave
units, contact our technical support team at:
Montreal area: [phone]
Canada / U.S.: 1-800-831-AUBE (2823)
Fax: [phone]
Email: [email protected]
Monday to Friday from 8:30 AM to 5:00 PM EST.
For more information on our products, visit us at
www.aubetech.com
Warranty
AUBE TECHNOLOGIES INC.
ONE (1) YEAR LIMITED WARRANTY
This product is guaranteed against workmanship
defects for a one year period following the initial
date of purchase. During this period, AUBE
Technologies Inc. will repair or replace, at our
option and without charge, any defective product
which has been used under normal conditions.
The warranty does not cover delivery costs and
does not apply to products poorly installed or
randomly damaged following installation. This
warranty cancels and replaces any other
manufacturer's express or implied warranty as
well as any other company commitment.
AUBE Technologies Inc. cannot be held liable for
related or random damages following the
installation of this product. The defective product
as well as the purchase invoice must be returned
to the place of purchase or mailed, prepaid and
insured, to the following address:
Aube Technologies Inc.
705 Montrichard
Saint-Jean-sur-Richelieu, Quebec,
Canada J2X 5K8
Power supply 12 V from remote unit
Maximum
slave units
up to 10 slave units per
master thermostat
Wire gauge 20 AWG
Size (H • W • D)
BASE
4.63 x 2.7 x 0.61 in.
(117.5 x 68.3 x 15 mm)
Supply
- PB112-120
- PB112-240
1800 W @ 120 VAC
60 Hz, 15 A resistive
3600 W @ 240 VAC
60 Hz, 15 A resistive
GFCI GA=5 mA / GB=30 mA
Certification c CSA us
Size (H • W • D)
BASE
4.63 x 2.7 x 1.45 in.
(117.5 x 68.3 x 37 mm)
Size (H • W • D)
INTERFACE
4.67 x 2.74 x 0.67 in.
(118.6 x 69.6 x 17 mm)
