HOMEOWNER’S GUIDE
69-1044-2
T841A,B Easy-To-See™
Heat Pump Thermostat
Features of Your New Thermostat
Enlarged, raised numbers make it easy for you to touch and see the
temperature settings.
You can hear an audible click and feel an indent for every two degrees
as you move the temperature setpoint lever.
The temperature setpoint lever lets you choose temperature settings
from 46°F (8°C) to 84°F (29°C).
Enlarged, raised letters aid you when you are setting the System switch
and Fan switch.
EH H O C A O
M19445
EM. HEAT HEAT OFF COOL
AUTO ON EM. HEAT AUX. HEAT
FAN
SYSTEM
SWITCH FAN
SWITCH
T841A
SETPOINT
SCALE
TEMPERATURE
SETPOINT LEVER
HEAT PUMP THERMOSTAT
80
80
70
70
60
60
50
50
H O C A O
M19446
HEAT OFF COOL
AUTO ON
FAN
SYSTEM
SWITCH FAN
SWITCH
T841B
SETPOINT
SCALE
TEMPERATURE
SETPOINT LEVER
HEAT PUMP THERMOSTAT
80
80
70
70
60
60
50
50
TRADELINE®

69-1044-2 G.H. Rev. 3-03 www.honeywell.com/yourhome
Printed in U.S.A. on recycled
paper containing at least 10%
post-consumer paper fibers.
Automation and Control Solutions
Honeywell International Inc. Honeywell Limited-Honeywell Limitée
1985 Douglas Drive North 35 Dynamic Drive
Golden Valley, MN 55422 Scarborough, Ontario
M1V 4Z9
Temperature Selection
To select the temperature setpoint, slide the lever to the desired point on the setpoint
scale. A click is heard and an indent felt every two degrees as the setpoint lever moves.
The enlarged, raised 5, 6, 7 and 8 on the right edge of the thermostat provide recognition
by touch and sight for the 50°F (10°C), 60°F (16°C), 70°F (21°C) and 80°F (27°C)
setpoints.
System Switch and Fan Switch Settings
To select System switch and Fan settings, slide the levers at the bottom of the thermostat
base to the desired setting. Enlarged, raised letters on the wallplate and the audible aid
click heard at each indent in setting System switch and Fan switch settings.
T841A: The large EH, H, O and C are the EM. HT., HEAT, OFF and COOL System switch
settings. The large A, O raised letters are the AUTO and ON Fan settings.
T841B: The large H, O and C are the HEAT, OFF and COOL System switch settings. The
large A, O raised letters are the AUTO and ON Fan settings.
NOTE: If the information on this card is desired in Braille, call 1-800-468-1502 for a copy.
