E528 Product Guide
Rev 8.0 12/16/2016 1
E528 Smart Digital Thermostat Product Guide
Table of Contents
Table of Contents .............................................. Page 1
Overview and General Concept......................... Page 2
Application......................................................... Page 2
Wireless Communication................................... Page 4
Installation Requirements .................................. Page 4
Mounting............................................................ Page 5
Input/Output....................................................... Page 6
E528.4G New Installation .................................. Page 8
Wiring ................................................................ Page 10
Load Specifications ........................................... Page 13
FCC Information ................................................ Page 13
Technical Specifications .................................... Page 14
Document Revision History ............................... Page 15

E528 Product Guide
Rev 8.0 12/16/2016 2
Overview and
General Concepts
INNCOM's e4 Smart Digital Thermostat is a powerful, multi-purpose Direct
Digital Control (DDC) device that can control virtually any HVAC system found
in hotel guestrooms.
The three e4 models meet different application requirements. The e528 and
e527 are wired and are typically used for new installation. The e529 is battery-
powered and is designed to meet the needs of existing properties where
rewiring is not practicable.
This document describes Model e528; information on the e529 and e527 can
be found in their respective product guides.
Application
In its most basic form, the e528 functions as a programmable DDC thermostat,
automatically adjusting fan speeds and valves to achieve set temperature
(Note: Guests can manually select heat or cool by pressing the OFF/AUTO
button and cycling through OFF, AUTO, HEAT and COOL). The e528 is also
an “intelligent” device capable of linking ancillary sensors and serving as an
information gateway. For example, coupled with a magnetic door switch (wired
or wireless), motion detectors, and other devices, the e528 becomes the brain
of a highly effective Energy Management System (EMS) application,
communicating EMS information requirements to central servers. It comes
standard with five relays and can be equipped with an on-board Infrared (IR) or
radio frequency (RF) transceiver and Passive Infrared (PIR) motion detector.
The e528 interfaces with all common HVAC unit voltage configurations (24 volt
to 277 volt). The e528 can be installed in a wired or wireless INNCOM
guestroom control system, which makes installation feasible and affordable in
either new construction or retrofit installations.
Through interfaces with other devices and sensors, the e528 supports the
following functions:
Figure 1. E528 Digital Thermostat

E528 Product Guide
Rev 8.0 12/16/2016 3
Remote HVAC control
•Guestroom HVAC diagnostics
•Remote room occupancy indication
•Automatic lighting control
•Remote mini-bar access reporting
•Remote smoke detector annunciation
•Central Electronic Lock control
•Humidity control
•Remote drape control
•Outside temperature display
•Peak demand load shedding
•Property/Building Management System (PMS/BMS) interface
A centrally controlled EMS package is created when the e528 is connected to
the property's Central Interface Network (CINET) with a pair of low voltage
wires or by the property’s high-speed TCP/IP network with the addition of a
TCT (an Ethernet gateway device). RF networking is possible with radio
equipped models.
The e528 features a guest-friendly graphic interface with intuitive controls
(Figure 2). A user guide for the e528, written primarily for installers and facility
management personnel, is available (see References below).
Figure 2. E528 Graphic Interface

E528 Product Guide
Rev 8.0 12/16/2016 4
Wireless Communication
2.4HHz Wireless RF
Table 1 e528 RF Characteristics
Installation Requirements
Location: The e528 must be located on a partitioning interior wall,
approximately 1.5 m (5 ft) above the floor, in a site of average
temperature. It is important to ensure that the thermostat is located away
from direct sunlight or radiant heat, air discharge grills, stairwells, outside
doors, steam or water pipes, warm air stacks, unheated/uncooled areas,
or sources of electrical or radio interference. The unit should not be
placed on an outside wall or behind a door. It is essential that the e4 is
mounted flush to the wall and mounted level in both the horizontal and
vertical planes; incorrect mounting can degrade IR, PIR, and
temperature measurement performance.
Installation Requirements for e4
equipped with PIR Motion Detection
The e4 thermostat can be equipped with a PIR
detector to augment the energy management
scheme by detecting motion in the guestroom.
Consider the PIR’s view angle, range
characteristics, and mounting position to ensure
proper coverage. Figure 3 below shows the ranges
of the flat and standard PIRs.
Performance 0dB 20dB
RF Data Rate 250kbps 250kbps
Antenna Type SMT SMT
Indoor Range 70ft 100ft+
Outdoor/RF line-of-site range 540ft 1000ft+
Transmit Power 1mW 10mW
Receive Sensitivity -94.6dBm -94.6dBm
Frequency Band 2.4GHz 2.4GHz
Encryption AES-128 AES-128
Protocol 802.15.4 802.15.4
Frequency Channels 11-26 11-26
Figure 3. PIR
Detection Ranges

E528 Product Guide
Rev 8.0 12/16/2016 5
Mounting
The e528 is usually mounted on a standard double-gang (4 x 4) junction box. If
mounted on a single-gang box, the left side (display side) of the e528 overlaps
the wall area to the left of the junction box. A low-voltage mounting plate, mud
ring, or low-voltage caddy may be used for mounting 24 volt applications.
To mount the e528:
1. Remove the two small screws at the base of the e528.
2. Pull the bottom of the back-mounting plate slightly away from the front
housing and then pull the back-mounting plate down.
3. Position the back plate insulator within the mounting plate as shown in
Figure 4.
4. Attach the mounting plate to the junction box, using the mounting screws
provided with the e528. Ensure that the plate is mounted with the raised
arrow pointing UP.
To simplify installing and removing the e528, the headers and sockets
described below and shown in Figure 5 are located on the back of the
e528. These accept pre-made wiring harnesses provided by INNCOM.
(Note: Take care to note which e528 model is being used. Each model
has slightly changed headers and connectors as identified in the
drawings on the next page.)
Figure 4 Mounting Assembly
Mounting Box Back Mounting Plate Back Plate Insulator

E528 Product Guide
Rev 8.0 12/16/2016 6
H1 – External Temperature Control Sensor
H2 – Power Input
H4 – IR Eye 5
H5 – Microprocessor Programming
H6 – PIR Sensor
H7 – Humidity Sensor
H8 – ES1 Key
H9 – Low Voltage Comm/Device Connection
H10 – RF Programming
Input/Output
The I/O headers for the e528.3G* and 4G* thermostats are substantially
different (see Figure 5 above). The statements and table below detail only the
headers that differ in function.
Low Voltage comm / device connector: This header accepts the provided 6-
pin harness used to connect low voltage communication, door/window position
switch, and other room devices to the e528. Table 3 shows pinout and function
for the 3G and 4G. For specifics, refer to the as-built wiring diagrams.
* “3G,” and “4G” are internal INNCOM product designations used for convenience to differentiate
individual hardware configurations. No difference in device capability or effectiveness is implied.
Due to end-of-life for certain 3G components, the e528.4G is now the standard INNCOM install,
but 3G installations are still supported.
E528 3G headers
E528 4G headers
10-pin Molex
Socket Accepts
the 10 pin Molex
plug pre-wired
with 8” color-
coded leads.
Connect to the
HVAC unit’s
power, fan and
valve signals.
10-pin Molex
Socket Accepts
the 10 pin Molex
plug pre-wired
with 8” color-
coded leads.
Connect to the
HVAC unit’s
power, fan and
valve signals.
H1 – Microprocessor Programming
H3 – External Temperature Control Sensor
H4 – Power Input
H5 – RS485 Network
H6 – ES1 Key
H7 – Low Voltage Comm/Device Connection
H8 – PIR
H9 – IR Eye 5

E528 Product Guide
Rev 8.0 12/16/2016 7
Table 3. E528 3G/4G Low Voltage Harness (P/N 62-1467) Pinout
External temperature control sensor: This header accepts the wiring
harness from an external temperature probe that can be used to supply the
e528 with remote temperature measurements. The e528 uses a 10K 1%
thermistor for external temperature measurement. This external temperature
sensor can be used to monitor room temperature at a different location from
where the e528 is mounted or to monitor pipe water temperature.
RS485 Networks: (refer to Figure 5)
E528.3G cannot act as the media gateway for in-room traffic towards the
RS485 network. The most common way to connect the e528.3G is to connect
a PC-485.S5 (P/N: 01-9905) on the S5bus.
E528.4G to 2G RS485 Networked Application: with or without door switch
input (See Figure 6)
•Using the adapter (P/N 203-251), connect the harness from the wall
box (P/N 62-1462) previously connected to the thermostat being
replaced to H1 of the adapter.
•Connect the harness H3 (rainbow) of 203-251 to the low voltage
comm/device connection of the e528.4G
•Connect the harness H2 (black) of 203-251 to the RS485 header of the
e528.4G
NOTE: Take care to not reverse the connections to the e528.4G!
Wire Color
Female
Connector
Male
Connector
Function
Comment
Brown 1 1 Common GND
Red
2
2
12VDC Out/In
12VDC Supply
Orange 3 3 S5Bus Data Tx/RX or IN 2 Communication Bus
Yellow
4
4
IN 1
Door, Window, PIR, Other
Green 5 5 CNET B RS485 Twisted Pair
Blue
6
6
CNET A
RS485 Twisted Pair

E528 Product Guide
Rev 8.0 12/16/2016 8
E528.4G New Installation
Stand alone application with/without door switch input
•Using the harness (P/N 62-1467), make the appropriate wire
connections, then plug the harness into the low voltage comm/device
connection of the e528.4G
RS485 Networked Application with/without door switch input
(See Figure 7)
•Using the harness (P/N 62-1467), make the appropriate wire
connections, then plug the harness into the low voltage comm/device
connection of the e528.4G.
•Using the adapter (P/N 203-250) and P/N 62-1532-B.12 cables,
connect the RS485 A pair to the two pin
•RS485 In header and the RS485 B pair going to the next thermostat to
RS485 Out header on the 203-250.
•Connect the harness of 203-250 to the RS485 network header of the
e528.4G.
Figure 6. 4G to 2G RS485 Networked Application
Figure 7. E527 4G New RS485
Networked Application

E528 Product Guide
Rev 8.0 12/16/2016 9
The e528.4G can be used to retrofit an application where a legacy e528 was used. Follow the procedure
below:
4G to 2G Standalone application: with/without door switch input (no backhaul network)
•Using the adapter (P/N 203-013) connect the harness from
the wall box (P/N 62-1462) previously connected to the
thermostat being replaced to H1 of the adapter
(see Figure 8).
•Connect the harness of 203-013 to the low voltage
comm/device connection of the e528.4G.
Molex 10-position female socket: This female socket
accepts the provided 10-pin Molex connector pre-wired with 8-
inch, color-coded wiring leads. These leads should be
connected to the 24VAC or 100–277VAC power, valve/fan
control wiring from the FCU, or other HVAC device with wire
nuts inside in the wall junction box in accordance with the
wiring diagram provided by INNCOM.
Note: For installations in which all leads are not required,
the extraneous leads should be cut off at the Molex
connector.
Figure 8 shows the pinout for the 10-position Molex male connector supplied with all relay output models
of the thermostat. The end view of the male connector from the wire insertion side with the pin numbers is
indicated. This is the same as looking at the female connector point on the back of the e528.
Typical functions for each wire are listed in Tables 4 and 5. For specifics, refer to the as-built wiring
diagrams.
Figure 8 E528.4G to 2G standalone application

E528 Product Guide
Rev 8.0 12/16/2016 10
Pin Color Typical Function
1 Green Ground
2 Red 24VAC
3
Black
Common
4 Blue High Fan
5
Brown
Medium Fan or Second Stage Heat
6 Yellow Cold Water Valve (FCU) or Compressor Signal
(Heat Pump)
7 White Hot Water Valve (FCU) or Reversing Valve
(Heat Pump)
8 Grey Valve Power
9 Violet Fan Power
10 Orange Low Fan
Pin Color Typical Function
1
Green
Ground
2 Black Line
3
White
Neutral
4 Yellow High Fan
5 Orange Medium Fan or Second Stage Heat
6 Red Cold Water Valve (FCU) or Compressor Signal
(Heat Pump)
7
Brown
Hot Water Valve (FCU) or Reversing Valve
(Heat Pump)
8 Grey Valve Power
9
Violet
Fan Power
10 Blue Low Fan
Wiring
The steps below provide an overview of the wiring process. Refer to the as-
built wiring diagrams provided for exact details.
1. If applicable, use wire nuts to connect the 6-pin low-voltage harness wires
to the applicable low-voltage communication (if e528 is part of a wired
Table 4. 24VAC Harness Color Code, Pinout, and Typical Functions
24VAC Harness
Table 5. 100-277VAC Harness Color Code, Pinout,
and Typical Functions
100-277VAC Harness
