Honeywell CM907 User manual

CM907 - User Guide
7 day Programmable
Room Thermostat
42010943-703 R1
© 2005 Honeywell International Inc.
Description
The Honeywell CM907 is a programmable room thermostat designed to
control your heating system efciently, providing comfortable temperatures
when you are at home and energy savings when you are away. The following
instructions explain how to program and use the CM907 to provide the most
home comfort at the least cost.
Features
Ergonomic User Interface features an ‘OK-button’ making the CM907 very
easy to use so you always stay in control.
Dynamic Text Display provides informative ‘on-screen’ feedback and
operational assistance to the user.
Extra Large LCD (Liquid Crystal Display) Screen with Backlight provides
added user friendliness and clearer viewing – even in the dark.
7-day heating program lets you set the CM907 independently for each day of
the week to match your lifestyle, whilst maximizing energy savings.
6 independent temperature levels per day lets you set any 6 temperatures
you require (from 5 to 35°C) so you can enjoy economical comfort every day
Holiday button saves energy by letting you reduce the temperature for 1 to 99
days while you are away from home, resuming normal operation on your return.
Party button lets you temporarily maintain (or adjust) the current temperature for
1 - 23 hours. Useful when you have guests or leave the house for a short period.
Day Off button copies Sunday’s program into any other day of the week, so that
you can make the CM907 follow this program if you have a day or days off.
Automatic Summer/Winter Time Change will adjust the clock automatically
for ‘Daylight Saving Time’.
Built-in Memory holds the user program indenitely so that it is never lost
– even if you remove the batteries.
Outside Temperature Sensor (optional accessory) can be tted to the
CM907 to display the temperature outside your home.
Remote Temperature Sensor (optional accessory) can be tted to the CM907
to control to the room temperature in another location, concealing the CM907.
Optimum Start option is an advanced feature which ensures that the optimum
temperature conditions are achieved at the required times.

CM907 - User Guide
7 day Programmable
Room Thermostat
42010943-703 R1
© 2005 Honeywell International Inc.
Description
The Honeywell CM907 is a programmable room thermostat designed to
control your heating system efciently, providing comfortable temperatures
when you are at home and energy savings when you are away. The following
instructions explain how to program and use the CM907 to provide the most
home comfort at the least cost.
Features
Ergonomic User Interface features an ‘OK-button’ making the CM907 very
easy to use so you always stay in control.
Dynamic Text Display provides informative ‘on-screen’ feedback and
operational assistance to the user.
Extra Large LCD (Liquid Crystal Display) Screen with Backlight provides
added user friendliness and clearer viewing – even in the dark.
7-day heating program lets you set the CM907 independently for each day of
the week to match your lifestyle, whilst maximizing energy savings.
6 independent temperature levels per day lets you set any 6 temperatures
you require (from 5 to 35°C) so you can enjoy economical comfort every day
Holiday button saves energy by letting you reduce the temperature for 1 to 99
days while you are away from home, resuming normal operation on your return.
Party button lets you temporarily maintain (or adjust) the current temperature for
1 - 23 hours. Useful when you have guests or leave the house for a short period.
Day Off button copies Sunday’s program into any other day of the week, so that
you can make the CM907 follow this program if you have a day or days off.
Automatic Summer/Winter Time Change will adjust the clock automatically
for ‘Daylight Saving Time’.
Built-in Memory holds the user program indenitely so that it is never lost
– even if you remove the batteries.
Outside Temperature Sensor (optional accessory) can be tted to the
CM907 to display the temperature outside your home.
Remote Temperature Sensor (optional accessory) can be tted to the CM907
to control to the room temperature in another location, concealing the CM907.
Optimum Start option is an advanced feature which ensures that the optimum
temperature conditions are achieved at the required times.

Contents
GETTING STARTED WITH THE CM907
STEP 1: Installing the Batteries......................................... 3
STEP 2: Setting the Date and Time................................... 4
STEP 3: Running the Built-In Heating Program ................ 4
PROGRAMMING THE CM907
The Built-in Heating Program............................................ 5
Reviewing the Heating Program ....................................... 5
Modifying the Heating Program........................................ 5
Disabling / Enabling Time Periods ................................... 7
OPERATING THE CM907
Choosing the Operating Mode ......................................... 8
AUTO mode ............................................................ 8
MAN mode .............................................................. 8
OFF mode ............................................................... 8
During Normal Operation ................................................. 8
Temperature Enquiry ............................................... 8
Temperature Override ............................................. 9
Using the Special Functions ............................................. 9
HOLIDAY Function .................................................. 9
PARTY Function..................................................... 10
DAY OFF Function ................................................. 11
Adjusting the Time.......................................................... 11
FINE TUNING THE CM907
Changing the User Parameters ...................................... 12
Change the Time Format....................................... 13
Reset the Built-in Program..................................... 13
Summer / Winter Time Change ............................. 13
FAQ’s & TROUBLESHOOTING
Frequently Asked Questions........................................... 14
Trouble Shooting Guide .................................................. 17
WHAT IS A PROGRAMMABLE ROOM THERMOSTAT?
An explanation for householders .................................... 18
Controls Layout
Day / Date Display
Time Display
Dynamic Text Display
Heating On Indicator
Battery Low Indicator
Temperature Display
Temperature Change Buttons
Temperature Enquiry Button
Slider Switch
Green OK Button
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
19
18
Program Buttons
Battery Compartment Lid
Battery Compartment
Holiday Function Button
Party Function Button
Day Off Function Button
Copy Day Button
Day Select Button
Time Change Buttons
COPY
DAY
DAY
1..6
AUTOMANOFF
CM907
DATE
PROG
AUTO
MAN
OFF
18
17
16
15
14
19
1235
46
8
9
10
7
13 12 11
Manufactured for and on behalf of the Environment and Combustion Controls Division of Honeywell Technologies Sàrl, Ecublens, Route du Bois 37,
Switzerland by its Authorised Representative Honeywell International Inc.
The time on the programmer must be correct. Some types have to be adjusted
in spring and autumn at the changes between Greenwich Mean Time and British
Summer Time.
You may be able to temporarily adjust the heating programme, for example,
‘Override’, ‘Advance’ or ‘Boost’. These are explained in the manufacturer’s
instructions.
Programmable room thermostats need a free ow of air to sense the temperature, so
they must not be covered by curtains or blocked by furniture. Nearby electric res,
televisions, wall or table lamps may prevent the thermostat from working properly.
WHAT IS A PROGRAMMABLE ROOM THERMOSTAT?

Contents
GETTING STARTED WITH THE CM907
STEP 1: Installing the Batteries......................................... 3
STEP 2: Setting the Date and Time................................... 4
STEP 3: Running the Built-In Heating Program ................ 4
PROGRAMMING THE CM907
The Built-in Heating Program............................................ 5
Reviewing the Heating Program ....................................... 5
Modifying the Heating Program........................................ 5
Disabling / Enabling Time Periods ................................... 7
OPERATING THE CM907
Choosing the Operating Mode ......................................... 8
AUTO mode ............................................................ 8
MAN mode .............................................................. 8
OFF mode ............................................................... 8
During Normal Operation ................................................. 8
Temperature Enquiry ............................................... 8
Temperature Override ............................................. 9
Using the Special Functions ............................................. 9
HOLIDAY Function .................................................. 9
PARTY Function..................................................... 10
DAY OFF Function ................................................. 11
Adjusting the Time.......................................................... 11
FINE TUNING THE CM907
Changing the User Parameters ...................................... 12
Change the Time Format....................................... 13
Reset the Built-in Program..................................... 13
Summer / Winter Time Change ............................. 13
FAQ’s & TROUBLESHOOTING
Frequently Asked Questions........................................... 14
Trouble Shooting Guide .................................................. 17
WHAT IS A PROGRAMMABLE ROOM THERMOSTAT?
An explanation for householders .................................... 18
Controls Layout
Day / Date Display
Time Display
Dynamic Text Display
Heating On Indicator
Battery Low Indicator
Temperature Display
Temperature Change Buttons
Temperature Enquiry Button
Slider Switch
Green OK Button
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
19
18
Program Buttons
Battery Compartment Lid
Battery Compartment
Holiday Function Button
Party Function Button
Day Off Function Button
Copy Day Button
Day Select Button
Time Change Buttons
COPY
DAY
DAY
1..6
AUTOMANOFF
CM907
DATE
PROG
AUTO
MAN
OFF
18
17
16
15
14
19
1235
46
8
9
10
7
13 12 11
Manufactured for and on behalf of the Environment and Combustion Controls Division of Honeywell Technologies Sàrl, Ecublens, Route du Bois 37,
Switzerland by its Authorised Representative Honeywell International Inc.
The time on the programmer must be correct. Some types have to be adjusted
in spring and autumn at the changes between Greenwich Mean Time and British
Summer Time.
You may be able to temporarily adjust the heating programme, for example,
‘Override’, ‘Advance’ or ‘Boost’. These are explained in the manufacturer’s
instructions.
Programmable room thermostats need a free ow of air to sense the temperature, so
they must not be covered by curtains or blocked by furniture. Nearby electric res,
televisions, wall or table lamps may prevent the thermostat from working properly.
WHAT IS A PROGRAMMABLE ROOM THERMOSTAT?

3
This section shows you how to setup and run the thermostat in 3 simple steps:
STEP 1: Installing the Batteries
Note: Please follow the instructions in this section only if the thermostat screen is
blank (no symbols or digits are displayed). If the screen displays some information
move on to STEP 2: Setting the Date and Time.
To install the Batteries:
a. Lift up the front cover of the thermostat
to reveal the battery cover and product
controls.
b. Remove the battery cover by pressing
down and sliding out.
c. Insert the 2 x AA LR6 Alkaline Batteries
supplied with the thermostat, ensuring
the correct orientation (see ‘Controls
Layout’ on page 2).
d. After a short pause the thermostat will
display information on the screen and
is now ready for use.
e. Replace the battery cover by sliding
it rmly back into the front of the
thermostat.
GETTING STARTED WITH THE CM907
PLEASE RESPECT YOUR ENVIRONMENT!
Take care to dispose of used batteries carefully.

4
5
STEP 2: Setting the Date and Time
To set the Date and Time:
a. Move the slider switch to the DATE position. ‘SET THE DAY’ will be displayed on
the screen and the day digits will be ashing.
b. Use the or buttons to set the correct day. When either of these buttons
are pressed ‘DAY OK?’ will be displayed. Once the correct day is reached, press
the green button to conrm.
c. Now the month digits will start ashing and ‘SET THE MONTH’ will be displayed.
Change the month and then the year using the or buttons, pressing the
green button to save any changes made. (If an invalid date has been entered
you will be returned to the start of the date setting mode).
d. After setting a valid date, the time digits will begin ashing and ‘SET THE TIME’
will be displayed.
e. Use the or buttons to set the correct time. Each press of the button will
change the time by one minute and holding the button down will change the time
slowly at rst and get progressively quicker. Once the correct time is set, press
the green button to conrm then ‘CHANGES SAVED’ will be displayed for a
moment followed by ‘DATE COMPLETE’.
Note: If the slider switch is moved at any time before ‘DATE COMPLETE’ is displayed
the changes to the date and time will NOT be saved.
STEP 3: Running the Built-in Heating Program
The thermostat is now ready for operation. Move the slider switch to the AUTO
position and the built-in heating program will start running. The built-in heating
program has been designed to provide normal comfort requirements, but if you want
to customise the default settings (as shown on the next page) please see the next
section ‘PROGRAMMING THE CM907’.
GETTING STARTED WITH THE CM907
DATE
PROG
AUTO
MAN
OFF

4
5
PROGRAMMING THE CM907
The Built-in Heating Program
The built-in heating program has 6 temperature level changes per day that can be
set between 3.00am and 2.50am the following day - allowing you to maintain the
evening temperature after midnight. Each temperature level can be set between
5°C and 35°C, and adjusted in 0.5°C increments. The factory default program for
heating is as follows:
Reviewing the Heating Program
To review or edit the heating program move the slider switch to the PROG position
then use the or buttons to navigate between the 6 individual programming
periods for Monday. Use the DAY button to step through each day of the week, so
the complete 7 day heating program can be reviewed or edited.
Modifying the Heating Program
To change the heating program:
a. Set the slider switch to the PROG position, entering programming mode. ‘SET
TIME 1’ will be displayed and the time settings for period 1 on Monday (MON)
will be ashing. The active period is highlighted by a ashing square symbol
around the numbers at the bottom of the screen and the selected day is ashing
in the top left hand corner of the screen.
Monday to Friday
Period 1 2 3 4 5 6
Time 6:30 8:00 12:00 14:00 18:00 22:30
Temperature 21°C 18°C 21°C 18°C 21°C 16°C
Saturday & Sunday
Period 1 2 3 4 5 6
Time 8:00 10:00 12:00 14:00 18:00 23:00
Temperature 21°C 21°C 21°C 21°C 21°C 16°C
DATE
PROG
AUTO
MAN
OFF
16
5
4
3
2

6
7
PROGRAMMING THE CM907
b. To adjust the period start time press the or buttons and ‘TIME 1 OK?’ will
be displayed. Holding the button down will change the time quickly.
Note: If you are pressing the or buttons and the display ashes the next
change period, it means the next change will be pushed forward if you continue
to press or buttons).
c. Press the green button to conrm the setting. ‘CHANGES SAVED’ is displayed
for 1.5 seconds then ‘SET TEMP 1’ will be shown.
Note: If the original time setting did not require adjustment press the green
button to move on to step ‘d.’.
d. The temperature setting for period 1 on Monday (MON) will now be ashing. To
adjust this press the or buttons and ‘TEMP 1 OK?’ will be displayed.
e. Press the green button to conrm the setting. ‘CHANGES SAVED’ will be
displayed for a moment followed by ‘SET TIME 2’.
f. The next time and temperature period will now be active. Adjust this by repeating
steps b - e above until all 6 periods are set for Monday or move the slider switch
to the AUTO position to run the program as set, at any time.
g. After setting period 6 ‘CHANGES SAVED’ will be displayed as before, followed
by ‘DAY COMPLETE’.
You now have a choice of how to set the program for the next day:
h. To COPY the Monday’s program to another day:
Press the COPY DAY button to copy Monday’s program into Tuesday. The display
will go blank apart from ‘COPY MON TO’, indicating the program for Monday will
be copied to the selected target day, which is ashing in the top left corner of the
display. To select a different target day press the DAY button to cycle through the
days. Once the required day is ashing accept it by pressing the green
button.
Note: Once the target day is conrmed it becomes the day that is copied if the
COPY DAY button is pressed again.
OR
To program a different day:
Press the DAY button to select the next day, which is displayed in the top left
corner of the display. The program for that day can then be adjusted by following
steps b - g above. Programs for the remaining days can be set in the same way,
using the DAY button to move to the next day.

6
7
PROGRAMMING THE CM907
i. To exit the programming mode move the slider switch to the desired operating
mode - AUTO, MAN or OFF. Note: To run the adjusted program select the AUTO
mode.
Note: If the unit is left in programming mode for more than 10 minutes without
the slider being moved or any buttons pressed, ‘MOVE THE SLIDER’ will be
displayed. Press a button to nish programming the thermostat or move the
slider to select the desired operating mode.
Disabling / Enabling Time Periods
The thermostat has 6 periods each day that can be programmed, but you may not
need all of these switch points for your heating requirements. Therefore, any period
from 2 to 6 can be disabled or enabled as follows:
To disable time periods:
Go to the desired period ( 2 to 6) by moving the slider switch to the PROG
position, then using the , and DAY buttons to navigate, ensuring the
correct period is highlighted with the ashing square symbol. Press and hold the
button for at least 2 seconds and the display will indicate the period has been
removed from the program.
To enable time periods:
Navigate to the disabled period by moving the slider switch to the PROG position,
then using the or and DAY buttons. Once selected ‘DISABLED’ will be
displayed. Press and hold the button for at least 2 seconds and ‘ENABLED’ will
be displayed for a moment before returning to normal programming mode.

8
9
OPERATING THE CM907
Choosing the Operating Mode
The thermostat can operate in three different modes: Automatic, Manual or Off. To
set the operating mode move the slider switch to the desired position. The screen
indicates which mode is currently active by displaying AUTO, MAN or OFF.
• AUTO (automatic) mode
Automatic mode sets the thermostat to follow the temperature program (default
or personalised). Operating the thermostat in this mode is the best way to
maintain a high level of temperature comfort whilst maximising your energy
savings.
• MAN (manual) mode
Manual mode sets the thermostat to act as a simple thermostat with a xed
setpoint throughout the day. The setpoint can be adjusted from 5°C to 35°C
by using the or buttons. The thermostat will continue to maintain this
temperature until another operating mode or temperature is selected.
• OFF mode
Off mode sets the thermostat to control to a minimum temperature setting of 5°C
(default) that acts as a frost protection measure for your home. This value can be
adjusted by calling your installer.
During Normal Operation
• Temperature Enquiry
In AUTO and MAN operating modes the thermostat will display the current room
temperature, which is indicated by the text ‘ROOM TEMP’ displayed on the
screen. To review the programmed ‘target’ temperature (the temperature which
the thermostat is trying to maintain) press the button. This ‘target’ temperature
value will be displayed ashing and the text ‘TARGET TEMP’ will be shown for 5
seconds before returning to the current room temperature value.
In OFF operating mode the thermostat again displays the current room
temperature, as above, but when the button is pressed the text ‘FROST TEMP’
is displayed indicating the set value to protect your home. To modify this value
please contact your installer.

8
9
OPERATING THE CM907
• Temperature Override
During normal operation (AUTO mode) the programmed temperature can be
adjusted manually by pressing the or buttons. The ‘target‘ temperature
will be displayed and ash for 5 seconds – during this time the or buttons
can be used to modify the set value.
Note: This temperature override is cancelled at the next programmed
temperature change.
Using the Special Functions
• HOLIDAY Function
The holiday function allows you to set a constant temperature (default = 10°C)
for a specied number of days (from 1 - 99 days). This lets you save energy and
related costs when you are away from home, but resumes normal operation on
the day of your return.
To set the Holiday function:
a. Move the slider switch to the AUTO or MAN position.
b. Press the button to display the holiday days counter and temperature
setting, along with the holiday indicator .
c. The day after the current day will be selected and ‘RETURN DATE OK?’ will be
displayed. Press the or time buttons to set the holiday time (1 – 99 days).
Note: (The day and date will update according to the number of days
selected).
d. Press the green button to conrm the setting.
e. ‘CHANGES SAVED’ will be displayed for a moment followed by ‘TEMP OK?’.
Press the or buttons to set the holiday temperature (5°C - 35°C)
f. Press the green button to conrm the setting. ‘HOLIDAY MODE’ will now
be displayed on the screen until the return date is reached or the holiday
mode is cancelled.
The thermostat will now control to the new temperature for the set number of days
that your home is vacant. At midnight the holiday counter will be reduced by one until
the selected number of days have passed. The thermostat will then return to normal
operation as set by the slider switch position (AUTO or MAN position). To cancel the
HOLIDAY setting or to exit the function at any time press the button a second time
or move the slider switch to a different position.

10
11
OPERATING THE CM907
• PARTY Function
The party function allows you to extend your heating program by a specied
number of hours at a particular temperature before resuming with the normal
temperature program. This is especially useful when you want to maintain or
increase the temperature during a special occasion such as a party or when
entertaining guests.
This function can also be used to reduce the temperature when you leave the
house for a short period (shopping, visiting friends, etc) thus saving energy and
saving you money.
To set the Party function:
a. Move the slider switch to the AUTO or MAN position.
b. Press the
button to display the party hours counter and temperature
setting, along with the party indicator
.
c. The text ‘PARTY DURATION’ will now be displayed on the screen. Use the
or buttons to set the number of hours (1 - 23 hours).
d. Press the green button to conrm the setting.
e. ‘CHANGES SAVED’ will be displayed for a moment followed by ‘TEMP OK?’
Use the
or buttons to set the desired temperature (5°C - 35°C).
f. Press the green button to conrm the setting. ‘PARTY MODE’ will now be
displayed on the screen until the timer reaches zero or the party mode is
cancelled.
The unit will now control to the new temperature for the set number of hours then
return to normal operation as set by the slider switch position (AUTO or MAN
position). To cancel the PARTY setting or to exit the function at any time press
the
button a second time or move the slider switch to a different position.

10
11
OPERATING THE CM907
• DAY OFF FUNCTION
The day off function allows you to temporarily run Sunday’s heating program for
as many days as you desire. This is useful when you have a day off during your
normal week or will, unintentionally, be at home on a workday due to illness,
etc.
To set the Day Off function:
a. Move the slider switch to the AUTO position.
b. Press the button to display the days off counter, ‘DAYS OFF’ will be
displayed and the day off indicator will appear.
c. Press the or buttons to set the number of days (1 – 99 days) you
would like the alternative heating program to run for.
Note: (The day and date will update according to the number of days
selected).
d. Press the green button to conrm the setting.
e. On conrmation ‘CHANGES SAVED’ will be displayed on the screen for a
moment and then will return to the normal display, with the days off indicator
displayed.
The thermostat will now control to the alternative heating program for the set
number of days before resuming with the normal heating program. To cancel the
DAY OFF mode or to exit the function at any time press the button a second
time or move the slider switch to a different position.
Adjusting the Time
To adjust only the time during normal operation use the or buttons to adjust
the time and press the green button again to conrm any changes.

12
13
FINE TUNING THE CM907
Changing the User Parameters
The user mode allows you to modify some basic settings of the thermostat to meet
your personal preferences. You can change the time display format (24hr or AM/PM),
reset the heating program to the built-in settings and disable or enable the summer/
winter time change feature.
To change any of these user’s parameters:
a. Move the slider switch to the OFF position, then press and hold the button for
approximately 5 seconds. button for approximately 5 seconds.
b. Once entered the following information will be shown on the screen:
COPY
DAY
DAY
1..6
CM907
DATE
PROG
AUTO
MAN
OFF
OFF

12
13
FINE TUNING THE CM907
c. Now choose which one of the following parameters you would like to change:
i) Change the time format
‘CLOCK SELECT’ should be displayed on the screen - press the or
buttons to select the preferred time format (12=AM/PM format, 24=24hr format)
and the display will ash, indicating a change has been made. To conrm this
change press the green button.
ii) Reset the built-in program to the factory default
Press the time button once. The display will show ‘RESET PROGRAM’.
Press the or buttons to select the preferred setting (0=user program,
1=factory program) and the display will ash, indicating a change has been
made. To conrm this change press the green button.
iii) Enable or disable summer/winter time change
Press the time button twice. The display will show ‘AUTO CHANGE’. Press
the or buttons to select the preferred setting (0=disabled/Off, 1=enabled/
On) and the display will ash, indicating a change has been made. To conrm
this change press the green button.
d. To exit the user mode move the slider switch to the AUTO, MAN or OFF
position.

14
15
How do I change the batteries on the CM907 when they run out?
The thermostat constantly monitors the battery power level, which typically last for
about 2 years before needing replaced. When the power is running low a ashing
symbol will be displayed on the screen. To change the batteries follow the steps in
the above section (‘STEP 1: Installing the Batteries’ on page 3), replacing the used
batteries with new ones in step c.
Note: While changing the batteries your program settings will be stored but you may
need to adjust the time and date settings to be correct.
How do I set one temperature for the whole day?
To operate as a simple thermostat with one temperature for a period of time, move
the slider switch to the MAN position. Adjust the manual temperature by pressing the
or buttons. This can be set anywhere from 5°C to 35°C in 0.5°C steps. The
thermostat will continue to maintain this temperature until another operating mode is
selected or the temperature is adjusted.
What is Optimum Start?
Optimum Start is a program which ensures that the optimum temperature conditions
are achieved at the required times. This is an Energy Efciency feature that adjusts
the start time of your heating system depending upon how cold it is. For example,
on cold days your heating system will be started earlier to ensure that your home is
warm when you get up (at the target temperature) and on warmer days the heating
system will be started later to save energy. So, if the Optimum Start Feature is used,
then the time / temperature settings which are entered into the thermostat should
be set to when you want to be warm by and not when you want the heating system
to start.
FAQ’s & TROUBLESHOOTING

14
15
FAQ’s & TROUBLESHOOTING
Can I use my CM907 to control my air-conditioning system?
Yes, if your system has been set up correctly you can use your thermostat to control
the cooling. To switch the thermostat between heating and cooling modes press
the
or buttons together for 5 seconds in any of the product operating modes
(AUTO, MAN or OFF). The text ‘COOLING’ will be displayed for a moment on the
screen to indicate the cooling operation is now active. The factory default program
for cooling is specied in the table below, but this can be modied in the same way
as the default heating program:
Monday to Friday
Period 1 2 3 4 5 6
Time 6:30 8:00 12:00 14:00 18:00 22:30
Temperature 24°C 28°C 24°C 28°C 24°C 24°C
Saturday & Sunday
Period 1 2 3 4 5 6
Time 8:00 10:00 12:00 14:00 18:00 23:00
Temperature 24°C 24°C 24°C 24°C 24°C 24°C
If something happens to my heating system how can I check that the thermostat
is working?
Refer to the Troubleshooting Guide on page 17. If you still need assistance after this
call your installer. The thermostat should only be opened or removed by a qualied
professional to prevent possible injury from electric shock and/or damage to the
product.

16
17
FAQ’s & TROUBLESHOOTING
What other accessories can I buy that work with the CM907?
1. Outside Temperature Sensor Accessory
The Outside Temperature Sensor accessory can be tted to your thermostat to
display the outside temperature. By pressing the button twice, the thermostat
displays the external temperature.
2. Remote Temperature Sensor Accessory
The Remote Temperature Sensor accessory can be tted to your thermostat to
control the temperature of another room where it is inconvenient to locate the
thermostat e.g. commercial premises where the public may tamper with the
buttons.
Note: For more information on the above accessories please contact your installer.

16
17
Troubleshooting Guide
Symptom CM907 has a blank LCD screen CM907 shows a ashing
symbol on the LCD screen The CM907’s LCD screen works but the heating does not switch on Heating switches ON or OFF too slowly or quickly Temperature swings between too hot and too cold. CM907 shows a ashing
symbol on the LCD
screen
Possible Cause Batteries not installed Incorrect battery orientation Exhausted batteries Batteries are exhausted and need replacing No power to heating system Program does not call for heat CM907 not connected to boiler properly CM907 not set correctly for your system CM907 not set correctly for your system Fault in CM907
Remedy Check to see if there are batteries in the battery compartment and the paper tab has been removed Check that the batteries have been installed in the correctorientation Replace with new batteries Replace with new batteries Check that there is power to the heating system. Move the slider switch to MAN and press or to
increase the temperature a few degrees above the current room temperature. The heating should come on after a few seconds. Call installer to check electrical connection between the CM907and the boiler. Call Installer Call Installer Remove and re-insert the batteries in the CM907. If the symbol does not clear itself in a few
minutes call the installer
