Honeywell C User manual

OWNER’S GUIDE
® U.S. Registered Trademark
Patents Pending
© 2004 Honeywell International Inc.
All Rights Reserved 69-1679EF—1
T8775A,C The Digital Round™
Non-Programmable
Thermostats

69-1679EF—1 2
Fig. 1. T8775 Thermostat (features and operation).
ROOM
SET
DISPLAYS ROOM
OR SET TEMPERATURE
(T8775C ONLY)
SELECTS
ON/AUTO
(T8775C ONLY)
SELECTS
COOL/OFF/HEAT
SHOWS THAT THE
CURRENT ROOM
TEMPERATURE
IS DISPLAYED.
SHOWS THAT THE
CURRENT
TEMPERATURE
SETTING IS DISPLAYED.
M19470
DISPLAYS AND ADJUSTS
TEMPERATURE SETTING/TURNS
BACKLIGHT ON

3 69-1679EF—1
Setting SYSTEM and FAN Switches (T8775C only)
❑System and Fan settings are controlled by using SYSTEM and
FAN switches located on the top of the thermostat (see Fig. 1).
IMPORTANT
Do not operate the T8775C in cooling mode when the
outdoor temperature is below 50°F (10°C), or damage to
compressor could result.
SET THE SYSTEM SWITCH:
❑Heat: The thermostat controls your heating system.
❑Off: Both heating and cooling systems are off.
❑Cool: The thermostat controls your cooling system.
SET THE FAN SWITCH:
❑Auto: Normal setting for most homes. The fan only runs with
the heating and cooling system.
❑On: The fan runs continuously. Use for improved air
circulation.
Operating Your Thermostat
NOTE: Batteries are not required because the temperature set-
ting is held permanently in memory.

69-1679EF—1 4
Backlit Display
❑The backlight can be turned on by turning the dial, or by
pushing the backlight button as shown in Fig. 1.
Display Temperature Setting
NOTE: Your temperature setting can be set anywhere from
40°F to 90°F (4°C to 32°C) in heating and 45°F to 99°F
(7°C to 37°C) in cooling (T8775C only).
❑Turn the dial one click to display
the current temperature setting.
A indicator points to Set
when the temperature setting is
displayed. If a change to the
temperature setting is not made
within five seconds, the mode
will switch to the room
temperature display.
❑A indicator points to Room
when the room temperature is
displayed.
ROOM
SET
M19489
ROOM
SET
M19490

5 69-1679EF—1
Adjust Temperature Setting
❑To lower the temperature setting, turn the dial
counterclockwise.
❑To raise the temperature setting, turn the dial clockwise.
Troubleshooting Guide
CAUTION
Equipment Damage Hazard.
Can cause permanent damage to compressor or
other equipment.
Do not operate cooling when outside temperature is
below 50°F (10°C).
Allow compressor to remain off for five minutes before
restarting.
See equipment manufacturer instructions.
Heating or cooling does not come on.
❑Make sure that the SYSTEM switch on the thermostat is set to
Heat or Cool (T8775C only).

69-1679EF—1 6
❑In heating, make sure the temperature setting is above the
room temperature and the flame is present in the display.
❑In cooling, make sure the temperature setting is below the
room temperature and a solid snowflake is present in the
display (T8775C only).
NOTE: If a call for cooling is made before the compressor has
been off for five minutes, or if a power interruption
occurs while the compressor is running, the thermostat
will go into a five-minute delay to protect the compres-
sor. The snowflake will flash during this delay.
❑Check the system fuse or circuit breaker and replace or reset if
necessary.
❑Check for air movement at the register.
If you have questions concerning this thermostat, call Honeywell
Customer Care at 1-800-468-1502.

7 69-1679EF—1

69-1679EF—1 J.S. Rev. 6-04 www.honeywell.com/yourhome
Printed in Mexico
Automation and Control Solutions
Honeywell International Inc. Honeywell Limited-Honeywell Limitée
1985 Douglas Drive North 35 Dynamic Drive
Golden Valley, MN 55422 Scarborough, Ontario
M1V 4Z9

® Marque de commerce déposée
aux É.-U. • Brevets en instance
© 2004 Honeywell International Inc.
Tous droits réservés
GUIDE DU PROPRIÈTAIRE
69-1679EF—1
Thermostats ronds numèriques,
non programmables The Digital
Round™ T8775A,C

69-1679EF—1 2
Fig. 1. Thermostat T8775 (caractéristiques et
fonctionnement).
ROOM
SET
AFFICHAGE DE LA
TEMPÉRATURE AMBIANTE
OU DU POINT DE CONSIGNE
(T8775C SEULEMENT)
SÉLECTION DE
ON OU AUTO
(T8775C SEULEMENT)
SÉLECTION DE
COOL, OFF OU HEAT
INDIQUE QUE LA
TEMPÉRATURE
AMBIANTE
ACTUELLE EST
AFFICHÉE.
INDIQUE QUE LE POINT
DE CONSIGNE ACTUEL
DE LA TEMPÉRATURE
EST AFFICHÉ.
AFFICHAGE ET RÉGLAGE
DU POINT DE CONSIGNE
OU RÉTROÉCLAIRAGE
MF19470
